CELESTRON

Accessories

1998

Accessories — General

AC Adapters . . . . . . . . . . . . . . . . 3

Binocular Neck Strap . . . . . . . . . 3

Binocular Tripod Adapter . . . . . . 3

Cases . . . . . . . . . . . . . . . . . . . . . 3

Car Battery Adapters . . . . . . . . . . 4

Collimation Tool . . . . . . . . . . . . 4

Dew Eliminator . . . . . . . . . . . . . 4

Flashlights . . . . . . . . . . . . . . . . . . 4

Focuser Assembly . . . . . . . . . . . . 5

LensPen . . . . . . . . . . . . . . . . . . . 5

Accessory Package Kits . . . . . . . . 5

Car Window Mount . . . . . . . . . . 5

Eyepieces

Economy, Terrestrial, SMA . . . . . 6

Plössl, Ultima . . . . . . . . . . . . . . . 7

LV, Cross Hair, Deluxe Zoom . . . 8

Ultima Spotting Scope . . . . . . . . 9

Eyeguard Set . . . . . . . . . . . . . . . . 9

Barlow Lenses . . . . . . . . . . . .10

Diagonals . . . . . . . . . . . . . . . .11

Finderscopes . . . . . . . . . . . . . .12

Filters

Eyepiece . . . . . . . . . . . . . . . . . . .14

Polarizing, Skylight, Moon . . . . .17

Solar . . . . . . . . . . . . . . . . . . . . . .18

LPR . . . . . . . . . . . . . . . . . . . . . . .19

Motor Drives

Economy and Deluxe . . . . . . . . .20

Declination Motors . . . . . . . . . .20

Guiding Eyepieces &

Illuminators . . . . . . . . . . . . .21

Photo Accessories

Reducer/Corrector f/6.3 . . . . . . .22

Radial Guider . . . . . . . . . . . . . . .22

Hand Controller . . . . . . . . . . . . .23

Focus Motors . . . . . . . . . . . . . . .23

Guidescope . . . . . . . . . . . . . . . .23

Counterweights . . . . . . . . . . . . .24

Lens Shades . . . . . . . . . . . . . . . .24

T-Adapters and T-Rings . . . . . . .25

Tele-Extender . . . . . . . . . . . . . . .26

Piggyback Mounts . . . . . . . . . . .26

T-C 16mm Adapter . . . . . . . . . .26

Computerized Circles/

Sky Maps/Books

Advanced Astro Master . . . . . . .27

Beginning Books . . . . . . . . . . . .27

Planispheres . . . . . . . . . . . . . . . .28

CD-ROM . . . . . . . . . . . . . . . . . . .28

Sky Maps . . . . . . . . . . . . . . . . . .28

Stereo Binocular Viewer . . .29

Tripods and Accessories . . .30

Equatorial Wedges . . . . . . . .32

Equatorial Mounts . . . . . . . .33

Warranty . . . . . . . . . . . . . . . . .34

Please note:

Items requiring 220V-50HZ are

available through Celestron’s

international dealers only.

TABLE OF CONTENTS

AC Adapters

Allow DC (battery powered) telescopes to be convert-

ed for use with 120 volt AC power.

AC Adapter – C5+, Celestar 8, Ultima 91

/4& 11

[18772]

AC Adapter – Celestar 8 Deluxe, G-9, G-11 and G-

14 Mounts, Ultima®2000 [18770]

Binocular Neck Strap – #71520

This wide, black cloth strap, enhanced with the

Celestron logo, is designed to add greater

comfort and ease of use to your binocular

viewing. Fits most manufacturers’ binocular

models.

Binocular Tripod Adapter – #93512-A

This useful adapter attaches to the center hinge of most high

quality binoculars, allowing you to mount them to any tripod

equipped with a standard 1

/4" x 20 mounting bolt. A must for

vibration-free viewing, this adapter conveniently sets your

hands free for other tasks while observing.

Cases

If you own a C5 or C8 telescope,

it’s imperative that you

protect your investment.

Celestron offers a large

case suitable for the

task, which accommo-

dates almost any C5 or

C8 fork mounted

telescope. It’s construct-

ed of space age resin,

making it waterproof, unbreakable, airtight and

extremely durable. The case is lined with die cut

foam for custom fitting. It features large handles and is equipped with wheels,

for easy transportation. Weight is 17 lbs. Made in the USA.

A case is available for all C90 Spotting Scopes. It’s made of sturdy ABS plastic

and is die cut to fit the C90, a camera body and several accessories.

C5/C8 Case — I.D.— 29" x 173/4" x 91/4" [302070]

C90 Case — I.D. — 141/2" x 101/2" x 51/4" [302042]

302070

302042

ACCESSORIES — GENERAL

Car Battery Adapters

Allow you to link your telescope drive directly to

the cigarette lighter receptacle of your car, for a

quick and easy DC power source in one step.

Car Batter Adapter – C5+, Celestar 8, Ultima®

/4& 11 [18767]

Car Battery Adapter – Ultima®2000 [18769]

Collimation Tool – #94183

The optical performance of most Newtonian tele-

scopes can be optimized by collimating, or realign-

ing, the telescope’s optics, as needed. This procedure

is easily accomplished with Celestron’s Collimation

Tool, a handy accessory that comes with detailed

instructions.

Dew Eliminator – #94122

Celestron’s 12 volt Dew Eliminator means viewing sessions

can last longer. It blows warm air to keep your corrector

plate and any optional accessories dew-free. Just plug it into

your car’s cigarette lighter receptacle for trouble-free observ-

ing. 156 watts. Weight: 9 ounces.

Flashlights

Red Astro Lite – #93590

An economical, disposable squeeze-type flashlight fitted

with a red cap to help preserve your night vision. Remove

the red cap for normal flashlight operation. Very compact size and

handy keychain.

LED Flashlight – #93592

A cost effective red LED flashlight for astronomy. It’s compact – only 6"

long and weighs just 2.5 ounces. Operates on two AA batteries (included).

Night Vision Flashlight – #93588

Celestron’s premium model for astrono-

my, using two red LEDs to preserve

night vision better than red filters or

other devices. Brightness is adjustable.

Operates on a single 9 volt battery

(included). Made in the USA.

#18767

#18769

From Top:

#93588, #93592,

#93590

Focuser Assembly – #93670

Celestron offers this very smooth and economical

/4" rack and pinion focuser for Newtonian

telescopes. The focuser glides easily and provides 2"

of focus travel. An adapter is included to allow use

with .96" eyepieces as well as 11

/4" eyepieces.

LensPen™– #93575

A superb new tool in optical lens cleaning technol-

ogy. Perfect for cleaning binocular lenses, small

aperture spotting scopes

and telescopes, eyepieces,

and other optical items.

The LensPen™comes

with a handy retractable

dust removal brush and a

special non-liquid

cleaning element, designed to never dry out. Safe and very easy to use.

Car Window Mount – #93513

This durable, heavy-duty mount is carefully

designed to attach easily to your car window

and provide stable, vibration-free support for

binoculars, telephoto lenses and spotting scopes.

Accessory Package Kits

Accessory packages are offered especially for Dobsonian telescopes at savings over

individually priced items.

#92505 — contains a 5x24 finderscope, 10mm SMA eyepiece — 11

/4", moon filter

— 11

/4" and a CD-ROM “The Sky for Celestron”.

#92506 — contains a 6x30 finderscope, 10mm SMA eyepiece — 11

/4", moon filter

— 11

/4", LED flashlight and Celestron Sky Maps.

#92507 — contains a 9x50 finderscope, 7.5mm Plössl eyepiece — 11

/4", 17mm

Plössl eyepiece — 11

/4", moon filter — 11

/4", Night Vision flashlight and a CD-ROM

“The Sky for Celestron”.

#92505 #92507

#92506

Economy Eyepieces: .96" and 11

Celestron offers these very economical

eyepieces to expand your viewing options.

They are all simple eyepiece designs —

Ramsden (SR & F) and Huygens (H & HM)

but perform quite well on f/8 or slower

telescopes. The optics are all glass and

they’re priced to make a complete range of

powers easily available.

Focal Item # Item # Eye Apparent

Length .96" 11

/4" Relief Field

4mm – SR 93201 93220 3mm 28°

6mm – F 93202 93221 3mm 28°

8mm – H 93203 93222 5mm 30°

12.5mm – H 93204 93223 8mm 30°

20mm – H 93205 93224 8mm 32°

25mm – HM 93206 93225 10mm 32°

Terrestrial .96" Erecting Eyepiece – #93216

This 1.5x eyepiece can be used on any telescope with

a .96" focuser to achieve an image correctly oriented

from top to bottom (rather than upside-down, as

most eyepieces display an image). Especially useful for

daytime terrestrial observing.

Super Modified Achromatic (SMA)

Eyepieces: .96" and 1

The SMA design is an improved version of the

Kellner eyepiece. SMAs are very good, economi-

cal, general purpose eyepieces that deliver a wide

apparent field, good color correction and an

excellent image at the center of the field of view.

The eyepieces are fully coated for maximum

contrast. Celestron offers a range of SMA

eyepieces in both .96" and 11

/4" sizes.

Focal Length Item # .96" Item # 11

/4" Eye Relief Apparent Field

6mm 93105 93371 4mm 52°

10mm 93108 93372 6mm 52°

12mm 93109 93373 7mm 52°

17mm 93110 93374 13mm 52°

25mm 93101-A 93007-A 14mm 52°

/4" models

.96" models

EYEPIECES

Plössl Eyepieces: .96" and 1

In a recent Sky and Telescope review, Celestron’s .96"

and 11

/4" Plössl eyepieces were rated as top ranking,

and found to outperform many similar, but more

expensive eyepieces. An exceptional value!

Celestron offers these premium eyepieces at

affordable prices, yet they’re among the best

designed and corrected eyepieces available. They’re

multicoated for enhanced contrast and all of the

/4" models are threaded to accept Celestron

colored eyepiece filters.

Focal Length Item # .96" Item # 11

/4" Eye Relief Apparent Field

6.3mm 93384 93338 5mm 52°

7.5mm 93380 93339 5mm 52°

10mm 93381 93340 7mm 52°

12.5mm 93385 93341 8mm 52°

17mm 93382 93342 13mm 52°

20mm 93343 15mm 52°

26mm 93383 93344 22mm 50°

32mm 93345 22mm 52°

40mm 93346 31mm 46°

Ultima®Eyepieces: 1

These are Celestron’s top of the line eyepieces, utilizing

a hybrid design of five elements. They feature long eye

relief and a wide field, and each air-to-glass surface is

fully multicoated to enhance contrast levels. These

special eyepieces are computer designed to keep visual

aberrations to an absolute minimum. They virtually

eliminate the following aberrations: spherical, color,

field curvature, coma, astigmatism, distortion and spherical distortion of the

exit pupil. The inside surfaces and edges of all lenses are blackened, to keep out

reflected light. Outside surfaces are flat black, with rubber grips for secure

handling. Rubber eyecups are included both for comfortable use and to keep

out extraneous light. Threaded barrels accept Celestron thread-in filters. Lens

and barrel caps are included for safe storage.

Focal Length Item # Eye Relief Apparent Field

5mm 93350 4mm 50°

7.5mm 93351 5mm 51°

12.5mm 93352 9mm 51°

18mm 93353 13mm 51°

24mm 93354 18mm 51°

30mm 93349 21mm 50°

35mm 93355 25mm 49°

42mm 93356 32mm 36°

Recently, Sky &

Telescope reviewed

Celestron’s Ultima®

eyepieces and rated

them best in their

class, with greater

contrast and image

sharpness than the

competitive models

of other

manufacturers.

LV Eyepieces: 1

These Vixen brand eyepieces (6 to 8 elements) are a

new breed, using the rare earth glass lanthanum in

one of their field lenses, for almost total freedom

from any visual aberrations. All focal lengths have a

comfortable 20mm of eye relief. Even when using

the 2.5mm LV eyepiece on a telescope, you’ll have

eye relief of 20mm! These eyepieces also feature soft rubber eyecups, rubber

coated bodies, and fully multicoated lenses for optical excellence.

Focal Length Item # Apparent Field

2.5mm 3714 45°

4mm 3715 45°

5mm 3716 45°

6mm 3717 45°

9mm 3718 50°

10mm 3719 50°

12mm 3865 50°

15mm 3756 50°

20mm 3757 50°

25mm 3758 50°

LV Zoom Eyepiece: 1

4"– #3777

This super premium zoom eyepiece has a focal length of

8mm to 24mm. It is the finest zoom eyepiece for low to

medium power observing. It’s an excellent zoom eye-

piece that performs superbly, with fully multicoated

surfaces. It offers an apparent field of 40° at 24mm and

60° at 8mm. Eye relief ranges from 15mm to 19mm.

Cross Hair Eyepiece: 1

4" – #93304

This eyepiece is of the Kellner design, with a focal length of

20mm. It’s ideal for centering alignment stars when using digital

setting circles or computerized telescopes. A useful all-around

eyepiece for many applications, including terrestrial observing. It

is fully coated and has an apparent field of 43°.

Deluxe Zoom Eyepiece: 1

4" – #93306

The Deluxe Zoom 6.5mm to 18mm 11

/4" eyepiece is a

recent design that has rapidly become the finest

zoom eyepiece ever offered for medium to high-

powered observing. This phenomenal eyepiece is

multicoated and extremely lightweight, weighing

just 5 ounces. It offers an apparent field of 38.5° at

18mm and 60.5° at 6.5mm. Eye relief is 11mm, even

at the highest power.

Ultima Spotting Scope Eyepieces

Extremely high quality eyepieces designed exclusively for the Ultima line of

spotting scopes.

Model 65mm Spotter 80mm Spotter Mount Type

#1828 20x 25x Bayonet

#1830 40x 50x Bayonet

#1838 16-48x Zoom 20-60x Zoom Thread

Eyeguard Set — #93330

A set of 10 rubber eyeguards that fit Celestron 11

/4" Economy, SMA and Plössl

(except 32 and 40mm) eyepieces as well as many eyepieces of other manufac-

turers. Allows more comfortable viewing by blocking out auxiliary light and

provides increased contrast for both astronomical and terrestrial viewing.

Clockwise: #1838, #1828, #1830

Barlow lenses offer an easy, economical way to

increase the magnification range of your eyepieces,

and Celestron carries an assortment of these highly

useful lenses. A Barlow lens doubles the magnifying

power of your eyepiece by doubling its effective focal

length. For example, an 18mm eyepiece used with a

2x Barlow lens would have the magnifying power of

a 9mm eyepiece. It’s like having two eyepieces in

one!

If you’re looking for an affordable way to achieve

high-power viewing of the moon and planets, double

stars and even close-up views of terrestrial subjects, a

Barlow lens is the answer.

Barlow lenses mount into either your telescope’s focuser or visual back.

The Economy models of .96" and 11

/4" are good choices when you want to

expand your power ranges at a very economical price.

Celestron’s premium quality .96" and 11

/4" achromatic Barlow lenses (#93502

and #93507) are compact and lightweight. Both are under three inches long,

with the 11

/4" lens weighing in at 4 ounces and the .96" lens a mere 2 ounces!

The clear aperture is 27mm on the 11

/4" model, and 21mm on the .96" unit.

The .96" Barlow is fully multicoated and the 11

/4" lens is multicoated.

The Ultima®Series Barlow (2x – 11

/4") is an air-spaced, three element apochro-

matic design with a 27mm clear aperture. This lens features a very high

quality, fully multicoated design. Amazingly compact and lightweight, it’s

just 5 ounces and 2.75" in length.

2x Barlow Lens – Economy – .96" [93211]

2x Barlow Lens – Economy – 11

/4" [93213]

2x Barlow Lens – Deluxe – .96" [93502]

2x Barlow Lens – Deluxe – 11

/4" [93507]

2x Barlow Lens – Ultima®Series - 11

/4"

[93506]

Top: #93506, 93502, #93507

Bottom: #93213, #93211

Eyepiece

Focuser or

Visual Back

Barlow Lens

Option:

Diagonal

BARLOW LENSES

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels Celestron Accessoires

Celestron

Celestron C10-NGT Manuel utilisateur

Celestron

Celestron POWER CONTROLLER 4X Manuel utilisateur

Celestron

Celestron SMART DEWHEATER AND CONTROLLER 2X Manuel utilisateur

Celestron

Celestron AllView Mount Manuel utilisateur

Celestron

Celestron CrossAim Manuel utilisateur

Celestron

Celestron FireCel Plus Manuel utilisateur

Celestron

Celestron 94155 Manuel utilisateur

Celestron

Celestron STARPOINTER PRO Manuel utilisateur

Celestron

Celestron NexImage Manuel utilisateur

Celestron

Celestron EclipSmart Manuel utilisateur

Celestron

Celestron FireCel Plus Manuel utilisateur

Celestron

Celestron Mossy Oak Gamekeeper FireCel+ 93549 Manuel utilisateur

Celestron

Celestron Popular Science ThermoCharge 3 Manuel utilisateur

Celestron

Celestron 94182 Manuel utilisateur

Celestron

Celestron StarSense 94008 Manuel utilisateur

Celestron

Celestron 93571 Manuel utilisateur

Celestron

Celestron StarPointer Manuel utilisateur

Celestron

Celestron ECLIPSMART 94248 Manuel utilisateur

Celestron

Celestron ELEMENTS THERMOTORCH 5 Manuel utilisateur

Celestron

Celestron 94306 Manuel utilisateur

Celestron

Celestron StarSense AutoAlign Manuel utilisateur

Celestron

Celestron Feathertouch SCT Microfocuser Manuel utilisateur

Celestron

Celestron WEDGE 93665 Manuel utilisateur

Celestron

Celestron 94020 Manuel utilisateur

Manuels Accessoires populaires d'autres marques

Hillco

Hillco 2810 Manuel utilisateur

Siemens

Siemens QSA2700D Manuel de l'opérateur

Contours

Contours ZY024 Manuel utilisateur

Saivod

Saivod VS621 Manuel utilisateur

Virtuox

Virtuox VirtuCLEAN 2.0 Manuel utilisateur

SCE

SCE ENVIRO-THERM SCE-TE170B24VSS Manuel utilisateur

Z-Wave

Z-Wave HSD-200Z Manuel utilisateur

turck

turck FMX-IM-2UPLI63FX Manuel utilisateur

Decagon Devices

Decagon Devices 10HS Manuel utilisateur

UPPAbaby

UPPAbaby Cup Holder Manuel utilisateur

Elko

Elko SmartSensor Leakage Wireless Manuel utilisateur

Grizzly

Grizzly H8371 Manuel utilisateur

Panasonic

Panasonic HG-T Series Manuel utilisateur

IFM Electronic

IFM Electronic Efector 250 Series Guide de référence

DigiDesign

DigiDesign 888/24 I/O Manuel utilisateur

PROZIS

PROZIS QUAY Manuel utilisateur

patagonia

patagonia PSI Vest Manuel utilisateur

SFC Energy

SFC Energy EFOY GO! Manuel utilisateur
