Chauvet PowerStream 4 Manuel utilisateur

Quick Reference Guide

PowerStream™ 4 QRG

Page 2 of 4

About This

Guide

The PowerStream™ 4 Quick Reference Guide (QRG) contains the product

’s

connection and mounting information.

Disclaimer

•Read ALL the disclaimers and Safety Notes in this document before

installing, operating, and maintaining this product.

Safety Notes

•DO NOT open this product unless instructed. It contains no user

serviceable parts.

•ONLY use this product in an area that has adequate ventilation.

•DO NOT operate this product outdoors or in any location where dust,

excessive heat, water, or humidity may affect it.

•DO NOT leave any flammable material within 5 cm from this product

while connected to the power outlet to minimize the risk of fire.

•DO NOT operate this product if you see damage on the housing. In this

case, have the damaged parts replaced by an authorized technician

immediately.

•ONLY connect this product to a grounded and protected circuit.

What Is

Included

•One PowerStream™ 4

•One Warranty Card

•One Quick Reference Guide

Features

•Split power in five directions

•Small form factor allows easy rigging

•Send power where it needs to go

•Lit indicator displays when power is present

•Resettable breaker protects your gear

PowerStream™ 4 QRG

Page 3 of 4

Product

Overview

AC Power

This product works with an input voltage range of 100~240 VAC, 50/60 Hz.

Set Up

1. Plug in a power cord to the power input.

2. Plug any additional products to the power outputs.

3. You can daisy chain additional PowerStream™ 4 products

by plugging

into any empty power output or the power through.

•Do not exceed 20 amps throughout your entire power run.

•The maximum load for the PowerStream™ 4 is 20 amps. Do not

exceed this rating.

•The maximum current for any power output on the

PowerStream™ 4 is 20 amps. Do not exceed this rating.

Power Input

Power Outputs (x4)

Power Through (+1)

PowerStream™ 4 QRG

Page 4 of 4

Mounting

Before mounting this product, read the Safety Notes at the beginning of this

guide.

Product

Mounting

Diagram

World Headquarters

CHAUVET®

General Information

Address: 5200 NW 108th Avenue

Sunrise, FL 33351

Voice: (954) 929-1115

Fax: (954) 929-5560

Toll free: (800) 762-1084

United Kingdom and Ireland

CHAUVET® Europe Ltd.

General Information

Address: Unit 1C

Brookhill Road Industrial Estate

Pinxton, Nottingham, UK

NG16 6NT

Voice: +44 (0)1773 511115

Fax: +44 (0)1773 511110

Technical Support

Voice: (954) 929-1115 (Press 4)

Fax: (954) 756-8015

Email: tech@chauvetlighting.com

Technical Support

Email: uktech@chauvetlighting.com

World Wide Web

www.chauvetpro.com

World Wide Web

www.chauvetlighting.co.uk

Outside the U.S., United Kingdom, or Ireland, contact your distributor of

record. Follow their instructions to request support or to return a product.

Visit our Web site for contact details.

PowerStream™ 4 QRG – Rev. 7

Printed in the P. R. C.

Mounting Holes (x3)
