9/22
If you have a Hinged Window the above kit will not work with it, you can place the end of the exhaust out
of the hinged window and the machine will vent this way, if you wish to seal the gap around the hose so to
seal the window there are fabric kits that can be purchases online from the likes of Amazon (we don’t sell
them Im afraid)
OPERATION
Before Use
Check that the Exhaust Hose has been mounted properly (see ‘Installation’ section). If the
exhaust Hose is not correctly used, hot air will blow back into the room you are trying cool
Check that the drain plug at the bottom rear of the unit is securely plugged in, to prevent water
leaks (see page 9 – Water Drainage)
Check that the local mains power matches that shown on the rating label of the unit
Check that the location of the unit is suitable (flat, stable surface; away from sources water /
heat)
If the unit has recently been transported, let it stand for 6 hours to allow the compress contents
to settle
Cooling mode
When the A/C enters cooling mode automatically or cooling mode is selected after
power ON, the cooling indicator lamp lights up.
Press Up/Down key to adjust setting temperature (16℃~30℃).
Press Speed key to choose High/Mid/Low speed.
Fan mode
When pressing mode key or choosing Fan mode by pressing the remote controller,
the wind indicator lamp lights up.
Press Speed key to choose High/Mid/Low speed.
Temperature can’t be set.
Dehumidification mode
When pressing mode key or choosing dehumidification
mode by pressing the remote controller, the
dehumidification indicator lamp lights up.
Remove the dehumidification water wedge, insert water
manifold, place the other end of the water manifold into
the water vessel or drainage passage, as shown in the
right figure.
After entering the dehumidification mode, if room
tempearture≥17℃ (62℉), the compressor is ON. Then
control as follows: when room temperature ≤15℃ (59℉),
the compressor is OFF; when temperature increases to room temperature≥15℃, the
compressor is started again (in order to protect the compressor, it will be restarted 3min.
later).
In dehumidification mode, the fan is defaulted to run at low speed, and wind speed
