CF MOTO UFORCE 1000 Manuel utilisateur

UFORCE

1000

This ROV should not be ridden by anyone under 16

years of age. Passenger under 12 are prohibited.

CF1000UU

OWNER’S MANUAL

READ THIS MANUAL CAREFULLY

It contains important safety information

TABLE OF CONTENTS

EVAP System (Evaporative Emission Control System) �� 2

Signal Words�� 3

Vehicle Identication Numbers and Key Information�� 7

UFORCE 1000 Specications�� 8

Operator Safety �� 15

General Safety Precautions �� 15

Owner Responsibilities�� 19

Safety Labels, Locations and Warnings�� 24

Potential Hazard Warnings�� 29

Controls and Features�� 46

Primary Controls �� 46

Secondary Controls�� 50

Vehicle Features �� 55

CVT System �� 65

How To Avoid CVT Drive Belt and Component Failure �� 66

Dashboard Indicators and Warnings�� 68

Operating Your Vehicle�� 76

Break-In Period �� 76

Pre-Ride Inspection�� 78

Throttle �� 78

Foot Brake�� 78

Starting the Engine�� 79

Shifting the Transmission �� 80

Safe Operation - Driving Safely�� 83

Responsibilities of the Operator �� 83

Practice Exercises�� 87

Operating Your Vehicle�� 90

Hauling and Towing Loads �� 95

Maintenance�� 100

Severe Use Denition �� 101

Periodic Maintenance Schedule and Icon Key�� 102

General Recommended Lubrication �� 103

Pre-Ride Maintenance Checklist�� 104

Break-In Maintenance Checklist �� 106

Periodic Maintenance Schedule�� 108

Maintenance Procedures �� 115

Cleaning and Storage �� 147

Transporting the Vehicle �� 151

Vehicle Issue Diagnosis �� 152

Engine doesn’t turn over �� 152

Engine pings or knocks �� 152

Engine stops or loses power �� 153

Engine turns over, Fails to start�� 155

Engine backres �� 156

Engine turns over, Fails to start�� 156

EFI Malfunction Indicator Light �� 158

EPS Malfunction Indicator Light �� 160

Electronic Power Steering (EPS) Fault Diagnosis and Solution �� 162

CFMOTO Limited Warranty�� 163

Warranty Terms & Conditions �� 163

U�S�A� EPA and CARB Emissions Control Limited Warranty �� 171

Noise Control System and Tampering �� 174

Change of Ownership �� 175

Foreword

Welcome

Thank you for purchasing a CFMOTO vehicle, and welcome to our world-wide family of CFMOTO

enthusiasts. Be sure to visit us online at www.cfmoto.com for the latest news, new product introductions,

upcoming events, and more.

CFMOTO is an international company that specializes in the development, manufacture, and marketing of

all-terrain vehicles, utility vehicles, large displacement motorcycles, and their core components. Founded

in 1989, CFMOTO is devoted to the development of independent brand cultivation and R&D innovation.

CFMOTO products are currently distributed through more than 2000 companions worldwide in more than 100

countries and regions. CFMOTO is edging into the advanced ranks in the world of powersports, and aims to

supply superior products to dealers and fans globally.

For safe and enjoyable operation of your vehicle, be sure to follow the instructions and recommendations

in this owner’s manual. Your manual contains instructions for minor maintenance. Information about major

repairs is outlined in the CFMOTO Service Manual.

Your CFMOTO dealer knows your vehicle best and is interested in your total satisfaction. Be sure to return to

your dealership for all of your service needs during, and after, the warranty period.

Due to constant improvements in the design and quality of productions components, some minor

discrepancies may result between the actual vehicle and the information presented in this publication.

Depictions and/or procedures within are intended for reference use only.

Foreword

WARNING

The engine exhaust from this product contains chemicals known to the State of California to cause

cancer, birth defects or other reproductive harm.

EVAP System (Evaporative Emission Control System)

Do not modify the EVAP system. Modication is a violation of EPA regulations. Ensure that all the hoses are

not clogged or kinked, otherwise it could damage the fuel pump or distort the fuel tank.

Catalytic Converter

CAUTION - Please respect the following instructions to protect your catalytic converter:

•Use only unleaded gasoline. Even if the gasoline contains a little lead, it could damage the reactive

metals contained in the catalytic converter and disable it.

•Never add rust preventive oil and engine oil into muffler, otherwise it could disable the catalytic

converter�

NOTE:

Some features described within this manual may not apply to models sold in North America. All descriptions

and directions given are from the operator’s perspective when seated in the vehicle.

Foreword

Signal Words

A signal word calls attention to a safety message or messages, a property damage message or messages,

and designates a degree or level of hazard seriousness. The standard signal words in this manual are

WARNING, CAUTION and NOTE or NOTICE.

The following signal words and symbols appear throughout this manual and on your vehicle. Your safety is

involved when these words and symbols are used. Become familiar with their meanings before reading the

manual:

WARNING

This safety alert and icon indicates a potential hazard that may result in serious injury or death.

CAUTION

This safety alert and icon indicates a potential hazard that may result in minor or moderate personal injury

and/or damage to the vehicle�

CAUTION

This safety alert without an icon indicates a situation that may result in damage to the vehicle.

NOTE or NOTICE

A note or notice will alert you to important information or instructions.

Foreword

NEVER:

• Operate without proper training or instruction.

• Operate on public roads. A collision can occur with another vehicle.

• Operate on paved roads. Pavement may seriously a󰀨ect handling and control.

• Operate at speeds too fast for your skill, conditions, or the terrain.

• Use ALCOHOL or DRUGS before or while driving this vehicle.

ALWAYS:

• Avoid paved surfaces, which may adversely a󰀨ect the handling and control.

• Use proper driving techniques to avoid vehicle overturn on hills, rough terrain, and when turning.

• Wear eye protection, helmet and protective clothing.

Foreword

READ THE OWNER’S MANUAL

FOLLOW ALL INSTRUCTIONS AND WARNINGS

WARNING

Read, understand, and follow all of the instructions and safety precautions in this manual and on all

product labels. Failure to follow the safety precautions could result in serious injury or death.

WARNING

The engine exhaust gas from this product contains CO, which is deadly gas and could cause

headaches, giddy, or lose consciousness, even death.

IntroductIon

Introduction

Thank you for purchasing a CFMOTO vehicle, and welcome to our world-wide family of CFMOTO

enthusiasts.

For safe and enjoyable operation of your vehicle, be sure to follow the instructions and recommendations

in this owner’s manual. Information about major repairs are outlined in the CFMOTO Service Manual, and

should only be performed by a CFMOTO service dealer and technician. Be sure to return to your dealership

for all of your service needs during, and after, the warranty period.

If you have questions or concerns about your vehicle

All questions or concerns related to your vehicle should be directed to your local CFMOTO dealer rst. Your

dealer knows your vehicle best and is interested in your total satisfaction. In the event your local dealer is

unable to resolve a product issue or concern, you can reach a CFMOTO customer service representative

depending on the market you reside in:

For USA: Please contact CFMOTO POWERSPORTS, INC. TEL: 763-398-2690, by e-mail: info@cfmotousa.

com, or online: https://cfmotousa.com/customer-care/customer-care-contact. Please note that customer

service does not have authority to approve or deny warranty, and cannot provide technical repair data,

diagnosis, or instructions.

For CANADA: Please contact CANADA MOTOR IMPORT INC. TEL: 1-418-227-2077, or online: https://www.

cfmoto.ca/en/customer-care/.

For a safety concern related to your Canadian vehicle, you may report your concern to Transport Canada

Defect Investigation and Recalls Division by mail, telephone, or online using the contact information below:

Mailing address: Transport Canada - ASFAD, 330 Sparks Street, Ottawa, ON, K1A 0N5

TEL: 819-994-3328 (Ottawa-Gatineau area or international) or toll-free: 1-800-333-0510 (In Canada)

Online: http://www.tc.gc.ca/recalls
