fw852 / fw872 Integrated

Fridge Freezer

Manual for Installation, Use and Maintenance

Important

The manufacturer cannot be held responsible for injuries or losses

caused by incorrect use or installation of this product. Please note

that we reserve the right to invalidate the guarantee supplied with this

product following incorrect installation or misuse of the appliance.

This appliance is not designed to be used by people (including

children) with reduced physical, sensorial or mental capacity, or

who lack experience or knowledge about it, unless they have had

supervision or instructions on how to use the appliance by someone

who is responsible for their safety.

Under no circumstances should any external covers be removed for

servicing or maintenance except by suitably qualiﬁed personnel.

Appliance information:

Please enter the details on the appliance rating plate below for

reference, to assist CDA Customer Care in the event of a fault with

your appliance and to register your appliance for guarantee purposes.

Appliance Model

Serial Number

CE Declarations of Conformity:

This appliance has been designed, constructed and marketed in

compliance with safety requirements of EEC Directive 2006/95/EEC

(Low voltage) and requirements of EMC Directive 2004/108/EEC.

This appliance has been manufactured to the strictest standards and

complies with all applicable legislation, including Electrical safety (LVD)

and Electromagnetic interference compatibility (EMC). Parts intended

to come into contact with food conform to EEC/89/109.4

IMPORTANT INFORMATION FOR CORRECT DISPOSAL OF THE

PRODUCT IN ACCORDANCE WITH EC DIRECTIVE 2002/96/EC.

At the end of its working life, the product must not be disposed of as

urban waste. The refrigeration system contains insulating gases and

refrigerants, which require specialised waste disposal. The valuable

materials contained in this appliance can be recycle. It must be taken

to a special local authority dierentiated waste collection centre or to

a dealer providing this service.

Before disposing of an old appliance, remove the door seals, latch or

bolt lock to avoid the risk of child entrapment.

Disposing of a household appliance separately avoids possible

negative consequences for the environment and health deriving from

inappropriate disposal and enables the constituent materials to be

recovered to obtain signiﬁcant savings in energy and resources. As a

reminder of the need to dispose of household appliances separately,

the product is marked with a crossed-out wheeled dustbin.

Important

Never store inﬂammable or explosive items and strong corrosive

acids or alkalis in the appliance.

This is a household appliance, which is produced in accordance with

the national standard. It is intended for food storage only, not for

storage of blood, medicine and biological products.

To prevent risk of ﬁre, keep the appliance away from petrol or any

other inﬂammables.

To prevent risk of electromagnetic interference or other accidents,

do not place a microwave oven on top of the refrigerator or use any

electric appliance inside the refrigerator.

Do not allow children to play with or near the appliance.

The internal surface of freezer compartment is very cold when the

appliance is running. Do not touch the surface especially when hands

are wet.

Do not splash water onto the appliance. Keep it away from places of

high humidity that may have adverse eect on the electric insulation

performance.

This appliance is designed to be used in ambient temperatures

between 10 and 32˚C. Use outside of this range may cause the

appliance to fail.

Before First Use

You must allow the fridge to settle for at least twenty four hours

prior to switching the power on.

It is recommended that you clean the interior of the appliance prior to

ﬁrst use, using a solution of bicarbonate of soda and warm water and

then thoroughly drying the interior.

The fridge may have an odour to it at ﬁrst use. This will disappear as

the appliance cools.

When ﬁrst switching the appliance on the fridge will default to 5°C

and the freezer to -18°C. The ﬁgure in the digital display for freezer

temperature will ﬂash until the temperature drops below 0°C.

Please note:

The appliance will work continuously until it comes down to the

correct temperature.

If the appliance is switched o, you should allow ﬁve minutes

before switching it on again to prevent unnecessary damage to the

compressor.

Never store inﬂammable or explosive items and strong corrosive

acids or alkalis in the appliance.

This fridge cools your food by making the inside back of the cavity

cold. It is normal for frost to build up on this surface; it then dissipates

and drains through a small drain at the bottom, where it evaporates

harmlessly. The presence of frosting at the back is not a malfunction

of the fridge.

Use

Fridge

• Never put liquids in the refrigerator uncovered.

• Never put hot foods in the refrigerator. Warm food should be

allowed to cool to room temperature before being put into the

refrigerator.

• Nothing should rest against the rear wall of the refrigerator, as this

will cause frost and possible condensation problems which will be

dicult to remove.

• Make sure food is clean and any extra water is wiped away before

putting into the fridge.

• Wrap or cover food before putting into the fridge. This will help

prevent the loss of moisture, keep food fresh and avoid unpleasant

odours.

• Sort foods prior to storing. Any foods to be used soon should be

stored at the front of the shelf to prevent deterioration caused by

the door being open for prolonged periods.

• Do not overﬁll the fridge. There should be sucient space between

the foods to allow the cool air to circulate.

• Thawing frozen foods in the fridge compartment will help to keep

the temperature low and save energy.

Freezer

• The freezer compartments are designed to store only frozen food.

• Never put hot or warm foods in the freezer, allow them to cool fully

before putting them into the freezer.

• Follow the instructions on the food packaging for storage of frozen

food. If no information is provided, foods should not be stored for

more than three months after the purchase date.

• Store food in small packages (ideally less than 2.5kg). This reduces

the freezing time and improves the quality of the food after thawing.

• Wrap food before putting into the freezer. To stop the wrapping

sticking together, ensure it is dry.

• Label the food before freezing with information including type of

food and dates of storage and expiry.

• Once food is thawed, it must not be refrozen unless it has been

completely cooked. Only defrost as much food as is required, to

prevent wastage.

• Bottled or canned drinks should not be stored in the freezer

compartments as they could explode.

• Check the rating plate to conﬁrm the maximum amount of fresh food

that can be frozen within a 24 hour period.

• Do not attempt to freeze more than the maximum amount.

• To freeze fresh food more quickly, switch on the super freeze

function a few hours prior to placing the food in the freezer.

• Do not use the super freeze function for more than 24 hours. Use

over the recommended time will place unnecessary strain on the

refrigeration system.

Storage

The fridge section is for short term food storage. Although the

temperature can be maintained between 0-10˚C, extended periods of

food storage is not recommended.

As the cold air circulates within the fridge, the temperature can vary

between the dierent sections. As such, foods should be stored in

dierent sections according to type. Section 6 is the coldest part of

the fridge.

1. Butter

2. Food in jars and bottles

3. Drinks, e.g. milk

4. Cooked food

5. Yogurts and cheese

6. Fresh meat and ﬁsh

7. Fruit and vegetables

The fridge shelves can be moved

according to the storage requirements

within the fridge section.

To move the shelf, lift up the front

section and then pull it outwards. To

replace, slide the shelf back into the

slot, and the lower the front section.

Fig. 1

Fig. 2

Control Panel

A. Refrigerator Button

This button is used to adjust the fridge temperature between 2°C and

10°C in 1°C increments.

To change the temperature setting, press this button once so the

display shows the set temperature and ﬂashes. While it is still ﬂashing,

press this button several times until the required temperature is shown

on the display. Approximately 5 seconds after your last press of this

button the new temperature is set and the display changes back to

showing the actual temperature inside.

After changing the temperature setting the time taken to achieve

the new temperature will depend on how big the change is from the

previous setting.

B. Refrigerator Temperature Display

In normal running this shows the actual temperature in the refrigerator

compartment. See above for how this is used in setting the

refrigerator temperature.

B C D

Fig. 3

C. Freezer Temperature Display

In normal running this shows the actual temperature in the freezer

compartment. If the temperature in the freezer is higher than 0°C this

will ﬂash, otherwise it will be static.

See below for how this display is used in setting the freezer

temperature.

D. Super Freeze Display

The super freeze function can be used to freeze large quantities of

fresh food as quickly as possible. Fig 3 shows how this display looks

when the super freeze is switched on.

To switch on the super freeze function, push and hold the freezer

button (E) for three seconds.

Once the food is frozen, push and hold the freezer button (E) for three

seconds again to switch o the super freeze function.

IMPORTANT Do not use the super freeze function for more than 24

hours at a time.

E. Freezer Button

The freezer temperature is regulated by this button between -25°C

and -15°C in 1°C increments.

To change the temperature setting, press this button once so the

display shows the set temperature and ﬂashes. While it is still ﬂashing,

press this button several times until the required temperature is

shown on the display. Approximately 5 seconds after your last press

of this button the new temperature is set and the display changes

back to showing the actual temperature inside: it will continue to ﬂash

if the actual temperature in the freezer is above 0°C, and until the

actual temperature falls below zero.

Ce manuel convient aux modèles suivants

Table des matières

Autres manuels CDA Réfrigérateur

CDA

CDA FF851 Manuel de référence

CDA

CDA FF851 Manuel de référence

CDA

CDA FW221 for Manuel de référence

CDA

CDA FW224 Guide de l'utilisateur

CDA

CDA CW897 Manuel utilisateur

CDA

CDA FW253 Manuel de référence

CDA

CDA FW254 Guide de l'utilisateur

CDA

CDA FW850 Manuel de référence

CDA

CDA PC52 Guide de démarrage rapide

CDA

CDA FW925 Guide de démarrage rapide

CDA

CDA CRI8851/1 Guide de l'utilisateur

CDA

CDA FW222 Manuel de référence

CDA

CDA CRI751/1 Guide de l'utilisateur

CDA

CDA FW851 Manuel de référence

CDA

CDA FW223 Manuel de référence

CDA

CDA FW822 Guide de démarrage rapide

CDA

CDA FW422 Guide de démarrage rapide

CDA

CDA FW250 Manuel de référence

CDA

CDA CRI951 Guide de l'utilisateur

CDA

CDA PC870 Guide de démarrage rapide

CDA

CDA pc88 Guide de démarrage rapide

CDA

CDA FW951 Manuel de référence

CDA

CDA FF820 Manuel de référence

CDA

CDA CRI751 Guide de l'utilisateur

Manuels Réfrigérateur populaires d'autres marques

Bonnet Neve

Bonnet Neve SKYVIEW PLUS Manuel utilisateur

Zanussi Electrolux

Zanussi Electrolux ZERB 8441 Manuel utilisateur

Sharp

Sharp SJ-BA31IEXW2-EU Manuel utilisateur

CORBERO

CORBERO CC2300MCW Manuel utilisateur

KitchenAid

KitchenAid 2205264 Manuel utilisateur

Stengel

Stengel KU 1101 A++ Manuel utilisateur

NEFF

NEFF KI181 Series Manuel utilisateur

Hoshizaki

Hoshizaki Reach-In Manuel utilisateur

Amana

Amana ASD2524VES00 Manuel utilisateur

BOMANN

BOMANN KGC 213 Manuel utilisateur

Danby

Danby DAR044A1SLDD Instructions de montage

Samsung

Samsung RF323TE Manuel utilisateur

Beko

Beko CSA31022 Manuel utilisateur

IKEA

IKEA FROSTIG C 185 E Manuel utilisateur

Electrolux

Electrolux ER 6821 D Manuel utilisateur

True

True TS-28 Manuel utilisateur

Frigidaire

Frigidaire FSC23R5DW9 Manuel utilisateur

Beko

Beko LSP4579W Manuel utilisateur

CDA fw852 Guide de sécurité

Manuels Réfrigérateur populaires d'autres marques
