Choetech HUB-M03 Manuel utilisateur
USB-C to HDMI + PD Adapter
HUB-M03
User Manual • Uživatelský manuál •
Užívateľský manuál • Használati utasítás
2
Dear customer,
Thank you for purchasing our product. Please read the following instructions carefully
before first use and keep this user manual for future reference. Pay particular attention
to the safety instructions. If you have any questions or comments about the device,
please contact the customer line.
✉www.alza.co.uk/kontakt
✆+44 (0)203 514 4411
Importer Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
3
Package Contents
1 x USB-C to HDMI + PD Adapter
1 x User Manual
1 x After-sale Card
Specifications
Interface
1 x USB-C Male; 1 x HDMI; 1 x USB-C Female
Protocol
DP Alt Mode
Maximum Resolution
4K (3840x2160) @60Hz
Charging Output
Up to 20V/3A (60W Max)
Connection Guides
1. Connect the USB-C connector to your USB-C device.
2. HDMI interface: Connect an HDMI-to-HDMI cable (non-included) to an HDMI display.
3. USB PD: Connect a USB-C to PD cable (non-included) to a PD charger.
Notebook
Type-C
Projector
Monitor
HDTV
4
Troubleshoot Using the USB Type-C to HDMI+PD adapter
Things to know before you begun common issues
1. Your laptop or device must have a USB-C port.
2. For video support, your USB-C laptop or device must support DP Alt Mode over USB-C,
or video signals cannot be sent to your monitors.
3. To check whether your device has the necessary DP Alt Mode, please refer to the
manual of your device or contact the computer’s manufacturer.
4. For video output, you must use a direct HDMI-to-HDMI cable, connecting a HDMI-to-
PD cable will not allow video signals to transmit.
5. The adapter is ONLY compatible with Thunderbolt 3 or USB-C devices with DP Alt
Mode, not for USB-C smartphones and tablets with MHL or SlimPort solution.
Having trouble with connecting USB-C laptop to the
adapter?
If you have problems connecting your USB-C laptop to a TV, monitor, or projector, then
restart your USB-C device, and reconnect the adapter.
Having trouble with video or audio playback?
Problem: Nothing displays on the second screen
Solution 1: Make sure your USB-C laptop is set to mirror or extend the screen.
To set the extend mode and mirror mode, here is how:
•For Mac based systems:
1. Go to the Apple menu in the upper left-hand corner and select System Preferences.
2. Select Displays.
3. For Mirroring Displays –go to Arrangement and select “Mirror Displays” to start
mirroring the display.
5
For Extending Displays –go to Arrangement, deselect “Mirror Displays”, open the
applications you need and drag them to your desired displays.
•For Windows based systems:
1. Press the Windows logo on the keyboard and then press P key on the keyboard.
2. A pop up will appear and simply choose the option you would like.
Alternatively, you can use following steps if the steps above do not work:
1. Right click on an open area of the desktop and select screen resolution.
2. Under multiple displays, select “Duplicate these displays” or Extend these displays,
then click OK.
Solution 2: Make sure your HDTV, monitor, or projector is set to the HDMI channel.
To check the video input setting, here is how:
Take a DELL monitor for example and do the following:
1. Press the Menu Button to launch the OSD menu and display the main menu.
2. Press Up/Down Buttons to move between options and find the Input Source.
3. Use the Input Source menu to select between different video inputs that are be
connected to your monitor.
For specific models, please follow the instructions in the owner’s manual for the screen
or check the manufacturer’s website.
Solution 3: Ensure that the computer connected to the adapter is running
correctly and is not in standby or hibernation mode. When the computer is in
standby or hibernation mode, the external monitor display is always blank.
Problem: The images on the external monitor flutter.
Check the display resolution setting of the computer and ensure that the resolution is
supported by the adapter.
To set the resolution of the external monitor, do the following:
•For the Windows based system:
1. Click Start -> Control Panel.
2. Depending on your Control Panel mode, do one of the following:
Click Display -> Change display settings.
6
Click Appearance and Personalization ->Display -> Change display setting.
3. In the Resolution drop-down list box, move the slider up to increase or down to
decrease the resolution of the external monitor.
•For Mac based systems:
1. Go to the Apple menu in the upper left-hand corner and select System references.
2. Click the Displays option and then click the Display tab.
3. Select the Scaled option to change your resolution.
Problem: No audio on the monitors that are connected to the adapter.
To resolve no sound or audio problems, following the steps bellow:
•For Windows based system:
1. Click Start -> Control Panel ->Hardware and Sound.
2. Click Manage audio devices under Sound to open the Sound window.
3. From the Playback tab on the Sound window, select the Monitor Model, and then
click the Set Default button.
•For Mac based systems:
1. Go to the Apple menu in the upper left-hand corner and select System Preferences.
2. Select Sound -> Click the Output tab -> Select Monitor Model for sound output.
7
For FAQs and More Information, Please Visit:
8
Warranty Conditions
A new product purchased in the Alza.cz sales network is guaranteed for 2 years. If you
need repair or other services during the warranty period, contact the product seller
directly, you must provide the original proof of purchase with the date of purchase.
The following are considered to be a conflict with the warranty conditions, for
which the claimed claim may not be recognized:
•Using the product for any purpose other than that for which the product is intended
or failing to follow the instructions for maintenance, operation and service of the
product.
•Damage to the product by a natural disaster, the intervention of an unauthorized
person or mechanically through the fault of the buyer (e.g. during transport, cleaning
by inappropriate means, etc.).
•Natural wear and aging of consumables or components during use (such as
batteries, etc.).
•Exposure to adverse external influences, such as sunlight and other radiation or
electromagnetic fields, fluid intrusion, object intrusion, mains overvoltage,
electrostatic discharge voltage (including lightning), faulty supply or input voltage and
inappropriate polarity of this voltage, chemical processes such as used power
supplies, etc.
•If anyone has made modifications, modifications, alterations to the design or
adaptation to change or extend the functions of the product compared to the
purchased design or use of non-original components.
9
Vážený zákazníku,
Děkujeme vám za zakoupení našeho produktu. Před prvním použitím si prosím pečlivě
přečtěte následující pokyny a tento manuál si uschovejte pro budoucí použití. Věnujte
zvláštní pozornost bezpečnostním pokynům. Pokud máte jakékoliv dotazy nebo
připomínky k produktu, kontaktujte zákaznickou linku.
✉www.alza.cz/kontakt
✆+420 255 340 111
Dovozce: Alza.cz a.s., Jankovcova 1522/53, Holešovice, 170 00 Praha 7, www.alza.cz
10
Balení obsahuje
1 x USB-C na HDMI + PD Adaptér
1 x Uživatelská příručka
1 x Poprodejní karta
Specifikace
Rozhraní
1 x USB-C Male; 1 x HDMI; 1 x USB-C Female
Protokol
DP Alt Mode
Max rozlišení
4K (3840x2160) @60Hz
Napájecí výstup
Až 20V/3A (60W Max)
Průvodce připojením
1. Připojte konektor USB-C k zařízení USB-C.
2. Rozhraní HDMI: Připojte kabel HDMI-na-HDMI (není součástí dodávky) k displeji HDMI.
3. USB PD: Připojte kabel USB-C k PD (není součástí dodávky) k nabíječce PD.
Notebook
Type-C
Projektor
Monitor
HDTV
