Manual 0-5228 1 Spool Cover Assembly Instruction

SPOOL COVER ASSEMBLY ( W4016300 ) INSTRUCTIONS

CIGWELD Pty. Ltd

71 Gower Street

Preston, Victoria, Australia, 3072

Telephone: +61 3 9474 7400, +61 3 9474 7391

www.cigweld.com.au

Manual 0-5228

Revision No.: AA

Issue Date: September 14, 2012

Spool Cover for VAF4, VAF4HD

and WeldSkill 4R Wirefeeders

Part Number: W4016300

Assembly Instructions

General Information

The Cigweld spool cover is designed to be used together with VAF4, VAF4 HD and WeldSkill 4R Wirefeeders. These

instructions will guide you through the proper assembly procedure of the spool cover.

Supplied Parts (For Transmig VAF4 and VAF4 HD Wirefeeders)

The following components are included in this kit:

Item Description Quantity

1 Bolt, M12 x 30 2

2 Star Washer, M12 2

3 Flat Washer, M12 2

4 Screw, Countersunk, M5 x 12 2

5 Spool Cover Mounting Bracket 1

6 Spool Cover 1

7 Spool Cover Mounting Bracket 1

Table 1 Spool Cover Assembly

Art # A-11347

Figure 1 Spool Cover Assembly (For Transmig VAF4 and VAF4 HD Wirefeeders)

Spool Cover Assembly Instruction 2 Manual 0-5228

SPOOL COVER ASSEMBLY (W4016300) INSTRUCTIONS

WARNING

Disconnect input power to the power source before installing or removing this control.

SAFETY INSTRUCTIONS AND WARNINGS

WARNING

PROTECT YOURSELF AND OTHERS FROM POSSIBLE SERIOUS INJURY OR DEATH. KEEP CHILDREN

AWAY. PACEMAKER WEARERS KEEP AWAY UNTIL CONSULTING YOUR DOCTOR. DO NOT LOSE THESE

INSTRUCTIONS. READ OPERATING/INSTRUCTION MANUAL BEFORE INSTALLING, OPERATING OR

SERVICING THIS EQUIPMENT.

Welding products and welding processes can cause serious injury or death, or damage to other equipment or

property, if the operator does not strictly observe all safety rules and take precautionary actions.

Safe practices have developed from past experience in the use of welding and cutting. These practices must be

learned through study and training before using this equipment. Some of these practices apply to equipment

connected to power lines; other practices apply to engine driven equipment. Anyone not having extensive

training in welding and cutting practices should not attempt to weld.

Safe practices are outlined in the Australian Standard AS1674.2-2007 entitled: Safety in welding and allied

processes Part 2: Electrical. This publication and other guides to what you should learn before operating

this equipment are listed at the end of these safety precautions. HAVE ALL INSTALLATION, OPERATION,

MAINTENANCE, AND REPAIR WORK PERFORMED ONLY BY QUALIFIED PEOPLE.

WARNING

ELECTRIC SHOCK can kill.

Touching live electrical parts can cause fatal shocks or severe burns. The electrode and work circuit

is electrically live whenever the output is on. The input power circuit and machine internal circuits

are also live when power is on. In semiautomatic or automatic wire welding, the wire, wire reel,

drive roll housing, and all metal parts touching the welding wire are electrically live. Incorrectly

installed or improperly grounded equipment is a hazard.

1. Do not touch live electrical parts.

2. Wear dry, hole-free insulating gloves and body protection.

3. Insulate yourself from work and ground using dry insulating mats or covers.

4. Disconnect input power or stop engine before installing or servicing this equipment. Lock input power

disconnect switch open, or remove line fuses so power cannot be turned on accidentally.

5. Properly install and ground this equipment according to its Owner’s Manual and national, state, and local

codes.

6. Turn off all equipment when not in use. Disconnect power to equipment if it will be left unattended or out of

service.

7. Use fully insulated electrode holders. Never dip holder in water to cool it or lay it down on the ground or the

work surface. Do not touch holders connected to two welding machines at the same time or touch other

people with the holder or electrode.

8. Do not use worn, damaged, undersized, or poorly spliced cables.

9. Do not wrap cables around your body.

Manual 0-5228 3 Spool Cover Assembly Instruction

SPOOL COVER ASSEMBLY ( W4016300 ) INSTRUCTIONS

10.Ground the workpiece to a good electrical (earth) ground.

11.Do not touch electrode while in contact with the work (ground) circuit.

12.Use only well-maintained equipment. Repair or replace damaged parts at once.

13.In conﬁned spaces or damp locations, do not use a welder with AC output unless it is equipped with a volt-

age reducer. Use equipment with DC output.

14.Wear a safety harness to prevent falling if working above ﬂoor level.

15.Keep all panels and covers securely in place.

WARNING

ARC RAYS can burn eyes and skin; NOISE can damage hearing.

Arc rays from the welding process produce intense heat and strong ultraviolet rays that can burn

eyes and skin. Noise from some processes can damage hearing.

1. Use a Welding Helmet or Welding Faceshield ﬁtted with a proper shade of ﬁlter (see ANSI Z49.1 and AS 1674

listed in Safety Standards) to protect your face and eyes when welding or watching.

2. Wear approved safety glasses. Side shields recommended.

3. Use protective screens or barriers to protect others from ﬂash and glare; warn others not to watch the arc.

4. Wear protective clothing made from durable, ﬂame-resistant material (wool and leather) and foot protec-

tion.

5. Use approved ear plugs or ear muffs if noise level is high.

6. Never wear contact lenses while welding.

WARNING

FUMES AND GASES can be hazardous to your health.

Welding produces fumes and gases. Breathing these fumes and gases can be hazardous to your

health.

1. Keep your head out of the fumes. Do not breathe the fumes.

2. If inside, ventilate the area and/or use exhaust at the arc to remove welding fumes and gases.

3. If ventilation is poor, use an approved air-supplied respirator.

4. Read the Material Safety Data Sheets (MSDSs) and the manufacturer’s instruction for metals, consumables,

coatings, and cleaners.

5. Work in a conﬁned space only if it is well ventilated, or while wearing an air-supplied respirator. Shielding

gases used for welding can displace air causing injury or death. Be sure the breathing air is safe.

6. Do not weld in locations near degreasing, cleaning, or spraying operations. The heat and rays of the arc can

react with vapours to form highly toxic and irritating gases.

7. Do not weld on coated metals, such as galvanized, lead, or cadmium plated steel, unless the coating is

removed from the weld area, the area is well ventilated, and if necessary, while wearing an air-supplied

respirator. The coatings and any metals containing these elements can give off toxic fumes if welded.

Spool Cover Assembly Instruction 4 Manual 0-5228

SPOOL COVER ASSEMBLY (W4016300) INSTRUCTIONS

WARNING

WELDING can cause ﬁre or explosion.

Sparks and spatter ﬂy off from the welding arc. The ﬂying sparks and hot metal, weld spatter, hot

workpiece, and hot equipment can cause ﬁres and burns. Accidental contact of electrode or welding

wire to metal objects can cause sparks, overheating, or ﬁre.

1. Protect yourself and others from ﬂying sparks and hot metal.

2. Do not weld where ﬂying sparks can strike ﬂammable material.

3. Remove all ﬂammables within 35 ft (10.7 m) of the welding arc. If this is not possible, tightly cover them

with approved covers.

4. Be alert that welding sparks and hot materials from welding can easily go through small cracks and open-

ings to adjacent areas.

5. Watch for ﬁre, and keep a ﬁre extinguisher nearby.

6. Be aware that welding on a ceiling, ﬂoor, bulkhead, or partition can cause ﬁre on the hidden side.

7. Do not weld on closed containers such as tanks or drums.

8. Connect work cable to the work as close to the welding area as practical to prevent welding current from

travelling long, possibly unknown paths and causing electric shock and ﬁre hazards.

9. Do not use welder to thaw frozen pipes.

10.Remove stick electrode from holder or cut off welding wire at contact tip when not in use.

WARNING

FLYING SPARKS AND HOT METAL can cause injury.

Chipping and grinding cause ﬂying metal. As welds cool, they can throw off slag.

1. Wear approved face shield or safety goggles. Side shields recommended.

2. Wear proper body protection to protect skin.

WARNING

CYLINDERS can explode if damaged.

Shielding gas cylinders contain gas under high pressure. If damaged, a cylinder can explode. Since

gas cylinders are normally part of the welding process, be sure to treat them carefully.

1. Protect compressed gas cylinders from excessive heat, mechanical shocks, and arcs.

2. Install and secure cylinders in an upright position by chaining them to a stationary support or equipment

cylinder rack to prevent falling or tipping.

3. Keep cylinders away from any welding or other electrical circuits.

4. Never allow a welding electrode to touch any cylinder.

5. Use only correct shielding gas cylinders, regulators, hoses, and ﬁttings designed for the speciﬁc

application; maintain them and associated parts in good condition.

6. Turn face away from valve outlet when opening cylinder valve.

7. Keep protective cap in place over valve except when cylinder is in use or connected for use.

8. Read and follow instructions on compressed gas cylinders, associated equipment, and CGA publication P-1

listed in Safety Standards.

Manual 0-5228 5 Spool Cover Assembly Instruction

SPOOL COVER ASSEMBLY ( W4016300 ) INSTRUCTIONS

WARNING

MOVING PARTS can cause injury.

Moving parts, such as fans, rotors, and belts can cut ﬁngers and hands and catch loose clothing.

1. Keep all doors, panels, covers, and guards closed and securely in place.

2. Stop engine before installing or connecting unit.

3. Have only qualiﬁed people remove guards or covers for maintenance and troubleshooting as necessary.

4. To prevent accidental starting during servicing, disconnect negative (-) battery cable from battery.

5. Keep hands, hair, loose clothing, and tools away from moving parts.

6. Reinstall panels or guards and close doors when servicing is ﬁnished and before starting engine.

WARNING

This product, when used for welding or cutting, produces fumes or gases which contain chemicals

know to the State of California to cause birth defects and, in some cases, cancer. (California Health

& Safety code Sec. 25249.5 et seq.)

NOTE

Considerations About Welding And The Effects of Low Frequency Electric and Magnetic Fields

The following is a quotation from the General Conclusions Section of the U.S. Congress, Ofﬁce of Technology

Assessment, Biological Effects of Power

Frequency Electric & Magnetic Fields - Background Paper, OTA-BP-E-63 (Washington, DC: U.S. Government

Printing Ofﬁce, May 1989): “...there is now a very large volume of scientiﬁc ﬁndings based on experiments at

the cellular level and from studies with animals and people which clearly establish that low frequency magnetic

ﬁelds and interact with, and produce changes in, biological systems. While most of this work is of very high

quality, the results are complex. Current scientiﬁc understanding does not yet allow us to interpret the evi-

dence in a single coherent framework. Even more frustrating, it does not yet allow us to draw deﬁnite conclu-

sions about questions of possible risk or to offer clear science-based advice on strategies to minimize or avoid

potential risks.”

To reduce magnetic ﬁelds in the workplace, use the following procedures.

1. Keep cables close together by twisting or taping them.

2. Arrange cables to one side and away from the operator.

3. Do not coil or drape cable around the body.

4. Keep welding power source and cables as far away from body as practical.

ABOUT PACEMAKERS:

The above procedures are among those also normally recommended for pacemaker wearers. Con-

sult your doctor for complete information.

Spool Cover Assembly Instruction 6 Manual 0-5228

SPOOL COVER ASSEMBLY (W4016300) INSTRUCTIONS

Recommended Protective Filters for Electric Welding

Description of Process Approximate Range of

Welding Current in Amps

Minimum Shade Number of

Filter(s)

Manual Metal Arc Welding - covered

electrodes (MMAW)

Less than or equal to 100 8

100 to 200 10

200 to 300 11

300 to 400 12

Greater than 400 13

Gas Metal Arc Welding (GWAW)

(MIG) other than Aluminium and

Stainless Steel

Less than or equal to 150 10

150 to 250 11

250 to 300 12

300 to 400 13

Greater than 400 14

Gas Metal Arc Welding (GMAW)

(MIG) Aluminium and Stainless Steel

Less than or equal to 250 12

250 to 350 13

Gas Tungsten Arc Welding (GTAW)

(TIG)

Less than or equal to 100 10

100 to 200 11

200 to 250 12

250 to 350 13

Greater than 350 14

Flux-cored Arc Welding (FCAW) -with

or without shielding gas.

Less than or equal to 300 11

300 to 400 12

400 to 500 13

Greater than 500 14

Air - Arc Gouging Less than or equal to 400 12

Plasma - Arc Cutting

50 to 100 10

100 to 400 12

400 to 800 14

Plasma - Arc Spraying —15

Plasma - Arc Welding

Less than or equal to 20 8

20 to 100 10

100 to 400 12

400 to 800 14

Submerged - Arc Welding —2(5)

Resistance Welding —Safety Spectacles or eye

shield

Refer to standard AS/NZS 1338.1:1992 for comprehensive information regarding the above table

Manual 0-5228 7 Spool Cover Assembly Instruction

SPOOL COVER ASSEMBLY ( W4016300 ) INSTRUCTIONS

Assembly Procedure For Transmig VAF4 and VAF4 HD Wirefeeders

Spool cover is assembled in the following steps:

1. Remove the spool hub assembly.

a. Remove the clip from the spool hub.

b. Unscrew the 3-lobe screw.

c. Remove the spool hub parts and the spacer in the following sequence. Note that the spacer is not

required when ﬁtting the spool cover.

Hexagon Nut

Spring Washer

Flat Washer,large hole

Spacer

Shaft

Friction Washer

Hub Wire Reel

Keyed Washer

Compression Spring

Flat Washer, small hole

3-lobe Screw

Retaining Clip

Art # A-11514

Figure 2 Removing Spool Hub Assembly (For Transmig VAF4 and VAF4 HD Wirefeeders)

2. Assemble the Spool Cover Mounting Brackets, one inside and one outside the spool cover, with the two

countersunk screws M5 x 12.

3. Secure the spool cover assembly to the spool support arm with M12 x 30 Bolts, Star Washers, M12, and

Flat Washers, M12 as shown in the diagram below.

Art # A-11344

Spool Cover Mounting Brackets

Spool Cover

Countersunk Screws,

M5×12

Hub Wire Reel

Keyed Washer

Compression Spring

Flat Washer, small hole

3-lobe Screw

Retaining Clip

Friction Washer

M12 x 30 Bolts;

Star Washers, M12;

Flat Washers, M12

Figure 3 Installing Spool Cover (For Transmig VAF4 and VAF4 HD Wirefeeders)

Spool Cover Assembly Instruction 8 Manual 0-5228

SPOOL COVER ASSEMBLY (W4016300) INSTRUCTIONS

3. Install the spool hub component parts over the spool hub shaft in the following sequence.

Friction Washer

Spool Hub

Keyed Washer

Spring

Flat Washer

3-lobe Screw

Retaining Clip

Art # A-11349

Figure 4 Spool Hub Assembly (For Transmig VAF4 and VAF4 HD Wirefeeders)

WARNING

Fully tighten all fasteners.

Manual 0-5228 9 Spool Cover Assembly Instruction

SPOOL COVER ASSEMBLY ( W4016300 ) INSTRUCTIONS

Refer to the ﬁgures below for the assembled spool cover:

Art # A-11356

Figure 5a Assembled Spool Cover (door opened) (For Transmig VAF4 and VAF4 HD Wirefeeders)

Art # A-11348

Figure 5b Assembled Spool Cover (For Transmig VAF4 and VAF4 HD Wirefeeders)

Spool Cover Assembly Instruction 10 Manual 0-5228

SPOOL COVER ASSEMBLY (W4016300) INSTRUCTIONS

Assembly Procedure For WeldSkill 4R Wirefeeder

1. Remove the spool hub assembly in the sequence as shown in the ﬁgure below (except for the spool hub

base).

Spool Hub Nut

Bolt

Flat Washer

Flange

Spool Hub

Art # A-11515

Spool Hub Base

Spool Cover

Fibre Washer

Spring

Figure 6 Removing Spool Hub Assembly (For WeldSkill 4R Wirefeeders)

2. Remove the spool hub base and the spool cover by loosening the M8 bolt.

M8 Bolt

Art # A-11516

Spool Hub Base

M8 Fasteners

Figure 7 Removing M8 Fasteners (For WeldSkill 4R Wirefeeders)

3. Fit the new spool cover and spool hub base using the M8 fasteners. (Please refer to Figure 7)
