...energy for a better life
1、Product Features
●Double CPU intelligent control technology, excellent performance
●The grid mode/energy-saving mode/battery mode could be set,
application flexible
●Charge current/battery type could be set, convenient and practical
● Intelligent fan control, save and reliable
● Pure sine wave AC output, and be adapt to all kinds of loads;
● LCD display equipment parameter in real-time, operation status be
clear at a glance
● Output overload, short circuit protection, various of automatic
protection and alarm warning;
2、Installation、Storage instruction
<1>Unpacking Inspection
1.1 Open the package, inspect product accessories,including:1 host,1
pcs user manual
1.2 Inspect whether the machine have been damaged during the
transport or not, If it have some damage, don’t start the machine, contact
the logistics company and dealer.
<2>Installation、Storage Notes
2.1 The product installation should be operated by professionals，or
assisted by dealer.
2.2 If it needs to transport machine,please take proper protection
measures; move the machine from low temperature environment to high
temperature environment，may appear droplet, please keep it dry and
ensure safety.
2.3 Don’t let the machine exposure in damp, inflammable and explosive
or large accumulation of dust environment. Don’t cover and block vents,
please preset above 10cm air circulation clearance so that having a
good cooling.
2.4 When the machine will not be used for long term, it needs closing the
battery switch on back panel;
-1-
7、Judgment and treatment for simple faults
Warning :High voltage inside the device! Do not open it by yourself,
or try to do maintenance, so as not to be in danger!
When you contact with engineers, please provide the following
information: machine model/problem date/complete description of the
problem(including indicator status, battery specification, all of the
connection etc)
Fault Possible causes solution
The grid occasional Strong out of restoration
fuse holder
Press again the strong out
part
Time degradation of
Machine with loads
Battery undercharge Make sure battery be full of
charging normally
Machine connect load
overcharge Move away non-key loads
Battery burn-in and can’t
charge enough power
Please contact with CSR
and get battery need
changing module
The machine can’t be
started
The grid input line or
battery input line is in
bad connect
Check and reconnection
Starting up alarm
Low battery Make sure battery be full of
charge normally
Overload Move away non-key loads
Buzzer for 2s, pause 1s Internal
over-temperature
Check fan and hear
dissipation whether be
blocked
Fan sometimes fast,
sometimes slow
Internal temperature
above 45℃fan fast,
below 42℃fan slow
Normal
