Channel iCapture Manuel utilisateur
DVR USER MANUAL | 1/1
CHANNEL SAFETY SYSTEMS t: 0845 884 7000 | w: www.channelsafety.co.uk
DIGITAL VIDEO RECORDER (DVR) USER’S MANUAL
CHANNEL SAFETY SYSTEMS t: 0845 884 7000
Peterseld Business Park f: 0845 884 6000
Bedford Road
Peterseld
Hampshire e: sales@channelsafety.co.uk
GU32 3QA w: www.channelsafety.co.uk
™
i
The complete professional CCTV kit
from Channel Safety Systems
DVR USER MANUAL | 1/2
CHANNEL SAFETY SYSTEMS t: 0845 884 7000 | w: www.channelsafety.co.uk
CONTENTS
1. Safety Instructions............................................................................................. 5
2. Chapter 1: Features........................................................................................... 6
3. Chapter 2: Overview ......................................................................................... 7
3.1. Front Panel .................................................................................................. 7
3.1.1 8CH CIF DVR Front Panel ....................................................................... 7
3.1.2 16CH-CIF DVR Front Panel ..................................................................... 8
3.2. Rear Panel.................................................................................................... 9
3.2.1 8CH-CIF DVR Rear Panel...........................................................................9
3.2.2 16CH-CIF DVR Rear Panel..................................................................... 10
3.3 8-CH Remote Controller........................................................................... 11
3.4 16-CH Remote Controller.......................................................................... 12
3.5 Mouse operation........................................................................................13
4. Chapter 3: DVR Installation ............................................................................ 14
4.1 HDD Installation (Applicable to the model with HDD drawer).............. 14
4.2 Camera and Monitor Connection ............................................................ 14
4.3 Power Supply connection ......................................................................... 14
5. Chapter 4: DVR Boot up.................................................................................. 15
5.1 System Initialization.................................................................................. 15
5.2 Live Interface ............................................................................................ 15
6. Chapter 5: DVR Menu .................................................................................... 16
6.1 Pop-up Menu ............................................................................................ 16
6.2 Main Menu Guide ..................................................................................... 17
6.3 Main Menu ................................................................................................ 18
6.3.1 Display................................................................................................... 18
6.3.2 Output Mode..........................................................................................19
6.3.3 Privacy Zone............................................................................................20
6.3.4 Record set: Record Parameters..............................................................21
6.3.5 Schedule..................................................................................................21
6.3.6 Main Stream ...........................................................................................22
6.3.7 Search: Record Search............................................................................22
6.3.8 Channel Select........................................................................................23
6.3.9 Event Search ..........................................................................................23
6.3.10 File Backup.............................................................................................24
6.3.11 File Backup: File Based On Event..........................................................24
6.3.12 File Backup: File Based On Time...........................................................25
6.3.13 Media Player Backup........................................................................25-26
6.3.14 Log Search .............................................................................................27
DVR USER MANUAL | 1/3
CHANNEL SAFETY SYSTEMS t: 0845 884 7000 | w: www.channelsafety.co.uk
6.3.15 Network: Network set............................................................................27
6.3.16 Router’s Port Forwarding.......................................................................27
6.3.17 Sub Stream..............................................................................................27
6.3.18 Email Set .................................................................................................28
6.3.19 Mobile Set...............................................................................................28
6.3.20 DDNS Set.................................................................................................29
6.3.21 Alarm: Motion........................................................................................29
6.3.22 Alarm Set ................................................................................................30
6.3.23 Device: Hard Disk Drive Set ...................................................................31
6.3.24 PTZ Set ....................................................................................................32
6.3.25 Serial Set .................................................................................................33
6.3.26 System: General......................................................................................33
6.3.27 DST Set....................................................................................................33
6.3.28 Network Time Protocol (NTP) Service ...................................................34
6.3.29 Users...................................................................................................34-35
6.3.30 Information ............................................................................................36
6.3.31 Advanced: Maintained......................................................................... 36
6.3.32 Event .......................................................................................................37
6.4 Menu Lock ................................................................................................. 37
6.5 Screen Mode.............................................................................................. 37
6.6 PTZ Control................................................................................................ 38
6.7 PIP Mode.................................................................................................... 39
6.8 Record search ............................................................................................ 39
6.9 Mute........................................................................................................... 39
6.10 Manual Record .......................................................................................... 39
6.11 Stop record ................................................................................................ 39
6.12 Start Sequence........................................................................................... 39
6.13 Start Cruise ................................................................................................ 39
7. Chapter 6: Web Application Manager........................................................... 40
7.1 Plug-in download and installation........................................................... 40
7.2 Web Application Manager Log-in............................................................ 41
7.3 Live interface............................................................................................. 41
7.3.1 Menu Bar .............................................................................................. 43
7.3.2 Live Display........................................................................................... 44
7.3.3 PTZ Control.............................................................................................45
7.3.4 Video Control .........................................................................................45
7.3.5 Record Search.........................................................................................46
7.3.7 Playback Control ...............................................................................47-48
7.3.8 Configuration.........................................................................................49
7.3.9 Display Configuration............................................................................49
CONTENTS CONTINUED....
DVR USER MANUAL | 1/4
CHANNEL SAFETY SYSTEMS t: 0845 884 7000 | w: www.channelsafety.co.uk
7.3.10 Record ...................................................................................................50
7.3.11 Network Parameters .........................................................................51-52
7.3.12 Alarm Set ................................................................................................53
7.3.13 Device......................................................................................................54
7.3.14 System................................................................................................55-56
7.3.14 Advanced...........................................................................................57-59
7.3.15 Local Setting...........................................................................................60
7.3.16 Logout.....................................................................................................60
8. Chapter 7: Appendix...................................................................................... 61
8.1 Operation Function Table.................................................................... 61-63
8.2 Record Alarm setting ................................................................................ 64
8.3 Troubleshooting ........................................................................................ 65
8.4 Usage Maintenance .................................................................................. 65
8.5 System Connection Diagram .................................................................... 66
8.6 Accessories................................................................................................. 67
CONTENTS CONTINUED....
DVR USER MANUAL | 1/5
CHANNEL SAFETY SYSTEMS t: 0845 884 7000 | w: www.channelsafety.co.uk
SAFETY INSTRUCTIONS
Please read all the safety instructions and user manual before the equipment is operated.
1. Power sources
This equipment should be operated only from the type of power source indicated on the marking label. If you are
not sure of the type of power, please consult your supplier.
2. Objects and Liquid
Never push objects of any kind through openings of this equipment and / or spill liquid of any kind on the equip-
ment as they may touch dangerous voltage points or short out parts that could result in a fire or electric shock.
3. Heat sources
Do not install near any heat sources such as radiators, heat registers, stoves or other apparatus (including am-
plifiers that produce heat.
4. Environment
Be careful to ensure your DVR is not installed in a dusty environment or near any magnetic fields.
5. Cleaning
Unplug this equipment from the wall outlet before cleaning it. Do not use liquid aerosol cleaners. Use a damp
soft cloth for cleaning.
6. Extreme weather conditions
Unplug this equipment during lightning storms or when unused for long periods of time.
7. Transportation of equipment
Do not place this equipment on unstable trolleys, stands, or tables. When a trolley is used, use caution when
moving the trolley / apparatus combination to avoid injury from tip-over. Disconnect the power before moving
the equipment. And the equipment should be moved with care.
8. Attachment
Never add any attachments and/or equipment without the approval of the manufacturer, as such additions may
result in the risk of fire, electric shock and other personal injury.
9. Correct Batteries
Risk of explosion occurs if battery is replaced by an incorrect type. Therefore you must use the same type of
battery as the one being used in the product.
10. Ventilation.
Do not block any ventilation openings, installation of the equipment in the rack should be such that the amount
of airflow required for safe operation of the equipment is not compromised.
11. Overloading
Do not overload wall outlets and extension cords to avoid the risk of fire or electric shock.
12. Reliable Earth connections (Grounding)
Reliable grounding of rack mounted equipment should be maintained. Particular attention should be given to
supply connections other than direct connections to the branch circuit.
DVR USER MANUAL | 1/6
CHANNEL SAFETY SYSTEMS t: 0845 884 7000 | w: www.channelsafety.co.uk
CHAPTER 1: FEATURES
Features:
• H. 264 video compression format; supports D1 resolution
• ADPCM audio compression format
• Windows Graphical interface; embedded real-time Linux2.6 operation system
• Friendly Menu reminder
• Multiple operation modes (Preview, record, playback, backup, network surveillance and mobile phone moni-
toring)
• Supports Double Encode bit network transmission
• Supports remote live surveillance via 3G mobile networks
• Supports Zoom in/out and sequence function
• The video package time is adjustable
• Multiple alarm record modes
• Rear USB2.0 ports for back-up, upgrade and mouse operation
• With IR remote control operation
• Multiple language OSD
• Support auto-maintain
Function Brief and Description
Real time monitoring
Double video output; with monitor, VGA virtual out-
put port or HDMI Output; Support net-viewer and MP
live surveillance and also support zoom in/out, auto
sequence and PIP display.
Record
H.264 video compression format; record quality/reso-
lution/frame rate adjustable, multiple record modes
(Always, Scheduled, Manual, Alarm, Motion detection
and remote record)
Record storage Support SATA large capacity HDD and save real-time
record image to HDD.
Playback Support DVR single CH and multiple CH Search/Play-
back of recorded files.
Backup Support DVR backup via USB flash drive, removable
drive, Recorder and network.
Alarm Setting Supports HDD & video input alarm management and
external alarm signal inputs.
Network operation Supports remote surveillance by authority users to
increase system security.
Mouse Operation Supports Mouse operation for faster menu naviga-
tion.
PTZ Control Supports PTZ camera operations through RS-485.
DVR USER MANUAL | 1/7
CHANNEL SAFETY SYSTEMS t: 0845 884 7000 | w: www.channelsafety.co.uk
CHAPTER 2: OVERVIEW
3.1 Front Panel
3.1.1 8CH CIF DVR Front Panel
Item Key title or
Indicator Function & Description
1 USB Port Connect to USB2.0 port
2 PLAY Enter into Pop-up Menu; Play record file.
3 PAUSE Pause / play frame by frame manually
4 STOP Stop playing or stop manual record
5 REC Press the button to start manual record.
6 PTZ Enter into PTZ control interface
7 REW
Move to left; Rewind function;
decrease PTZ rotation speed and parameter value;
On preview mode, holding pressing the button to switch GUI operation device
8 Down key Move down
9 FWD Right key, F. Forward key; increase PTZ rotation speed and Parameter value.
Enter into Pop-up Menu; Play record file.
10 MENU/ESC Enter into Main menu, exit or stop playing
11 IR Receiver Receives IR signal from Remote Controller
12 SEARCH Record search
13 MUTE Mute on/off
14 CH- Switch to previous channel
15 CH+ Switch to next channel
16 ALL On live mode, clicking the button will switch to Quad display.
17 Up key Move up
18 menu Enter menu, select
19 Power Indicator If the “Green” indicator is on the system is getting power normally.
20 HDD Indicator When the “Red” indicator flashes it means the hard drive is being read or written
to.
DVR USER MANUAL | 1/8
CHANNEL SAFETY SYSTEMS t: 0845 884 7000 | w: www.channelsafety.co.uk
3.1.2 16CH CIF DVR Front Panel
Item Type Key title or
Indicator Function & Description
1Indicator HDD indicator When the “Red” indicator flashes it means the hard drive is being
read or written to.
2 Power indicator If the “Green” indicator is on, the system is getting power normally
3 IR Receiver Receives IR signal from Remote Control
4Complex Key Menu Enter into main menu / Exit
5 PTZ Enter into PTZ control, select [Enter] / [Edit] operation
6
Direction Key
UP Move up
7 RIGHT Move right / FWD
8 DOWN Move down
9 LEFT Move left / RWD
10
Channel
Select &
numeric input
Single Channel
and numeric
key
1. Number 1~9 stand for numeric 1~9 and CH 1~9.
2. CH11-CH16 select method: press firstly numeric key 1 and then
other numeric key. For example CH16 select firstly press 1, and then
press 6.
3. Holding press key 0 for three seconds may convert current out-
put device
11 Rec. Manual record Press the button to start manual record
12
Play Control
Stop Stop playing and stop manual record
13 By frame Play frame by frame
14 Play Convert to play status
15 Mute Open or close audio input
16 Multi Display Live display Quad mode, 9-split and 16-split mode
17 USB Port USB Port Connect to USB2.0 port
DVR USER MANUAL | 1/9
CHANNEL SAFETY SYSTEMS t: 0845 884 7000 | w: www.channelsafety.co.uk
3.2 Rear Panel
3.2.1 8CH CIF DVR Rear Panel
Item Physical port Function & Description
1 Video input Connect CH1-16 (Virtual) video input（BNC interface（
2 Video output (UP) Main video output; (Down) Spot output (BNC interface)
3 Audio input Connect CH1-4 audio signal input (BNC interface)
4 Audio output Connect audio signal output, including spot main audio output and se-
quence audio output (BNC interface)
5 Audio input Connect (CH5~CH16) Audio input
6 Ethernet: Port Connect LAN, Ethernet (RJ45 interface)
7 Power Switch Turn Power on and off
8 HDMI HDMI Output
9 VGA Port Connect to VGA monitor, such as PC monitor
10 USB Port Connect USB mouse
11 RS-485/Sensor/Alarm RS485/Sensor/Alarm interface (see pin outs below)
12 Power Port Connect power supply - DC12V 4A
DVR USER MANUAL | 1/10
CHANNEL SAFETY SYSTEMS t: 0845 884 7000 | w: www.channelsafety.co.uk
3.2.2 16CH CIF DVR Rear Panel
Item Physical port Function & Description
1 Video input Connect CH1-16 (Virtual) video input（BNC interface（
2 Video output Connect monitor output(BNC interface)
3 Audio input Connect CH1-4 audio signal input (BNC interface)
4 Audio output 2CH output; BNC (interface（
5 Ethernet: Port Connect LAN, Ethernet (RJ45 interface)
6 Power Switch Turn Power on and off
7 HDMI HDMI Output
8 VGA Port Connect to VGA monitor, such as PC monitor
9 USB Port Connect USB mouse
10 RS-485/Sensor/Alarm RS485/Sensor/Alarm interface (see pin outs below)
11 Power Port Connect power supply - DC12V 5A
RS485/Sensor/Alarm port functions:
Alarm input: Connect [-] port of your sensor to G (GND) pin, and [+] port to channel input according to the
alarm device you purchased. Alarm output: Connect to the two ports marked with “out” PTZ Port-Connect
your camera to RS-485A and RS485B accordingly.
Table des matières
Manuels Système de sécurité populaires d'autres marques
EDM
EDM Solution 6+6 Wireless-AE Manuel utilisateur
Highway Safety Group
Highway Safety Group EA401 Manuel utilisateur
Siren
Siren LED GSM Manuel utilisateur
Detection Systems
Detection Systems 7090i Instructions de montage
Se-Kure Controls
Se-Kure Controls MicroMini SK-4841 Manuel utilisateur
Siemens
Siemens FDM273 Manuel utilisateur
