Chamberlain MyQ Manuel utilisateur

Before starting...

YOU MUST HAVE:

• Router with Wi-Fi

• Broadband Internet Connection

• Wi-Fi Hub Serial Number (located on the bottom of the Wi-Fi hub)

To reduce the risk of SEVERE INJURY to persons:

•DO NOT enable the Chamberlain Universal Smartphone Garage Door

Controller if operating either one-piece or swinging doors. To be enabled

ONLY on a sectional door.

Read instructions thoroughly BEFORE beginning.

If using this product with residential door openers,

this product must be used only with door openers

manufactured after 1993 that utilize photoelectric

sensors. The photoelectric sensors are always

located on or near the bottom of the door track.

STOP

INSTALL THE DOOR SENSOR

STEP

Position the door sensor vertically and attach to a clean, dry location on the top

panel of the garage door with fastening strips (provided).

Press in the bottom of the door sensor and remove the front cover. Position

the door sensor vertically and attach to the top panel of the garage door with

screws (provided). Replace the front cover.

LED

Front

Cover Screws

Test BUTTON

Top Panel

of Garage Door Top Panel

of Garage Door

Fastening

Strips

Door

Sensor

Top OR

Install the bracket for the Wi-Fi hub on the ceiling near the garage door opener.

Use the bracket as a template and mark holes for the bracket. Be sure the Wi-Fi

hub is visible when standing in the path of the door. Slide the Wi-Fi hub onto

the bracket. Connect to AC power.

The blue, green, and yellow LEDs on the Wi-Fi hub will blink momentarily

indicating a successful power up. Then the blue LED will blink indicating the

Wi-Fi needs to be setup.

Bracket

Anchors

Screws Wi-Fi Hub

Light

INSTALL THE WI-FI HUB

STEP

APPLE®DEVICES (IPHONE®3GS, 4, 4S, AND 5,

IPOD TOUCH®3RD THROUGH 5TH GENERATION):

1. Connect your Apple®mobile device to your Wi-Fi network.

2. On your Apple®mobile device, go to Settings > Bluetooth, and

turn on Bluetooth.

3. Find the Bluetooth MyQ-nnn device and select MyQ-nnn device to

pair.

4. Follow the mobile device prompts to add the Wi-Fi hub to your Wi-Fi network

and then download the Chamberlain MyQ®Home Control app.

NOTE: It may take a few minutes for the Wi-Fi hub to connect to the Internet.

When fully connected to the Internet, the green LED on the Wi-Fi hub will be

on solid.

5. Launch the app and follow the onscreen instructions.

CONNECT TO THE INTERNET

STEP

ANDROIDTM AND ALL OTHER DEVICES:

1. Go to the mobile device’s Wi-Fi Settings and turn on Wi-Fi.

2. Locate the list of available Wi-Fi networks and select “MyQ-nnn” network.

3. Launch the mobile device’s web browser and type “setup.myqhome.com”

into the web browser’s address bar.

4. The MyQ®Wi-Fi Setup page will open.

5. Follow the steps in the MyQ®Wi-Fi Setup page to complete the setup.

NOTE: The network’s name and its associated security key/password

(if applicable) will be required.

Need help?

Go to the Help section at

www.mychamberlain.com, or call

Chamberlain Technical Support at

1-800-528-9131.

ONE YEAR LIMITED WARRANTY

The Chamberlain Group, Inc. warrants to the ﬁrst retail

purchaser of this product that is free from defect in materials

and/or workmanship for a period of 1 year from the date of

purchase.

NOTICE: To comply with FCC and/or Industry Canada (IC) rules,

adjustment or modiﬁcations of this transceiver are prohibited.

THERE ARE NO USER SERVICEABLE PARTS.

This device complies with Part 15 of the FCC rules and IC

RSS-210. Operation is subject to the following two conditions:

(1) this device may not cause harmful interference, and (2)

this device must accept any interference received, including

interference that may cause undesired operation.

The Chamberlain Group, Inc.

845 Larch Avenue

Elmhurst, Illinois 60126-1196

114A4618

Apple, App Store, iPhone, and iPod touch are trademarks of Apple

Inc., registered in the U.S. and other countries.

Android™ is a registered trademark of Google Inc.

“Made for iPod” and “Made for iPhone” mean that an electronic accessory

has been designed to connect speciﬁcally to iPod or iPhone respectively,

and has been certiﬁed by the developer to meet Apple performance

standards. Apple is not responsible for the operation of this device or its

compliance with safety and regulatory standards. Please note that the use

of this accessory with iPod or iPhone may affect wireless performance.

INSTRUCCIONES RESUMIDAS

Controlador

telefónico

universal

para puertas

de garaje

Antes de comenzar...

NECESITA:

• Router con Wi-Fi

• Conexión a Internet de banda ancha

• Número de serie del distribuidor de Wi-Fi (en la parte inferior de la unidad o

en la tarjeta de conﬁguración)

ADVERTENCIA

Para reducir el riesgo de accidentes LESIÓNES GRAVES:

• NO usar el controlador universal de puertas de garaje para teléfono

inteligente con puertas de una pieza ni puertas giratorias. Activarlo

ÚNICAMENTE en puertas seccionales.

Leer las instrucciones ANTES de comenzar.

Para usar este producto en instalaciones

residenciales, el abre-puerta debe ser un modelo

posterior a 1993, ya que utilizan sensores

fotoeléctricos. Los sensores fotoeléctricos se

encuentran siempre cerca de la parte inferior de la

guía de la puerta.

ALTO
