Cisco C190 Email Security Appliance

Quick Start Guide

• Welcome

• Before You Begin

• Document Network Settings

• Plan the Installation

• Install the Appliance in a Rack

• Plug In the Appliance

• Temporarily Change Your IP Address for Remotes Access

• Connect to the Appliance

• Power Up the Appliance

• Log In to the Appliance

• Run the System Setup Wizard

• Run the Active Directory Wizard (Optional)

• Check for Available Upgrades

• Configure Network Settings

• Configuration Summary

• Where to Go from Here

• Cisco Notification Service

Welcome

The Cisco C190 appliance is designed to serve as your SMTP email gateway at

your network perimeter—that is, the first appliance with an IP address that is

directly accessible to the Internet for sending and receiving email. Many of the

features (including reputation filtering, data loss prevention, content scanning,

spam detection, and virus protection) require you to install the Cisco appliance

into your existing network infrastructure.

This guide describes how to physically install your Cisco C190 appliance and

use the System Setup Wizard to configure basic settings.

Before You Begin

Before you begin the installation, make sure that you have the items needed.

The following items are included with the Cisco C190 Email Security Appliance:

• Rail kit

• Power cables

• Console cable

• A card listing the location of online documentation for your appliance.

You will need to provide the following items yourself:

• Rack cabinet enclosure (if rack-mounting the appliance)

• Phillips-head screwdriver for assembling rails

• 10/100 Gigabit Base-T TCP/IP LAN

• Ethernet cable for connecting the appliance to your network

• Desktop or laptop computer

• Web browser (or SSH and terminal software)

• Network and administrator information for the “Document Network

Settings” section on page 3 and “go live” configuration

Document Network Settings

Before you begin, write down the following information about your network

and administrator settings.

System Settings

Enable/Disable

Network Integration

Interfaces

Default System Hostname:

Email System Alerts To:

Deliver Scheduled Reports To:

Time Zone Information:

NTP Server:

Admin Password:

SenderBase Network Participation:

AutoSupport: Enable/Disable

Default Gateway (router) IP Address:

DNS (Internet or specify own):

IP Address:

Network Mask:

Fully Qualified Hostname:

Accept Incoming Mail Domain:

Accept Incoming Mail Destination:

Relay Outgoing Mail:

IP Address:

Network Mask:

Fully Qualified Hostname:

Accept Incoming Mail Domain:

Accept Incoming Mail Destination:

Relay Outgoing Mail:

Message Security

SenderBase Reputation Filtering: Enable/Disable

Cisco Anti-Spam Scanning Engine: Enable/Disable

Plan the Installation

To defend your email system against spam, malware, phishing, and other

threats, the Cisco C190 appliance must be installed at the perimeter of your

network. It needs to be the first appliance with an IP address that can access the

Internet.

Plan for your network configuration to look something like this:

McAfee Anti-Virus Scanning Engine: Enable/Disable

Sophos Anti-Virus Scanning Engine: Enable/Disable

Virus Outbreak Filters: Enable/Disable

Advanced Malware Protection 

Scanning Engine

Enable/Disable

Message Security

Install the Appliance in a Rack

Install the Cisco C190 Email Security Appliance using the rails supplied. For

information about these installation options, see the Cisco x90 Series Content

Security Appliances Installation and Maintenance Guide.

Appliance Placement in a Rack

• Ambient Temperature—To prevent the appliance from overheating, do not

operate it in an area that exceeds an ambient temperature of 104°F (40°C).

• Air Flow—Be sure that there is adequate air flow around the appliance.

• Mechanical Loading—Be sure that the appliance is level and stable to avoid

any hazardous conditions.

Plug In the Appliance

Plug the female end of the power cable into the power supply on the back panel

of the appliance. Plug the male end into an electrical outlet.

Temporarily Change Your IP Address for Remotes

Access

To remotely configure the Cisco C190 using the network connection, you must

temporarily change the IP address of your computer. Alternatively, you can use

the serial console to configure the Cisco C190, without changing the IP address.

If you use the serial console, proceed to section 8 below.

Note Make a note of your current IP configuration settings because you will

need to revert to these settings after you finish the configuration.

For Windows

The exact steps depend on your operating system version.

Step 1 Go to the Start menu and choose Control Panel.

Step 2 Click Network and Internet, then Network and Sharing Center.

Step 3 Click the Change adapter settings link.

Step 4 Right-click Local Area Connection and choose Properties.

Step 5 Click Internet Protocol Version 4, then choose Properties.

Step 6 Note your current settings.

Step 7 Select Use the Following IP Address.

Step 8 Enter the following changes:

• IP Address: 192.168.42.43

• Subnet Mask: 255.255.255.0

• Default Gateway: 192.168.42.1

Step 9 Click OK and Close to exit the dialog box.

For Mac

The exact steps depend on your operating system version.

Step 1 Launch the Apple menu and choose System Preferences.

Step 2 Click Network.

Step 3 Click the lock icon to allow changes.

Step 4 Select the network configuration with the green icon. This is your active

connection. Then click Advanced.

Step 5 Click the TCP/IP tab and from Ethernet settings, choose Manually from

the drop-down list.

Step 6 Enter the following changes:

• IP Address: 192.168.42.43

• Subnet Mask: 255.255.255.0

• Router: 192.168.42.1

Step 7 Click OK.

Connect to the Appliance

The Cisco C190 appliance has two gigabit network ports: 

Data 1 and Data 2. At least one static IP address is required to send and receive

email.

You can receive and deliver email from a single connection to either network

port if your network topology dictates it. Two IP addresses can be configured on

one network interface.

Alternatively, you can connect the Data 1 network port to your public network

and connect the Data 2 network port to your private network.

To access the appliance by Ethernet, connect to Data 1 as your management

interface and configure incoming email on Data 2.

For serial access to the appliance, connect to the console port.

Item Port Description

1Remote

Power Cycle

The port that is used for Remote

Power Cycle (RPC).

2Console The console port that directly

connects a computer to the

appliance.

3Data 1 A Gigabit Ethernet customer data

interface. This port is used as a

management interface.

4Data 2 A Gigabit Ethernet customer data

interface.

Power Up the Appliance

Power up the appliance by pressing the On/Off switch on the front panel of the

Cisco C190. You must wait 10 minutes for the system to initialize each time you

power up the system. After the machine powers up, solid green lights on the

front of the appliance indicate that the appliance is operational. The network

activity light will be green but may not be solid. .

Note If turned on quickly after connecting power to the appliance, the

appliance powers up, the fans spin and the LEDs turn on. Within 30-60

seconds, the fans stop and all LEDs turn off. The appliance powers on

31 seconds later. This behavior is by design to allow the system

firmware and controller to synchronize. 



Wait at least 10 minutes for the system to complete the power up

sequence and the LEDs to turn green. If you turn the power off before

the initialization is complete, the appliance will NOT reach an

operational state and must be returned to Cisco.

You can log in to the Cisco C190 appliance using one of two interfaces: the

web-based interface or the command-line interface.

Web-Based Interface

Step 1 For web browser access via the Ethernet port (see the “Connect to the

Appliance” section on page 7), go to the appliance’s management

interface by entering the following URL in a web browser:

http://192.168.42.42

Step 2 Log in with the following credentials:

• Username: admin

• Password: ironport

Command-Line Interface

Step 1 Access the command-line interface locally or remotely:

• To access the CLI locally, set up a terminal to connect to the serial

port using 9600 bits, 8 bits, no parity, 1 stop bit (9600, 8, N, 1) and

flow control set to Hardware. To physically connect the terminal,

see the “Connect to the Appliance” section on page 7).

• To access the CLI remotely, initiate an SSH session to the IP address

192.168.42.42.

Step 2 Log in as admin with the password ironport.

Step 3 At the prompt, run the systemsetup command.

Run the System Setup Wizard

The System Setup Wizard starts automatically when you access the appliance via

the web-based interface (or when you run the systemsetup command from the

command-line interface.)

Step 1 Start the System Setup Wizard.

Step 2 Accept the end user license agreement.

Step 3 Enter information from the “Document Network Settings” section on

page 3.

Step 4 Set anti-spam and anti-virus security settings.

Step 5 Review the configuration summary page.

Step 6 Click Install this Configuration.

The appliance may not appear to have accepted your configuration or

be performing the installation. This is because you have changed the IP

address, but the installation is underway.

Step 7 If you temporarily changed the IP address of your computer as

described in the “Temporarily Change Your IP Address for Remotes

Access” section on page 5, change the IP address settings back to the

original values.

Step 8 Ensure that your laptop and the appliance are connected to the

network.

Step 9 Log back in to the appliance with the username admin and the new

password that you set in the System Setup Wizard.

The Cisco C190 Email Security Appliance uses a self-signed certificate

that may trigger a warning from your web browser. You can simply

accept the certificate and ignore this warning.

Step 10 Write down your new administrator password and keep it in a safe

place.

Run the Active Directory Wizard (Optional)

After running the System Setup Wizard in the web interface, the Active Directory

Wizard appears. If you are running an Active Directory server on your network,

use the Active Directory Wizard to configure an LDAP server profile for the

Active Directory server.

If you are not using Active Directory or want to configure it later, click Skip this

Step. You can run the Active Directory Wizard later by going to System

Administration > LDAP. Select the “using Active Directory Wizard” check box,

and then click Add LDAP Server Profile.

Note You will need the hostname and login information for your Active

Directory account to run the Active Directory Wizard.

Note Commit any changes you make in the GUI by clicking Commit

Changes. This button appears if you have any uncommitted changes

that need to be saved.
