Cisco WUSB100 Instructions d'utilisation d'origine

For additional information or troubleshooting help, refer to the User Guide on the CD-ROM.

Additional support is also available by phone or online.

Website

http://www.linksys.com/international

Product registration

http://www.linksys.com/registration

Linksys is a registered trademark or trademark of Cisco Systems, Inc. and/or its affiliates in the U.S.

and product names are trademarks or registered trademarks of their respective holders.

www.linksys.com

RangePlus Wireless

Network USB Adapter

Model No: WUSB100

QUICK INSTALLATION

Package Contents

RangePlus Wireless Network•

USB Adapter

Setup CD-ROM•

User Guide on CD-ROM•

Quick Installation Guide•

Setup for Windows Vista

The Windows Vista WirelessH.

Network Configuration utility icon

appears on your desktop’s system

tray.

You can use this utility to configure

or change your wireless settings.

NOTE: For help with the Windows Vista Wireless Network

Conguration utility, refer to Windows Vista Help and Support, by

clicking Vista’s Start button > Help and Support.

Congratulations! Setup is complete.

7111510A-JL

Windows Vista Wireless Network

Configuration Utility Icon

Wireless Connection Status

The Adapter is installed and set up using the Setup Wizard on the enclosed

Setup Wizard CD.

IMPORTANT: Do not install the Adapter in your computer

until you are instructed to do so, or the Adapter will not install

correctly.

Insert the Setup Wizard CD intoA.

your CD-ROM drive.

NOTE: Windows or other personal rewalls may ask for

permission to run the software or program. You will need to allow

the software to run in order to continue.

TheB. Welcome screen appears on

your monitor.

Click the Click Here to Start

button.

Installation1

Insert the CD-ROM

Click Here to Start

Installation

Setup for Windows Vista

Read the License Agreement,C.

and click Next to continue the

installation.

Locate an available USB slot on yourD.

computer.

Insert the Adapter into the slot until

it locks into place.

Click Next.

After you install the AdapterE.

correctly, the Congratulations

screen appears.

Click Finish.

If your computer runs Windows XP or 2000, proceed to step 2,“Setup forF.

Windows XP or 2000”.

If your computer runs Windows Vista, proceed to step 3,“Setup for

Windows Vista”.

License Agreement

Insert the Adapter

Congratulations

This screen appears when you areE.

connected to your network.

Select Save this network, if you

want to save your settings.

Click Close.

TheF. Set Network Location screen

may appear to help apply the

correct settings for your type of

location. If it doesn’t appear, go to

step H.

Select Home, Work, or Public

location.

This screen varies according to theG.

selected location.

Click Close.

Connected to Network

Select Network Location

Network Settings Saved

8 5

The first Windows Vista WirelessA.

Network Configuration utility

screen appears. Select your

network, and then click Connect.

If your network has no wirelessB.

security, this screen appears. If your

network has wireless security, go to

step C.

To connect to your unsecured

network, click Connect Anyway

and go to step E.

Enter the security key or passphraseC.

(also known as pre-shared key or

WEP key, depending on your type

of security).

Click Connect.

This screen appears while theD.

Adapter connects to your network.

Do not cancel, unless you want to

end the installation.

Setup for Windows Vista3

Select Network

Unsecured Network

Secured Network

Connecting to Network

The Available Wireless Networks screen appears. From this screen, you can launch

one of the two setup methods.

If your network appears on the Available Wireless Networks screen, continue with

this Quick Installation. If your network does not appear on the Available Wireless

Networks screen, click Advanced Setup and follow the on-screen prompts.

A. On the Available Wireless Networks

screen, the available networks

are listed in the table. Select your

network, and then click Connect.

If your network has no wireless security, you will be taken directly to theB.

Congratulations screen, shown in step C. If your network has wireless

security, you will see one of these wireless security screens. Follow the

instructions for the screen you see.

WPA2-Personal Needed for Connection

Enter the Pre-Shared Key of your1.

wireless network. It must have 8-63

characters.

Click2. Connect and go to step C.

Setup for Windows XP or 20002

Select Network

WPA2-Personal Needed for Connection

Setup for Windows XP or 2000

WPA-Personal Needed for Connection

Select your encryption method and1.

enter a Pre-shared Key.

Encryption Select the encryption

method of your wireless network,

TKIP or AES.

Pre-shared Key Enter the Pre-

shared Key of your wireless

network. It must have 8-63

characters.

Click2. Connect and go to step C.

WEP Needed for Connection

Select the level of encryption, and1.

then enter the Passphrase or WEP

Key.

WEP Select the level of encryption,

64-bit or 128-bit.

Passphrase Enter the Passphrase

of your wireless network. It is case-

sensitive and must have 16 or fewer

alphanumeric characters.

WEP Key Enter the WEP Key of

your wireless network. For 64-bit

encryption, enter 10 hexadecimal

characters (“0” to “9” and “A” to “F”).

For 128-bit encryption, enter 26

hexadecimal characters.

Click2. Connect and go to step C.

WPA-Personal Needed for Connection

WEP Key Needed for Connection

On theC. Congratulations screen, click

Finish.

TheD. Link Information screen of the

Wireless Network Monitor appears

the first time you run the Setup

Wizard. To exit the Monitor, click the

Xin the upper right corner.

NOTE: After the Adapter is installed, the Wireless Network

Monitor screen opens, and its icon appears in your computer’s

system tray. You can double-click the icon to open the Monitor

if you want to find available wireless networks or change the

Adapter’s configuration. For detailed information on the Monitor,

refer to the User Guide on the CD-ROM.

Congratulations! Setup is complete.

Congratulations

Connected to Network
