BT2610U
Product Specification:
Main parameter:
•output power：5W×2
•frequency response：75hz-18khz
•RMS：（ THD = 10%）
•drive：1.5’×2
•power supply：DC 5V
•distortion：≦1%
•S / N：≥ 65dB
•battery capacity：2000mAh/3.6V-4.2V
•battery working time：2.5-3hours (play as the max Volume)
•battery charging time：2.5-3 hours
•size：L336 *w61.5 * h61.5mm
•N.W.：790g
Packing Contents:
1、the quake blue-tooth speaker
2、user’s manual
3、USB charging cable
4、3.5mm stereo cable
Charging the Speaker:
Before using the speaker for the first time, charging it for at least 2 hours.
1、Plug the USB cable into the port on the speaker, plug the other end into the USB port on the adapter(5V).
2、Red LED will turn on to indicate that the unit is charging.
3、Red LED will turn off when fully charged.
Start-up& Shutdown Functions:
1、Long press POWER to start the blue-tooth speaker.
2、Trumpet emit and alternating flashing blue LED.(蓝色 LED 快速闪烁）
3、Long press POWER to shutdown the blue-tooth speaker.
4、Blue LED off if shutdown the speaker.
Pairing the Device:
1、Place the speaker near the Blue-tooth-enabled device.
2、Long press POWER to start the blue-tooth speaker, alternating flashing blue LED（蓝色 LED 快速闪烁）, the speaker is now
in pairing mode.
3、Follow the instructions of your device to search for the speaker.
4、The speaker is called “BT2016U”, enter the PIN”0000”if need.
5、The blue LED will turn on and trumpet emit when pairing is complete.
6、The speaker is in the state of pairing the last device default in the first 3 seconds after starting. If failing to pair, the
speaker will be in state of pairing automatically.
