INSTRUCTION MANUAL
(M097B01-03-16A)
Multifunction multimeter
CirCAMP-4DP
CirCAMP-2IP

2
CirCAMP-4DP, CirCAMP-2IP
Instruction Manual

SAFETY PRECAUTIONS
DISCLAIMER
CIRCUTOR, SA reserves the right to make modi cations to the device or the unit speci ca-
tions set out in this instruction manual without prior notice.
CIRCUTOR, SA on its web site, supplies its customers with the latest versions of the device
speci cations and the most updated manuals.
www.circutor.com
DANGER
Warns of a risk, which could result in personal injury or material damage.
ATTENTION
Indicates that special attention should be paid to a speci c point.
Follow the warnings described in this manual with the symbols shown below.
If you must handle the unit for its installation, start-up or maintenance, the following
should be taken into consideration:
Incorrect handling or installation of the unit may result in injury to personnel as well as damage
to the unit. In particular, handling with voltages applied may result in electric shock, which may
cause death or serious injury to personnel. Defective installation or maintenance may also
lead to the risk of re.
Read the manual carefully prior to connecting the unit. Follow all installation and maintenance
instructions throughout the unit’s working life. Pay special attention to the installation stan-
dards of the National Electrical Code.
Refer to the instruction manual before using the unit
In this manual, if the instructions marked with this symbol are not respected or carried out correctly, it can
result in injury or damage to the unit and /or installations.
CIRCUTOR, SA reserves the right to modify features or the product manual without prior noti cation.
3
Instruction Manual
CirCAMP-4DP, CirCAMP-2IP

CONTENTS
SAFETY PRECAUTIONS ���������������������������������������������������������������������������������������������������������������������������������������3
DISCLAIMER ����������������������������������������������������������������������������������������������������������������������������������������������������������3
CONTENTS�������������������������������������������������������������������������������������������������������������������������������������������������������������4
REVISION LOG�������������������������������������������������������������������������������������������������������������������������������������������������������6
1�- VERIFICATION UPON RECEPTION����������������������������������������������������������������������������������������������������������������� 7
2�- PRODUCT DESCRIPTION��������������������������������������������������������������������������������������������������������������������������������7
3�- DEVICE INSTALLATION �����������������������������������������������������������������������������������������������������������������������������������9
3�1�- PRELIMINARY RECOMMENDATIONS ����������������������������������������������������������������������������������������������������9
3�2�- INSTALLATION ���������������������������������������������������������������������������������������������������������������������������������������10
3�3�- DEVICE TERMINALS������������������������������������������������������������������������������������������������������������������������������10
3�3�1�- CirCAMP-4DP MODEL �����������������������������������������������������������������������������������������������������������������10
3�3�2�- CirCAMP-2IP MODEL ������������������������������������������������������������������������������������������������������������������� 11
3�4�- CONNECTION DIAGRAM�����������������������������������������������������������������������������������������������������������������������12
3�4�1�- CirCAMP-4DP MODEL ������������������������������������������������������������������������������������������������������������������12
3�4�2�- CirCAMP-2IP MODEL�������������������������������������������������������������������������������������������������������������������� 13
3�5�- CONNECTIONS����������������������������������������������������������������������������������������������������������������������������������������14
4�- OPERATION ���������������������������������������������������������������������������������������������������������������������������������������������������15
4�1�- KEY FUNCTIONS ������������������������������������������������������������������������������������������������������������������������������������� 15
4�2�- DISPLAY ���������������������������������������������������������������������������������������������������������������������������������������������������15
4�3�- LED INDICATORS������������������������������������������������������������������������������������������������������������������������������������16
4�3�1�- CirCAMP-4DP MODEL ������������������������������������������������������������������������������������������������������������������16
4�3�2�- CirCAMP-2IP MODEL�������������������������������������������������������������������������������������������������������������������� 17
4�4�- IMPULSE INPUTS ������������������������������������������������������������������������������������������������������������������������������������18
4�5�- RELAY OUTPUTS ������������������������������������������������������������������������������������������������������������������������������������19
4�6�- CIRCUIT BREAKER���������������������������������������������������������������������������������������������������������������������������������19
4�6�1�- CirCAMP-4DP MODEL ������������������������������������������������������������������������������������������������������������������� 19
4�6�2�- CirCAMP-2IP MODEL ���������������������������������������������������������������������������������������������������������������������20
4�7�- REAL TIME CLOCK ���������������������������������������������������������������������������������������������������������������������������������21
5�- DISPLAY IMPROVEMENTS ���������������������������������������������������������������������������������������������������������������������������22
5�1�- DISPLAY IN STANDBY MODE����������������������������������������������������������������������������������������������������������������22
5�1�1�- CirCAMP-4DP MODEL ������������������������������������������������������������������������������������������������������������������23
5�1�2�- CirCAMP-2IP MODEL�������������������������������������������������������������������������������������������������������������������� 24
5�2�- DISPLAY IN READING MODE ����������������������������������������������������������������������������������������������������������������� 25
5�2�1�- CirCAMP-4DP MODEL ������������������������������������������������������������������������������������������������������������������� 25
5�2�2�- CirCAMP-2IP MODEL ���������������������������������������������������������������������������������������������������������������������27
6�- CONFIGURATION ������������������������������������������������������������������������������������������������������������������������������������������29
7�- COMMUNICATIONS���������������������������������������������������������������������������������������������������������������������������������������29
7�1�- OPTICAL COMMUNICATIONS PORT ����������������������������������������������������������������������������������������������������� 29
7�2�- PLC COMMUNICATIONS�������������������������������������������������������������������������������������������������������������������������29
7�3�- RS-485 COMMUNICATIONS (according to version)����������������������������������������������������������������������������� 30
7�3�1� CONNECTIONS�������������������������������������������������������������������������������������������������������������������������������30
7�4�- DLMS PROTOCOL�����������������������������������������������������������������������������������������������������������������������������������31
7�4�1�- ABSTRACT OBJECTS: SAP ASSIGNMENT, LN ASSOCIATIONS, COSEM ������������������������������� 31
7�4�2�- IDENTIFICATION NUMBERS ��������������������������������������������������������������������������������������������������������� 35
7�4�3�- CLOCK �������������������������������������������������������������������������������������������������������������������������������������������� 36
7�4�4�- ERRORS������������������������������������������������������������������������������������������������������������������������������������������37
7�4�5�- EVENTS�������������������������������������������������������������������������������������������������������������������������������������������37
7�4�6�- CONTROLLING THE CIRCUIT BREAKER ������������������������������������������������������������������������������������ 45
7�4�7�- FIRMWARE UPDATE ���������������������������������������������������������������������������������������������������������������������� 46
7�4�8�- METERING POINT ID ���������������������������������������������������������������������������������������������������������������������47
7�4�9�- FIRMWARE VERSION �������������������������������������������������������������������������������������������������������������������� 47
7�4�10�- OPTICAL PORT CONFIGURATION ���������������������������������������������������������������������������������������������47
7�4�11�- RS-485 PORT CONFIGURATION ������������������������������������������������������������������������������������������������� 48
7�4�12�- TIMEOUT���������������������������������������������������������������������������������������������������������������������������������������48
7�4�13�- RESETTING THE DEVICE������������������������������������������������������������������������������������������������������������49
7�4�14�- ACTIVE ENERGY��������������������������������������������������������������������������������������������������������������������������49
7�4�15�- IMPULSE INPUTS ������������������������������������������������������������������������������������������������������������������������50
7�4�16�- INSTANTANEOUS VALUES ��������������������������������������������������������������������������������������������������������50
7�4�17�- TRANSFORMER RATIO ���������������������������������������������������������������������������������������������������������������54
4
CirCAMP-4DP, CirCAMP-2IP
Instruction Manual

7�4�18�- OBJECTS RELATED TO PRE-PAYMENT������������������������������������������������������������������������������������ 55
7�4�19�- LOAD PROFILES��������������������������������������������������������������������������������������������������������������������������61
8�- TECHNICAL FEATURES ��������������������������������������������������������������������������������������������������������������������������������63
9�- MAINTENANCE AND TECHNICAL SERVICE������������������������������������������������������������������������������������������������ 67
10�- GUARANTEE�������������������������������������������������������������������������������������������������������������������������������������������������67
11�- CE CERTIFICATE ������������������������������������������������������������������������������������������������������������������������������������������68
5
Instruction Manual
CirCAMP-4DP, CirCAMP-2IP

REVISION LOG
Table 1: Revision log�
Date Revision Description
07/16 M097B01-03-15A Initial Version
02/17 M097B01-03-16A
Changes in the following sections:
2. - 3.3.2. - 3.4.2. - 3.5. - 4. - 4.3.2. - 4.4. - 4.3.2. - 4.4.-
4.5. - 4.6.2. - 5.1.2. - 5.2.2. - 7.4.2. - 7.4.5.6. - 7.4.14. -
7.4.15. - 7.4.16. - 7.4.17. - 7.4.18.1. - 7.4.19. - 8
Note: The images of the devices are for illustrative purposes only and may differ from the orig-
inal device.
6
CirCAMP-4DP, CirCAMP-2IP
Instruction Manual

1�- VERIFICATION UPON RECEPTION
Check the following points when you receive the device:
a) The device meets the specications described in your order.
b) The device has not suffered any damage during transport.
c) Perform an external visual inspection of the device prior to switching it on.
d) Check that it has been delivered with the following:
- An installation guide.
If any problem is noticed upon reception, immediately contact the transport
company and/or CIRCUTOR's after-sales service.
2�- PRODUCT DESCRIPTION
CirCAMP-xxP units are a range of multichannel compact energy meters, with additional inputs
for metering the impulses of other devices, such as water and gas meters.
The system consists of two models:
El CirCAMP-4DP is a static energy meter that can manage 4 single-phase measurements
independently, all sharing the same neutral terminal.
El CirCAMP-2IP is a static energy meter that can manage 2 three-phase measurements,
indirectly /5A and independently in current, all sharing the same voltage.
Active energy is measured in compliance with Class B, according to European Directive
22/2004 EC.
The device features:
- 2 keys that allow you to browse the different screens and program the device.
- Indicator LEDs: 13 CirCAMP-4DP model y 7 CirCAMP-2IP model.
- Verication LEDs: 4 CirCAMP-4DP model y 2 CirCAMP-2IP model.
- LCD display, displays all parameters,
- 2 connection seals,
- 2 terminal covers, to cover the measuring terminals of the device and the xing screws.
7
Instruction Manual
CirCAMP-4DP, CirCAMP-2IP

- Communications via an optical port.
- RS-485 communications (according to version).
- PLC OFDM communications.
The CirCAMP-xxP is offered in different versions, Table 2 shows all of the possible options of
the device.
Table 2: CirCAMP-xxP options�
Options CirCAMP-4DP Code
Connection mode 4 single-phase measurements with shared neutral 1
Accuracy Class B active / Does not measure reactive energy 10
Measurement voltage 230 V E
Current measurement system Transformer D
Current measurement 5(32) A 7
Frequency
50 Hz A
60 Hz B
Automatic (50/60Hz) C
Communications PLC OFDM / RS-485 8
PLC OFDM B
Expansion 4 potential free outputs / 4 inputs 3
Model Pre-payment P
Number of quadrants Storage in both directions 2
Additional features With circuit breaker on the phase lines 2
Options CirCAMP-2IP Code
Connection mode 2 three-phase measurements with common volt-
ages 6
Accuracy Class B active / Does not measure reactive energy 10
Measurement voltage
3 x 127/220 V N
3 x 230/400 V Q
3 x 127/220 V ... 3 x 230/400 V U
Current measurement system Transformer T
Current measurement 5(10) A 8
Frequency
50 Hz A
60 Hz B
Automatic (50/60Hz) C
Communications PLC OFDM / RS-485 8
PLC OFDM B
Expansion 4 potential free outputs / 4 inputs 3
Model Pre-payment P
Number of quadrants Storage in both directions 2
Additional features No additional features 0
8
CirCAMP-4DP, CirCAMP-2IP
Instruction Manual

3�- DEVICE INSTALLATION
3.1.- PRELIMINARY RECOMMENDATIONS
In order to use the device safely, it is critical that individuals who handle it follow
the safety measures set out in the standards of the country where it is being used,
use the personal protective equipment necessary, and pay attention to the vari-
ous warnings indicated in this instruction manual.
The CirCAMP-xxP device must be installed by authorised and qualied staff.
The power supply plug must be disconnected and measuring systems switched off before
handling, altering the connections or replacing the device. It is dangerous to handle the device
while it is powered.
Also, it is critical to keep the cables in perfect condition to avoid accidents, personal injury and
damage to installations.
The manufacturer of the device is not responsible for any damage resulting from failure by the
user or installer to heed the warnings and/or recommendations set out in this manual, nor for
damage resulting from the use of products or accessories that did not come with the device or
that were made by other manufacturers.
If an anomaly or malfunction is detected in the device, do not use the device to take any meas-
urements.
Inspect the work area before taking any measurements. Do not take measurements in danger-
ous areas or where there is a risk of explosion.
Disconnect the device from the power supply (device and measuring system
power supply) before maintaining, repairing or handling the device's connections.
Please contact the after-sales service if you suspect that there is an operational
fault in the device.
9
Instruction Manual
CirCAMP-4DP, CirCAMP-2IP

3.2.- INSTALLATION
On the side of the device are all of the indications adjusted to the CEI 62052-11 standard.
The device is installed on a DIN rail. All connections are located inside the electric panel.
Terminals, opening roofs or removing elements can expose parts that are haz-
ardous to the touch while the device is powered. Do not use the device until it is
fully installed.
3.3.- DEVICE TERMINALS
3�3�1�- CirCAMP-4DP MODEL
Table 3:List of CirCAMP-4DP terminals
Device terminals
1 : Input channel 1 25,26 : Channel 3 relay output
3 : Output channel 1 27,28 : Channel 4 relay output
4 : Input channel 2 / Power supply 31 : Impulse input common
6 : Output channel 2 32 : Channel 1 impulse input
7 : Input channel 3 33 : Channel 2 impulse input
9 : Output channel 3 34 : Channel 3 impulse input
10: Input channel 4 35 : Channel 4 impulse input
11 : Neutral connection 36,37 : Reclose input
12 : Output channel 4 38 : B, RS-485 communications (according to version)
21,22 : Channel 1 relay output 39 : S, RS-485 communications (according to version)
23,24 : Channel 2 relay output 40 : A, RS-485 communications (according to version)
1 3 4 6 11
7910 12 31 32 33 34 35 36 37 38 39 40
21 22 23 24 25 26 27 28
Figure 1:CirCAMP-4DP terminals�
10
CirCAMP-4DP, CirCAMP-2IP
Instruction Manual
Ce manuel convient aux modèles suivants
1
Table des matières
Autres manuels Circutor Multimètre
Manuels Multimètre populaires d'autres marques

Gossen MetraWatt
Gossen MetraWatt METRAmax 6 Manuel utilisateur

PeakTech
PeakTech 4000 Manuel d'utilisation et d'entretien

YOKOGAWA
YOKOGAWA 90050B Manuel utilisateur

Gossen MetraWatt
Gossen MetraWatt METRALINE DMM16 Manuel utilisateur

Fluke
Fluke 8846A Manuel d'utilisation et d'entretien

Tempo Communications
Tempo Communications MM200 Manuel utilisateur
