Centrios 1713161 Manuel utilisateur

Wireless Talk

Bluetooth Headset

with Charging Dock

Owner’s Manual

COMMUNICATIONS

1713161

Table of Contents

1. Brief Introduction................................................ 3

1.1 What is Bluetooth? ................................................... 3

1.2 Bluetooth Headset 1713161 ................................... 3

2. Overview .............................................................. 4

3. Getting started.................................................... 5

3.1 Charging ...................................................................... 5

3.2 Wearing the headset ............................................. 6

4. How to use........................................................... 7

4.1 Turn On/Off the headset....................................... 7

4.2 Pairing with cell phone ......................................... 7

4.3 Pairing with other Bluetooth devices.............. 7

4.4 To make a call........................................................... 8

4.5 Indicators ................................................................... 8

5. Maintenance and Care....................................... 9

6. Speciﬁcations...................................................... 10

Congratulations on the purchase of your quality Centrios Wireless Talk

Bluetooth Headset with Charging Dock featuring Bluetooth technology for

wireless conversation. Before using it, please read the user’s manual carefully.

1. Brief Introduction

1.1 What is Bluetooth?

Bluetooth technology is a close range of radio technology to transmit signals

wirelessly over short distances between mobile phones, computers, headphones,

printers, PDAs and other devices.

1.2 Centrios 1713161

Bluetooth headset

This Bluetooth headset is compatible with any Bluetooth device. It features

crystal clear sound, 9 hours talk time and 170 hours standby time. This Bluetooth

headset is stylish in a small, ultra light-weight design. You can wear it both on

your right or left ear with the included ear hook and rubber ear-piece cap. It

performs well even in noisy conditions. After paired and connected with your

Bluetooth mobile phone, you can have conversations wirelessly with the headset.

The features are:

 • Answercall,endcallandrejectcallwirelessly

 • Rediallastcall

 • Voicedial

 • Adjustvolume

 • SwitchtheconversationbetweenBluetoothheadsetandthephone

 • Deletecurrentconnectingdeviceandconnectwithotherdeviceimmediately

 • Microphonemute

 • Call-waiting(yourphonemustsupportthisfunction)

 • Supportsthree-wayconversations(yourphonemustsupportthisfunction)

2. Overview

1. Ear hook

 2.MFB:Turnonandofftheheadset/Answerthecall/Rejectthecall/Dialthe

  lastnumber(Note: MFB=multi-functionbutton)

3. Indicator

 4.Microphone

 5.Volume+

 6.Volume-/voicedial

7. Dock

 8.Rubberear-piececap

1. Ear hook

3. Indicator

7. Dock

4.Microphone

8.Rubberearcap

5.Volume+

6.Volume-/voicedial

2.MFB

3. Getting Started

3.1 To Charge

Initial Charge

Before you use this Bluetooth headset, please place the headset on the dock,

thenplugtheminiUSBtothedockandchargeitfor2hours.

Subsequent Charges

When you hear a low battery warning sound and the red light blinks, you must

recharge the headset.

a. As the picture shows, place the headset onto the dock and plug the mini

  USBporttothedock.Payattentiontothedirectionoftheport,toavoid 

damaging the port.

b. When the adapter is connected with the power supply, the headset comes

into charging status, red light turns on and after 2 hours, once the battery is

charged, the red light turns off.

3.2 Wearing the headset

Rubber Earpiece Cap

 • YoucanplacetheearpiececapontheBluetoothHeadsetsoitcanbeused

for both left/right ears.

 • Placetheheadsetinyourear,turnittowardsyourmouthandturn

the headset.

With the ear hook

 • Removethebiggerrubbercapandplacethesmallrubbercaponthe 

earpeice. Install the ear hook as per the below picture. The hook can be

worn on your left or right ear by turning in either direction.

4. How to Use

4.1 Turn On/Off the headset

 • PresstheMFBfor5seconds,youwillhearaDItoneaswellasbluelight 

blinking once. The headset is then turned on.

 • PresstheMFBfor2to3seconds,youwillhearaDItoneaswellasbluelight

blinking once. Then the headset is turned off.

 • Iftheheadsethasbeenonformorethan10minuteswithoutndinga 

pairing device, then it will turn off automatically to save power.

 • Therewillbeanindicatortoneandaredlightblinkingwhenthebattery 

power is low.

Note: The headset will turn off automatically when the battery power is low.

4.2 Pairing with cell phone

 • Theheadsetmustbepairedwiththecellphonebeforeitisconnected.Please

keep them within a distance of 5 meters when pairing them.

 • WhenOff,presstheMFBfor7to8secondsandyouwillhearaDItone 

indicator and a DONGDONG indicator, the red and blue lights then blink. The

headset is in pairing status now.

 • Refertoyourcellphone’smanualforinformationonndingBluetooth

paired devices.

 • Pleaseselect1713161Centriosinthelistandconrmaccordingtothecell

  phone.Inputthecode1234,thenpairingshouldbesuccessfullynished.

4.3 To make a call

 • Theheadsetwillonlyconnectwiththelastpaireddeviceautomatically.Ifyou

wish to pair with a new device you will have to pair the device with the

  headsetagain.Pleaserefereto“Pairingwithcellphone”fordetails(4.2).

Function Status Operations

Cell phone Headset The headset

 Voicedial Standby Turningon PresstheVolume+(for2seconds)

until a tone is heard

Redialthe Standby Turningon PresstheMFBonce

last number

 Adjustthe Conversation Converstation PresstheVolume+and-

 Volume

 Endthecall Conversation Converstation PresstheMFBonce

 Accepting Ringing Turningon PresstheMFBonce

the call

 Rejectthecall Ringing Turningon PresstheMFB(for2seconds)

 Switchthecall Conversation Turningon PresstheVolume+for(2seconds)

to cell phone

 Mute Conversation Conversation PresstheVolume+and-for(2secs.)

    Simultaneouslyandreleaseit

4.5 Indicators

Charging

Indicator Status

Redlightsturnson Charging

 Redlightturnsoff Chargingcomplete

4.4 To make a call

The headset supports both handsfree and headset functions. How to dial depends on

what your cell phone supplies.

Remark: Not all cell phones support all the functions listed below, please refer to your

cell phone or user manual.

Connected with cell phone

Indicator Status Remark

 Bluelightblinksevery1sec. Standbypairedbutnotconnected

 Bluelightblinkstwice Standbyandconnectedwith

every 4 secs. other devices

Blue light blinks once every sec. Conversation

Blue and red light blink alternately Pairing

Redlightwill

turn on to

indicate the

low battery

5. Maintenance and Care

Pleaserefertofollowingsuggestionsthatwillhelpyoutofulllanywarranty

obligationsandtoenjoythisproductformanyyears.

1. Keep this kit dry. Humidity and all types of liquids or moisture will corrode

the electronic circuits

 2.Don’tstoretheheadsetinhotareas.Hightemperaturescanshortenthelifeof

electronic devices, damage batteries and warp or melt certain plastics.

 3.Don’tattempttoopentheheadset.

 4.Don’tdrop,knockorshaketheheadset.Roughhandlingcanbreakinternal

circuit boards.

 5.Don’tuseharshchemicals,cleaningsolvents,orstrongdetergentstoclean

the headset.

 6.Storecarefullywhennotinusetopreventbreakage.

 7.Pleasehavetheheadsetrepairedbyqualiedpersonnelonly.

6. Speciﬁcations

Bluetooth BluetoothV2.0+EDR

Operating Frequency Band 2.402GHz~2.480GHzunlicensedISMband

Modulate methods GFSK

Sensitivity BER=0.1%understandardconditions:-80dB

Corresponding speed 2Mbps(Max)

Function Range 10m

Working time Up10h

Standby time 240h

Input Voltage DC:+5.0±0.25V/300mA

Working temperature -20+75˚C

Charging time 2.0~2.5h

Dimensions 47*18*10.mm

Weight 12g
