Chicago Electric Power Systems 96706 Manuel d'installation

5000W CONTINUOUS/10,000W

SURGE POWER INVERTER

96706

SET UP AND OPERATING INSTRUCTIONS

Visit our website at: http://www.harborfreight.com

Read this material before using this product.

Failure to do so can result in serious injury.

SAVE THIS MANUAL.

contained herein may be reproduced in any shape or form without the express written consent of

Harbor Freight Tools. Diagrams within this manual may not be drawn proportionally. Due to continuing

improvements, actual product may differ slightly from the product described herein. Tools required for

assembly and service may not be included.

For technical questions or replacement parts, please call 1-800-444-3353.

Revised Manual 07i, 08f, 09d, 09l

Page 2SKU 96706 For technical questions, please call 1-800-444-3353.

SAVE THIS MANUAL

Keep this manual for the safety warn-

ings and precautions, assembly, operat-

ing, inspection, maintenance and cleaning

procedures. Write the product’s serial

number in the back of the manual near the

assembly diagram (or month and year of

purchase if product has no number). Keep

this manual and the receipt in a safe and

dry place for future reference.

IMPORTANT SAFETY

INFORMATION

In this manual, on the labeling,

and all other information provid-

ed with this product:

This is the safety alert

symbol. It is used to alert

you to potential personal

injury hazards. Obey all

safety messages that

follow this symbol to avoid

possible injury or death.

DANGER indicates

a hazardous

situation which, if not

avoided, will result in death or

serious injury.

WARNING

indicates a

hazardous situation which, if

not avoided, could result in

death or serious injury.

CAUTION, used

with the safety

alert symbol, indicates a

hazardous situation which, if

not avoided, could result in

minor or moderate injury.

NOTICE is used to

address practices

not related to personal injury.

CAUTION, without

the safety alert

symbol, is used to address

practices not related to

personal injury.

General Safety Warnings

WARNING Read all safety

warnings and instructions.

Failure to follow the warnings and

instructions may result in electric

shock, re and/or serious injury.

Save all warnings and

instructions for future reference.

SAVE THESE INSTRUCTIONS

Work area safety1.

Keep work area clean and well lit.a.

Cluttered or dark areas invite acci-

dents.

Do not operate the Inverter in ex-b.

plosive atmospheres, such as in

the presence of ammable liquids,

gases or dust.

Keep children and bystandersc.

away while operating the Inverter.

Distractions can cause you to

lose control.

Electrical safety2.

Inverter plugs must match the out-a.

let. Never modify the plug in any

way. Do not use any adapter plugs

with grounded products. Unmodi-

ed plugs and matching outlets will

reduce risk of electric shock.

Avoid body contact with earthed orb.

grounded surfaces such as pipes,

radiators, ranges and refrigerators.

Page 3SKU 96706 For technical questions, please call 1-800-444-3353.

There is an increased risk of electric

shock if your body is grounded.

Do not expose Inverters to rain orc.

wet conditions. Water entering a

this unit will increase the risk of

electric shock.

This product is intended for use in ad.

well-ventilated inside area only. Do

not use outdoors.

Personal safety3.

Stay alert, watch what you are do-a.

ing and use common sense when

operating a Inverter. Do not use a

Inverter while you are tired or under

the inuence of drugs, alcohol or

medication. A moment of inattention

while operating may result in serious

personal injury.

Wear splash-resistant ANSI-ap-b.

proved safety goggles and electri-

cally insulated gloves while as-

sembling battery bank or working

near batteries.

Inverter use and care4.

Do not force the Inverter. Use thea.

correct product for your application.

The correct product will do the job

better and safer at the rate for which

it was designed.

Do not use the Inverter if the switchb.

does not turn it on and off. Any In-

verter that cannot be controlled with

the switch is dangerous and must be

repaired.

Disconnect the plug from thec.

power source of the Inverter

before making any adjustments.

Such preventive safety measures

reduce the risk of starting the

Inverter accidentally.

Store idle Inverters out of thed.

reach of children and do not allow

persons unfamiliar with the Invert-

er or these instructions to operate

it. Inverters are dangerous in the

hands of untrained users.

Maintain the Inverter. Check fore.

breakage of parts and any other con-

dition that may affect the Inverter’s

operation. If damaged, have it re-

paired before use. Many accidents

are caused by poorly maintained

products.

Use the Inverter in accordance withf.

these instructions and in the man-

ner intended for the particular type

of product, taking into account the

working conditions and the work to

be performed. Use of the Inverter

for operations different from those

intended could result in a hazardous

situation.

Service5.

Have your Inverter serviced by a

qualied repair person using only

identical replacement parts. Never

open the metal cover of the Inverter.

This will ensure that the safety of the

Inverter is maintained.

SPECIFIC SAFETY RULES

Maintain labels and nameplates on1.

the Inverter. These carry important

safety information. If unreadable or

missing, contact Harbor Freight Tools

for a replacement.

Avoid unintentional starting. Prepare2.

to begin work before turning on the

Inverter.

Do not leave the Inverter unattended3.

when it is plugged into an electrical

Page 4SKU 96706 For technical questions, please call 1-800-444-3353.

outlet. Turn it off and unplug it from

the electrical outlet before leaving.

4. The Inverter gets hot

during use. The heat can

build up to unsafe levels

and create a re hazard if

it does not receive adequate ventila-

tion, due to an electrical fault, or if it is

used in a hot environment.

Do not place the Inverter on a am-

mable surface, or near combustible

items. Do not obstruct any vents on

the Inverter. Especially avoid plac-

ing the Inverter on carpets and

rugs; they are not only ammable,

but they also obstruct vents under-

neath it.

Place the Inverter on a stable, solid,

nonammable surface (such as a

stable metal workbench or concrete

oor) at least 1 foot away from all

ammable objects, such as drapes or

walls. Keep a re extinguisher and a

smoke detector in the area. Avoid

touching the Inverter with an exposed

hand; always wear gloves.

This product is not a toy. Keep it out5.

of reach of children.

The Inverter must only be connected6.

to batteries with an output of 12 VDC.

Batteries with lower voltage will not

operate the Inverter correctly, and a

higher charge could damage the unit.

Do not use the Inverter with positive7.

ground electrical systems.

Some rechargeable tools and ap-8.

pliances can damage the Inverter.

Check the temperature of the device

several times when it is charging. If

the device becomes extremely hot;

turn the power off, remove the de-

vice, and do not use with the Inverter

again.

The positive (+) battery on the Invert-9.

er must be the last connection made,

and must be connected before the

Inverter is turned on.

Do not attempt to power a device, or10.

combination of devices, of over 5,000

Watts. This will damage the Inverter.

Do not use the Inverter to power such11.

sensitive devices such as computers

or hospital equipment.

People with pacemakers should12.

consult their physician(s) before use.

Electromagnetic elds in close prox-

imity to heart pacemaker could cause

pacemaker interference or pacemak-

er failure. In addition, people with

pacemakers should:

• Avoid operating alone.

• Do not use with power switch locked

on.

• Properly maintain and inspect to

avoid electrical shock.

WARNING: The brass components13.

of this product contain lead, a chemi-

cal known to the State of California

to cause birth defects (or other repro-

ductive harm). (California Health &

Safety code § 25249.5, et seq.)

The warnings, precautions, and in-14.

structions discussed in this instruction

manual cannot cover all possible con-

ditions and situations that may occur.

It must be understood by the operator

that common sense and caution are

factors which cannot be built into this

product, but must be supplied by the

operator.

SAVE THESE

Page 5SKU 96706 For technical questions, please call 1-800-444-3353.

INSTRUCTIONS.

GROUNDING

TO PREVENT

ELECTRIC SHOCK

AND DEATH FROM

INCORRECT GROUNDING

WIRE CONNECTION:

Check with a qualied

electrician if you are in doubt

as to whether the outlet is

properly grounded. Do not

modify the power cord plug

provided with the tool. Never

remove the grounding prong

from the plug. Do not use the

tool if the power cord or plug

is damaged. If damaged, have

it repaired by a service facility

before use. If the plug will not

t the outlet, have a proper

outlet installed by a qualied

electrician.

Grounded Tools: Tools with Three

Prong Plugs

3-Prong Plug and Outlet

Tools marked with “Grounding Re-1.

quired” have a three wire cord and

three prong grounding plug. The

plug must be connected to a properly

grounded outlet. If the tool should

electrically malfunction or break

down, grounding provides a low

resistance path to carry electricity

away from the user, reducing the risk

of electric shock. (See 3-Prong Plug

and Outlet.)

The grounding prong in the plug is2.

connected through the green wire in-

side the cord to the grounding system

in the tool. The green wire in the cord

must be the only wire connected to

the tool’s grounding system and must

never be attached to an electrically

“live” terminal. (See 3-Prong Plug

and Outlet.)

The tool must be plugged into an3.

appropriate outlet, properly installed

and grounded in accordance with all

codes and ordinances. The plug and

outlet should look like those in the

preceding illustration. (See 3-Prong

Plug and Outlet.)

Double Insulated Tools: Tools

with Two Prong Plugs

Outlets for 2-Prong Plug

Tools marked “Double Insulated” do1.

not require grounding. They have

a special double insulation system

which satises OSHA requirements

and complies with the applicable

standards of Underwriters Labora-

tories, Inc., the Canadian Standard

Association, and the National Electri-

Page 6SKU 96706 For technical questions, please call 1-800-444-3353.

cal Code. (See Outlets for 2-Prong

Plug.)

Double insulated tools may be used2.

in either of the 120 volt outlets shown

in the preceding illustration. (See

Outlets for 2-Prong Plug.)

Extension Cords

Grounded1. tools require a three wire

extension cord. Double Insulated

tools can use either a two or three

wire extension cord.

As the distance from the supply outlet2.

increases, you must use a heavier

gauge extension cord. Using exten-

sion cords with inadequately sized

wire causes a serious drop in voltage,

resulting in loss of power and pos-

sible tool damage.

(See Table A.)

The smaller the gauge number of the3.

wire, the greater the capacity of the

cord. For example, a 14 gauge cord

can carry a higher current than a 16

gauge cord. (See Table A.)

When using more than one exten-4.

sion cord to make up the total length,

make sure each cord contains at

least the minimum wire size required.

(See Table A.)

If you are using one extension cord5.

for more than one tool, add the

nameplate amperes and use the sum

to determine the required minimum

cord size. (See Table A.)

If you are using an extension cord6.

outdoors, make sure it is marked with

the sufx “W-A” (“W” in Canada) to

indicate it is acceptable for outdoor

use.

Make sure the extension cord is prop-7.

erly wired and in good electrical con-

dition. Always replace a damaged

extension cord or have it repaired by

a qualied electrician before using it.

Protect the extension cords from8.

sharp objects, excessive heat, and

damp or wet areas.

RECOMMENDED MINIMUM WIRE

GAUGE FOR EXTENSION CORDS*

(120/240 VOLT)

NAMEPLATE

AMPERES

(at full load)

EXTENSION CORD

LENGTH

25’

50’

75’

100’

150’

0 – 2.0 18 18 18 18 16

2.1 – 3.4 18 18 18 16 14

3.5 – 5.0 18 18 16 14 12

5.1 – 7.0 18 16 14 12 12

7.1 – 12.0 18 14 12 10 -

12.1 – 16.0 14 12 10 - -

16.1 – 20.0 12 10 - - -

TABLE A

* Based on limiting the line

voltage drop to ve volts at

150% of the rated amperes.

Symbology

Double Insulated

Canadian Standards Association

Underwriters Laboratories, Inc.

V~ Volts Alternating Current

AAmperes

n0xxxx/min. No Load Revolutions per Minute

(RPM)

Page 7SKU 96706 For technical questions, please call 1-800-444-3353.

UNPACKING

When unpacking, check to make sure

that the item is intact and undamaged. If

any parts are missing or broken, please

call Harbor Freight Tools at

1-800-444-3353 as soon as possible.

FUNCTIONS

The Inverter converts power from

a DC power source into AC power. The

resulting charge can then be used to

power AC devices, such as power tools

or appliances, up to a maximum of 5,000

Watts. Up to four devices can be powered

at once, provided the sum of the devices’

maximum wattage remains below 5,000

Watts.

INSTALLATION

Read the ENTIRE IMPORTANT

SAFETY INFORMATION

section at the beginning of this

manual including all text under

subheadings therein before set

up or use of this product.

CAUTION! This Inverter must only be

connected to batteries with a output

voltage of 12 volts DC. Lower volt-

age will not operate the Inverter prop-

erly, and more voltage could damage

the Inverter or the device being pow-

ered. Do not use this Inverter with

positive ground electrical systems.

The Inverter is congured to have a

number of shut-down points, for the

safety of the operator, the unit, and the

devices being used with it.

If the DC rating input voltage from•

the battery drops to 10.6V, the

alarm on the Inverter will sound.

Should the input voltage drop to

10V the Inverter will shut down

automatically. Recharge the bat-

tery soon.

If the DC rating input voltage•

from the battery exceeds 15V the

Inverter will shut down automati-

cally.

When the output load power rises•

higher than the rating power of the

Inverter; the unit will shut down

automatically.

The Inverter will automatically•

shut down when its internal tem-

perature reaches 149° F.

REV 09b

SPECIFICATIONS

Input Voltage 12-15 VDC

Output Voltage 120 V~, 60 Hz

Continuous Power 5,000 Watt

Surge Power 10,000 Watt

Operating Conditions 50° - 149° F (auto-shutdown @ 149° F)

AC Receptacles Four 3-prong grounded polarized outlets

Fuse Type Twenty 40 Amp Internal Fuses (professional replacement only)

Cable #00 AWG or Thicker Cable Required (not included).

Overall Dimensions 22-1/2” L x 8” W x 6-7/8” H

Page 8SKU 96706 For technical questions, please call 1-800-444-3353.

Place the Inverter on a dry, level,1.

non-ammable surface capable of

supporting the weight of the unit.

Make sure the Inverter has adequate

ventilation and is not in direct sun-

light.

Due to the large power drain of this2.

inverter, automotive installation is not

recommended.

Cooling Fan + Input

Terminal

– Input

Terminal

Ground Terminal

3. Connect one end of a ground wire

(not included, #00 AWG or thicker

cable recommended) to the wing

nut located on the back of the In-

verter. Then connect the other end

of the ground wire to a paint/rust free

grounded metal surface, such as a

water pipe.

Battery Type Selection:4.

Use only deep cycle lead-acid bat-•

teries with this inverter, such as 12

volt marine/RV deep-cycle batter-

ies. Do not use automotive, engine

starting (SLI), or maintenance-free

wet cell batteries with this inverter;

they are designed for repeated,

shallow discharge and will wear out

quickly.

Gel and AGM (Absorbed Glass•

Mat) batteries can be used with this

inverter, but they require special

charging procedures. Refer to bat-

tery supplier’s instructions.

Battery capacity selection:5.

Inverter

Output

about 1 hour

discharge time

(Minimum battery

capacity)

about 4 hour

discharge time

(Optimal battery

capacity)

500W 80 Ah 200 Ah

1000W 150 Ah 400 Ah

1500W 240 Ah 700 Ah

2000W 300 Ah 1000 Ah

3000W 450 Ah 1500 Ah

4000W 600 Ah 2000 Ah

5000W 750 Ah 2500 Ah

Consult the chart above for ap-

proximate run time at different battery

capacities. If the battery does not

have a capacity this large individually,

use a bank of batteries as explained

below.

Battery Bank assembly instructions:6.

Read the following safety rulesa.

before assembling the battery

bank:

Connect batteries in parallel•

(negative terminals together to

one cable; positive terminals

together to the other cable) as

shown in Battery Bank Example

illustration ONLY.

Do not connect 12V batteries•

in series (from negative of one

battery to the positive of the

next). This connection can result

in voltage high enough to cause

ELECTROCUTION.

Wear splash-resistant ANSI-•

approved safety goggles and

electrically insulated gloves

while assembling battery bank.

Only connect similar batteries•

together in a battery bank. Do

not connect old and new batteries

together, wet and gel cells together,

REV 09d

Page 9SKU 96706 For technical questions, please call 1-800-444-3353.

or batteries of different capacities

together.

Connect all batteries in the battery•

bank together using #00 AWG or

thicker cables. Since amp draw on

this low-voltage circuit will be very

high, thinner cables would present

a re hazard.

Locate battery bank in a clean, well-•

ventilated area, away from ignition

sources and ammable materials.

Batteries release explosive hydro-

gen gas while charging.

Charge, store, and maintain batter-•

ies according to supplier’s instruc-

tions.

–+

OUTPUT

(To Positive

Inverter Terminal)

To Increase

Capacity, Connect

Additional

12 V / 200* Ah

Lead-Acid

Batteries Here

(To Negative

Inverter Terminal)

OUTPUT

12 V /

200* Ah

Lead- Acid

Battery

12 V /

200* Ah

Lead- Acid

Battery

12 V / 400^ Ah Battery Bank Example

* 200 Ah batteries shown for illustration.

^ Bank Capacity = (single battery capacity) x (# of batteries)

400 Ah capacity is for two, 200 Ah batteries.

b. Connect the batteries in parallel as

shown above. Connect all of the

positive terminals to one another.

Then connect all the negative termi-c.

nals to one another.

Connect the negative and positived.

output cables to opposite ends of

the bank. Do not allow the output

cables to touch one another.

Test the voltages at the output ca-e.

bles to help ensure that the battery

bank is properly wired. If the voltage

is higher than 13 volts, then part of

the battery bank is likely connected

in series (a negative terminal of one

battery attached to a positive termi-

nal of another) instead of in parallel.

Carefully examine the diagram and

correct the wiring before attaching to

the inverter.

Turn the Power Switch on the front of7.

the inverter off.

Connect the output cables from the8.

battery bank to the inverter.

REV 09d

Page 10SKU 96706 For technical questions, please call 1-800-444-3353.

OPERATING INSTRUCTIONS

120 V~ Receptacles

Power

Switch

1. Plug 120 V~ device(s) into the Re-

ceptacles. The devices must not use

more than 5,000 (total) Watts during

continuous operation, otherwise they

may overload the Inverter.

Turn the Power Switch to the “ON”2.

position.

Turn the tool or appliance on. If the3.

alarm sounds, turn off the device(s).

Unplug the device(s) from the Invert-

er. Check the wattage of the devices,

if there were multiple devices plugged

in, discontinue use of one or more.

If a single device set the alarm off,

it is not appropriate for use with the

Inverter.

The “SELECT” button allows the4.

operator to view the level of DC input

voltage versus the level of AC output

wattage.

To prevent accidents, turn off the tool5.

and disconnect the power supply

after use. Clean, then store the tool

indoors out of children’s reach.

NOTE: Some rechargeable tools/appli-

ances may damage the Inverter

or the device(s). When rst using

a rechargeable device, check the

Inverter’s temperature for the rst ten

minutes. If it becomes abnormally

hot, do not use the device with the

Inverter.

REV 09d
