CHROMATEQ TOUCH 512 Manuel utilisateur



TOUCH

512/1024



WallmountedDMXLightingController



Datasheet&

QuickstartGuide



CongratulationsonyourpurchaseofaCHROMATEQcontroller.



PleasereadthismanualcarefullyandthoroughlybeforeusingtheTOUCHChromateq.



Theinformationpresentedhereprovidesausefulintroductiontothewiderangeoffeatures,settingsandfunctionsavailableinthis

compactandversatileTOUCH



TheTOUCHTechnicalManualiswritteninEnglishandFrench.

(LemanueltechniqueduTOUCHestrédigéenanglaisetenfrançais.)



AllproductsandsoftwarearedevelopedanddesignedinFrance.



CHROMATEQSARL

191AlléedeLauzard34980StGélyduFescFRANCEVAT:FR18521458034Siret:52145803400027Web&E-mail:

www.chromateq.comPhone:+33952210755/+8613422062209Whatsapp:+8613422062209Wechat:ChromateqQQ:

2908265661



Twitter:https://twitter.com/Chromateq

Facebook:https://www.facebook.com/ChromateqCompany/

YouTube:https://www.youtube.com/c/chromateq



----------------------



CopyrightInformationandDisclaimer

Copyright©2021-CHROMATEQ.Allrightsreserved.

Nopartofthispublicationmaybereproduced,distributedortransmittedinanyformorbyanymeanswhatsoever,including

photocopying,recordingorotherelectronicormechanicalmethods,withoutthepriorwrittenpermissionofthepublisher,exceptin

thecaseofbriefquotationsincriticismsandcertainothernon-commercialusespermittedbycopyrightlaw.



Foranyrequestforauthorization,writetothepublisherattheaddressabove.



Trademarkcredits

MicrosoftandWindowsareU.S.registeredtrademarksofMicrosoftCorporations.Art-NetTM-DesignedbyandCopyrightArtistic

LicenseHoldingsLtd.Allotherproductsmentionedhereinmaybetrademarksoftheirrespective®companies.



PackageContents

1xTOUCH

1xUSBcable

1xPowersupply9-12VDC-Optional(Euro/USsocket)

1xsoftwaredownloadlinkandtechnicaldocumentation



 2

TechnicalManual&QuickStartGuide

Caution:Checkthecontentsofthepackageandtheconditionoftheinterfaceafterunpacking!Contactyoursupplierifsomething

ismissingorisdamaged.Donotusethedeviceifitappearstobedamaged!


Tabledesmatières
Introduction  5
Technical  5
Devicefeatures  5
Softwareoption  6
Connectorsandoperationpanel  7
Rearpanel&  7
Operationpanel  8
USBdriversinstallation  9
MultipleUSBconnections  9
Standalonemodesettings  10
Deviceconﬁguration  10
IN/OUTtab  10
"MergeDMXIn/DMXOut"option  11
Art-Net/sACNuniverserange:  11
Clocktab  12
Optionstab  12
Master/Slavetab 13
Master/Slavemode"bydefault"  14
Commandstab  15
Zonestab  15
Conﬁguringthestandalonemodesofthedevice  16
Scenesselectionandconﬁguration  18
Choiceoftriggers  18
Triggersbybuttonsinthe"Device"tab  18
ExternalcontactsTrigger:  19
TriggersbyDMX-IN  20
Timetriggers  21
Singletrigger  21
Permanenttrigger  21
Lightintensitytrigger  22
Priorityofhourlytrigger  22
Advancedtriggeroptions.  22
Restoreafterpoweroff  23
Playinpriority  23
Saveinmemoryoption  23
Basicbackup  24
SavetoaninternalandexternalmicroSDcard  24
BackingupArt-NetorsACNtoanexternalSDcard  24
Standaloneuse  25
Switchtostandalonemode  25
ExternalandUSBpowersupply  25
Chargingtheclockbattery  25
 3



PlayashowviaaMicroSDCard 25

Dimensionsandmounting 27

Troubleshooting 28



 4



Introduction



Thistouchpaneliscompatiblewithallthemanufacturer’ssoftware,itcanbeintegratedinto

scalablecontrolsystemsdesignedforﬁxedindoorinstallations,ordeployedindividuallywithouta

computerasastandalone,elegant,simplebutsophisticatedcontrolsolution.

TheSDcardofferstheabilitytoexpandmemorycapacity,DMXsplittermodeenhancesthe

reliabilityofDMXnetworks.



Objectives

Thepurposeofthistechnicalmanualistodeveloptheoptionsmanagedbythedevicein

standalonemode,forsoftwareoptions,pleaserefertothesoftwaremanuals.



Technicalfeatures



Connectors

USB-C,ScrewterminalandRJ45(Externalcontact,

Master/Slave,Infrared,LightSensor)

DMXlines

2x512channels8and16-bitDMXchannels

Internalmemory

yes,4MB(noSDcardrequired)

Internalmemorycapacity

20000stepswith16hp.,6000stepswith512hp.,3000

stepswith1024hp.

Externalmemory

MicroSDcard(acceptsFAT,FAT32,Class10SDcardupto

256GB)

CPU

32-bitprocessor

Powersupply

5Vto24VDC,0.2A/5VviaUSB-C

Power/Consumption

0.3~0.5W

IPrating

IP40

Dimensions(mm)

H:144(5.67in)/L:97(3.82in)/l:10(0.39in)

Netweight(device)

0.2Kgs(0.44lbs)

Grossweight(fullcost)

0.3Kgs(0.66lbs)

Highvoltageprotection

Yes,fusesanddiodes

Case

ABSglasspanel

Environmentofuse

Interior

Storage

Storedry

Temperatureofuse

-40to+85C°

Certiﬁcations

CE,RoHS

Internationalguarantee

Yes,5years

Compatibilityofsystems

Windows(7andhigher),MACOSX(10.13andhigher)and

Linux(64Bits,Debian,Redhat,Archlinux,RaspberryPi)



Devicefeatures

 5



DMX512mode

2x512output(Splitter,PC+Autonomous)or512outputand

512ininput(PConly,DMXrecording,DMXtrigger,DMX

merge)

DMX1024

2x512output,1024inoutputor512outputand512ininput

(PCandstandalonemode,DMXrecording,DMXtrigger,

DMXmerge)

Multiplezones(DMX1024mode

only)

5zones,playsupto5scenessimultaneously

Combinedareas(DMX1024

modeonly)

yes

Clockinrealtime-RTC

Timeandcalendartriggering

Touchbuttons

8scenes,5zones(1024),4modes,1on/off

Touchcontrolwheel

yes(color,CTC,dimmerintensity,speed,scenes)

Externalcontacts

4(15maximum)

Master/Slavesynchro

Yes,32maxperwiring



Softwareoption



LineDMX

Art-Net

Options

SoftwarePlayer

512/1024DMXchannels

1universe(512)

2universes(1024)

LiveBoardmode

SoftwarePro

Software

512/1024DMXchannels

1universe(512)

2universes(1024)

Normalmode,

30minaudioandvideo

timelineloop

Pixelmapping

software

512/1024DMXchannels

4universes(512)

8Universe(1024)

Normalmode(512)

30min(1024)audio

andvideotimelineloop

(1024)

StudioDMX3D

viewer

Fullmode

Wi-Light2App

ControlsPlayer,ProandPixxemsoftwareoveralocalWiFinetwork

Freesoftware

updates

Yes



 6



Connectorsandoperationpanel



Rearpanel&belowpanel



Caution

TheRJ45portfunctionsarenotavailableforserialnumbersT00001toT00199.



 7



1-Rj45Pinout:

1.GND

2.5VDCOutput-Fortriggers

3-6.TRIGA,B,C,D-DryContactpins

7.M/SDATA-Master/SlaveData

8.M/SCLK-Master/SlaveClock



2-7PinTerminalblock

1.DMX1-

2.DMX1+

3.GND(DMX1+2)

4.DMX2-

5.DMX2+

6.GND(PowerInput)

7.DCPowerInput(VCC,5-24V/(0.1A)



3-USB-CConnector(5VDCinput)

4-MicroSDPort



Operationpanel



 8

1-Zoneselection(TOUCH1024)|Page

selection(TOUCH512)Taptoselect

zones/Pagesindividually.Hold2stocombine

Zones

2-Scenes#Pick1-8(8scenesperZoneor

Page)

3-TactilewheelpickeranddialAdjust

colourtemperature,intensity(+/-)orspeed

(+/-)andscenes.ColourwheelPickRGB-AW

colourfortheselectedzone(Colourmode

selected)

4-ColourtemperatureCooltowarmwhite

representationfortheselectedzone(CCT

modeselected)

5-DimmerintensityLightintensity(+/-

)Representation(Dimmermodeselected)

6-DimmermodeactivationUsethewheelto

adjustbrightnessforselectedzone(Active

for5sifnoaction)

7-ColourmodeactivationUsethewheelto

pickRGB-Amber-Whitecolour.Hold3sto

entercool/warmwhitemode

8-ScenemodeactivationUsethewheelto

startorstoptheselectedscene

9-SpeedmodeActivationUsethewheelto

changethecurrentscenespeed(Activefor

5sifnosecond)

10-On/OffTaptocancelwheelsettings

(Hold3sforblackout)



USBdriversinstallation



InstallUSBdriverstocommunicatewiththedeviceandchangesettings.

InstallationofUSBdriversisrequiredonlyforWindowsattheendofinstallation.

DriversforMacandLinuxsystemsareinstalledautomatically.



USBdriversveriﬁcation:

IntheWindowsDeviceManager.Checkthatthedeviceiconisvisiblein"USBBusControllers".



Ifdriversarenotinstalled,theWindowsDeviceManagerlistsadevicewithayellowwarning.



OnMacOS,simplychecktheUSBdevicetreetoview"DMX512StandAloneDevice".OnLinux,

usethe"lsusb"commandtoview"DMX512StandAloneDevice"asalist.



AftercontrolsoftwareinstallationandUSBdrivers

●ConnectthedevicewiththeUSBcable.

●StarttheDEVICETOOLorthesoftwareandselect"OpenUSBDevice"or"USB"tocheckthe

successofdriversinstallation.



Allconnectedanddetecteddevicesarelisted.



MultipleUSBconnections



 9



Standalonemodesettings



Instandalonemodeofthecontrolsoftware, conﬁgurethedeviceaccordingtothe

availableoptionsthenselectandconﬁgurethetriggersofscenestobewritteninmemory.



Deviceconfiguration



IN/OUTtab



SelectaDMXinput/Outputconﬁgurationofthedevicefromthedrop-downmenu



Availableconﬁgurationswillbedisplayeddependingontheconnecteddevicedependingon

whetherithas1.2or4DMXlines.



●AOUT-Assigns1outputuniverseontheDMXline(s),fordevicesthathavemorethan1

DMXlinesduplicatetheuniverseoneach.

●ABOUT-Assigns1differentoutputuniverseon2DMXlines,fordevicesthathave4DMX

linesduplicatestheﬁrst2linesonthenext2lines.

●AOUT/BorDIN-Assigns1outputuniverseontheﬁrstline(s)andusesthelastDMXline

asDMXinput.

●ABCOUT-Assigns1differentuniverseoutputontheﬁrst3DMXlines.

●ABCDOUT-Assigns1differentuniverseoutputon4DMXlines.

●ABOUT/DIN-Assigns1differentoutputuniverseontheﬁrst2linesandusesthelast

DMXlineasDMXinput.

●ABCOUT/DIN-Assigns1differentoutputuniverseontheﬁrst3linesandusesthelast

DMXlineasDMXinput.



 10
