Cloud CDR-1 Manuel utilisateur
CDR-1 & CDR1F
Remote Control Units
Installation Guide
CDR‑1 & CDR1F Installation Guide v1.0 3
Contents
Introduction...................................................................4
Model types............................................................................................... 4
What’s in the box .................................................................................... 5
Installation .....................................................................5
CDR networks and terminations......................................................... 5
Cable length and DC power considerations ..................................... 8
Wiring ........................................................................................................ 9
Connecting and mounting – CDR‑1..................................................10
Connecting and mounting – CDR1F.................................................13
Conguration.............................................................. 15
Installer mode.........................................................................................15
User mode ..............................................................................................16
Engineer mode .......................................................................................16
Default settings.......................................................................................17
Notes ........................................................................... 18
CDR‑1 & CDR1F Installation Guide v1.04
The CDR-1 & CDR1F are remote control units specically designed for use with the
DCM-1. They may be tted to standard electrical back boxes in whatever location is
convenient in each zone.
Model types
The CDR‑1 and CDR1F are electrically and operationally identical, but differ in their
physical dimensions and mounting arrangements.
The CDR‑1 is a surface‑mounting unit, which may be mounted via its supplied•
mounting plate either to a single‑gang back box, or directly to a suitable wall.
Max. projection from the wall is 30 mm.
The CDR1F is a ush-tting panel which ts to a standard dual-gang back box. Max. •
projection from the wall is 10 mm.
Note:Where the term “CDR” is used in this manual, the text can be taken to apply to
both the CDR‑1 and CDR1F. In the section describing mounting (where the two types
differ), the full product names are used. An exception to this refers to the DCM‑1’s
remote control ports, which are described as CDR-1 PORTS, to match the labeling
on the DCM‑1 itself.
A zone may have one CDR, more than one, or none at all. The DCM‑1 can support
up to 100 CDRs. CDRs are interconnected with standard CAT‑5 UTP cable; units
may be daisy‑chained at will and/or connected individually back to the DCM‑1’s four
CDR-1 PORTS using almost any wiring topology convenient for the installation.
The CDR provides the user with the following local control functions for the zone in
which it is installed:
Source selection
•
Level control•
Group enable/disable (providing the zone has been dened as a group member)•
Local zone EQ adjustment (requires enabling on the DCM‑1 and entry of a key•
code)
An Installer Mode permits zone assignment and adjustment of other installation
parameters.
Introduction
CDR‑1 & CDR1F Installation Guide v1.0 5
What’s in the box
As well as this manual, the shipping carton should contain the items listed below.
Please contact your Cloud dealer immediately if any of them are missing.
CDR-1 CDR1F
CDR‑1 Remote Control panel CDR1F Remote Control panel
Mounting plate 2x M3.5 panhead screws
2x M3.5 x 20 panhead screws 2‑pin 5 mm–pitch screw terminal connector
2x M3 x 8 countersunk head screws
CDR networks and terminations
CDRs are connected to the DCM‑1’s CDR‑1 PORT sockets using standard unscreened
CAT‑5 cable and RJ45 connectors. It may be possible to use pre‑made CAT‑5 “patch
cables” to connect any CDRs installed close to the DCM‑1;otherwise CAT‑5 cable and
crimp RJ45 plugs should be used.
Note: All CAT‑5 cabling should be wired “pin‑to‑pin”; “crossed” or “null” cables will
not work.
CDRs may be connected to the DCM‑1 either by wiring them directly and individually,
or by “daisy‑chaining” them together. In most installations, a combination of these
methods is likely to be the most convenient solution from the point of view of practical
cabling. The diagrams on page 6 illustrate the types of wiring schemes that may be
employed; almost any variation on these is permissible.
Note that the two types of CDR may be intermixed freely as the installation requires.
Installation
CDR‑1 & CDR1F Installation Guide v1.06
CDR-1PORTS
PORT
A
PORT
A
PORT
B
PORT
B
AllDCM-1terminations are OFF
Te rmination ON TerminationON
DCM-1
IN
IN
IN
IN
Te rmination ON TerminationON
CDR-1PORTS
PORT
A
PORT
A
PORT
B
PORT
B
Port Atermination ON
Te rmination ON
Allother terminations areOFF
DCM-1
IN
IN
OUT
CDR-1PORTS
PORT
A
PORT
A
PORT
B
PORT
B
Allother terminationsare OFF
Port Atermination ON
Termination ON
Port Btermination ON
DCM-1
IN
IN
OUT
IN
IN
OUT
(a)
(b)
(c)
CDR‑1 & CDR1F Installation Guide v1.0 7
Diag. (a) shows four CDRs, each connected to one DCM‑1 port; (b) shows a single
daisy‑chain of two CDRs all on one port; c) shows two daisy‑chains each of two CDRs
using two ports. Note that in the diagrams there is deliberately no indication as to
which zones any of the CDRs are in; this is because the system imposes no restriction
on their physical location. CDRs in different zones may be in the same “chain”, and
interconnections may be made purely on the basis of wiring convenience.
The CAT‑5 wiring is essentially a data network, and as such, must be correctly
terminated. Both the DCM‑1 and CDR are provided with means of setting their
network terminations ON or OFF.
The rule governing terminations is:
Devices (DCM‑1 or CDR) at the ends of a cable run must have their terminations•
set ON.
All intermediate devices must have their terminations set OFF.•
If both connectors on the same DCM‑1 CDR‑1 PORT (either PORT A or•
PORT B) are being used, the DCM‑1 may be considered as an intermediate device,
and its termination should be set to OFF*.
The correct termination setting is indicated for each device in the three wiring examples
illustrated on page 6. See Step 5 of “Connecting and Mounting – CDR-1” on page
page 11, or Step 3 of “Connecting and Mounting – CDR1F” on page 14 for details
of how to set it.
*Please refer to the DCM-1 Installation and User Guide, Section 4 (Appendix), for details of how to
set/unset the DCM‑1’s CDR‑1 PORT network terminations.
CDR‑1 & CDR1F Installation Guide v1.08
Cable length and DC power considerations
The DCM-1’s internal PSU has sufcient capacity to power 8 CDRs (i.e., one per zone)
provided cable runs are not excessive and good quality cable and connectors are used.
If a system has more than 8 CDRs in total, one or more additional PSUs will certainly
be required.The probability of correct operation is a function of cable length, cable and
connector quality, the number of CDRs daisy‑chained, and how many of them are at a
great distance from the DCM‑1.
The maximum recommended cable length of the CDR network for reliable data
transmission is 1 km. This gure applies either to the total cable run between the
“farthest” CDR and the DCM‑1 if a single daisy‑chain of CDRs has been employed (as
in (b) on page 6), or to the total run between the most remote CDRs if the DCM‑1 is
in the “middle” of the chain (as in illustration (a) on page 6). Cable runs longer than this
may work satisfactorily, but this cannot be guaranteed. Note that the 1 km gure is a
maximum over which data may be reliably transmitted, not over which a set of CDRs
may be reliably powered. In all systems, it is the power distribution which will limit
maximum cable length, not the data.
If a CDR is found to operate unreliably, it should be powered independently from a
local PSU.The Cloud CPM‑PSU is suitable for this purpose, and should be connected
to the EXT POWER socket at the rear of the CDR. In the case of the CDR‑1, this is
a coaxial socket, mounted vertically on the PCB to the right (viewed from the rear).
See diag. on page 11. In the case of the CDR1F, the EXT POWER socket is a 2‑pin
5 mm‑pitch screw terminal type connector below the RJ45 connectors; a mating male
connector is supplied with the unit. See diag. on page 13.
Note:Wiring convention of the external PSU is unimportant,as the CDR incorporates a
bridge rectier circuit which allows it to accommodate either polarity of connection.
Note that any further CDRs connected to the POWER OUT connector will be
powered by the external PSU.
If a third‑party external PSU is to be used, it should be rated at either 12 – 24V DC or
9 – 17 V AC.The current consumption of a CDR is 50 mA at 12 V.
CDR‑1 & CDR1F Installation Guide v1.0 9
Wiring
Feed the installed CAT‑5 cable(s) (or pre‑made patch cable(s)) into the back box
on which the CDR is to be mounted. If not using pre‑made cables, crimp the RJ45
connector(s) as per the pinout diagram below:
PIN USE CAT‑5 CORE
1 n/u White + Orange
2 n/u Orange
3 n/u White + Green
4 DC +ve Blue
5 0v White + Blue
6 n/u Green
7 Data H White + Brown
8 Data L Brown
The connection at the DCM‑1 end is identical. Note that the CAT‑5 interconnection
provides DC power as well as data, but also see the following chapters concerning
connecting and mounting the CDR‑1 and CDR1F.
1
81
8
1
81
8
CDR‑1 & CDR1F Installation Guide v1.010
Connecting and mounting – CDR‑1
The CDR‑1 is designed for use with single‑gang UK, US or Australian electrical back
boxes, using the mounting plate provided. It is also possible to mount it without a back
box directly onto a wall.
The mounting plate has several sets of xing holes to accommodate the different styles
of box. UK single-gang boxes are square, but note that if tting to a US or Australian
box, it should be tted with the long axis horizontal (‘landscape’ orientation), with the
screw holes to left and right.
1. Detach the mounting plate from the rear of the CDR‑1 by removing the two
countersunk M3 screws. Retain the screws.
2. With back box: bring the CAT‑5 cable(s) into the back box and pass through the
entry hole on the mounting plate. If a local external PSU is being used to power
the CDR‑1, the DC feed from this should be fed through as well.
Without back box: simply pass the cables through the mounting plate entry
hole.
3. With back box: attach the mounting plate to the back box using the M3.5 screws
provided and the appropriate holes in the mounting plate (according to back box
type).
Without back box: x the mounting plate directly to the wall, using screws (not
supplied) of a length and type appropriate for the wall construction. Note that it
is important that only countersunk‑headed screws are used, as a raised screw head
may foul the CDR‑1’s internal PCB.
