mode .
3) Use the bank UP and DOWN keys to select the axis you wish to assign (Pan or TILT).
4) Use the “ Tap/Display ” button to select 16 or 8 channel mode.
5) Press the button corresponding to the scanner you wish to assign.
6) While holding the mode button press the scene number corresponding to the slider
which controls the movement. (Example: If pan is controlled by slider number 4,
press and hold the “ Mode ” button while tapping scene button 4#).
7) When finished press the “ Mode ” and “ Fine ” buttons at the same time again to exit
Assign mode.
S
S
S
S CENES
CENES
CENES
CENES
�
�
�
�
Programming
Programming
Programming
Programming
A
A
A
A
Scene
Scene
Scene
Scene
1) Enter program mode (See Enabling Program Mode)..
2) Check the blackout key and verify that the LED is not lit, if it is, press it once to exit
blackoutmode.
3) Verify that the speed and fade time sliders are positioned at zero.
4) Press the scanner button corresponding to the unit wish to control.
You
may control
more than one scanner at time by pressing the button corresponding to the scanner(s)
you wish to program.
5) Move the faders and joystick to the desired position. If necessary, you may select
page B to control channels 9-16.
6) Tap the bank Up/Down button to choose the bank you want to store this scene into.
There are a total of 30 banks you can select, you may store up to 8 scenes in each
bank.
7) Once all scanners are programmed into the desired position for the scene, tap the
MIDI/Rec button to program this scene into memory.
8) Tap the scene button you wish to store your scene into. All LEDs will flash three
times signifying this operation. The LCD readout will show the bank and scene.
9)
To
unselect the scanner(s) you have been programming and switch to another simply
press the button of the scanner you have been programming again, deselecting it, and
select another scanner.
10) Repeat steps 2-7 until all scenes have been programmed.
11) If you don
’
t intend to continue programming at this time, press and hold the program
