Clas Ohlson BW6200 Manuel utilisateur

















SUOMINORSKSVENSKAENGLISH









Please read the entire instruction manual

before using and save it for future use.

We apologise for any text or photo errors

and any changes of technical data.

If you have any questions concerning

technical problems please contact our

Customer Service Department (see

address on reverse.)



Product description

To remember

Usage

Advanced usage

Care and maintenance

Troubleshooting

Waste disposal

Specications

ENGLISH









This remote control is manufactured pre-

programmed and replaces up to 6 separate

remote controls for controlling, for example,

TVs, VCRs, satellite and digital TV receivers,

and DVD players. You only have to enter the

correct device code and your URC will be

ready for use. A list of device codes is found

at the very end of this instruction manual. The

URC can also be taught (programmed) by

existing remote controls.

- Pre-programmed for most existing

brands.

- Replaces damaged or lost remote

controls.

- Replaces up to 6 remote controls, for

example for TVs, VCRs, satellite and

digital TV receivers, and DVD players.

- Function for Teletext.

- Operated with 4 x R03/AAA batteries (not

included)



- The remote control is compatible with

most brands on the market but it might

not be compatible with your specic

model of the device. Even if the brand

is included in the code list.

- It is not possible to see in the code list if

the remote control ts your specic device

model, you have to try it out.

- The remote control may work with more

codes than one. One has to try it out until

nding the code that works with the most

buttons.

ENGLISH









When a button is pressed, the display is lit for

about 15 seconds, thereafter the display goes

into a sleep mode (energy saving mode).

Press the display again to activate the buttons

and the display.

The display’s buttons only react to button

presses as long as the display is lit. The direct

buttons react even when the display is in

sleep mode.

Button Sound

All buttons give off a low beep when pressed.

The button sound cannot be turned off.

VO L+

VO L-

P- P +

ENGLISH





The touch screen’s buttons

1. Infrared sender

2. LED indicator

3. Touch screen

4. Function buttons

5. Battery lid (on the back)

6. Device buttons (device modes,

buttons for selecting device)

7. Function buttons

8. Mute button (TV sound on/off)

9. SHIFT button (for the SHIFT function)

10.PAGE button (turn to next page of

button set)



On the lower part of the remote control,

there are 9 direct buttons with the following

functions:

Circuit breaker ON/OFF

P+ Programme/Channel up

P- Programme/Channel down

VOL+ Volume up

VOL- Volume down

GREEN button Quick button for, among

other things, Teletext

RED button Quick button for, among

other things, Teletext

YELLOW button Quick button for, among

other things, Teletext

BLUE button Quick button for, among

other things, Teletext

Note: Green, red, yellow and blue buttons

are also used by some satellite and cable TV

receivers.

ENGLISH









The remote control is operated with

4 x R03/AAA batteries.

1. Remove the battery lid on the backside.

2. Put in the batteries according to the

marking in the battery compartment.

Remember to turn the batteries right with

plus (+) and minus (-) according to the

marking.

3. Put the battery lid back.

Low batteries

If the battery symbol is shown in the

display the batteries are starting to go low.

You then have to replace the batteries with

new ones.

ENGLISH







Entering device code

Enter the code in the following manner:

1. Open the included code list and look

under the headline for the type of device

that corresponds to your equipment.

TV Brands – Codes for TVs

VCR Brands – Codes for VCRs

SAT Brands – Codes for satellite recei-

vers as well as codes for digital receivers

for cable TV and terrestrial television

broadcasting.

CBL Brands – Codes for analogue cable

TV receivers.

DVD Brands – Codes for DVD players.

Under this headline you then look for the

code that corresponds to the brand of

your device, for example Philips. Every

code contains 4 digits. If there is more

than device code for your brand, you

begin with the rst one.

2. Turn on, for example, the TV manually or

with the original remote control. Choose

channel 1.

3. Press the button for desired device,

for example [ TV ]. The symbol for the

chosen function ashes.

4. Press the buttons [ P+ ] and [ VOL- ]

simultaneously for 3 seconds until the

LED light is lit.

5. Enter your four digit device code with the

buttons [ 0 ] – [ 9 ].

The LED light ashes a few times and

then goes off.

Test the function of the remote control with

the device that you have just programmed.

If the device responds correctly to the but-

tons you press, you have entered the right

device code. Otherwise, you will have to

repeat the procedure above with the other

device codes available for your brand until

your device reacts in the right way when

you press the buttons and until most buttons

work correctly.

ENGLISH





In the same manner, you set the device

codes for other devices as well. Just

remember to press the button for device

type in step 3 above.

Note

If the LED light ashes 6 times while

entering the four digit device code the

programming has been interrupted for one

of the following reasons:

1. No digit has been pressed during an 8

second period.

2. An invalid device code has been ente-

red.

3. The device code has not been entered

correctly. The device code may only

contain the numbers 0-9.

Programming a new device code for a

chosen device type automatically replaces

the old code.

[ TV ] – the button can only save TV

codes.

[ VCR ] – the button can only save VCR

codes.

[ DVD ] and [ SAT ] – the buttons can

save all device codes (including TV and

VCR codes)

Tip!

When you have found the correct device

code we recommend that you write down

the code on the label on the backside of

the remote control.

If no device code works with your device

If you cannot nd the correct device code

for your device you can search through all

the remote control’s codes for the respec-

tive device type.

TV - TVs

VCR - VCRs

SAT - Satellite and digital TV receivers

DVD - DVD players

ENGLISH









If you cannot nd the right device code

in the list, you can search in the following

manner:

1. Turn on, for example, the TV manually

or with the original remote control.

2. Press the button for the desired device,

for example [ TV ]

First press the [ SHIFT ] button and

then button for desired device.

3. Press the buttons [ P+ ] and [ VOL- ]

simultaneously for 3 seconds until the

LED light is lit.

4. Enter the corresponding search code

from the following table.

The LED light ashes 2 times and is

then turned off.

Device type Search code

TV 0001

VCR 0002

SAT 0003

CBL 0004

DVD 0005

(In this example, you press the code for

TV: 0001)

5. Again, press the same button as in step

2 for desired device type.

(In this example the [ TV ] button).

6. Press the buttons [ P+ ] and [ VOL- ]

simultaneously for 3 seconds until the

LED light is lit. Now the remote control is

ready to search.

7. Point the remote control towards desired

device (in this example, the TV) and

press the button ON/OFF several

times slowly and with patience until the

device is turned off. When the device

has turned off, you immediately press

the device button (for this example

[ TV ] ) to store the search code. The

LED light is turned off.

ENGLISH

In the same manner as above, search for the

device code for other devices. Remember

to press the correct button for the desired

device in steps 2 and 5 above.

Important!

If the circuit breaker function on your device

is not controlled by infrared lights, you follow

steps 2 through 6 above and start the search.

Then, follow the instructions below.

- Press alternately on the button ON/OFF

and another important function button

until your device reacts with the desired

function. Press the button for the device

you have chosen in the steps above (in

this example the [ TV ] button) to store

the search code.

For example, you press alternately

on ON/OFF and another important

function button or on ON/OFF and

PLAY ►.

- Every time that you press the button

ON/OFF the remote control skips to

the next code and send out a signal for

turning off the device. If you do not ma-

nage to stop pressing ON/OFF in time

before the device is turned off, you turn

on the device as fast as you can. Before

the indicator (the LED light) is turned

off you press [ P- ] to skip backwards.

Repeat step 7 above and store the code.

- If the LED light ashes 6 times after that

you have pressed ON/OFF , you have

reached the library’s last code. Press

on (in this example [ TV ] ) to restore

the remote control and repeat the above

procedure to search again.

Note

DVD, SAT and other device codes may be

stored on all function buttons except TV and

VCR.

ENGLISH
