BRTRO-420 Drawer Type Reflow Oven Operating Manual
- 1 -
1. Preface
Dear customer, welcome to use our machine.
This manual details the use of the machine, including safety precautions,
performance parameters, and parameter setting method. Spend a little time reading
this manual before formal production, will help you to produce high quality circuit
board safely and efficiently according to your needs.
If there is any problem in using, welcome to contact us. Your satisfaction is our
satisfaction; your success is our success.
2. Precaution
Too high or too low voltage may cause machine work properly, or damage
machine’s electrical control system;
Please do not disassemble, because it can lead to electric shock or poor heat
insulation;
Must use the power cord attached to the machine, the power cord that is
not up to the rated power requirements may cause overheat, even cause
fire;
Keep the machine away from flammable and explosive goods;
Keep the machine clean and ventilated, especially in the back of the
machine, keep at least 20cm of space, to ensure good heat dissipation and
welding effect;
The waste gas from the chimney needs to be collected and processed when
machine running, direct discharge may cause damage to the body, and
cause pollution to the environment;
The waste gas discharged from the chimney and the chimney itself has a
high temperature, rush contact has a risk of being scalded;
Pay attention to prevent waste heat of the drawer when operating.
