Click CLF6-BLK Manuel utilisateur

15cm Desk Fan with Clip

Model Number: CLF6-BLK

USER MANUAL

AFTER SALES SUPPORT

(AU) 1300 886 649 (NZ) 0800 836 761

E209

AFTER SALES SUPPORT

(AU) 1300 886 649 (NZ) 0800 836 761 | info@tempo.org

Contents

Important Safety Instructions 3

Product Overview 5

Getting Started 6

Operating Instructions 7

Other Useful Information 8

AFTER SALES SUPPORT

(AU) 1300 886 649 (NZ) 0800 836 761 | info@tempo.org 3

Important Safety Instructions

Read this manual thoroughly before first use, even if you are familiar with this

type of product. The safety precautions enclosed herein reduce the risk of fire,

electric shock and injury when correctly adhered to. Make sure you understand

all instructions and warnings. Keep the manual in a safe place for future

reference, along with the completed warranty card, purchase receipt and carton.

If you sell or transfer ownership of this product, pass on these instructions to the

new owner. Always follow basic safety precautions and accident prevention

measures when using an electrical appliance, including the following:

Electrical safety and cord handling

• Voltage: Make sure your outlet voltage and circuit frequency correspond to the

voltage stated on the appliance rating label.

• Water: To protect against ﬁre and electric shock, do not immerse the cord, plug

or the fan in water or other liquid, or expose the electrical connections to water.

Ensure your hands are dry before handling the plug or switching on the fan. Do

not use the fan outdoors or on wet surfaces. Protect it from liquid spills.

• Damage: Check the power cord regularly for visible damage. If the cord is

damaged, it must be replaced by the manufacturer, its authorised service

centres or appropriately qualiﬁed personnel in order to avoid any hazards.

WARNING! Do not pick up or operate the appliance if the power supply cord,

plug or housing is damaged, or after it malfunctions or has been dropped or

damaged in any manner. In case of damage, contact our after sales support

line for advice.

• Protect the power cord:

• Do not operate the fan with the cord coiled up; always fully unwind.

• Do not twist or kink the cord or let it touch heated surfaces or sharp edges.

• Do not allow the cord to hang over the edge of a table or bench.

• Do not put any stress on the cord where it connects to the product.

• Never carry the fan by the cord.

• WARNING! No extension cord, no timer: Do not use this fan with an extension

cord, plug adaptor, external timer or separate remote-control system. In the

event of danger, the plug must be quickly and easily accessible.

• Connection: To insert the plug, grasp it ﬁrmly and guide it into outlet.

• Disconnection: Unplug the appliance from the power outlet when it is not in

use and before cleaning, servicing, moving or storing the appliance, and before

removing a front or rear guard (grille). Grasp the plug and remove it from the

outlet, do not pull the cord when disconnecting.

• RCD: Unless your home is already ﬁtted with a residual current device (safety

switch), we recommend installing an RCD with a rated residual operating

current not exceeding 30mA to provide additional safety protection when using

electrical appliances. See your electrician for professional advice.

AFTER SALES SUPPORT

(AU) 1300 886 649 (NZ) 0800 836 761 | info@tempo.org

Important Safety Instructions (Cont.)

Usage conditions and restrictions

• Domestic use only: This appliance is intended for indoor household use

only. It is not suitable for commercial, industrial or outdoor use. Do not

use in moving vehicles or boats. Do not use it for anything other than its

intended purpose, and only use it as described in this manual. Any other

use may cause ﬁre, electric shock or injury.

• Not a dryer: Do not use this fan as a dryer.

• Attachments: The use of accessory attachments not recommended in this

manual may cause hazards.

• Usage restriction: This fan is not intended for use by persons (including

children) with reduced physical, sensory or mental capabilities, or lack of

experience and knowledge, unless they have been given supervision or

instruction concerning use of the appliance by a person responsible for their

safety.

• Children: This fan is not a toy. Supervise children to ensure they do not play

with the fan. Close supervision is necessary when any appliance is used by

or near children.

• Unattended: Do not leave the fan unattended when in use. Always switch it

off and unplug when not in use, if left unattended and before cleaning and

storing.

• Location: Place the fan on a dry, ﬂat, stable surface when operating .

• Assembly: Do not operate the fan until fully assembled with all parts.

• WARNING! DO NOT use the fan in the following areas:

* Near an open ﬂame, a hot burner, oven or other source of high heat.

* On a soft surface (such as carpet), or where it may tip over during use.

* Outdoors or in areas of high humidity, without suitable ventilation.

* In a bathroom or near water-filled baths, swimming pools or washbasins.

* Near curtains or in tight corners, to enjoy maximum airflow.

* In areas where paint, petrol, etc. is stored and there is a risk of explosion

or ﬁre from ﬂammable gases.

• CAUTION! Avoid contact with moving parts. Never insert ﬁngers, hands,

pencils or any other objects through the grilles when fan is running.

• CAUTION! Risk of ﬁre: Make sure nothing is blocking the airﬂow outlet

and air intake grilles. Do not use the fan under a blanket or in poorly

ventilated locations.

• Liability: We assume no liability for any damages or personal injury caused

by misuse of the product and/or failure to follow these instructions.

AFTER SALES SUPPORT

(AU) 1300 886 649 (NZ) 0800 836 761 | info@tempo.org 5

Product Overview

Parts list

1 Speed control

2 Motor housing

3 Fan handle

4 Rear guard (grille)

5 Motor shaft

6 Plastic blade

7 Front guard (grille)

8 Tilt adjustment knob

9 Rotary pillar

10 Rotary joint

11 Clip

12 Plastic base

AFTER SALES SUPPORT

(AU) 1300 886 649 (NZ) 0800 836 761 | info@tempo.org

Getting Started

Before ﬁrst use

• This product has been packaged to protect it against transportation

damage. Unpack the appliance and keep the original packaging carton

and materials in a safe place. It will help prevent any damage if the

product needs to be transported in the future, and you can use it to store

the appliance when it is not in use. In the event that the carton is to be

disposed of, please recycle all packaging materials where possible.

• Make sure all packaging materials and stickers are removed before ﬁrst

use. Plastic wrapping can be a suocation hazard for babies and young

children, so ensure all packaging materials are out of their reach and

disposed of safely.

• Unwind the cord to its full length and inspect it for damage. Do not use

the appliance if the appliance or its cord have been damaged or are not

working properly. In case of damage, contact our after sales support

line for advice on examination or return of the damaged product.

• Read the manual to familiarise yourself with the parts and operating

principles. Pay particular attention to the safety instructions.

Assembly

This fan can be clipped to the edge of a desk or table, or to the base

provided and then used freestanding on the table or desktop. If the fan

parts are disassembled, proceed as follows:

• First attach the rotary pillar to the base so it is stable. Open the clip and

insert it into the opening on the base, as illustrated (Fig. 1). Close the

clip and ensure the fan sits securely on the base. Attach the fan head

onto the rotary pillar, as illustrated (Fig. 2). Then tighten the tilt angle

adjustment in the desired position.

• Alternatively, open the clip, detach it from the base and clip it securely

to the edge of your table or desktop (Fig. 3).

(Fig. 2)

(Fig. 1) (Fig. 3)

AFTER SALES SUPPORT

(AU) 1300 886 649 (NZ) 0800 836 761 | info@tempo.org 7

Operating Instructions

Using the fan

• Clip the fan to the base (Fig. 1) and place it on a ﬁrm, ﬂat surface for

desktop operation. Alternatively, clip it to the edge of your desk or table

using the clip (Fig. 3).

• Plug the fan into an appropriate power outlet and switch on power to

the outlet.

• Move the speed control to select the desired speed (Fig. 4):

0.......O

1.......Low

2.......High

• Loosen the tilt angle adjustment knob to tilt the fan vertically (Fig. 5),

then tighten the knob again securely.

• The rotary pillar may be manually adjusted 360 degrees to direct the

airﬂow horizontally into all directions. (Fig. 6).

(Fig. 5)

(Fig. 4) (Fig. 6)

AFTER SALES SUPPORT

(AU) 1300 886 649 (NZ) 0800 836 761 | info@tempo.org

Other Useful Information

CAUTION!

Always switch o and disconnect the appliance from the power supply

before attempting any maintenance or cleaning the fan.

Cleaning and maintenance

• Dusting: Clean your fan periodically by lightly running a vacuum

cleaner nozzle (soft brush) over the front and rear guards to remove

any dust or dirt that may have accumulated inside or on the unit.

Alternatively, clean the front and rear guards with a soft cloth or soft,

thin paper towel.

• Stubborn stains: Use a slightly damp and soapy cloth, but not too wet,

for stubborn stains. Use caution around the motor housing area. Do not

allow the motor or other electrical components to be exposed to water.

• Service/repair: The appliance requires little maintenance and contains

no user-serviceable parts. Do not attempt to take it apart, repair or

modify it. Do not operate the fan if its power cord or plug is damaged,

or when it is working abnormally. In case of damage or malfunction,

or if the cord is damaged, have the unit repaired by trained personnel

only, or contact the after sales support line for advice on repair or

replacement.

• Before calling for service: Check that your wall outlet is working

properly, that the plug is ﬁrmly placed in the socket and switched on,

and that all required switches are in the ON position.

• Storage: When you have ﬁnished using the fan at the end of the season,

wipe o any dust to maintain it in good working order for the next

season. Store the fan in its original box in a safe, dry location, protected

from dust.

WARNING: Electric shock hazard!

• Before assembly, cleaning, storage or removing the guard(s), ensure

the fan is switched off and disconnected from the power outlet.

• Do not immerse the fan in water or other liquids. Do not allow water

to drip on or into the fan motor housing. Do not spray with liquids.

• Never use petrol, solvents, harsh detergents, or abrasive or alkaline

cleaners on the fan.

AFTER SALES SUPPORT

(AU) 1300 886 649 (NZ) 0800 836 761 | info@tempo.org 9

Other Useful Information (Cont.)

Technical speciﬁcations

Power 15W, 220-240V~, 50Hz

Power cord 1.5m

Design Desk Fan with Clip (15cm Blades)

Fan speeds 2 (Low - High)

Dimensions (mm) 200 (D) x 210 (W) x 310 (H)

Weight 740g

CLASS II - DOUBLE INSULATED APPLIANCE

This symbol indicates that the appliance has been designed

in such a way that it does not require a safety connection to

electrical earth (ground).

NOTE:

Due to continued product improvement, images and illustrations in this manual

may vary slightly from the product purchased. All images in this manual are for

reference purposes only. Parts are not necessarily pictured to scale.

Responsible disposal

• At the end of its working life, make the appliance unserviceable by

unplugging it from the power outlet and cutting the power cord.

• Do not throw this appliance out with your household rubbish.

Electrical and electronic products contain substances which can have a

detrimental eect on the environment and human health if disposed of

inappropriately. Observe any local regulations regarding the disposal of

electrical consumer goods and dispose of it appropriately for recycling.

Contact your local authorities for advice on recycling facilities in your

area.

The RCM Mark (Regulatory Compliance Mark) indicates that the

product complies with the relevant guidelines of the ACMA as

well as corresponding government requirements for the safety of

electrical devices.

E209

AFTER SALES SUPPORT

(AU) 1300 886 649 (NZ) 0800 836 761 | info@tempo.org

This page has been left blank intentionally.

Table des matières

Autres manuels Click Ventilateur

Click

Click TF-A02 Manuel utilisateur

Click

Click CLHHF Manuel utilisateur

Click

Click PFM7-SZ Manuel utilisateur

Click

Click EXC250 Manuel utilisateur

Click

Click FT-30MD Manuel utilisateur

Click

Click CMT-60W Manuel utilisateur

Click

Click FT-40MD Manuel utilisateur

Click

Click CSEF200S Guide d'installation

Click

Click EXC200 Manuel utilisateur

Manuels Ventilateur populaires d'autres marques

ELTA FANS

ELTA FANS H03VV-F Manuel utilisateur

Hunter

Hunter 20714 Manuel d'instructions

Emerson

Emerson CARRERA VERANDA CF542ORB00 Manuel utilisateur

Hunter

Hunter Caraway Manuel d'instructions

Panasonic

Panasonic FV-15NLFS1 Manuel utilisateur

Kompernass

Kompernass KH 1150 Manuel utilisateur

VES

VES FALA100/12V/TR Manuel utilisateur

Vertiv

Vertiv Liebert DCD Manuel utilisateur

Westinghouse

Westinghouse GFP Series Manuel utilisateur

Venmar

Venmar KUBIX HRV PLUS Series Manuel utilisateur

Maico

Maico ECR 31 Manuel utilisateur

Sonnenkonig

Sonnenkonig Dinky Manuel utilisateur

S&P

S&P ECOWATT HXBR Manuel utilisateur

Wider

Wider IMP03369BH Manuel utilisateur

Panasonic

Panasonic F-60DHN Manuel utilisateur

Hinkley

Hinkley HIGHLAND Manuel utilisateur

Broan

Broan 766BN Manuel utilisateur

Premium

Premium PFS16022 Instructions de montage
