better AIRFLOW

by DESIGNTM

Custom Fan SolutionsTM

• Suitable for roof or wall mount

• Backward inclined, non-overloading wheels

• Spun aluminum housing

• Weather resistant construction

• Blades & inlets fabricated from aluminum

• Available in single & three phase voltages

• Belt drive capacities to 17,650 cfm

• Direct drive capacities to 2,750 cfm

EXHAUST FANS

CDB & CDD

DOWNBLAST

FANS

FFEEAATTUURREESS&&BBEENNEEFFIITTSS

• Suitable for roof or wall mount (up to model CDB-24/2HP)

• Backward inclined, non-overloading wheels

• Spun aluminum housing for weather resistant durability

• Fully ventilated motor cooling compartment for long motor life

• Quick release latches for easy access to motor compartment

• Blades and inlets fabricated from aluminum

• Variable pitch motor pulley allows for field adjustment and system balancing

• High efficiency wheels and low tip speeds result in quiet operation

• Disconnect switch

• Bird screen

• Vibration isolation

• 110 F max. temperature rating

• Available in the following voltages:

o 115-208/230V 1 phase

o 208/230V 1 phase

o 208/230-460V 3 phase

o 575V 3 phase

CCDDBBBBEELLTTDDRRIIVVEEDDOOWWNNBBLLAASSTTFFAANNSS

AACCCCEESSSSOORRIIEESS//OOPPTTIIOONNSS

• Gravity damper • Motorized damper

• Wall mount sleeve • Roof curb

MODEL HT W B C D E R RO

(LBS)

DAMPER

SQUARE

MANUFACTURE

CODE

CDB-07 25.5 26.3 2 21.0 19.5 12 12.1 16 90 15.0 BDCR7

CDB-08 25.5 26.3 2 21.0 19.5 12 12.1 16 90 15.0 BDCR8

CDB-09 25.5 26.3 2 21.0 19.5 12 12.1 16 90 15.0 BDCR9

CDB-11 25.5 26.3 2 21.0 19.5 12 12.1 16 105 15.0 BDCR11

CDB-13 27.3 29.6 2 21.0 19.5 12 13.3 16 105 15.0 BDCR13

CDB-15 30.6 33.3 2 24.8 23.0 12 14.9 20 130 19.0 BDCR15

CDB-18 32.8 38.3 2 28.0 26.5 12 16.5 24 190 23.0 BDCR18

CDB-20 32.8 38.3 2 28.0 26.5 12 18.0 24 195 23.0 BDCR20

CDB-24 37.8 42.5 2 33.0 31.5 12 23.9 28 215 27.0 BDCR24

CDB-30 40.0 52.0 2 40.0 38.0 12 24.0 36 380 35.0 BDCR30

CDB-36 43.0 66.0 2 44.5 43.0 12 30.8 36 420 35.5 BDCR36

*DO NOT USE FOR CONSTRUCTION CONSULT FACTORY FOR CERTIFIED PRINTS

DIMENSIONS IN INCHES*

20 GAUGE

STEEL

CONTRUCTION

3" FLANGE

CURB (OPTIONAL)

CCDDBBBBEELLTTDDRRIIVVEEDDOOWWNNBBLLAASSTTFFAANNSS

MODEL RPM

MTR

0” S.P.

CFM

SONE / BHP

0.25” S.P.

CFM

SONE / BHP

0.50” S.P.

CFM

SONE / BHP

0.75” S.P.

CFM

SONE / BHP

1” S.P.

CFM

SONE / BHP

1.25” S.P.

CFM

SONE / BHP

1.50” S.P.

CFM

SONE / BHP

CDB-07-14 700 0.25 355

2.0 / 0.02

CDB-07-14 900 0.25 455

4.3 / 0.04

300

2.9 / 0.05

CDB-07-14 1100 0.25 560

6.4 / 0.08

434

5.5 / 0.08

265

5.3 / 0.08

CDB-07-14 1300 0.25 660

6.8 / 0.13

556

6.8 / 0.13

440

6.5 / 0.13

256

6.2 / 0.12

CDB-07-14 1500 0.25 760

11.1 / 0.19

673

11.0 / 0.20

577

10.8 / 0.20

468

10.2 / 0.20

295

9.0 / 0.18

PERFORMANCE

CDB-08-14 700 0.25 512

2.4 / 0.2

CDB-08-14 900 0.25 655

5.0 / 0.05

483

4.5 / 0.06

CDB-08-14 1100 0.25 800

7.3 / 0.09

670

7.1 / 0.10

500

6.4 / 0.10

CDB-08-14 1300 0.25 945

9.8 / 0.14

841

9.5 / 0.15

712

8.8 / 0.17

544

8.5 / 0.16

CDB-08-14 1500 0.25 1095

13.1 / 0.22

1002

12.9 / 0.23

900

12.9 / 0.25

775

12.4 / 0.25

628

11.3 / 0.25

CDB-09-14 800 0.25 715

3.8 / 0.04

428

3.6 / 0.04

CDB-09-14 1000 0.25 895

6.8 / 0.07

701

6.7 / 0.08

CDB-09-14 1200 0.25 1075

9.3 / 0.12

928

9.1 / 0.13

717

9.1 / 0.14

CDB-09-14 1400 0.25 1255

11.6 / 0.19

1136

11.5 / 0.21

984

11.3 / 0.22

771

9.9 / 0.22

CDB-09-13 1600 0.33 1435

16.1 / 0.28

1332

15.7 / 0.30

1211

15.3 / 0.32

1057

14.7 / 0.33

870

13.8 / 0.32

585

13.0 / 0.30

CDB-11-14 800 0.25 735

2.7 / 0.03

CDB-11-14 1000 0.25 920

4.2 / 0.06

710

3.6 / 0.09

CDB-11-14 1200 0.25 1105

6.7 / 0.10

965

6.0 / 0.15

728

5.4 / 0.16

CDB-11-13 1400 0.33 1286

8.7 / 0.16

1212

8.8 / 0.20

986

8.2 / 0.25

788

6.6 / 0.26

CDB-13-14 800 0.25 1298

5.7 / 0.08

1000

6.0 / 0.16

CDB-13-14 900 0.25 1458

7.2 / 0.11

1207

6.4 / 0.13

CDB-13-14 1000 0.25 1622

9.2 / 0.15

1394

8.5 / 0.18

1113

7.5 / 0.19

CDB-13-14 1100 0.25 1781

11.4 / 0.20

1575

10.9 / 0.23

1356

10.0 / 0.25

CDB-13-13 1200 0.33 1943

14.0 / 0.26

1762

13.8 / 0.30

1561

12.7 / 0.32

1288

12.0 / 0.32

CDB-13-12 1300 0.50 2107

13.9 / 0.33

1932

13.9 / 0.36

1756

13.6 / 0.39

1553

11.6 0.40

CDB-13-12 1400 0.50 2272

15.9 / 0.41

2108

15.0 / 0.44

1948

14.7 / 0.48

1769

13.9 / 0.50

1541

12.3 / 0.50

CCDDBBBBEELLTTDDRRIIVVEEDDOOWWNNBBLLAASSTTFFAANNSS

MODEL RPM

MTR

0” S.P.

CFM

SONE / BHP

0.25” S.P.

CFM

SONE / BHP

0.50” S.P.

CFM

SONE / BHP

0.75” S.P.

CFM

SONE / BHP

1” S.P.

CFM

SONE / BHP

1.25” S.P.

CFM

SONE / BHP

1.50” S.P.

CFM

SONE / BHP

CDB-15-14 700 0.25 1807

5.0 / 0.10

1376

4.0 / 0.12

CDB-15-14 800 0.25 2068

7.0 / 0.15

1708

6.1 / 0.18

1066

4.4 / 0.17

CDB-15-13 900 0.33 2330

8.9 / 0.21

2017

8.1 / 0.24

1600

6.9 / 0.26

CDB-15-13 1000 0.33 2586

10.7 / 0.29

2327

9.9 / 0.30

1995

9.1 / 0.35

1446

7.1 / 0.33

CDB-15-12 1100 0.50 2844

10.9 / 0.38

2605

10.9 / 0.42

2321

10.8 / 0.45

1957

9.6 / 0.46

1155

9.3 / 0.39

CDB-15-34 1200 0.75 3106

13.9 / 0.49

2886

13.8 / 0.53

2643

13.5 / 0.57

2343

12.8 / 0.59

1915

11.6 / 0.57

PERFORMANCE

CDB-20-14 500 0.25 2862

5.0 / 0.15

2094

3.7 / 0.17

CDB-20-13 600 0.33 3444

7.5 / 0.25

2890

6.4 / 0.30

CDB-20-12 700 0.50 4010

10.5 / 0.39

3592

9.6 / 0.45

2939

8.1 / 0.47

CDB-20-34 800 0.75 4580

12.7 / 0.58

4229

11.9 / 0.65

3746

10.7 / 0.69

3049

8.9 / 0.68

CDB-20-01 900 1.00 5156

15.5 / 0.81

4849

15.5 / 0.90

4476

14.7 / 0.95

3954

13.5 / 0.96

3224

11.3 / 0.92

CDB-18-14 600 0.25 2344

5.9 / 0.17

1905

5.0 / 0.20

CDB-18-13 700 0.33 2739

8.8 / 0.26

2361

7.8 / 0.30

1830

6.6 / 0.30

CDB-18-12 800 0.50 3138

11.6 / 0.39

2800

10.6 / 0.43

2445

9.5 / 0.46

1681

8.9 / 0.42

CDB-18-34 900 0.75 3529

13.7 / 0.55

3235

12.9 / 0.60

2928

11.9 / 0.63

2559

10.9 / 0.64

CDB-18-01 1000 1.00 3920

14.8 / 0.74

3661

14.8 / 0.79

3384

14.0 / 0.83

3086

12.8 / 0.86

2682

11.9 / 0.85

CDB-24-14 400 0.25 3781

5.8 / 0.17

2437

4.6 / 0.20

CDB-24-34 600 0.75 5687

12.0 / 0.56

5075

11.3 / 0.65

4002

9.4 / 0.65

CDB-24-02 800 2.00 7592

19.2 / 1.29

7141

19.2 / 1.40

6549

18.3 / 1.48

5847

17.5 / 1.52

4964

15.9 / 1.51

2975

16.1 / 1.26

CDB-30-34 400 0.75 6553

7.1 / 0.51

5571

6.2 / 0.59

3674

5.0 / 0.53

CDB-30-32 500 1.50 8186

11.3 / 0.95

7425

10.4 / 1.08

6454

9.1 / 1.11

4953

8.1 / 1.06

CDB-30-02 600 2.00 9840

14.1 / 1.64

9212

14.2 / 1.81

8550

12.6 / 1.90

7701

11.2 / 1.93

6443

10.9 / 1.87

CDB-30-03 700 3.00 11500

17.7 / 2.59

10944

17.6 / 2.79

10393

17.0 / 2.91

9841

15.8 / 3.00

9025

14.9 / 3.00

8054

13.9 / 3.00

6763

13.8 / 2.82

CDB-36-34 300 0.75 8790

5.9 / 0.50

6827

5.0 / 0.61

CDB-36-32 400 1.50 11759

10.6 / 1.14

10441

9.6 / 1.34

8594

8.4 / 1.38

CDB-36-03 500 3.00 14700

15.5 / 2.20

13686

14.7 / 2.47

12514

13.7 / 2.63

10971

12.4 / 2.66

7759

12.4 / 2.31

CDB-36-05 600 5.00 17654

21.0 / 3.77

16771

21.0 / 4.08

15903

19.8 / 4.35

14859

18.8 / 4.50

13638

18.0 / 4.56

12000

17.9 / 4.47

CURB (OPTIONAL)

3" FLANGE

20 GAUGE

STEEL

CONSTRUCTION

CCDDDDDDIIRREECCTTDDRRIIVVEEDDOOWWNNBBLLAASSTTFFAANNSS

FFEEAATTUURREESS&&BBEENNEEFFIITTSS

• Suitable for roof or wall mount

• Backward inclined, non overloading wheels

• Spun aluminum housing for weather resistant durability

• Wire conduit provides protected channel for electrical connections

• Blades and inlets fabricated from aluminum

• Bird screen

• Variable speed control

• 110 F max. temperature rating

• Available in 115V 1 phase

AACCCCEESSSSOORRIIEESS//OOPPTTIIOONNSS

• Gravity damper

• Motorized damper

• Wall mount sleeve

• Roof curb

MODEL HT W B C D E R RO

(LBS)

DAMPER

SQUARE

MANUFACTURE

CODE

CDD-10 14.5 20.8 2 19.0 17.5 12 8.1 8.1 13 12 DR10H

CDD-12 16.3 23.8 2 19.0 17.5 12 10.6 10.6 13 12 DR12H

CDD-25 19.1 26.3 2 21.0 19.5 12 12.1 12.1 16 15 DR25H

CDD-30 19.1 26.3 2 21.0 19.5 12 12.1 12.1 16 15 DR30H

CDD-33 19.1 26.3 2 21.0 19.5 12 12.1 12.1 16 15 DR33H

CDD-50 21.8 29.8 2 21.0 19.5 12 13.3 13.3 16 15 DR50H

CDD-75 23.4 33.3 2 24.8 23.0 12 14.9 14.9 20 19 DR75H

CDD-85 23.4 33.3 2 24.8 23.0 12 14.9 14.9 20 19 DR85H

*DO NOT USE FOR CONSTRUCTION CONSULT FACTORY FOR CERTIFIED PRINTS

DIMENSIONS IN INCHES*

MODEL RPM

MTR

0” S.P.

CFM

SONE/BHP

0.125” S.P.

CFM

SONE/BHP

0.25” S.P.

CFM

SONE/BHP

0.375” S.P.

CFM

SONE/BHP

0.50” S.P.

CFM

SONE/BHP

0.625” S.P.

CFM

SONE/BHP

0.75” S.P.

CFM

SONE/BHP

0.875” S.P.

CFM

SONE/BHP

1” S.P.

CFM

SONE/BHP

CDD-10 1000 0.07 338

3.1 / 0.02

259

3.1 / 0.02

166

3.1 / 0.02

CDD-10 1100 0.07 371

3.7 / 0.02

300

3.7 / 0.02

226

3.7 / 0.02

111

3.7 / 0.02

CDD-10 1200 0.07 405

4.4 / 0.03

339

4.4 / 0.03

275

4.4 / 0.03

188

4.4 / 0.03

CDD-10 1300 0.07 439

5.2 / 0.04

378

5.2 / 0.04

319

5.2 / 0.04

250

5.2 / 0.04

155

5.2 / 0.04

CDD-10 1400 0.07 473

6 / 0.05

416

6 / 0.05

361

6 / 0.05

303

6 / 0.05

227

6 / 0.05

122

6 / 0.05

CDD-10 1500 0.07 507

7.2 / 0.06

453

7.2 / 0.06

402

7.2 / 0.06

351

7.2 / 0.06

288

7.2 / 0.06

211

7.2 / 0.06

CDD-10 1600 0.07 541

8 / 0.07

490

8 / 0.07

442

8 / 0.07

394

8 / 0.07

342

8 / 0.07

275

8 / 0.07

197

8 / 0.07

PERFORMANCE

CDD-12 925 0.18 505

4.1 / 0.03

384

4.1 / 0.03

250

4.1 / 0.03

110

4.1 / 0.03

CDD-12 1025 0.18 559

5.0 / 0.04

451

5.0 / 0.04

335

5.0 / 0.04

205

5.0 / 0.04

CDD-12 1125 0.18 614

6.1 / 0.06

516

6.1 / 0.06

413

6.1 / 0.06

299

6.1 / 0.06

181

6.1 / 0.06

CDD-12 1225 0.18 668

7.3 / 0.08

578

7.3 / 0.08

486

7.3 / 0.08

385

7.3 / 0.08

276

7.3 / 0.08

171

7.3 / 0.08

CDD-12 1325 0.18 723

8.6 / 0.10

640

8.6 / 0.10

555

8.6 / 0.10

465

8.6 / 0.10

369

8.6 / 0.10

267

8.6 / 0.10

172

8.6 / 0.10

CDD-12 1425 0.18 778

10.0 / 0.12

701

10.0 / 0.12

622

10.0 / 0.12

541

10.0 / 0.12

453

10.0 / 0.12

360

10.0 / 0.12

267

10.0 / 0.12

180

10.0 / 0.12

CDD-25 775 0.25 620

2.8 / 0.07

522

2.8 / 0.07

375

2.8 / 0.07

CDD-25 875 0.25 701

3.8 / 0.10

617

3.8 / 0.10

506

3.8 / 0.10

CDD-25 975 0.25 781

4.9 / 0.14

706

4.9 / 0.14

618

4.9 / 0.14

495

4.9 / 0.14

CDD-25 1075 0.25 861

5.8 / 0.19

793

5.8 / 0.19

719

5.8 / 0.19

624

5.8 / 0.19

491

5.8 / 0.19

CDD-30 1100 0.25 911

6.3 / 0.07

838

6.3 / 0.07

756

6.3 / 0.07

656

6.3 / 0.07

532

6.3 / 0.07

CDD-30 1200 0.25 994

7.4 / 0.09

927

7.4 / 0.09

854

7.4 / 0.09

771

7.4 / 0.09

672

7.4 / 0.09

543

7.4 / 0.09

CDD-30 1300 0.25 1077

8.6 / 0.11

1015

8.6 / 0.11

950

8.6 / 0.11

880

8.6 / 0.11

793

8.6 / 0.11

698

8.6 / 0.11

568

8.6 / 0.11

CDD-30 1400 0.25 1160

10 / 0.14

1103

10 / 0.14

1044

10 / 0.14

979

10 / 0.14

907

10 / 0.14

824

10 / 0.14

733

10 / 0.14

606

10 / 0.14

CDD-30 1500 0.25 1243

11.5 / 0.17

1190

11.5 / 0.17

1135

11.5 / 0.17

1076

11.5 / 0.17

1015

11.5 / 0.17

940

11.5 / 0.17

863

11.5 / 0.17

775

11.5 / 0.17

654

11.5 / 0.17

CDD-30 1600 0.25 1326

13.1 / 0.21

1276

13.1 / 0.21

1225

13.1 / 0.21

1171

13.1 / 0.21

1114

13.1 / 0.21

1053

13.1 / 0.21

980

13.1 / 0.21

906

13.1 / 0.21

824

13.1 / 0.21

CCDDDDDDIIRREECCTTDDRRIIVVEEDDOOWWNNBBLLAASSTTFFAANNSS

MODEL RPM

MTR

0” S.P.

CFM

SONE/BHP

0.125” S.P.

CFM

SONE/BHP

0.25” S.P.

CFM

SONE/BHP

0.375” S.P.

CFM

SONE/BHP

0.50” S.P.

CFM

SONE/BHP

0.625” S.P.

CFM

SONE/BHP

0.75” S.P.

CFM

SONE/BHP

0.875” S.P.

CFM

SONE/BHP

1” S.P.

CFM

SONE/BHP

CDD-33 1100 0.33 859

6.3 / 0.09

783

6.3 / 0.09

715

6.3 / 0.09

635

6.3 / 0.09

535

6.3 / 0.09

CDD-33 1200 0.33 938

7.5 / 0.12

868

7.5 / 0.12

803

7.5 / 0.12

739

7.5 / 0.12

657

7.5 / 0.12

555

7.5 / 0.12

CDD-33 1300 0.33 1016

8.7 / 0.15

951

8.7 / 0.15

890

8.7 / 0.15

833

8.7 / 0.15

765

8.7 / 0.15

685

8.7 / 0.15

579

8.7 / 0.15

CDD-33 1400 0.33 1094

10.1 / 0.19

1034

10.1 / 0.19

975

10.1 / 0.19

923

10.1 / 0.19

868

10.1 / 0.19

799

10.1 / 0.19

721

10.1 / 0.19

617

10.1 / 0.19

CDD-33 1500 0.33 1172

11.6 / 0.23

1116

11.6 / 0.23

1060

11.6 / 0.23

1010

11.6 / 0.23

961

11.6 / 0.23

904

11.6 / 0.23

839

11.6 / 0.23

763

11.6 / 0.23

667

11.6 / 0.23

CDD-33 1600 0.33 1250

13.1 / 0.28

1198

13.1 / 0.28

1145

13.1 / 0.28

1097

13.1 / 0.28

1051

13.1 / 0.28

1004

13.1 / 0.28

945

13.1 / 0.28

884

13.1 / 0.28

812

13.1 / 0.28

PERFORMANCE

CDD-50 1050 0.5 1631

8.4 / 0.13

1510

8.4 / 0.13

1375

8.4 / 0.13

1210

8.4 / 0.13

1015

8.4 / 0.13

791

8.4 / 0.13

CDD-50 1150 0.5 1787

9.7 / 0.17

1677

9.7 / 0.17

1557

9.7 / 0.17

1426

9.7 / 0.17

1258

9.7 / 0.17

1074

9.7 / 0.17

866

9.7 / 0.17

CDD-50 1250 0.5 1942

11.3 / 0.22

1841

11.3 / 0.22

1735

11.3 / 0.22

1618

11.3 / 0.22

1480

11.3 / 0.22

1323

11.3 / 0.22

1151

11.3 / 0.22

964

11.3 / 0.22

CDD-50 1350 0.5 2097

13 / 0.27

2004

13 / 0.27

1909

13 / 0.27

1801

13 / 0.27

1693

13 / 0.27

1550

13 / 0.27

1402

13 / 0.27

1243

13 / 0.27

1079

13 / 0.27

CDD-50 1450 0.5 2253

14.8 / 0.34

2166

14.8 / 0.34

2078

14.8 / 0.34

1981

14.8 / 0.34

1880

14.8 / 0.34

1767

14.8 / 0.34

1635

14.8 / 0.34

1494

14.8 / 0.34

1346

14.8 / 0.34

CDD-85 1150 0.75 2366

11.1 / 0.25

2251

11.1 / 0.25

2134

11.1 / 0.25

2003

11.1 / 0.25

1866

11.1 / 0.25

1703

11.1 / 0.25

1526

11.1 / 0.25

1331

11.1 / 0.25

1102

11.1 / 0.21

CDD-85 1250 0.75 2572

12.8 / 0.33

2467

12.8 / 0.33

2359

12.8 / 0.33

2244

12.8 / 0.33

2122

12.8 / 0.33

1987

12.8 / 0.33

1837

12.8 / 0.33

1674

12.8 / 0.33

1499

12.8 / 0.33

CDD-85 1350 0.75 2778

14.7 / 0.41

2681

14.7 / 0.41

2581

14.7 / 0.41

2480

14.7 / 0.41

2367

14.7 / 0.41

2254

14.7 / 0.41

2122

14.7 / 0.41

1984

14.7 / 0.41

1834

14.7 / 0.41

CDD-75 775 0.75 1686

7.1 / 0.22

1532

7.1 / 0.22

1356

7.1 / 0.22

1141

7.1 / 0.22

CDD-75 875 0.75 1904

8.8 / 0.31

1768

8.8 / 0.31

1617

8.8 / 0.31

1449

8.8 / 0.31

1248

8.8 / 0.31

CDD-75 975 0.75 2121

10.6 / 0.43

2000

10.6 / 0.43

1870

10.6 / 0.43

1729

10.6 / 0.43

1569

10.6 / 0.43

1384

10.6 / 0.43

1086

10.6 / 0.43

CDD-75 1075 0.75 2339

12.7 / 0.57

2230

12.7 / 0.57

2116

12.7 / 0.57

1989

12.7 / 0.57

1859

12.7 / 0.57

1709

12.7 / 0.57

1540

12.7 / 0.57

1294

12.7 / 0.57

CDD-75 1175 0.75 2557

14.9 / 0.75

2457

14.9 / 0.75

2354

14.9 / 0.75

2243

14.9 / 0.75

2126

14.9 / 0.75

2001

14.9 / 0.75

1865

14.9 / 0.75

1712

14.9 / 0.75

1523

14.9 / 0.75

CCDDDDDDIIRREECCTTDDRRIIVVEEDDOOWWNNBBLLAASSTTFFAANNSS

CDB/CDD-0807

CDB & CDD DOWNBLAST FANS

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels CFM Ventilateur

CFM

CFM TNC-0506 Manuel utilisateur

CFM

CFM DVK-0910 Manuel utilisateur

CFM

CFM TF140-EC Guide de maintenance et de service

CFM

CFM AXP100 Guide de maintenance et de service

CFM

CFM GEF10 Instructions d'utilisation et de sécurité

CFM

CFM AFK-0906 Manuel utilisateur

CFM

CFM AIB-1006 Manuel utilisateur

CFM

CFM TBF120 Instructions d'installation et d'utilisation

CFM

CFM CF Guide de maintenance et de service

CFM

CFM SEF Instructions d'installation et d'utilisation

CFM

CFM TEK225H-H2 Manuel utilisateur

CFM

CFM 109539 Manuel utilisateur

CFM

CFM TF100-EC Guide de maintenance et de service

CFM

CFM DVK-T Guide de maintenance et de service

CFM

CFM MFT-S Series Instructions d'installation et d'utilisation

CFM

CFM AXC Series Guide de maintenance et de service

CFM

CFM HRV-0904 Manuel utilisateur

CFM

CFM TBF90 Instructions d'installation et d'utilisation

CFM

CFM TF140-DC Guide de maintenance et de service

CFM

CFM ABP-0905 Manuel utilisateur

CFM

CFM CF Guide de maintenance et de service

CFM

CFM RMD-0807 Manuel utilisateur

CFM

CFM ECO-FLO Guide de maintenance et de service

CFM

CFM AXC100B Manuel utilisateur

Manuels Ventilateur populaires d'autres marques

ELTA FANS

ELTA FANS H03VV-F Manuel utilisateur

Hunter

Hunter 20714 Manuel d'instructions

Emerson

Emerson CARRERA VERANDA CF542ORB00 Manuel utilisateur

Hunter

Hunter Caraway Manuel d'instructions

Panasonic

Panasonic FV-15NLFS1 Manuel utilisateur

Kompernass

Kompernass KH 1150 Manuel utilisateur

VES

VES FALA100/12V/TR Manuel utilisateur

Vertiv

Vertiv Liebert DCD Manuel utilisateur

Westinghouse

Westinghouse GFP Series Manuel utilisateur

Venmar

Venmar KUBIX HRV PLUS Series Manuel utilisateur

Maico

Maico ECR 31 Manuel utilisateur

Sonnenkonig

Sonnenkonig Dinky Manuel utilisateur

S&P

S&P ECOWATT HXBR Manuel utilisateur

Wider

Wider IMP03369BH Manuel utilisateur

Panasonic

Panasonic F-60DHN Manuel utilisateur

Hinkley

Hinkley HIGHLAND Manuel utilisateur

Broan

Broan 766BN Manuel utilisateur

Premium

Premium PFS16022 Instructions de montage
