SVW101 Drawers

Manual for Installation, Use and Maintenance

2

Important

This appliance must only be used for the purpose for which it is intended, i.e. storage. Any other use could be dangerous

and may lead to premature failure of the appliance.

Appliance information:

Please enter the details on the appliance rating plate below for reference, to assist CDA Customer Care in the event of a

fault with your appliance and to register your appliance for guarantee purposes.

Appliance Model

Serial Number

Important

• Do not rest or sit on the drawer when open, as this will damage the telescopic runners.

• The maximum capacity of the drawer is 20 kg.

• Do not cover the bottom of the drawer with aluminium foil or other objects.

Use only the supplied mat.

• To avoid scratching, do not drag dishes on the bottom of the drawer.

THE MANUFACTURER DECLINES ALL RESPONSIBILITY FOR EVENTUAL DAMAGES CAUSED BY FAILURE TO

OBSERVE THESE INSTRUCTIONS.

Before ﬁrst use

Before using the drawer for the ﬁrst time we recommend that you clean it with a damp cloth, then dry thoroughly.

3

Install

Check the measurements on g 3 to conrm the requirements for

your installation. Please note, the oven dimensions show a standard

CDA oven and will vary depending on the appliance being installed

above the drawer.

1. Locate the product centrally on the supporting shelf and x into

position using the xing screws and plastic supports (g 2).

2. Carefully t the appliance on top of the warming drawer, taking

care not to scratch the top stainless edge of the drawer unit.

4. Secure the oven into the housing using appropriate xing screws.

5. The drawer is supplied with three metal ﬁller strips with

a self-adhesive backing. These strips should be attached to the

drawer to seal any gaps between the appliance and the

housing. Remove the protective foil from the trim and position

the trim as shown in ﬁg 1 so they are ﬂush with the rear and side

walls of the housing, then attach to the drawer. If there is

no rear wall to the housing, the rear trim is not required.

Fig. 1

Fig. 2

Fig. 3

7

573

20-24

594

598

595

715-720

560-568

548

23

128

537

141

6

4

Customer Care Department • The Group Ltd. • Harby Road • Langar • Nottinghamshire • NG13 9HY

T: 01949 862 012 F: 01949 862 003 E: [email protected] W: www.cda.eu

Passionate about style

To contact our Customer Care Department, or for Service,

please contact us on the details below.
