Central Machinery 93012 Manuel utilisateur

16 INCH VARIABLE SPEED

ASSEMBLY AND OPERATING INSTRUCTIONS

3491 MISSION OAKS BLVD., CAMARILLO, CA 93011

VISIT OUR WEB SITE AT HTTP://WWW.HARBORFREIGHT.COM

this manual or any artwork contained herein may be reproduced in any shape or

form without the express written consent of Harbor Freight Tools.

For technical questions and replacement parts, please call 1-800-444-3353

93012

SCROLL SAW

Page 2

SKU 93012 For technical questions, please call 1-800-444-3353

SPECIFICATIONS

rotoM)putrats(A4.0,zH06,esahpelgnis,CAV021

droCrewoPdednuorggnorp-eerht,)L("7'6

hctiwSyekgnikcolelbavomerh

tiw,ffO/nO,elggoT

tliTelbaT)tfel(seerged54ot0

htpeDgnittuC)mumixam(sehcni2

epyTedalB .sretpadadedivorphtiwe

dalbdnenialpesunaC;edalbdnEniPL"5

enihcamnodetnuomedalbIPT51

htpeDtaorhTsehcni61

ekortSedalBhcni1

deepSgnit

tuCelbairaV;etuniMrepsekortS0061ot).nim(004

snoisnemiDllarevOsehcni)L(42x)W(01x)H(4/3-11

snoisnemiDesaBseh

cni)L(8/5-51x)tsediwta(4/3-8

seloHgnitnuoMesaBseloh).aid(hcni61/5-4

thgieW.sbl32

seirosseccA ;sretpadAedalB

dnenialP-2;)mm4dna5.2(sehcnerWxeH-2

edalBwaSIPT81erapS-1

serutaeF tropmuucaVDO"2/1-1,pmupriaswollebdetar

getnI,tnemtsujdatoofporD

SAVE THIS MANUAL

You will need the manual for the safety warnings and precautions, assembly instructions,

operating and maintenance procedures, parts list and diagram. Keep your invoice with this

manual. Write the invoice number on the inside of the front cover. Keep the manual and

invoice in a safe and dry place for future reference.

GENERAL SAFETY RULES

WARNING!

READ AND UNDERSTAND ALL INSTRUCTIONS. Failure to follow all instructions

listed below may result in electric shock, fire, and/or serious injury.

SAVE THESE INSTRUCTIONS

Work Area

1. Keep your work area clean and well lit. Cluttered benches and dark areas invite

accidents.

2. Do not operate power tools in explosive atmospheres, such as in the presence

of flammable liquids, gases, or dust. Power tools create sparks which may ignite the

dust or fumes.

3. Keep bystanders, children, and visitors away while operating a power tool.

Distractions can cause you to lose control. Protect others in the work area from debris

such as chips and sparks. Provide barriers or shields as needed.

CUS

187941

REV 05/05;09/05

Page 3

SKU 93012 For technical questions, please call 1-800-444-3353

Electrical Safety

4. Avoid body contact with grounded surfaces such as pipes, radiators, ranges,

and refrigerators. There is an increased risk of electric shock if your body is

grounded.

5. Do not expose power tools to rain or wet conditions. Water entering a power tool

will increase the risk of electric shock.

6. Grounded tools must be plugged into an outlet properly installed and grounded

in accordance with all codes and ordinances. Never remove the grounding

prong or modify the plug in any way. Do not use any adapter plugs. Check with

a qualified electrician if you are in doubt as to whether the outlet is properly

grounded. If the tools should electrically malfunction or break down, grounding

provides a low resistance path to carry electricity away from the user.

7. Double insulated tools are equipped with a polarized plug (one blade is wider

than the other). This plug will fit in a polarized outlet only one way. If the plug

does not fit fully in the outlet, reverse the plug. If it still does not fit, contact a

qualified electrician to install a polarized outlet. Do not change the plug in any

way. Double insulation eliminates the need for the three wire grounded power

cord and grounded power supply system.

8. Do not abuse the Power Cord. Never use the Power Cord to carry the tools or

pull the Plug from an outlet. Keep the Power Cord away from heat, oil, sharp

edges, or moving parts. Replace damaged Power Cords immediately. Damaged

Power Cords increase the risk of electric shock.

9. When operating a power tool outside, use an outdoor extension cord marked

“W-A” or “W”. These extension cords are rated for outdoor use, and reduce the risk of

electric shock.

Personal Safety

10. Stay alert. Watch what you are doing, and use common sense when operating a

power tool. Do not use a power tool while tired or under the influence of drugs,

alcohol, or medication. A moment of inattention while operating power tools may

result in serious personal injury.

11. Dress properly. Do not wear loose clothing or jewelry. Contain long hair. Keep

your hair, clothing, and gloves away from moving parts. Loose clothes, jewelry, or

long hair can be caught in moving parts.

12. Avoid accidental starting. Be sure the Power Switch is off before plugging in.

Plugging in power tools with the Power Switch on, invites accidents.

13. Remove adjusting keys or wrenches before turning the power tool on. A wrench

or a key that is left attached to a rotating part of the power tool may result in personal

injury.

14. Do not overreach. Keep proper footing and balance at all times. Proper footing

and balance enables better control of the power tool in unexpected situations.

Page 4

SKU 93012 For technical questions, please call 1-800-444-3353

Tool Use and Care

16. Use clamps (not included) or other practical ways to secure and support the

workpiece to a stable platform. Holding the work by hand or against your body is

unstable and may lead to loss of control.

17. Do not force the tool. Use the correct tool for your application. The correct tool

will do the job better and safer at the rate for which it is designed.

18. Do not use the power tool if the Power Switch does not turn it on or off. Any tool

that cannot be controlled with the Power Switch is dangerous and must be replaced.

19. Disconnect the Power Cord Plug from the power source before making any

adjustments, changing accessories, or storing the tool. Such preventive safety

measures reduce the risk of starting the tool accidentally.

20. Store idle tools out of reach of children and other untrained persons. Tools are

dangerous in the hands of untrained users.

21. Maintain tools with care. Keep cutting tools sharp and clean. Properly maintained

tools with a sharp cutting edge are less likely to bind and are easier to control. Do not

use a damaged tool. Tag damaged tools “Do not use” until repaired.

22. Check for misalignment or binding of moving parts, breakage of parts, and any

other condition that may affect the tool’s operation. If damaged, have the tool

serviced before using. Many accidents are caused by poorly maintained tools.

23. Use only accessories that are recommended by the manufacturer for your

model. Accessories that may be suitable for one tool may become hazardous when

used on another tool.

Service

24. Tool service must be performed only by qualified repair personnel. Service or

maintenance performed by unqualified personnel could result in a risk of injury.

25. When servicing a tool, use only identical replacement parts. Follow instructions

in the

“Inspection, Maintenance, And Cleaning”

section of this manual. Use of

unauthorized parts or failure to follow maintenance instructions may create a risk of

electric shock or injury.

SPECIFIC SAFETY RULES FOR THIS PRODUCT

1. Maintain labels and nameplates on the Scroll Saw. These carry important

information. If unreadable or missing, contact Harbor Freight Tools for a replacement.

2. Always wear ANSI approved safety impact eye goggles, dust mask and heavy

work gloves when using the Scroll Saw. Using personal safety devices reduce the

risk for injury. Safety impact eye goggles and heavy work gloves are available from

Harbor Freight Tools.

Page 5

SKU 93012 For technical questions, please call 1-800-444-3353

3. Maintain a safe working environment. Keep the work area well lit. Make sure there

is adequate surrounding workspace. Always keep the work area free of obstructions,

grease, oil, trash, and other debris. Do not use a power tool in areas near flammable

chemicals, dusts, and vapors. Do not use this product in a damp or wet location.

4. Avoid unintentional starting. Make sure you are prepared to begin work before

turning on the Scroll Saw.

5. Do not force the Scroll Saw. This tool will do the work better and safer at the speed

and capacity for which it was designed.

6. Always unplug the Scroll Saw from its electrical outlet before performing any

inspection, maintenance, or cleaning procedures.

7. Never leave the Scroll Saw unattended while running. Turn power off if you have to

leave the Scroll Saw.

8. Before each use, check all nuts, bolts, and screws for tightness. Vibration during

use may cause these to loosen.

9. Keep extension cord off the ground and away from water.

10. Always connect the Line Cord to a Ground Fault Circuit Interrupter (GFCI)

protected electrical outlet.

11. Install this product on a proper surface. Locate on a flat, level, and solid surface

that is capable of supporting the weight of the Scroll Saw.

12. Do not try to cut material too small to be securely held by hand. Cuts to hands can

occur.

13. Avoid awkward hand positions where a sudden slip could cause hand contact

with the blade.

14. When cutting a long piece of material, make sure it is supported off the table at

the same table height.

15. Hold the workpiece firmly against the table.

16. Do not feed material too fast while cutting.

17. Use caution when cutting off round material such as dowel rods or tubing. They

have a tendency to roll while being cut causing the Blade to “bite.”

18. If the blade binds in the workpiece when backing out of the cut, immediately turn

the saw power Off and carefully back material off Blade.

WARNING! People with pacemakers should consult their physician(s) before using

this product. Operation of electrical equipment in close proximity to a heart pacemaker

could cause interference or failure of the pacemaker.

Page 6

SKU 93012 For technical questions, please call 1-800-444-3353

WARNING! Some dust created by power sanding, sawing, grinding, drilling, and

other construction activities, contain chemicals known (to the State of California) to

cause cancer, birth defects or other reproductive harm. Some examples of these chemi-

cals are: lead from lead-based paints, crystalline silica from bricks and cement or other

masonry products, arsenic and chromium from chemically treated lumber. Your risk

from these exposures varies, depending on how often you do this type of work. To

reduce your exposure to these chemicals: work in a well ventilated area, and work with

approved safety equipment, such as those dust masks that are specially designed to

filter out microscopic particles.

(California Health & Safety Code 25249.5, et seq.)

GROUNDING

WARNING!

Improperly connecting the grounding wire can result in the risk of electric shock.

Check with a qualified electrician if you are in doubt as to whether the outlet is

properly grounded. Do not modify the power cord plug provided with the tool or

product. Never remove the grounding prong from the plug. Do not use the tool if

the power cord or plug is damaged. If damaged, have it repaired by a service

facility before use. If the plug will not fit the outlet, have a proper outlet installed by

a qualified electrician.

Grounded Tools with Three Prong Plugs

1. Tools marked with “Grounding Required” have a three wire cord and three prong

grounding plug. The plug must be connected to a properly grounded outlet. If the tool

should electrically malfunction or break down, grounding provides a low resistance

path to carry electricity away from the user, reducing the risk of electric shock. (See

Figure A.)

2. The grounding prong in the plug is connected through the green wire inside the cord to

the grounding system in the tool. The green wire in the cord must be the only wire

connected to the tool’s grounding system and must never be attached to an electrically

“live” terminal. (See Figure A.)

3. Your tool must be plugged into an appropriate outlet, properly installed and grounded

in accordance with all codes and ordinances. The plug and outlet should look like

those in the following illustration. (See Figure A.)

Figure A Figure B

Page 7

SKU 93012 For technical questions, please call 1-800-444-3353

EXTENSION CORDS

1. Grounded tools require a three wire extension cord. Double Insulated tools can use

either a two or three wire extension cord.

2. As the distance from the supply outlet increases, you must use a heavier gauge

extension cord. Using extension cords with inadequately sized wire causes a serious

drop in voltage, resulting in loss of power and possible tool damage. (See Table A.)

3. The smaller the gauge number of the wire, the greater the capacity of the cord. For

example, a 14 gauge cord can carry a higher current than a 16 gauge cord. (See Table

A.)

4. When using more than one extension cord to make up the total length, make sure

each cord contains at least the minimum wire size required. (See Table A.)

5. If you are using one extension cord for more than one tool, add the nameplate

amperes and use the sum to determine the required minimum cord size. (See Table A.)

6. If you are using an extension cord outdoors, make sure it is marked with the suffix “W-

A” (“W” in Canada) to indicate it is acceptable for outdoor use.

7. Make sure your extension cord is properly wired and in good electrical condition.

Always replace a damaged extension cord or have it repaired by a qualified

electrician before using it.

8. Protect your extension cords from sharp objects, excessive heat, and damp or wet

areas.

Table A

RECOMMENDED MINIMUM WIRE GAUGE FOR EXTENSION CORDS*

(120 VOLT)

NAMEPLATE

AMPERES

(At Full Load)

EXTENSION CORD LENGTH

Feet

100

Feet

150

Feet

0 – 2.0 18 18 18 18 16

2.1 – 3.4 18 18 18 16 14

3.5 – 5.0 18 18 16 14 12

5.1 – 7.0 18 16 14 12 12

7.1 – 12.0 16 14 12 10 -

12.1 – 16.0 14 12 10 - -

16.1 – 20.0 12 10 - - -

* Based on limiting the line voltage drop to five volts at 150% of the rated amperes.

Page 8

SKU 93012 For technical questions, please call 1-800-444-3353

SYMBOLOGY

Ta b l e B

UNPACKING

When unpacking, check to make sure that all the parts are included. Refer to the Assembly

section, and the Assembly Drawing and Parts List at the end of this manual.

If any parts are missing or broken, please call Harbor Freight Tools at the number on the

cover of this manual as soon as possible.

2 – Hex Wrenches (2.5 and 4 MM);

2 – Plain End Blade Adapters;

1 – Spare Saw Blade

Accessories

REV 02/07

Page 9

SKU 93012 For technical questions, please call 1-800-444-3353

ASSEMBLY INSTRUCTIONS

Mounting Scroll Saw to Workbench

1. Pick a solid, wood workbench to mount the saw. The workbench must be stable, and

able to support the weight of the Scroll Saw and the material being cut.

2. Find the four 5/16 inch mounting holes in the Base (9) and mark through the holes for

drilling with a 3/8 inch drill bit. Remove Scroll Saw to drill holes.

3. Replace Scroll Saw over holes and mount with the following hardware (not supplied):

4 - Hex Head Screws, 1/4 inch x 20 x length required; 4 - Flat Washers, 9/32 I.D.; 4-

Lock Washers, 9/32 I.D.; and 4-Hex Nuts, 1/4 x 20.

4. Check that all Scroll Saw screws and nuts are tight before using the machine.

Check and Align Bevel Indicator

1. Loosen Table Lock Knob (44) and move the table until it is approximately

perpendicular (right angle) to the blade. See photo below.

2. Use a small combination square to set the table at 90 degrees to the blade.

3. Tighten the Table Lock Knob (44).

4. Loosen Pan Screw (14) holding the bevel Scale Indicator (13), and adjust Indicator to

point to “0” degrees. Retighten Pan Screw.

Note: The bevel Scale Indicator (13) is a guide and should not be relied upon for preci-

sion settings. Make practice cuts in scrap wood to determine if the angle settings are

correct.

OPERATING INSTRUCTIONS

Controls and Indicators

(1)

Workpiece Foot Lock

Knob (68)

Bevel Scale (15)

On / Off Switch (72) with

Locking Key

Variable Speed Knob (81)

Saw Table (53)

Blade Tension Knob (21)

Workpiece Foot (48)

Table Lock Knob (44)

Scale Indicator (13)

Vacuum Hose Connection

REV 05/05

Page 10

SKU 93012 For technical questions, please call 1-800-444-3353

Turning On and Adjusting Speed

The On/Off locking Switch (72) needs to have the Switch key inserted before the switch can

be used. This feature prevents unauthorized use of the saw.

1. Insert plastic Switch Key into On/Off Switch (72).

2. To turn saw On, place finger on left side of switch and push right.

3. To turn saw Off, place finger on right side of switch and push left.

4. Turn the Variable Speed Knob (81) clockwise to increase the stokes per minute.

5. To lock switch in Off position, pull out the Switch key and store in a safe place.

WARNING: Keep hands and fingers away from the moving Saw Blade.

Table Angle Adjustment

The Saw Table (53) can be adjusted between 0 and 45 degrees as follows:

1. Loosen Table Lock Knob (44) and move the table until the desired angle is reached as

indicated on the Bevel Scale (15). Refer to the photo at the bottom of page 9.

2. Tighten the Table Lock Knob (44).

Straight, Cross, Bevel Cuts, and Ripping

1. Using a pencil, mark the cut-line on the workpiece.

2. Slide the workpiece underneath the Workpiece Foot (48).

If necessary, adjust the Workpiece Foot by loosening the Workpiece Foot Lock Knob

(68) and sliding the Workpiece Foot (up or down) until it lightly rests on the workpiece.

Tighten the Workpiece Foot Lock Knob (68).

3. Set the On/Off Switch (72) to the On position. The Saw Blade starts moving.

4. Using both hands, carefully guide the workpiece into the blade to cut.

Press down on the workpiece and slowly guide it through the Saw Blade (45). Do not

force the material through the Blade or the Blade could break.

Inside Cuts

1. Using a pencil, mark the cut-line on the workpiece.

2. Drill a 1/4 inch hole in the workpiece.

3. Follow the procedures for removing and installing the Saw Blade (45) as described on

page 13.

4. Place the workpiece on the Saw Table (53) so that the hole is centered over the Blade

access hole.

5. Insert the Blade through the hole in the workpiece and the Saw Table (53).

6. Reinstall the Blade and properly adjust tension. Refer to page 13.

Make sure Blade teeth are facing forward and down.

Autres manuels pour 93012

Table des matières

Autres manuels Central Machinery Scie

Central Machinery

Central Machinery 99553 Manuel d'installation

Central Machinery

Central Machinery 61712 Manuel utilisateur

Central Machinery

Central Machinery 62519 Instructions de montage

Central Machinery

Central Machinery 60564 Instructions de montage

Central Machinery

Central Machinery 60500 Instructions de montage

Central Machinery

Central Machinery 94652 Manuel utilisateur

Central Machinery

Central Machinery 67595 Manuel d'installation

Central Machinery

Central Machinery 32206 Manuel du propriétaire

Central Machinery

Central Machinery 97099 Manuel d'installation

Central Machinery

Central Machinery 93380 Manuel utilisateur

Central Machinery

Central Machinery 41889 Guide de référence rapide

Central Machinery

Central Machinery 63469 Instructions de montage

Central Machinery

Central Machinery 93491 Manuel utilisateur

Central Machinery

Central Machinery 03179 Manuel utilisateur

Central Machinery

Central Machinery 32208 Manuel d'installation

Central Machinery

Central Machinery 93012 Instructions de montage

Central Machinery

Central Machinery 46813 Guide de référence rapide

Central Machinery

Central Machinery 92658 Manuel utilisateur

Central Machinery

Central Machinery 04333 Manuel utilisateur

Central Machinery

Central Machinery 93762 Manuel utilisateur

Central Machinery

Central Machinery 93012 Manuel utilisateur

Central Machinery

Central Machinery 95112 Manuel de la liste des pièces

Central Machinery

Central Machinery 45804 Manuel utilisateur

Central Machinery

Central Machinery 94443 Manuel utilisateur

Manuels Scie populaires d'autres marques

RIDGID

RIDGID BS1400 Manuel utilisateur

ATIKA

ATIKA BWS 400-2 Manuel utilisateur

RGC

RGC FS20 Manuel utilisateur

Makita

Makita M2300 Manuel utilisateur

IMET Spa

IMET Spa BASIC 300 PLUS SHI Manuel utilisateur

IMET Spa

IMET Spa SIRIO 370 AF-E Manuel utilisateur

Optimum

Optimum OPTisaw CS 275 Manuel utilisateur

Makita

Makita BPB180 Manuel utilisateur

Stihl

Stihl MS 462 C-M Manuel utilisateur

AEG

AEG TS 250 K Manuel utilisateur

Meec tools

Meec tools 004665 Manuel utilisateur

Makita

Makita LS1018L Manuel utilisateur

Ryobi

Ryobi RCS1400 Manuel utilisateur

DeWalt

DeWalt DCS391 Manuel utilisateur

Sealey

Sealey SA72 Manuel utilisateur

skilsaw

skilsaw SPT88 Instructions de montage

Urrea

Urrea SI810 Dimensions et guide d'installation

EINHELL

EINHELL BKG 210/1 Manuel utilisateur
