CDVI CDV-DDP Manuel utilisateur

CDV-DDP

User Manual

Door Station

1 2 3

654

7 8 9

RF CARD

Read this manual carefully before using the product, and keep it well for future use.



Contents

1.Parts and Functions...................................1

2. Terminal Descriptions ...............................1

3.Door Station Mounting...............................2

4. System Connection ..................................3

5. Door Lock Connections .............................6

6. Door Station Congurations ......................8

7. Specication ..........................................21

1.Parts and Functions

2. Terminal Descriptions

Camera Lens

Night View LED

Speaker

Adjustable Camera

Connectiong Port

With rainy cover

350 mm

128 mm

1 2 3

654

7 8 9

RF CARD

LCD Screen

ID Card Window

Digital Keypad

Microphone

T/R -

CN-LK

T/R+

J/KMB JP-LK

Bus

SD Card Slot

EB+

EB-

N.O

LK+

LK-

+12V

• +12V:12VDCpoweroutput.

• LK-(GND):Powerground.

• LK+(COM):CommoncontactoftheRelay.

• NO.:NormallyopencontactoftheRelay(refertoDTtechnicalguideforLockconnection

detailinformations).

• EB+:Exitbuttonconnectionport.

• EB-:Exitbuttonconnectionport.

• JP-LK:Forelectroniclocksafetytypesetting(refertoDoorStationLockConnections).

• T/R-:USB-RS485communicationterminalnegative.

• T/R+: USB-RS485communicationterminalpositive.

• Bus(L1,L2):non-polaritybusline.

-1-

3.Door Station Mounting

1 2 3

5 6

Drill a hole and attach the

rainy cover to it

Attach screws to fix the

metal box

Attach the unit to the rainy

cover correctlly

Attach the baffle to protect

the unit from droping

The last view for all mounting

The view for rainy

cover after mounted

Adjust the camera angle and attach the

metal to the panel and wire correctly.

Camera

angle

2mm

147mm

395mm

-2-

4. System Connection

Basic IN-OUT Wiring:

Code=1, DIP-6=off

Code=31, DIP-6=off

Code=32, DIP-6=on

1 2 3

654

7 8 9

RF CARD

1 2 3 4 5 6

85~260AC

DPS PS5

1 2 3 4 5 6

CALL

UNLOCK

TALK/MON

IN-USE

CALL

UNLOCK

TALK/MON

IN-USE

CALL

UNLOCK

TALK/MON

IN-USE

ID Code=0(Please refer to section 6->part

3(About Debug Tools)->Basic Tools

Detail(table 2->ID Code) in details)

-3-

Basic Star Wiring:

ID Code=0 1 2 3

654

7 8 9

RF CARD

1 2 3 4 5 6

Code=32, DIP-6=on

1 2 3 4 5 6

Code=30, DIP-6=on

1 2 3 4 5

Code=31, DIP-6=on

123 4 5 6

Code=29, DIP-6=on

Code=4, DIP-6=on

Code=2, DIP-6=on

Code=3, DIP-6=on

Code=1, DIP-6=on

CALL

UNLOCK

TALK/MON

IN-USE

CALL

UNLOCK

TALK/MON

IN-USE

CALL

UNLOCK

TALK/MON

IN-USE

CALL

UNLOCK

TALK/MON

IN-USE

CALL

UNLOCK

TALK/MON

IN-USE

CALL

UNLOCK

TALK/MON

IN-USE

CALL

UNLOCK

TALK/MON

IN-USE

CALL

UNLOCK

TALK/MON

IN-USE

85~260AC

DPS PS5

OFF ON

DBC4

A B C D

DBC4

A B C D

Impedance

switch

Impedance

switch

DIP=on,off,off

-4-

Multi Door Stations Wiring:

1 2 3 4 5 6

ID Code=1

1 2 3

654

7 8 9

RF CARD

ID Code=0

1 2 3

654

7 8 9

RF CARD

ID Code=3

1 2 3

654

7 8 9

RF CARD

ID Code=2

1 2 3

654

7 8 9

RF CARD

85~260VAC

DPS PS5

Code=4, DIP-6=on

CALL

UNLOCK

TALK/MON

IN-USE

Code=3, DIP-6=on

Code=2, DIP-6=on Code=1, DIP-6=on

CALL

UNLOCK

TALK/MON

IN-USE

CALL

UNLOCK

TALK/MON

IN-USE

CALL

UNLOCK

TALK/MON

IN-USE

DBC4

A B C D

OFF ON

Impedance

switch

DIP=on,off,off

DBC4

A B C D

-5-

5. Door Lock Connections

1. Internal Power Supply Mode

Usethepowerofthesystemtosupplyfortheelectroniclock,sothatthelockcanbeconnected

tothedoorstationdirectly,withoutanadditionalpowersupplyfortheelectroniclock.Notethat

thedoorstationcanonlyoutput12Vdcpower,thereforethekindoflockislimited.

• Theratedpowerofthelockmustbelessthan12Vdc300mAwhenusinginternalpower

supplymode

• TheGNDmustconnecttothenegativeofthelock,andtheCOMconnecttothepositive.

• Jumpersetto1-2positionforPower-off-to-Unlocksafetytype(Normally closed mode);

setto2-3positionforPower-on-to-Unlocktype(Normally open mode).

• Ifdifferentunlockingtimeisneededtobeconfigured,changetheUnlock Timingon

doorstation.(Indebugstate,press[1#]-->[1]InstallerSetup-->[2]UnlockTiming)

JP_LK

12V 300mA

Jumper set to 2-3 position

-+12V

LK - (GND)

LK+(COM)

N.O.

EB+

EB -

set to Normally open on the

Unlock Relay mode

A. Connection for Power-on-to-Unlock type:

12V 300mA

Jumper set to 1-2 position

+12V

LK - (GND)

LK+(COM)

N.O.

EB+

EB -

set to Normally Closed on the

Unlock Relay mode

JP_LK

B. Connection for Power--off-to-Unlock type:

-6-

+12V

LK - (GND)

LK+(COM)

N.O.

EB+

EB -

Remove the Jumper

set to Normally Open on the

Unlock Relay mode (default)

JP_LK

Note: Cut off this line when

using external power supply

+12V

LK - (GND)

LK+(COM)

N.O.

EB+

EB -

Remove the Jumper

set to Normally Closed on the

Unlock Relay mode

JP_LK

Note: Cut off this line when

using external power supply

2. External Power Supply Mode

Whentheelectroniclockisover12Vdc,additionalpowersupplyforthelockisneeded.

• Thepowersupplyforthelockmustbelessthan48Vdc1.5A.

• TheJumpermustberemovedwhenusingexternalpowersupply.Thedefaultsettingis

Power-on-to-Unlocktype(Normally open mode),ifusePower-off-to-Unlocktype,

changetheUnlockRelaymodetoNormally closed mode.

• Ifdifferentunlockingtimeisneededtobecongured,changetheUnlock Timingon

doorstation.(Indebugstate,press[1#]-->[1]InstallerSetup-->[2]UnlockTiming)

C. Connection for Power-to-Unlock type:

D. Connection for Power--off-to-Unlock type:

-7-

6. Door Station Congurations

1. About room code(address):

RoomCode(alsocalledroomaddress)isacodeassignedtoeachmonitor,toidentifydifferent

monitors;eachmonitorhaveauniqueroomcodeinonebuildingroomCodeisstoredineach

Monitor’sinnerEEPROMmemory,anddoesnotloseeventhemonitorispoweroff.

2. About Debug State:

TheDebugStateisyourstartingpointforusingalltheapplicationsonCDV-DDP.

WhenDoorStationisin

standby,press'#'key

Press"2#"keytoexitoutthedebugstate.

input'9008',theninputthe

AdminCode.(66666666by

default)

DebugStatemenuislaunched

[ 9 0 0 8 ]

Please Input Password

1 2 3

654

7 8 9

RF CARD

>> Debug State <<

1 - # To o l s

0 - # R e d i a l

2 - # E x i t s

3. About Debug Tools:

DuringworkingatDebugState,press"1#"toentertoolspage,DebugToolsoverviewsisshown

asbelow:

1. Installer Setup

2. Setup

3. Card Memory

4. Online Monitors

5. Online Devices

6. Voltage Measure

Pres NO.

to select

*Back

Tools

>> Debug State <<

0 - # R e d i a l

2 - # E x i t s

1 - # To o l s

-8-
