CATEYE

QUICK

CYCLOCOMPUTER

CC-RS100W

•

This instruction manual is subject

to change without notice. See our

website for the latest instruction

manual (PDF).

• For details on mounting and

setup, see the Quick Start Manual

(Web).

Setting up the QUICK

Mounting the QUICK

Starting measurement

Changing settings

Warning / Caution

Product Warranty, etc.

SearchCATEYE QUICK

Appendix

(1/3)

2.5

Tightening torque

recommendation

0.5 N•m (50 N•cm)

Mounting the QUICK

1 Mount the bracket

Adjust the mounting angle so that the

back side of the QUICK faces the speed

sensor.

Correct Wrong

Bracket Bracket rubber pad Speed sensor

Sensor rubber pad

ø25 to 26 mm

Bracket

Bracket rubber pad

Bracket

Handlebar diameter

ø31.8 mm

Nylon tie (x 2)Magnet

Appendix

(2/3)

SENSOR ZONE

Max.

70 cm

Mounting the QUICK

2 Mount the speed sensor

Mount the speed sensor in a po-

sition where the distance from

the QUICK to the speed sensor is

within the signal range.

3 Mount the magnet

Speed sensor

CutSensor rubber pad

Nylon tie

Pull tight

• Mounting on left front fork

• Mounting on right front fork

To sensor zone

Spoke

Magnet

Appendix

(3/3)

SENSOR ZONE

5 mm

Mounting the QUICK

5 Attach/detach the QUICK

6 Test operation

After attaching the QUICK, rotate the front wheel gently to check that current speed

is displayed on the QUICK.

If the speed is not displayed, refer to the attachment conditions in steps 1, 2, and 4

again.

4 Adjust the speed sensor and the magnet

The magnet passes through

the speed sensor zone.

The clearance between the

speed sensor and the magnet

is within 5 mm (3/16”).

* The magnet may be mounted at any position on spoke as long as attachment

conditions are satisﬁed.

Click

Magnet

Sensor zone

Speed sensor

Magnet

Release button

Mount Detach

Appendix

(1/2)

When using the

QUICK for the

ﬁrst time, con-

ﬁgure the initial

settings.

MODE

Battery

case cover

MODE

1 Clear all data.

Press the AC button on the back of the QUICK.

* All data is deleted and the QUICK is reset to its

factory default settings.

2 Select the measurement unit.

Select “km/h” or “mph”.

3 Set tire circumference.

Enter the tire circumference of the front

wheel in mm. (100 – 3999 mm)

* Refer to “Tire circumference” (page 6).

4 Set the clock.

Each time MODE is pressed and held,

settings switch from time display mode,

to hours, to minutes.

5 Press MENU to complete setup.

Setup is completed and the QUICK switches to the measure-

ment screen.

For instructions on how to start measurement, refer to

“Starting measurement” (page 7).

MODE

(Back side)

MODE

Setting up the QUICK

km/h ↔mph

Conﬁrm

Increase numbers

Move to next digit

(Press and hold)

Conﬁrm

Setup complete

Switch between 24h and

12h or increase numbers

Switch setting item or

move to next digit

(Press and hold)

Time display mode

MinutesHours

Short press

Long press

(2 sec.)

Appendix

(2/2)

Tire circumference

Tire circumference can be determined by either of the following two methods:

• Measure the actual tire circumference (L)

After ensuring that the tire pressure is appropriate, sit on your

bike, roll it forward so that the tire makes one full revolution (use

the valve or other marking as a reference), and measure the dis-

tance traveled on the road.

• Tire size chart

* The tire size or ETRTO code is indicated on the side of the tire.

ETRTO Tire size L (mm)

47-203 12x1.75 935

54-203 12x1.95 940

40-254 14x1.50 1020

47-254 14x1.75 1055

40-305 16x1.50 1185

47-305 16x1.75 1195

54-305 16x2.00 1245

28-349 16x1-1/8 1290

37-349 16x1-3/8 1300

32-369 17x1-1/4 (369) 1340

40-355 18x1.50 1340

47-355 18x1.75 1350

32-406 20x1.25 1450

35-406 20x1.35 1460

40-406 20x1.50 1490

47-406 20x1.75 1515

50-406 20x1.95 1565

28-451 20x1-1/8 1545

37-451 20x1-3/8 1615

37-501 22x1-3/8 1770

40-501 22x1-1/2 1785

47-507 24x1.75 1890

50-507 24x2.00 1925

54-507 24x2.125 1965

25-520 24x1(520) 1753

24x3/4 Tubular 1785

28-540 24x1-1/8 1795

32-540 24x1-1/4 1905

25-559 26x1(559) 1913

32-559 26x1.25 1950

37-559 26x1.40 2005

40-559 26x1.50 2010

47-559 26x1.75 2023

50-559 26x1.95 2050

54-559 26x2.10 2068

57-559 26x2.125 2070

58-559 26x2.35 2083

ETRTO Tire size L (mm)

75-559 26x3.00 2170

28-590 26x1-1/8 1970

37-590 26x1-3/8 2068

37-584 26x1-1/2 2100

650C Tubular 26x7/8

1920

20-571 650x20C 1938

23-571 650x23C 1944

25-571 650x25C 26x1(571) 1952

40-590 650x38A 2125

40-584 650x38B 2105

25-630 27x1(630) 2145

28-630 27x1-1/8 2155

32-630 27x1-1/4 2161

37-630 27x1-3/8 2169

40-584 27.5x1.50 2079

50-584 27.5x1.95 2090

54-584 27.5x2.1 2148

57-584 27.5x2.25 2182

18-622 700x18C 2070

19-622 700x19C 2080

20-622 700x20C 2086

23-622 700x23C 2096

25-622 700x25C 2105

28-622 700x28C 2136

30-622 700x30C 2146

32-622 700x32C 2155

700C Tubular 2130

35-622 700x35C 2168

38-622 700x38C 2180

40-622 700x40C 2200

42-622 700x42C 2224

44-622 700x44C 2235

45-622 700x45C 2242

47-622 700x47C 2268

54-622 29x2.1 2288

56-622 29x2.2 2298

60-622 29x2.3 2326

Setting up the QUICK

L mm

Appendix

(1/2)

MODE

* The average speed displays .E instead of the measurement value when the moving

time exceeds approximately 28 hours or the trip distance exceeds 1000 km. In this

situation, the data must be reset.

Switching current function

Pressing MODE switches the current function displayed at the bottom of the screen.

Starting measurement

On the measurement screen, press MENU to go to the menu

screen. Various settings can be changed on the menu screen.

[Measurement screen]

Current speed

0.0 (4.0) – 99.9 km/h

[0.0 (3.0) – 62.0 mph]

Measurement unit

Current function

Av Average Speed (*)

0.0 – 99.9 km/h

[0.0 – 62.0 mph]

Mx Maximum Speed

0.0(4.0) – 99.9 km/h

[0.0(3.0) – 62.0 mph]

Tm Moving Time

0:00’00” – 9:59’59”

Dst Trip Distance

0.00 – 999.99 km [mile]

Odo Total distance

0.0 – 9999.9 /

10000 – 99999 km [mile]

Clock

0:00 – 23:59

or 1:00 – 12:59

(Back side)

Icon Description

Sensor signal icon

Flashes in sync with the sensor

signal.

Pace arrows

Indicates whether the current

speed is faster ( ) or slower ( )

than the average speed.

Appendix

(2/2)

(2 seconds)

Starting/stopping measurement

Measurement starts automatically when the

bicycle moves.

During measurement the measurement unit

(km/h or mph) ﬂashes.

Resetting data

Pressing MODE for 2 seconds when on the measurement screen

resets all measurement data to 0 (excluding Odo).

Starting measurement [Measurement screen]

MODE

Power-saving function

If the QUICK does not receive any

signal for 10 minutes, the pow-

er-saving screen is activated and

only the clock is displayed.

If MODE is pressed or a sensor

signal is received while the pow-

er-saving screen is activated, the

QUICK returns to the measurement

screen.

* When the QUICK is left on the

power-saving screen for one

hour, the display enters the sleep

state and only shows the mea-

surement unit. When the QUICK

is in this state, you can return

to the measurement screen by

pressing MODE.

MODE

Measurement starts Measurement stops

1 hour

10 minutes

Automatic

return

Sleep

Power-saving screenMeasurement screen

Appendix

(1/4)

MODE

Changing settings

On the measurement screen, press MENU to go to the menu screen.

Various settings can be changed on the menu screen.

* After changing settings, always press MENU to conﬁrm changes.

* When the menu screen is left on for 1 minute, the QUICK returns to the measurement screen.

[Menu screen]

Tire circumference

Set the tire circumference.

(0100 – 3999 mm)

* Refer to “Tire circumference” (page 6) for

tire circumferences.

Manual distance input

Clock

Select measurement

unit

MODE

Increase numbers

MODE

Increase numbers

MODE

Increase numbers

MODE

Increase numbers

Measurement

screen Menu screen Description

(Back side)

Conﬁrm

(Press and hold)

MODE

(Press and hold)

MODE

(Press and hold)

MODE

Change setting

(Press and hold)

MODE

(Press and hold)

MODE

Appendix

(2/4)

MODE

Changing settings

Clock

Set the clock.

Manual distance input

Tire circumference

Select measurement

unit

MODE

Increase numbers

MODE

Increase numbers

Menu screen Description

Measurement

screen

[Menu screen]

12h ↔ 24h

Select display

Set “hours”

Set “minutes”

(Back side)

(Press and hold)

MODE

(Press and hold)

MODE

(Back side)

Conﬁrm

Change setting

(Press and hold)

MODE

(Press and hold)

MODE
