Cine Gears Esprocker Manuel de l'opérateur

The Quick Instruction of Cinegears

Esprocker Digital Wireless Controller

V1.0

Esprocker Controller

And

Different Perspective Views

Turn On/O Esprocker Controller

Automatic Lens Calibration

Hold the (REC) and (A) button for three seconds.

Manuel Lens Calibration

Hold the (REC) and (B) button for three seconds. Press the (A) button to rotate the

lens clockwise, then press the (A) button again to stop the rotation and press the

(REC) button to set the start point. Press the (B) button to rotate counter clockwise

and press the (B) button again to stop the rotation, then press the (REC) button

to choose the end point.

Setting up Two Preset points

Push the rocker swtich button on your esprocker controller to a lens focus distance

point, then press and hold the (A) button for three seconds to record that point.

Then move on to the next lens focus distance point, press and hold the (B) button

for three seconds to record your second lens focus distance point.

Setting up Preset

Hold the (A) and (B) button for three seconds to get the accessibility to the esprocker

function manual. F01 is the motor rotating speed option. F03 is the manual lens

calibration option. F05 is the recalibrating focus controller option. F06 is the

direction display option.

7 Recalibrating Focus Controller

After you get to your esprocker function manual, go to the F05 function. Push the

rocker swtich button to the left end point then press the (REC) button. Push the

rocker swtich button again to the right end point then press the (REC) button

again. This sets up your full camera lens traveling distance with your esprocker’s

rocker swtich button distance from left to right that you have set.

Esprocker

Hold the (REC) button for three seconds to turn the esprocker controller on/o.

Synchronize Esprocker Controller and Motor

Hold the button on the motor for three seconds then hold all three buttons on the

esprocker controller for three seconds.

CINEGEARS Esprocker Digital Wireless Rocker Switch

Controller KIT User Manual

V1.0

Specifications

Esprocker Controller

It is the smallest wireless solution for solo camera operation. The unit sports

an REC trigger, a small LED screen, a focus switch, and the ability to store up to

two focus presets.

With our latest Wireless Esprocker Controller, you can deliver a reliable signal

from up to 100 meters away. It allows users to control lens focus and camera REC

start/stop from nger tip, making it perfect for jib, Steadicam, or MoVI shots.

The build in Panasonic rechargeable batter provides up to 8 working hours power.

15 digital speed mood for smooth transition from 2 focus preset.

You won’t nd anything more compact or functional.

Pick up this ultra durable unit from the store.

Introduction

- Small, Light, Rocker Switch

- LED screen to show focus depth

- Set up to two focus presets

- Remote REC trigger

- 100 Meter Wireless Control Range

- Mountable Side Bracket

- Adjustable Rocker Switch

- USB Charger 8 Hour Internal Battery

- Compact design

Esprocker Full Instruction

1. Turn On/Off Esprocker Controller

2. Synchronize Esprocker Controller and Motor

3. Automatic Lens Calibration

4. Manual Lens Calibration

Hold the (REC) button on your esprocker controller for three seconds to turn

it on. When your esprocker controller is on, hold the (REC) button for three

seconds to turn it off. The number that shows up on your esprocker controller

when you turn it on is the esprocker controller’s battery percentage.

Hold the button on your motor that flashes blue for three seconds, when the

button’s light turns green, press and hold all three buttons, (REC), (A) and (B) on

your esprocker controller for three seconds. In this way, it synchronizes both the

esprocker controller and motor together.

Hold the (REC) button for three seconds to turn the esprocker controller on/off.

Hold the button on the motor for three seconds then hold all three buttons on

the esprocker controller for three seconds.

Hold the (REC) and (A) button for three seconds.

After your esprocker controller and motor are synchronized, press and hold

(REC) and (A) button on your esprocker controller at the same time for three

seconds, this activates the automatic lens calibration. This option is for the

camera lens that has the hard stops. For the camera lens that does not have

the hard stops, read the following manual lens calibration below.

Hold the (REC) and (B) button for three seconds. Press the (A) button to rotate

the lens clockwise, then press the (A) button again to stop the rotation and press

the (REC) button to set the start point. Press the (B) button to rotate counter

clockwise and press the (B) button again to stop the rotation, then press the

(REC) button to choose the end point.

After your esprocker controller and motor are synchronized, press and hold

the (REC) and (B) button on your esprocker controller at the same time for three

seconds until S-1 flashes. Then press and hold the (A) button for three seconds

until the gear rotates. When your camera lens reaches the minimum focus

distance, press on the (A) button again which makes the gear stop rotating.

Then press the (REC) button to set your camera minimum focus distance

point. After you set the minimum focus distance point, S-2 should be flashing.

Then press and hold the (B) button for three seconds, the gear will rotate to the

opposite direction. When it reaches your camera’s maximum focus distance point,

you have to press the (B) button again to stop the rotation of the gear. Then

press the (REC) button to set the camera’s maximum focus distance. Remember,

you can always press on the (A) button or the (B) button for the micro adjustments

when it passes the camera’s focus distance.

Setting up Two Preset points

Push the rocker switch on your esprocker controller to a lens focus distance

point, then press and hold the (A) button for three seconds to record that point.

Then move on to the next lens focus distance point, press and hold the (B)

button for three seconds to record your second lens focus distance point.

Setting up Preset

Hold the (A) and (B) button for three seconds to get the accessibility to the

esprocker function manual. F01 is the motor rotating speed option. F03 is the

manual lens calibration option. F05 is the recalibrating focus controller option.

F06 is the direction display option.

7 Recalibrating Focus Controller

First, go to your esprocker function manual by pressing and holding the (A) and

(B) button for three seconds at the same time. Then, go to the F05 function by

pressing the (B) button for four times and press the (REC) button to enter that

function. Push the rocker switch button to the left end point and press the (REC)

button to record that rotation angle. Then, push the rocker switch button again to

the right end, and press the (REC) button again to record your second rotation

angle. This sets up your full camera lens traveling distance to the rocker switch

travelling distance you have set. In other words, the rotating distance of your

camera lens will lengthen while the distance of the esprocker rocker switch button

will shorten.

When you press and hold the (A) and (B) button on your esprocker controller for

three seconds, this gives you the accessibility to your esprocker controller’s

function manual. To enter each function you can just simply press the (REC)

button. The F01 function is the speed control which makes the gear rotate on a

different range of speed. Press on the (A) or (B) button to change the number,

the larger the number goes, the faster the gear rotates. After you choose a speed

number, press the (REC) button again to let your espresso controller to record

that number.

After you get to your esprocker function manual, go to the F05 function. Push

the rocker switch button to the left end then press the (REC) button. Push the

rocker switch button again to the right end then press the (REC) button again.

Disclaimers

Congratulations on purchasing your new CINEGEARS product. Please read this manual carefully

before using the product. By using this product, you hereby agree to this disclaimer and signify that

you have read it in full. You agree that you are responsible for your own conduct and any content

created while using CINEGEARS products, and for any consequence thereof. You agree to use

this product only for purposes that are proper and in accordance with local regulations, terms and

any applicable polices and guidelines.

By reading this disclaimer, you also agree:

1, Any part of this disclaimer is subject to change without prior notice. Refer to

WWW.CINGEARS.COM for the latest version.

2, CINEGEARS reserves the right of final interpretation of this disclaimer.

CINEGEARS and the Follow Focus Kit are registered trademarks of Llittlecent International

Trading Corp. as names of product, brand, etc., appearing in this manual are trademarks or

registered trademarks of their respective owner companies. This product and manual are

reproduced in any form without the prior written consent or authorization of CINEGEARS.

ONLINE SUPPORT

CINEGEARS

Please CINEGEARS.COM to check the latest version

http://cinegears.com/?page_id=1084

Cinegears is an industry leading company that designs and manufactures digital wireless follow

focus systems, lens control systems, camera motion control systems and accessories for film and

broadcast industry. As a big believer in the power of creativity and ideas, we designed the wireless

motor drive that integrated a built in wireless transmitter, and the wireless finger wheel controller.

The Cinegears wireless lens control system has international CE certification on all its equipment.

CINEGEARS lens control system can achieve the finest minutia of focus pulling, with extreme

accuracy and control. It provides smooth focus control for shooting 4k footage at an affordable price.

We have been doing this for three years and our equipment has been used on hundreds of movies.

Filmmakers of all experience levels will benefit greatly from a simple, professional, and well rounded

follow focus system. The Single Axis, and Multi Axis models provide greater ease, with less crew,

and less wires. You can achieve professional film quality scenes on a shoestring budget. Camera

operators, assistant camera operators, and jib operators can use the wireless follow focus to attain

that perfect shot.
