Chiayo SDR-5900 Manuel utilisateur

Operation manual

CHIAYO ELECTRONICS CO., LTD.

SDR-5900

Dual-Channel 2-Way Sync True

Diversity Receiver

SDR-5900 Dual-Channel 2-Way Sync True Diversity Receiver

Thank you for choosing this wireless microphone system! For more details, please take a few

moments to read this operating manual to have a thorough understanding of the function and

operation of both transmitter and receiver.

In the box

SDR-5900 receiver

two transmitters

(handheld / belt-pack)

a pair of antennas

audio cable

switching adaptor

operation manual

** Remark: The above specifications are subject to change without prior notice.

Important

1.Please make sure that the output DC voltage range of the switching power covers that

specified by the receiver before turning it on.

2.The RF meter bars and antenna diversity indicator will appear to denote RF signal received

after turning on the transmitter.

3.The receiver and transmitter must be the same frequency.

4.While using the transmitter, the audio meter bars will appear to denote audio signal received.

RF meter Antenna selection Transmitter battery

Channel / frequency Audio meter

590

F雙頻

道數位鎖

定

自動

對

頻自動

選

訊無線麥克風

系

統

RF AF

MHz

650.250

C H 00 2

FREQ

Instructions

Parts and functions

►front panel

1. Power switch

2. LCD

3. UP button

4. MENU button

5. IR sensor area

6. DOWN button

7. ENTER button

8. IrDA synchronization button

9. Volume control

10.LCD

11.UP button

12.MENU button

13.IR sensor area

14.DOWN button

15.ENTER button

16.IrDA synchronization button

17.Volume control

►rear panel

18.Antenna B (TNC type)

19.Channel 2’s balanced audio output

20.Mixed unbalanced audio output

21.Mixed MIC/LINE audio output

impedance switch

22.Channel 1’s balanced audio output

23.DC input

24.Antenna A (TNC type)

FRE Q S Q

R F A F

MHz

C H BA

MENUMENU

ENTERENTER SYNCSYNC MAXMINMIN FREQ SQ

R F A F

MHz

C H BA

MENUMENU

ENTERENTER SYNCSYNC MAXMINMIN

POWERPOWER

TRUE DIVERSITY RECEIVERTRUE DIVERSITY RECEIVER

SDR-5900SDR-5900

1 2 3 4 5

6 7 8

910 11 12 13

14 15 16

A N T. B M IC 2 O U T

1.G

M IX E D O U T

MIC LINE

M I C 1 O U T

1.G

DC IN

12V

AN T. A

18 19

20 21

Channel 1

Channel 2

SDR-5900 Dual-Channel 2-Way Sync True Diversity Receiver

CHANNEL scanning

For an interference- free operation, a cleaner channel might be necessary if the current one

receives too much interference. To operate the scanning:

1 Press MENU button to make the frequency icon appear on the bottom.



2 Press ENTER button until this icon flashes to denote readiness for setting.



3 Press ▲(up) or ▼(down) button to find and locate a clear, interference- free channel.



4 After a channel is chosen, press ENTER button or wait 5 seconds to store the setting.



FREQ S Q

RF AF

MHz

C H BA

MENUMENU

ENTERENTER SYNCSYNC MAXMINMIN

RF AF

MHz

650.250

C H 002

FREQ

FREQ S Q

RF AF

MHz

C H BA

MENUMENU

ENTERENTER SYNCSYNC MAXMINMIN

RF AF

MHz

650.250

C H 002

FREQ

FREQ S Q

RF AF

MHz

C H BA

MENUMENU

ENTERENTER SYNCSYNC MAXMINMIN

FREQ

RF AF

MHz

652.000

C H 009

FREQ S Q

RF AF

MHz

C H BA

MENUMENU

ENTERENTER SYNCSYNC MAXMINMIN

FREQ

RF AF

MHz

652.000

C H 009

Instructions

Channel synchronizing between receiver and transmitter

Align infrared areas of the receiver and transmitter within 10~30cm.

Changing the receiver’s channel

1 Press the synchronizing button of the

transmitter.

2 The transmitter's LED will glow to denote

synchronizing signal transmitted.

3 The channel/frequency of the receiver will

change and then the synchronization is

complete.

Changing the transmitter’s channel

1 Press the SYNC button of the receiver

2 The receiver’s LCD will show to

denote synchronizing signal being sent.

3 The channel/frequency of the transmitter will

change and then the synchronization is

complete.

If it doesn’t work check that you have the IR sensor panels aligned, that they are facing each

other, devices are within 10~30cm of each other, and try again.

FRE Q SQ

RF AF

MHz

C H BA

MENUMENU

ENTERENTER SYNCSYNC MAXMINMIN

FRE Q SQ

RF AF

MHz

C H BA

MENUMENU

ENTERENTER SYNCSYNC MAXMINMIN

10~30cm

SDR-5900 Dual-Channel 2-Way Sync True Diversity Receiver

SQUELCH (SQ) adjusting

When interference is encountered try reducing the sensitivity of the receiver, thus less

susceptible to interference. To operate the squelch setting:

1 Press MENU button to turn to the squelch setting page.



2 Press ENTER button until this icon flashes to denote readiness for setting.



3 Press ▲(up) or ▼(down) button to select a new squelch (sensitivity) level between 1

and 10.



4 After a squelch (sensitivity) level is chosen, press ENTER button or wait 5 seconds to

store the setting.



FREQ S Q

RF AF

MHz

C H BA

MENUMENU

ENTERENTER SYNCSYNC MAXMINMIN

LE-02

FREQ S Q

RF AF

MHz

C H BA

MENUMENU

ENTERENTER SYNCSYNC MAXMINMIN

LE-02

FREQ S Q

RF AF

MHz

C H BA

MENUMENU

ENTERENTER SYNCSYNC MAXMINMIN

LE-06

FREQ S Q

RF AF

MHz

C H BA

MENUMENU

ENTERENTER SYNCSYNC MAXMINMIN

LE-06

Instructions

Audio output connection

There are three audio outputs on the back of the receiver, Mic-level balanced (channel 1 and

channel 2), and Line-level unbalanced (mixed). Use shielded audio cable for the connection

between the receiver and the amplifier/mixer. If the amplifier/mixer has a 1/4"(6.3mm) phone

jack, connect a cable from the 1/4"(6.3mm) unbalanced audio output from the receiver to the

amplifier/mixer. If the amplifier/mixer has an XLR input, connect a cable from the balanced XLR

audio output from the receiver to the amplifier/mixer input.

Mixed unbalanced audio output

MIC/LINE output impedance level switch ► ►

Individual balanced audio output

Rack mounting

The receiver can be cabinet-mounted with accompanied kit as illustrated below.

ANT. B MIC 2 OUT

1.G

MIXED OUT

MI C LI N E

MIC 1 OUT

1.G

DC IN

12 V

ANT. A

ANT. B MIC 2 OUT

1.G

MIXED OUT

MIC LINE

MIC 1 OUT

1.G

DC IN

12V

ANT. A

ANT. B MIC 2 OUT

1.G

MIXED OUT

MI C LI N E

MIC 1 OUT

1.G

DC IN

12 V

ANT. A



MIC level for connecting to MIC IN.

LINE level for connecting to LINE IN or AUX IN

CHIAYO ELECTRONICS CO.,LTD.

Http://www.chiayo.com.tw｜Email: sales@chiayo.com.tw

Office: 30, Lane 27, Section 4, Jen-Ai Road, Taipei 10685, Taiwan

Tel: 886-2-27415741｜Fax: 886-2-27525242

Factory: 88, Chung-Hsiao Street 2, Chiayi 60080, Taiwan

Tel: 886-5-2711000｜Fax: 886-5-5767611
