3B10 Extractor
Installation, Use and Maintenance
2
Important
The CDA Group Ltd cannot be held responsible for injuries or losses
caused by incorrect use or installation of this product. Please note
that CDA reserve the right to invalidate the guarantee supplied with
this product following incorrect installation or misuse of the appliance
or use in a commercial environment.
This appliance is not designed to be used by people (including
children) with reduced physical, sensorial or mental capacity, or
who lack experience or knowledge about it, unless they have had
supervision or instructions on how to use the appliance by someone
who is responsible for their safety.
Under no circumstances should any external covers be removed for
servicing or maintenance except by suitably qualified personnel.
Appliance information:
Please enter the details on the appliance rating plate below for
reference, to assist CDA Customer Care in the event of a fault with
your appliance and to register your appliance for guarantee purposes.
Appliance Model
Serial Number
CE Declarations of Conformity:
This appliance has been manufactured to the strictest standards and
complies with all applicable legislation, including Gas safety, Electrical
safety (LVD) and Electromagnetic Interference Compatibility (EMC).
3
IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE
PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.
At the end of its working life, the product must be taken to a special
local authority waste collection centre or to a dealer providing
appliance recycling services.
Disposing of a household appliance separately avoids possible
negative consequences for the environment and health. It also
enables the constituent materials to be recovered, saving both energy
and resources. As a reminder of the need to dispose of household
appliances separately, the product is marked with a crossed-out
wheeled dustbin .
Please note:
•Under no circumstances should the extractor be
connected to any gas ventilation system, flue system or
hot air ducting system.
• Do not vent the extractor into an attic or loft space.
•Only install the extractor in rooms with adequate
ventilation. Remember that the extractor is powerful and
whatever air is extracted needs to be replaced.
•Do not tile the extractor in. It should be removable for
service or maintenance.
•Do not use silicone sealant to secure the extractor to the
wall.
•You must be able to isolate the extractor from the mains
electrical supply after installation.
4
•Steam cleaners must not be used when cleaning this
appliance.
•The performance of your extractor will vary depending
on a number of factors, such as supply voltage and
cleanliness of the filters.
Note:
For best performance, you should switch on the extractor 15 minutes
before starting to cook and leave it to run for approximately 15
minutes after the end of cooking.
Using Your Extractor
A - Light key
B - Minus key
C - Speed indicator
D - Plus key
E - Timer key
Fig. 1
A EDCB
5
To switch the extractor on:
• Touch the “Plus” key (D) to start the extractor running at the lowest
speed.
Setting the extractor speed when it is running:
The extractor may run at a choice of 4 speeds, indicated by the
“Speed indicator” lights (C) on the control panel.
• To increase the speed touch the “Plus” key (D). The speed will
increase by one increment for each touch of this key.
• To decrease the speed touch the “Minus” key (B). The speed will
decrease by one increment for each touch of this key.
To switch the extractor o:
• Touch the “Minus” key (B) several times to turn the extractor to its
lowest speed setting, then once more to turn it o.
To switch the light on or o:
• Touch the “Light” key (A).
The timer function:
The timer function sets the extractor to switch itself o after ten
minutes have passed. This is ideal when you leave the kitchen after
cooking as the extractor can be left to clear the air then switch o to
save power, without you disturbing your meal to switch it o.
• To set this function, touch the “Timer” key “E”. The “Speed
indicator” will start to flash to show this function has been activated.
• To cancel this function, press either the “Plus” or “Minus” button (D)
or (B).
6
Care and Maintenance
IMPORTANT : DO NOT PERFORM MAINTENANCE OR CLEANING
OF THE EXTRACTOR WITHOUT FIRST SWITCHING OFF THE
ELECTRICITY SUPPLY.
Cleaning
You should use a nonabrasive cleaner. Any abrasive cleaner
(including Cif) will scratch the surface.
You can clean your extractor eectively by simply using a dilute
solution of water and mild detergent and drying to a shine with a clean
cloth, for example the CDA E-Cloth.
Cleaning the grease filter
The grease filter should be kept clean to minimise the risk of fire.
The grease filter may be removed then cleaned with hot soapy water.
You can also wash the grease filter in a dishwasher, ensuring that you
place it in an upright position to prevent damage from other items in
the dishwasher.
Please note:
Cleaning the grease filter in the dishwasher may lead to
discolouration. This is normal and does not constitute a fault with the
appliance.
To remove the aluminium grease filter for cleaning
• Pull the catch handle on the grease filter gently downwards to
release the front of the grease filter and lower it slightly. The rear
of the filter can then be released from its locating tags at the rear of
the appliance.
7
To re-fit the aluminium grease filter after cleaning
• Replacement of the aluminium grease filter is a straight reversal of
the removal process.
Changing the charcoal filter (re-circulating only)
To ensure best performance of your extractor, you should replace the
charcoal filter every four to six months, depending on use.
To attach a charcoal filter:
• Remove the grease filter as described above.
• Position the charcoal filter in the aperture. It is a tight fit so should
remain in place until the grease filter is replaced to lock it into
position.
• Finally, replace the grease filter.
IMPORTANT: Steam cleaners must not be used to clean this
appliance.
If your extractor is not working:
1. Check that the mains supply has not been switched o.
2. Check that the fuse in the spur has not blown.
The LED Lamps
The LED lamp strips are long-life items that are not designed to be
replaced by the user. In the unlikely event of a lamp failure, contact
CDA Customer Care for assistance.
8
Mains Electricity Connection
THIS APPLIANCE MUST BE CONNECTED TO THE MAINS SUPPLY
BY A COMPETENT PERSON, USING FIXED WIRING VIA A DOUBLE
POLE SWITCHED FUSED SPUR OUTLET AND PROTECTED BY A
3A FUSE.
We recommend that the appliance is connected by a qualified
electrician, who is a member of the N.I.C.E.I.C. and who will comply
with the I.E.T. and local regulations.
The wires in the mains lead of this appliance are coloured in
accordance with the following code:
Green & Yellow = Earth
Blue = Neutral
Brown = Live
As the colours of the wires in the
mains lead for the appliance may not
correspond with the coloured markings
identifying the terminals connecting to
the fused spur, proceed as follows:
•The wire which is coloured green
and yellow must be connected to the terminal marked “E” (Earth) or
coloured green.
•The wire which is coloured blue must be connected to the terminal
marked “N” (Neutral) or coloured black.
•The wire which is coloured brown must be connected to the
terminal marked “L” (Live) or coloured red.
DOUBLE POLE
SWITCHED
FUSED SPUR OUTLET
USE A 3 AMP FUSE
Fig. 2
9
Note: Use a 3A Fuse.
Assembly and electrical connection should be carried out by
specialised personnel.
When installing this product we recommend you seek the help of
another individual.
Do not mount the isolation switch behind the chimney section. It is a
requirement that you must be able to isolate the extractor from the
mains electrical supply after installation.
This appliance is intended to be connected to the mains electrical
supply by means of an isolation switch and fused spur and is intended
to be protected by a 3A fuse. The use of a 13A fuse can cause
damage to the internal wiring in the event of a fault, and may also
invalidate the warranty.
Electrical Information
Mains electrical voltage: 230Vac
Total rated power consumption: 275W
10
Installation
When the extractor is to be installed
above an electric hob, the minimum
distance between the hob and extractor
must exceed 650mm.
When the extractor is to be installed
above a gas hob, the minimum distance
between the hob and extractor must
exceed 650mm.
If the instructions provided with your gas hob state that the required
distance between the hob and extractor must be greater than
650mm, then that is the distance that should be observed; this is a
legal requirement and may lead to your hob being disconnected from
the gas supply and the installation being reported to RIDDOR (The
height should be measured from the top of the burners).
IN THE ABSENCE OF ANY INSTRUCTIONS SUPPLIED WITH THE
GAS HOB, THE MINIMUM DISTANCE BETWEEN THE HOB AND
EXTRACTOR MUST BE AT LEAST 760mm.
The width of any hob must not be greater than the width of the
extractor installed above it.
Ducting and Ventilation
For best performance and lowest noise output, we recommend the
use of 150mm ducting. 125mm ducting may be used but this will
reduce performance and increase the noise of the extractor.
Gas: 650mm minimum
Electric: 650mm minimum
Fig. 3
