Cisco RV110W Mode d’emploi

Cisco Small Business

RV110W Wireless-N VPN Firewall

ADMINISTRATION

GUIDE

Revised March 2012

Cisco and the Cisco logo are trademarks or registered trademarks of Cisco and/or its affiliates in the U.S. and other countries. To view a list of Cisco trademarks,

go to this URL: www.cisco.com/go/trademarks. Third-party trademarks mentioned are the property of their respective owners. The use of the word partner

does not imply a partnership relationship between Cisco and any other company. (1110R)

Cisco RV110W Administration Guide 3

Contents

Chapter 1: Introduction 8

Product Overview 8

Getting to Know the Cisco RV110W 10

Front Panel 10

Back Panel 12

Installing the Cisco RV110W 13

Placement Tips 13

Connecting the Equipment 13

Using the Setup Wizard 15

Using the Getting Started Page 16

Navigating through the Pages 18

Saving Changes 19

Viewing the Help Files 19

Configuration Next Steps 20

Verifying the Hardware Installation 20

Connecting to Your Wireless Network 21

Chapter 2: Configuring Networking 22

Configuring the WAN Settings 22

Configuring Automatic Configuration (DHCP) 22

Configuring Static IP 23

Configuring PPPoE 23

Configuring PPTP 25

Configuring L2TP 26

Configuring Optional Settings 28

Configuring the LAN Settings 29

Changing the Default Cisco RV110W IP Address 30

Configuring DHCP 31

Configuring VLANs 32

Configuring Static DHCP 34

Viewing DHCP Leased Clients 35

Cisco RV110W Administration Guide 4

Contents

Configuring a DMZ Host 35

Configuring RSTP 36

Port Management 37

Cloning the MAC Address 39

Configuring Routing 40

Configuring the Operating Mode 40

Configuring Dynamic Routing 40

Configuring Static Routing 41

Configuring Inter-VLAN Routing 42

Viewing the Routing Table 43

Configuring Dynamic DNS 43

Configuring the IP Mode 44

Configuring IPv6 45

Configuring the WAN for an IPv6 Network 45

Configuring IPv6 LAN Settings 49

Configuring IPv6 Static Routing 52

Configuring Routing (RIPng) 54

Configuring Tunneling 54

Viewing IPv6 Tunnel Status 55

Configuring Router Advertisement 56

Configuring Advertisement Prefixes 57

Chapter 3: Configuring the Wireless Network 60

Wireless Security 60

Wireless Security Tips 60

General Network Security Guidelines 62

Cisco RV110W Wireless Networks 62

Configuring Basic Wireless Settings 63

Editing the Wireless Network Settings 65

Configuring the Security Mode 66

Configuring MAC Filtering 69

Cisco RV110W Administration Guide 5

Contents

Configuring Time of Day Access 70

Configuring the Wireless Guest Network 71

Configuring Advanced Wireless Settings 73

Configuring WDS 76

Configuring WPS 77

Chapter 4: Configuring the Firewall 79

Cisco RV110W Firewall Features 79

Configuring Basic Firewall Settings 81

Configuring Remote Management 83

Configuring Universal Plug and Play 84

Managing Firewall Schedules 85

Adding or Editing a Firewall Schedule 85

Configuring Services Management 85

Configuring Access Rules 86

Adding Access Rules 87

Creating an Internet Access Policy 90

Adding or Editing an Internet Access Policy 90

Configuring Port Forwarding 91

Configuring Single Port Forwarding 92

Configuring Port Range Forwarding 93

Configuring Port Range Triggering 93

Chapter 5: Configuring VPN 95

VPN Tunnel Types 95

VPN Clients 96

Configuring PPTP 96

Configuring NetBIOS Over VPN 97

Creating and Managing PPTP Users 97

Creating and Managing QuickVPN Users 98

Importing VPN Client Settings 99

Cisco RV110W Administration Guide 6

Contents

Configuring Basic VPN Settings (Site-to-Site VPN) 100

Viewing Default Values 101

Configuring Advanced VPN Parameters 102

Managing IKE Policies 102

Managing VPN Policies 103

Configuring Certificate Management 108

Configuring VPN Passthrough 109

Chapter 6: Configuring Quality of Service (QoS) 111

Configuring Bandwidth Management 111

Configuring Bandwidth 111

Configuring Bandwidth Priority 112

Configuring QoS Port-Based Settings 113

Configuring CoS Settings 114

Configuring DSCP Settings 114

Chapter 7: Administering Your Cisco RV110W 116

Setting Password Complexity 117

Configuring User Accounts 118

Setting the Session Timeout Value 119

Configuring Simple Network Management (SNMP) 119

Configuring SNMP System Information 119

Editing SNMPv3 Users 120

Configuring the SNMP Traps 121

Using Diagnostic Tools 122

Network Tools 122

Configuring Port Mirroring 124

Configuring Logging 124

Configuring Logging Settings 124

Configuring the E-Mailing of Logs 126

Configuring Bonjour 128

Cisco RV110W Administration Guide 7

Contents

Configuring Date and Time Settings 128

Backing Up and Restoring the System 129

Backing Up the Configuration Settings 130

Restoring the Configuration Settings 131

Copying the Configuration Settings 131

Generating an Encryption Key 132

Upgrading Firmware or Change the Language 132

Restarting the Cisco RV110W 134

Restoring the Factory Defaults 134

Running the Setup Wizard 134

Chapter 8: Viewing the Cisco RV110W Status 136

Viewing the Dashboard 137

Viewing the System Summary 139

Viewing the Wireless Statistics 141

Viewing the VPN Status 142

Viewing the IPSec Connection Status 143

Viewing Logs 144

Viewing Connected Devices 145

Viewing Port Statistics 146

Viewing the GuestNet Status 147

Appendix A: Using Cisco QuickVPN 148

Overview 148

Before You Begin 148

Installing the Cisco QuickVPN Software 149

Installing from the CD-ROM 149

Downloading and Installing from the Internet 151

Using the Cisco QuickVPN Software 151

Appendix B: Where to Go From Here 154

Cisco RV110W Administration Guide 8

Introduction

This chapter provides information to familiarize you with the product features,

guide you through the installation process, and get started using the

browser-based Device Manager.

•Product Overview

•Getting to Know the Cisco RV110W

•Installing the Cisco RV110W

•Connecting the Equipment

•Using the Setup Wizard

•Verifying the Hardware Installation

•Connecting to Your Wireless Network

Product Overview

Thank you for choosing the Cisco Small Business RV110W Wireless-N VPN

Firewall.

The Cisco RV110W is an advanced Internet-sharing network solution for your

small business needs. It allows multiple computers in your office to share an

Internet connection through both wired and wireless connections.

The Cisco RV110W provides a Wireless-N access point, combined with support

for Virtual Private Network (VPN) clients to make remote access to your network

more secure.

The router 10/100 Fast Ethernet WAN interface connects directly to your

broadband DSL or Cable modem.

Introduction

Product Overview

Cisco RV110W Administration Guide 9

LAN Ethernet Interfaces

The Cisco RV110W provides four full-duplex 10/100 Fast Ethernet LAN interfaces

that can connect up to four devices. You can connect a Cisco Small Business

switch to one of the available ports to expand your network as needed.

Wireless Access Point

The Cisco RV110W wireless access point supports the 802.11n standard with

MIMO technology, which multiplies the effective data rate. This technology results

in better throughput and coverage than that provided by 802.11g networks.

Firewall and VPN Client Access

The Cisco RV110W incorporates a Stateful Packet Inspection (SPI)-based firewall

with Denial of Service (DoS) prevention and a Virtual Private Network (VPN)

engine for secure communication between mobile or remote workers and branch

offices.

The Cisco RV110W supports up to five client-to-gateway VPN tunnels to facilitate

branch office connectivity through encrypted virtual links. Users connecting

through a VPN tunnel are attached to your company network with secure access

to files, e-mail, and your intranet as if they were in the building.

Security

The Cisco RV110W implements WPA Personal, WPA Enterprise, WPA2 personal,

WPA2 Enterprise, and WEP Security, along with other security features including

the disabling of SSID broadcasts, MAC- based filtering, and allowing or denying

“time of day” access per SSID.

Quality of Service

The Cisco RV110W supports Wi-Fi Multimedia (WMM) and Wi-Fi Multimedia

Power Save (WMM-PS) for Quality of Service (QoS).

The Cisco RV110W also supports 802.1p, Differentiated Services Code Point

(DSCP), and Type of Service (ToS) for wired QoS, which can improve the quality of

your network when using delay-sensitive Voice over IP (VoIP) applications and

bandwidth-intensive video streaming applications.

Wireless Distribution System

The Cisco RV110W wireless access point supports Wireless Distribution System

(WDS), which allows the wireless coverage to be expanded without wires.

Introduction

Getting to Know the Cisco RV110W

Cisco RV110W Administration Guide 10

Virtual Networks

The Cisco RV110W also supports multiple Service Set Identifiers (SSIDs) for the

use of virtual networks (up to four separate virtual networks), with 802.1Q-based

VLAN support for traffic separation.

Configuration and Administration

With the Cisco RV110W embedded web server, you can configure the

Cisco RV110W settings using the browser-based Device Manager. The

Cisco RV110W supports Internet Explorer, Firefox, and Safari web browsers.

The Cisco RV110W also provides a Setup Wizard that allows you to easily and

quickly configure the Cisco RV110W basic settings.

Getting to Know the Cisco RV110W

Front Panel

Power The Power light is green to indicate the unit is powered

on. The light flashes green when the power is coming

on.

WPS The Wi-Fi Protected Setup (WPS) button is used to

configure wireless access for devices in your network

that are WPS-enabled. See Configuring WPS, page 77

for more information.
