6 Chapter 2 General description of the device
•When the sensors cannot be deployed at the desired measuring point, the
LF010 allows you to apply different OFFSETS to each sensor.
•The XP010 MAIN sensor and the XS010 SECONDARY sensors have a
CLASS 1 measuring accuracy according to IEC 61672-1. The 50 Hz to 5 kHz
1/3 octave band filters comply with IEC 61260 and the CTE (National Building
Code).
•It detects TAMPERING of the limiter, sensors and sound system: Emission
and reception limit exceedance, parallel sources, tampering of the limiter and
the sound system chain, and tampering, disconnection or change of the main
and secondary sensors. The LF010, the XP010 main sensor and the XS010
secondary sensors are fully sealable.
•It records sound levels and incidents on a BY MINUTE basis and can commit
two years of information to memory every 10 minutes. It also records all
actions performed in the limiter, keeping track of what has been done, when
and by whom.
•The LF010 also has a front COLOUR TOUCHSCREEN to display the
measured information and communication status.
Full HD 1080p VIDEO OUTPUT:
•The video output is compatible with HDMI DISPLAYS and allows the sound
engineer/DJ to view clear and user-friendly information in real time to keep the
sound levels under optimal control and below the limit. This new approach
gives control to the DJ so that the limiter does not have to abruptly attenuate
the sound level.
•It allows the activity owner to afford greater exposure to the EVENTS,
PARTIES and ADVERTISEMENTS of sponsoring brands or to showcase their
own articles and promotions.
ADAPTABLE LIMITATION AND CONTROL:
•It enables you to program different emission and reception LIMITS for the
three DAY/EVENING/NIGHT time zones.
•It has different control modes for emission and reception and
ATTACK/RELEASE that can be configured with different speeds
(slow/medium/fast).
•It includes a MUSIC GAP detection system that maintains attenuation
between song tracks, making it ideal for playlists or CDs with gaps between
tracks.
•It features the ENOS (Extraneous Noise Override System) system that allows
uncut playback or kills audience shouting or clapping: Live concerts, sports
broadcasts, etc.
•The LF010 limiter can completely MUTE the music if the limiter is not
connected to the mains, it can switch off the main sensor, apply periods of
silence at the end of the session (schedule control) or activate a voice-
operated alarm for evacuation and emergency applications.
EASY TO INSTALL:
•It is very easy to install, as it has a built-in responsive design web server that
allows you to install, program and download data from a laptop, tablet or
