Installation options
Select an installation option.
Installation option 1: Desktop
Option 1 uses the included panel tabletop stand.
To desktop mount the panel:
1. Insert the kickstand to the rear of the panel. The stand pops into place,
locking to the panel.
Note: There are 2 options for tabletop stand orientation. Each option results
in a different viewing angle.
Orientation 1: Insert the stand into the panel with the tail facing down,
creating a downward facing arc. This gives the panel a more forward-facing
view, close to a 60° angle.
Orientation 2: Insert the stand into the panel with the tail facing upward,
creating a curve upward. This gives the panel a more upward-facing view,
close to a 30° angle.
2. Slide a stand grip onto each slot on the stand.
(Optional) To prevent the panel from sliding, attach the included non-slip
base grips. Place one base grip on each corner of the panel.
3. Plug the included power supply into the rear of the Android panel.
4. Plug the opposite end of the power supply into an electrical outlet.
The tablet automatically powers up.
Installation option 2: Wall mounted
Option 2 requires the panel to be wall mounted. Use the included screws and
metal plate to mount the panel flush with the wall.
To wall mount the panel:
1. Place the mounting bracket against the wall, ensuring that it is in the desired
location and close to an outlet.
2. Using 2 of the included screws and a power drill, securely attach the bracket
to the wall.
3. Plug the included power supply into the rear of the ClareHome panel.
4. Slide the panel onto the mounting bracket.
5. Plug the opposite end of the power supply into an electrical outlet.
The tablet automatically powers up.
