Charder MS 2210R Manuel utilisateur

MS 2210R

USER MANUAL

Please keep the instruction manual at hand all the time for future reference.

TABLE OF CONTENTS

PREFACE........................................................................................2

GENERAL INFORMATION..............................................................2

SAFETY INSTRUCTION..................................................................2

ENVIROMENTAL.............................................................................3

CLEANING.......................................................................................3

MAINTENANCE...............................................................................3

WEIGHING OPERATION.................................................................3

WARRANTY-LIABILITY...................................................................4

DISPOSING OF THE SCALE...........................................................5

SPECIFICATION..............................................................................5

KEY FUNCTIONS............................................................................6

INSTRUCTION OF USE ..................................................................7

INSTRUCTION OF CONNECTING WIRELESS SCALE..................8

SWITCHING BETWEEN WIRELESS CHANNEL.............................9

INSTRUCTION OF POWER SUPPLY BY ADAPTOR...................10

INSTALLING BATTERY.................................................................10

POWER SUPPLY ON DECK .........................................................11

MS2210R ENVIRONMENT SET UP..............................................12

ERROR MESSAGE........................................................................14

PREFACE

Thank you for choosing CHARDER MEDICAL product. All features

of this product were designed to state of the art and are optimized

for simple and straightforward use. If you have any queries or

experience any problems not addressed in the operating

instructions, please contact your CHARDER MEDICAL service

partner, or visit us on the Internet at www.chardermedical.com

GENERAL INFORMATION

We strongly recommend you use the scales on flat and hard surface.

Any soft surface, like carpet will cause inaccuracy.

SAFETY INSTRUCTION

Before putting the device into use, please read with care

the information given in the Operating Instructions. They

contain important instructions for installation, proper use and

maintenance of the device.

The manufacturer shall not be liable for damages arising out of

failure to heed the following instructions:

When using electrical components under increased safety

requirements, always comply with the appropriate regulations.

Improper installation will render the warranty null and void.

Ensure the voltage marked on the power supply unit matches

your mains power supply.

This device is designed for use indoors.

Observe the permissible ambient temperatures for use

The device meets the requirements for electromagnetic

compatibility. Do not exceed the maximum values specified in

the applicable standards.

If you have any problem, contact your local CHARDER MEDICAL

service partner.

ENVIROMENTAL

All batteries contain toxic compounds; disposal of batteries

should be delegated to a competent organisation, complying with

the deposit of Poisonous Waste Regulation 1972.

Please do not incinerate batteries.

The optimum operating temperature for the scale is 5 to +35 ;℃ ℃

although it will operate at higher and lower temperatures the

scales battery life will be adversely effected.

CLEANING

We would recommend using alcohol based wipes or similar

when cleaning the scales.

Please do not use large amounts of water when cleaning the

scales as this will cause damage to the scales electronics, you

should also refrain from using corrosive liquids or high pressure

washers.

Always disconnect the scales from the mains power supply

before cleaning.

MAINTENANCE

The scale does not require any routine maintenance.

However, we recommend checking the scale’s accuracy at

regular intervals. The regularity of these checks is dependent on

the level of use and the state of the scale. If any inaccuracies

occur, please contact your local dealer or CHARDER MEDICAL

service partner.

WEIGHING OPERATION

Before reading detailed instructions on how to use all the weighing

functions that are built into your scale, please read the following

important guidelines:

Always be sure that the display shows `Zero` before use, if it

does not then please press the ZERO key.

The device is designed to detect when a stable weight is

achieved, the indicator will `bleep` twice to indicate a stable weight

value, your reading should be taken at this point.

WARRANTY-LIABILITY

If a fault or defect is present on receipt of the unit which is within

CHARDER MEDICAL’s scope of responsibility, CHARDER shall

have the right to either repair the fault or supply a replacement unit.

Replaced parts shall be the property of CHARDER. Should the fault

repairs or replacement delivery not be successful, the statutory

provisions shall be valid. The period of warranty shall be two years,

beginning on the date of purchase. Please retain your receipt as

proof of purchase. Should your scale require servicing, please

contact your dealer or CHARDER MEDICAL Customer Service.

No responsibility shall be accepted for damage caused through

any of the following reasons: Unsuitable or improper storage or use,

incorrect installation or commissioning by the owner or third parties,

natural wear, changes or modifications, incorrect or negligent

handling, overuse, chemical, electrochemical or electrical

interference or humidity, unless this is attributable to negligence on

the part of CHARDER MEDICAL.

If operating, climatic or any other influences lead to a major

change in conditions or material quality, the treaty for perfect unit

functioning shall be rendered null and void. If CHARDER provides

and individual warranty, this means that the unit supplied will be free

of faults for the length of the warranty period.

DISPOSING OF THE SCALE

This product is not to be treated as regular household waste, but

should be handed into an electrical/electronic equipment recycling

centre.

You can obtain further details from your local council, your municipal

waste disposal company or the firm which you purchased the

product.

SPECIFICATION

MODEL MS 2210R

CAPACITY 300kg x100g ;

660lb x 0.2lb

150kg x 50g

330lb x 0.1lb

150kg x 50g

without waving

tare function

ACCURACY

200g ;

0.4lb

100g ;

0.2lb

100g ;

0.2lb

MEASURING

UNIT kg & lb

LCD DISPLAY

1.0” LCD digital display

DIMENSION 900mm(L) x 550mm(W) x 60mm(H)

KEY

FUNCTIONS

ON/OFF , HOLD , UNIT , TARE , channel

Display: 1.5V AA battery & 9V -12V adaptor

POWER SUPPLY

Platform: 1.5V AA battery & Adaptor

OPERATING

TEMPERATURE

5 / 35℃ ℃

KEY FUNCTIONS

Key Description

ON/OFF Press to switch scales ON &OFF

HOLD Press to lock the weight of measured subject.

UNIT Press to switch between kg or lb measuring unit.

TARE Press to tare the weight of subject on platform.

Wireless channel switch between 1 to 3

*Tare the weight of subject previously so that the operator can get

the net weight only.

Face plate with waving tare function

Face plate without waving tare function

INSTRUCTION OF USE

1. Press button to switch on the scale.

2. First, the LCD displays program version and zero symbol

has shown at bottom left. Then LCD displays “0.0kg”

3. Loading the animal.

4. LCD displays the weight of animal

5. Press button to lock the weight of animal while it’s moving.

6. Weight will be locked and display on LCD while weight is stable.

7. Press button again to disable the hold function.

Over weight:

When the weight exceeds the limit of the scale then “Err” code will

appear on LCD. It is recommended to unload the weight to normal

measuring range or will damage the scale.

TARE:

button is to deduct the weight of subject which is on the

platform.

For example:

We usually place a rubber mat on platform before we measure the

animal. A rubber mat weights 1.5kg. When loading the animal the

scale displays 1.5kg more. Because of a rubber mat.

Press button after placing a rubber mat on the platform to

tare the weight before loading animal. You will get “0.0kg”. Then

loading the animal to acquire net weight.

INSTRUCTION OF CONNECTING WIRELESS

SCALE

1.Charder wireless scale MS2210R has a wireless display which

has three wireless channels can serve total three wireless platforms

at one time.

2.Switch channel between 1, 2 or 3 channel at bottom of platform

before connecting to display.

3.Press button to match platform channel. The black arrow

changes from channel 1 , 2 and 3.

4.A wireless symbol appears at

upper left corner when connecting

to wireless platform.

5.A stable symbol appears and system back to zero after

connection completed.

6.Start to weigh after system zero.

Channel 2

Channel 3

Channel 1

SWITCHING BETWEEN WIRELESS CHANNEL

To switch wireless channel at wireless platform, please find the dip

switch at the bottom of the scale. To select any of three channels

please follow drawing below.

***Pin 4 is not in use.

Channel 1

Channel 2

Channel 3
