Chroma Broadway Manuel utilisateur

Chroma-Q™

Broadway™

User Manual

Version 6.3 December 2006

PN: 101-0500 Broadway

Broadway User Manual 1 V6.3 December 2006

Disclaimer

The information contained herein is offered in good faith and is believed to be accurate.

However, because conditions and methods of use of our products are beyond our control, this

information should not be used in substitution for customer's tests to ensure that Chroma-Q

products are safe, effective, and fully satisfactory for the intended end use. Suggestions of use

shall not be taken as inducements to infringe any patent. Chroma-Q sole warranty is that the

product will meet the sales specifications in effect at the time of shipment. Your exclusive

remedy for breach of such warranty is limited to refund of purchase price or replacement of any

product shown to be other than as warranted.

Chroma-Q reserves the right to change or make alteration to devices and their functionality

without notice due to our on going research and development.

The Chroma-Q Broadway has been designed specifically for the professional entertainment

lighting industry. Regular maintenance should be performed to ensure that the products

perform well in the entertainment environment.

If you experience any difficulties with any Chroma-Q products please contact your selling

dealer. If your selling dealer is unable to help please contact support@chroma-q.com. If the

selling dealer is unable to satisfy your servicing needs, please contact the following, for full

factory service:

Outside North America: North America:

Tel: +44 (0)1494 446000 Tel: 416-255-9494

Fax: +44 (0)1494 461024 Fax: 416-255-3514

[email protected] supp[email protected]

For further information please visit the Chroma-Q website at www.chroma-q.com.

Chroma-Q is a trademark, for more information on this visit www.chroma-q.com/trademarks.

The rights and ownership of all trademarks are recognised.

Note: The current version of the Chroma-Q range uses a "digital" control card, a binary DMX

address switch and a different method of gel string calibration and fixing.

Please read this manual and the gel fitting supplement before using the product.

Broadway User Manual 2 V6.3 December 2006

Table of Contents

1. Product Overview ……………………..………………………….………............... 3

2. Operation ……………...…………………………………………………….………... 3

2.1 Control and power cables …………………………………………………… 4

2.2 Setting the DMX address ……………………………………………………. 4

2.3 PSU / splitterbox options ……………………………………………………. 5

2.4 PSU / splitterbox capacity …………………………………………………… 5

2.5 Mounting positions …………………………………………………………… 5

2.6 Using Mark I and Mark II units together …………………………………… 5

2.7 Safety wire …………………………………………………………………….. 5

2.8 F.C.C. Regulations (USA) ……………………………………………………. 5

2.9 Troubleshooting ……………………………………………………………… 6

2.10 Limited warranty ……………………………………………………………… 6

2.11 Technical specifications ……………………………………………………… 7

2.12 Product ordering ……………………………………………………………… 8

3. Table of DMX binary address settings ………………………………………..… 10

3.1 1-128 ………………….…………………………………………………….… 10

3.2 129-256 ……………………………………………………………………….. 11

3.3 257-384 ……………………………………………………………………….. 12

3.4 385-512 ……………………………………………………………………….. 13

Broadway User Manual 3 V6.3 December 2006

1. Product overview

The Chroma-Q is designed to be one of the most reliable colour changers available. The

utilisation of digital circuitry and high technology composite materials, produces an affordable

colour changer which is capable of scrolling gel strings of various lengths from 2 to 16 colours.

The Chroma-Q will read ANSI E1.11 USITT DMX 512-A protocol, which enables individual

addressing of each unit. This allows for easy grouping of multiple units. The units are

individually addressed by setting the 10 pin binary dip switch, as displayed in the panel view

below and the instructions on page 4 section 2.2.

The Chroma-Q is supplied power and control signals by means of a XLR 4-pin connector. The

XLR 4-pin output may then be used to connect other units in turn on the same line. Each chain

line must be terminated by connecting the output cable from the last unit in the chain to the

corresponding return connection on the PSU / splitterbox, as shown in the System Diagram on

page 4.

Note: For the optimum performance of a system the Chroma-Q colour changer maximum

cable length per distribution line must not exceed 60m / 200ft including the return to the PSU /

splitterbox.

The Chroma-Q is equipped with an integral cooling fan. Each unit is also equipped with three

diagnostic LED indicators (found on the underside of the unit); showing Power, DMX signal and

DMX level (see section 2.9 Troubleshooting on page 6 for full details).

2. Operation

2.1 Control and power cables

2.2 Setting the DMX address

2.3 PSU / splitterbox options

2.4 PSU / splitterbox capacity

2.5 Mounting positions

2.6 Using Mark I and Mark II units together

2.7 Safety wire

2.8 F.C.C. Regulations (USA)

2.9 Troubleshooting

2.10 Limited warranty

2.11 Technical specifications

2.12 Product ordering

For gel string dimensions, assembly, loading and calibration - see the separate leaflet enclosed

with your Chroma-Q.

Broadway User Manual 4 V6.3 December 2006

2.1 Control and power cables

The Chroma-Q utilises an XLR 4-pin cable system. This is used to supply power and data

transfer. Pins 1 and 4 supply 24VDC power; pins 2 and 3 supply ANSI E1.11 USITT DMX 512-A

control protocol with a ground drain wire to the connector shell.

Only genuine Tourflex Datasafe cable is recommended for use with the Chroma-Q colour

changing system (see Product ordering on page 8).

Damage will occur if the power connections short-circuit to the data or ground / shield

connections. When assembling XLR 4-pin cables, heat shrink sleeving should be used on each

individual data pin and the drain wire to prevent short circuits.

Note: It is very important to ensure that the drain wire from the cable shield is connected to

both connector cases.

The cables are wired pin to pin, in the following format:

Pin # Function

1 0V DC

2 Control data minus (-)

3 Control data plus (+)

4 24V DC (+ve)

Chassis Ground bonding

System Diagram

Each PSU / splitterbox can accommodate two circuits. The total cable length per circuit must

not exceed 60m / 200ft or a Voltage drop will be imposed on the system. The total quantity of

Chroma-Q Broadway units is dependent on the size of the PSU / splitterbox. (See PSU /

splitterbox capacities on page 5 or in the User Manual of each PSU / splitterbox.)

2.2 Setting the DMX address

The DMX address for each unit is set using the 10 way binary switch on the back of the unit

(see page 3). The address switches are pushed up (rotated) to the on setting. Add the address

together to reach the control address required. Example: 1 + 2 = 3, 4 + 64 + 256 = 324.

The Chroma-Q can also be set to a second motor speed. By moving switch 10 on the binary dip

switch to the on (up) position, the inherent speed of the Chroma-Q will decrease by

approximately 50% (ideal for environments that are particularly noise sensitive).

Broadway User Manual 5 V6.3 December 2006

2.3 PSU / splitterbox options

The Chroma-Q PSU / splitterboxes are available in 3 models: The Chroma-Q PS02 is suitable

for a maximum of 2 Power Units (PU), the Chroma-Q PS08 is suitable for a maximum of 8 PU

and the Chroma-Q Magic Box PS12 is suitable for a maximum of 12 PU. 1 unit of the Chroma-Q

Broadway is equivalent to 1 PU.

Each Chroma-Q PSU / splitterbox is equipped with the following:

1) Red 24 Volt DC power indicator

2) Green DMX signal indicator

3) DMX 5 pin input and thru sockets

4) 2 x XLR 4-pin output sockets

5) 2 x XLR 4-pin return sockets

6) IEC 320 AC mains input socket

The purpose of the PSU / splitterbox is to combine the DMX control signal and the 24VDC

power into individual outputs. There are two output circuits for distribution on each PSU /

splitterbox, each is capable of supplying power and data for the Chroma-Q range of colour

changers. The maximum cable length, including the return, for the circuit is 60m / 200ft.

Each output must be connected back to its own return. The reason for the return socket is to

increase the size of the power cable to reduce Voltage loss in each circuit and to provide DMX

signal termination.

2.4 PSU / splitterbox capacities

The Chroma-Q PS02 (2PU) can run up to 2 Chroma-Q Broadway units

The Chroma-Q PS08 (8PU) can run up to 8 Chroma-Q Broadway units

The Chroma-Q Magic Box PS12 (12PU) can run 12 Chroma-Q Broadway units

(For details, please refer to User Manual for each PSU / splitterbox)

2.5 Mounting Position

The Chroma-Q is designed to be mounted in an upright position with the base of the unit below

the fixture. Do not mount in an inverted position with the base of the unit above the fixture, as

the rising heat from the fixture may cause gel string damage.

A large number of mounting plates are available; please contact your dealer for a full list.

Always ensure that the Chroma-Q is powered before the fixture and that you reverse the

procedure at the end of the show. Failure to do so may cause gel string damage.

2.6 Using Mark I and Mark II Chroma-Q CQ1’s units together

Mark I and Mark II units can easily be used on the same show. To do this, calibrate the Mark I

units first and last frames to the same frames of the Mark II units.

2.7 Safety wires

The safety wire supplied with your Chroma-Q should always be used.

2.8 F.C.C. Regulations (USA)

This device complies with part 15 of the F.C.C. rules. Operation is subject to the following:

(i) This device may not cause harmful interference, and

(ii) This device must accept any interference that may cause undesired operation

Broadway User Manual 6 V6.3 December 2006

2.9 Troubleshooting

Troubleshooting of a Chroma-Q is aided by the indications provided by the 3 diagnostic LED's

visibly through the Chroma-Q body. All troubleshooting procedures should begin with a LED

check.

The power supplies are designed to shut down if their outputs are shorted. They will not reset

until the AC supply has been disconnected and reconnected. The power supply red LED is an

indicator of output Voltage not input Voltage.

Note: A high percentage of problems are caused by corrupt DMX control protocol. We highly

recommend the use of genuine Tourflex Datasafe cables for all Chroma-Q colour changer and

DMX control protocol cables.

Symptom Possible Cause Solution

All units show no power

indicator (Red LED).

24V DC power supply is not

providing power to units.

Check if the mains power to

the PSU is ok and the red

24VDC LED is on.

Single unit power indicator is

off (Red LED).

Electronics fault in unit. Call selling dealer.

Power indicator light is

flashing. (Red LED).

Gel string is jammed. Readjust or replace faulty gel

string and / or turn power off

and on again. This will reset

the unit.

Unit has dim power light (Red

LED).

Voltage has dropped below

acceptable level.

Check that the return line has

been installed. Check

maximum cable length has

not been exceeded.

DMX indicator on all units is

off (Green LED).

No DMX is present at the

PSU / splitterbox.

Check that the DMX cable is

properly connected to DMX

input on the PSU /

splitterbox. Check that DMX

indicator light, located on the

PSU/splitterbox, is on.

DMX indicator light on one

group of Chroma-Q's are off

(Green LED).

One output of the PSU /

splitterbox has failed.

Faulty first XLR 4-pin cable at

splitterbox output.

Call selling dealer.

Test cables.

Level indicator does not

respond to DMX control

signal (Yellow LED).

Improper address. Reassign unit addressing.

Level indication changes

intensity, but gel string does

not move.

Mechanical failure. Call selling dealer.

No power from PSU, but AC

is OK.

Cable short has shut down

PSU / splitterbox.

Remove all cables from the

splitterbox allow 30 seconds

to reset, reconnect AC supply

and test. Check cables for

shorts

2.10 Limited warranty

Your Chroma-Q colour changers and PSU / splitterbox are covered by a 12 month warranty

against defects in manufacture. The warranty covers parts and labour but excludes the cost of

freight. In the case of any warranty claims, please contact your selling dealer. If the selling

dealer is unable to assist you, please e-mail [email protected] or call either number

detailed on page 1.

Broadway User Manual 7 V6.3 December 2006

2.11 Technical specifications

Chroma-Q Broadway Colour Changer Specification

Dimensions: 205mm (w) x 240mm (h) x 75mm (d)

8 1/8" (w) x 9 ½” (h) x 3 “(d)

Weight: 1.05kg / 2.3lb (without mounting frame)

Aperture: 127mm / 5” diameter

Gel frame capacity: between 2 - 16 frames

Speed: 2 seconds with dip switch 10 to Off

Speed 2: 5 seconds with dip switch 10 to On

Address: 10 way binary dip switch address up to 512 channels

Power requirements: 24V DC

Power consumption: 0.45A peak at 24V DC with dip switch 10 to On

0.9A peak at 24V DC with dip switch 10 to Off

Protocol requirements: ANSI E1.11 USITT DMX 512-A

Body material: UL94 V0 rated reinforced PBT compound

Body color: Black

Mounting plate: Mounting plates are available to suit numerous fixtures (see

separate price list for current selection)

Input connector: XLR 4-pin male (power and control protocol)

Output connector: XLR 4-pin female (power and control protocol)

European approvals: Complies with EU directives: EMC 89/336/EEC Class A.

Harmonised standards applied in order to verify compliance with

directives: EN 56022:1994, EN 50082-1: 1992 & EN 60950

North American approvals: Radiated Emissions: Complies with FCC part 15 subpart B, class

A for unintentional radiators. Low Voltage Directive: Complies

with CSA 22.2 950, UL 1950

Chroma-Q PSU / splitterbox specification

Dimensions PS08: 217mm (w) x 79mm (h) x 194mm (d)

8.6" (w) x 3.1” (h) x 7.6”(d)

Dimensions PS12: 219mm (w) x 88mm (h) x 279mm (d)

8.6" (w) x 3.5” (h) x 11“(d)

Dimensions PS02: 43mm (w) x 76mm (h) x 144mm (d)

1.7" (w) x 3” (h) x 5.7“(d)

Weight PS08: 2kg / 4.4lbs

Weight PS12: 3.2kg / 7.1lbs

Weight PS02: 0.75kg / 1.7lbs

Power requirements: 115 / 230V AC (internally switchable, isolate from mains before

removing cover). This power supply must be connected to

ground (earth)

Broadway User Manual 8 V6.3 December 2006

Protocol requirements: ANSI E1.11 USITT DMX 512-A

Body material: Powder-coated aluminium

Body color: Black

Mounting options: Either freestanding or can be hung from a hook clamp (not

supplied)

Circuit out connector: XLR 4-pin female (power and control protocol)

Return connector: XLR 4-pin male (power and control protocol)

Power input connector: IEC 320 10A, UL rated

Control input connector: XLR 5-pin male (protected with clamping diodes)

Control out connector: XLR 5-pin female (DMX link)

European approvals: Complies with EU directives: EMC 89/336/EEC and LVD

73/23/EEC. Harmonised standards applied in order to verify

compliance with directives: EN 50081-1 & EN 50082-1: 1992

North American approvals: Radiated Emissions: Complies with FCC part 15, subpart B, class

A for unintentional radiators.

2.12 Product Ordering List

CQ1/D Chroma-Q Digital colour changer

CQB Broadway Digital colour changer

CQM1 M1 Digital colour changer

CQM2 M2 Digital colour changer

CQM5 M5 Digital colour changer version II

CQM8 M8 Digital colour changer version II

MP1 Mounting plate for Par 64, aperture 165mm

MP2 Mounting plate for Source 4 Par

MP3 Mounting plate for Source 4 / Shakespeare

MP4 Mounting plate for 6" Leko / 360Q, 190mm × 190mm

MP5 Mounting plate 185mm × 185mm

MP6 Mounting plate 254mm × 254mm, aperture 190mm for analog

MP7 Mounting plate 254mm × 254mm, aperture 190mm for digital

MP8 Mounting plate 305mm × 305mm for digital

MPM5 Mounting frame for M5 version II

MPM8 Mounting frame for M8 version II

PS08 8PU PSU / splitterbox

MBPS12 12U PSU / splitterbox

GST16 16 frame "Theatre" gel string for Original Chroma-Q

GST16/D 16 frame "Theatre" gel string for Digital Chroma-Q

GSR16 16 frame "Rock & Roll" gel string for Original Chroma-Q

GSR16/D 16 frame "Rock & Roll" gel string for Digital Chroma-Q

GT1 Gel tabs for Digital Chroma-Q, Broadway, M1, M2

GT2 Gel tabs for Digital M5, M8 version I

ST High temperature clear tape

PT Paper (masking) tape

BDT Set/3 plastic barndoor tabs for Chroma-Q, M1

BDTM Set/3 metal barndoor tabs for M2

Broadway User Manual 9 V6.3 December 2006

Chroma-Q Data Safe Chroma-Q Cables

CQC3 1m / 3ft colour changer cable, 4 pin male - female

CQC5 1.5m / 5ft colour changer cable, 4 pin male - female

CQC10 3m / 10ft colour changer cable, 4 pin male - female

CQC25 7.5m / 25ft colour changer cable, 4 pin male - female

CQC50 15m / 50ft colour changer cable, 4 pin male - female

CQC100 30m / 100ft colour changer cable, 4 pin male - female

DMX Datasafe Control Cables

DS10 3m / 10ft 5 pin XLR DMX cable, male - female

DS25 7.5m / 25ft 5 pin XLR DMX cable, male - female

DS50 15m / 50ft 5 pin XLR DMX cable, male - female

DS100 30m / 100ft 5 pin XLR DMX cable, male - female

TP 5 pin XLR DMX termination plug (120 Ohm)

Note: cables will be in metric lengths for Europe and imperial in the US

Table des matières

Autres manuels Chroma Matériel de DJ

Chroma

Chroma Color Block 2 Plus Nano Manuel utilisateur

Chroma

Chroma Studio Force T Phosphor Manuel utilisateur

Chroma

Chroma Color Force II 72 Manuel utilisateur

Chroma

Chroma AutoLED II Manuel utilisateur

Chroma

Chroma Studio Force V Phosphor Manuel utilisateur

Chroma

Chroma Magic Box PS12 Manuel utilisateur

Chroma

Chroma Inspire XT Manuel utilisateur

Chroma

Chroma Color One 100X Manuel utilisateur

Chroma

Chroma Studio Force V Phosphor Manuel utilisateur

Chroma

Chroma Studio One 100 D Manuel utilisateur

Chroma

Chroma Color Block 2 Manuel utilisateur

Chroma

Chroma Brute Force 4 Manuel utilisateur

Chroma

Chroma Studio Force II V12 Manuel utilisateur

Chroma

Chroma Color Block DB4 Manuel utilisateur

Chroma

Chroma Color Force 48 Manuel utilisateur

Chroma

Chroma Color Block DB4 Manuel utilisateur

Chroma

Chroma Studio One 100 T Manuel utilisateur

Chroma

Chroma Color Force 12 Manuel utilisateur

Chroma

Chroma Color Force II 12 Manuel utilisateur

Chroma

Chroma Mirror Manuel utilisateur

Chroma

Chroma Color Force 12 Manuel utilisateur

Chroma

Chroma Color Force II 12 Manuel utilisateur

Chroma

Chroma Color Force II 12 Manuel utilisateur

Chroma

Chroma Color Punch Manuel utilisateur

Manuels Matériel de DJ populaires d'autres marques

ALPHA LITE

ALPHA LITE ALPHA 1500 Manuel du propriétaire

Chauvet

Chauvet OVATION E-930VW Manuel utilisateur

Zumtobel

Zumtobel APHRODITE Home Manuel utilisateur

Snow Masters

Snow Masters Zig Oscillator Manuel utilisateur

EuroLite

EuroLite 50530554 Manuel utilisateur

Beamz

Beamz BUV243 Manuel utilisateur

thomann

thomann Stairville DJ Lase 40-G MK-III Manuel utilisateur

Eagletone

Eagletone 6 Eyes Flower Manuel utilisateur

EuroLite

EuroLite FLD-1508 Manuel utilisateur

Technical Pro

Technical Pro LG8xSEA Manuel utilisateur

JB Systems

JB Systems Lounge Laser DMX Manuel utilisateur

Lightmaxx

Lightmaxx Vega Halo 90 Manuel utilisateur

Elation

Elation FUZE WASH Z350 Manuel utilisateur

Maverick

Maverick MK3 WASH Manuel utilisateur

Infinity

Infinity TF-260C7 Fresnel Manuel utilisateur

Chauvet

Chauvet EVE E-50Z Manuel utilisateur

Eliminator Lighting

Eliminator Lighting E 138 Manuel utilisateur

EuroLite

EuroLite Mini Multicolor LED Flashing Light SC Manuel utilisateur
