Cisco WMP110 RangePlus Instructions d'utilisation d'origine
Model No: WMP110
RangePlus Wireless
PCI Adapter
QUICK INSTALLATION
Package Contents
RangePlus Wireless PCI Adapter
Setup Wizard CD-ROM
User Guide on CD-ROM
Quick Installation Guide
Two (2) Antennas
•
•
•
•
•
3
The Adapter is installed and set up using the Setup Wizard on the enclosed
Setup Wizard CD.
IMPORTANT: Do not install the Adapter in your computer
until you are instructed to do so, or the Adapter will not install
correctly.
Insert the Setup Wizard CD into
your CD-ROM drive.
NOTE: Windows or other personal firewalls may ask for
permission to run the software or program. You will need to allow
the software to run in order to continue.
The Welcome screen appears.
Click the Click Here to Start
button.
A.
B.
Insert the CD-ROMInsert the CD-ROM
Click Here to StartClick Here to Start
Installation1�
4
Installation
Read the License Agreement, and
select I accept the terms in the
License Agreement.
Click Next to continue the
installation.
Before connecting the PCI Adapter
to your PC, make sure that your
desktop PC is powered down.
Open your PC case and locate
an available PCI slot on the
motherboard. Check with your
computer manufacturer for
instructions.
C.
D.
E.
License AgreementLicense Agreement
Power Down the Desktop PCPower Down the Desktop PC
5
Installation
Slide the PCI Adapter into the PCI
slot. Make sure that all of its pins
are touching the slot's contacts. You
may have to apply a bit of pressure
to slide the adapter all the way in.
After the adapter is firmly in place,
secure its fastening tab to your PC's
chassis with a mounting screw.
Then, close your PC
Attach the two (2) external
antennas to the adapter’s antenna
ports.
Power on your desktop PC.
Congratulations! Installation is complete.
If your computer runs Windows XP or 2000, proceed to“Section 2: Setup
for Windows XP or 2000”.
If your computer runs Windows Vista, proceed to“Section 3: Setup for
Windows Vista”.
F.
G.
H.
I.
Insert the AdapterInsert the Adapter
Attach the AntennasAttach the Antennas
6
Installation
7
Setup for Windows XP or 20002�
The Adapter supports, Wi-Fi Protected Setup, a feature that makes it easy to set
up your wireless network.
If the Available Wireless Networks screen
appears, your router does not support
this feature. Proceed to the“No Wi-Fi
Protected Setup” section.
If the Connect to a Network screen
appears, the Adapter detects a router
that supports Wi-Fi Protected Setup.
Proceed to the “Wi-Fi Protected Setup”
section.
No Wi-Fi Protected Setup
From the Available Wireless Networks screen, you can launch one of the two
setup methods.
If your network appears on the Available Wireless Networks screen, proceed
to step A. If your network does not appear on the Available Wireless Networks
screen, click Advanced Setup and follow the on-screen prompts.
Available Wireless NetworksAvailable Wireless Networks
Connect to a NetworkConnect to a Network
8
Setup for Windows XP or 2000
On the Available Wireless Networks
screen, the available networks
are listed in the table. Select your
network, and then click Connect.
If your network does not use wireless security, proceed to the“Wireless
Security Disabled”section. If your network uses wireless security, proceed
to the Wireless Security Enabled” section.
Wireless Security Disabled
Click Connect Anyway.
Click Finish.
A.
B.
A.
B.
Available Wireless NetworksAvailable Wireless Networks
Click Connect AnywayClick Connect Anyway
CongratulationsCongratulations
9
Setup for Windows XP or 2000
The Status screen of the Wireless
Network Monitor appears the first
time you run the Setup Wizard. To
exit the Monitor, click the Xin the
upper right corner.
NOTE: After the Adapter is installed, the Wireless Network
Monitor screen opens, and its icon appears in your computer’s
system tray. You can double-click the icon to open the Monitor
if you want to find available wireless networks or change the
Adapter’s configuration. For detailed information on the Monitor,
refer to the User Guide on the CD-ROM.
Congratulations! Setup is complete.
Wireless Security Enabled
If your network has wireless security, you will see one of these wireless
security screens. Follow the instructions for the screen you see.
WPA2-Personal Key Needed for Connection
Enter the Passphrase (also called
a pre-shared key) of your wireless
network. It must have 8-63
characters.
Click Connect and go to step B.
C.
A.
1.
2.
Connected to the NetworkConnected to the Network
WPA2-Personal Key Needed for ConnectionWPA2-Personal Key Needed for Connection
10
Setup for Windows XP or 2000
WPA-Personal Key Needed for Connection
Enter the Passphrase (also called
a pre-shared key) of your wireless
network. It must have 8-63
characters.
Click Connect and go to step B.
WEP Key or Passphrase Needed for Connection
Enter the Passphrase or WEP Key.
Passphrase The Passphrase is
case-sensitive and must have 16 or
fewer alphanumeric characters.
WEP Key For 64-bit encryption,
enter 10 hexadecimal characters
(“0” to “9” and “A” to “F”). For 128-bit
encryption, enter 26 hexadecimal
characters.
Click Connect and go to step B.
On the Congratulations screen, click
Finish.
1.
2.
1.
2.
B.
WPA-Personal Key Needed for ConnectionWPA-Personal Key Needed for Connection
WEP Key or Passphrase Needed for
Connection
WEP Key or Passphrase Needed for
Connection
CongratulationsCongratulations
