Casio Privia PX-100 Manuel utilisateur

PX100-ES-1

USER’S GUIDE

GUÍA DEL USUARIO

Please keep all information for future reference.

Guarde toda información para tener como referencia futura.

Safety Precautions

Before trying to use the piano, be sure to

read the separate “Safety Precautions”.

Precauciones de seguridad

Antes de intentar usar el piano, asegúrese

de leer las “Precauciones de seguridad”

separadas.

NOTICE

This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to

Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful

interference in a residential installation. This equipment generates, uses and can radiate radio frequency

energy and, if not installed and used in accordance with the instructions, may cause harmful interference to

radio communications. However, there is no guarantee that interference will not occur in a particular

installation. If this equipment does cause harmful interference to radio or television reception, which can be

determined by turning the equipment off and on, the user is encouraged to try to correct the interference by

one or more of the following measures:

•Reorient or relocate the receiving antenna.

•Increase the separation between the equipment and receiver.

•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.

•Consult the dealer or an experienced radio/TV technician for help.

FCC WARNING

Changes or modifications not expressly approved by the party responsible for compliance could void the

user’s authority to operate the equipment.

TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, REFER SERVICING TO QUALIFIED SERVICE

PERSONNEL.

CASIO ELECTRONICS CO., LTD.

Unit 6, 1000

North Circular Road

London NW2 7JD, U.K.

This mark is valid in the EU countries only.

Please keep all information for future reference.

Important!

Please note the following important information before using this product.

• Before using the optional AD-12 Adaptor to power the unit, be sure to check the AC Adaptor for any

damage first. Carefully check the power cord for breakage, cuts, exposed wire and other serious damage.

Never let children use an AC adaptor that is seriously damaged.

• The product is not intended for children under 3 years.

• Use only CASIO AD-12 adaptor.

• The AC adaptor is not a toy.

• Be sure to disconnect the AC adaptor before cleaning the product.

412A-E-002A

E-1

Contents

Company and product names used in this

manual may be registered trademarks of others.

412A-E-003A

General Guide ..........................E-2

Playing Back All the Music Library Tunes .. E-3

Power Supply ...........................E-4

Using the AC Adaptor ................................. E-4

Connections .............................E-5

Connecting Headphones ............................ E-5

Connecting to a PEDAL Jack ..................... E-5

Playing with Different Tones ...E-6

Selecting and Playing a Tone ..................... E-6

Using Tone Effects ...................................... E-6

Layering Two Tones .................................... E-7

Assigning Different Tones to the

Left and Right Sides of the Keyboard......... E-7

Using the Piano’s Pedals ............................ E-8

Using the Built-in Metronome ..................... E-9

Playing Rhythms....................E-10

Using Auto Accompaniment...................... E-11

Learning to Play the Music

Library Tunes .........................E-15

Playing a Music Library Tune ................... E-15

Practicing a Music Library Tune ............... E-15

Recording to and Playing

Back from Song Memory.......E-16

Recording Your Keyboard Play................. E-17

Playing Back from Song Memory ............. E-18

Other Settings ........................E-19

Changing the Keyboard Touch ................. E-19

Changing the Piano Key ........................... E-19

Changing the Pitch of the Piano to

Match Another Instrument ........................ E-19

Using MIDI ................................................ E-20

Expanding the Selections in the

Music Library ............................................ E-21

Troubleshooting.....................E-22

Specifications.........................E-23

Operational Precautions .......E-24

Setting Control Key Chart .....E-25

Appendix ..................................A-1

Tone List ..................................................... A-1

Rhythm List ................................................. A-1

Song List ..................................................... A-1

Fingered Chord Chart ................................. A-2

MIDI Implementation Chart

E-2

General Guide

Back Panel Attachment of the Score Stand

Insert the score stand into the slot at the top of the digital piano as

shown in the illustration.

Left Side Panel

412A-E-004A

456

9 0 A B C D E F KH I J

NOTE

•Each chapter of this manual starts with an illustration

of the piano’s console, which shows the buttons and

other controllers you need to operate.

CONTROL

REVERB

CHORUS

E-3

1PEDAL DAMPER jack

2PEDAL SOFT/SOSTENUTO jack

3POWER button

4DC 12V jack

5MIDI OUT/IN terminals

6PHONES jacks

7VOLUME knob

8CONTROL button

9REVERB CHORUS button

0INTRO/ENDING button

ASYNCHRO/FILL-IN button

BPLAY/STOP, START/STOP button

CMUSIC LIBRARY, RHYTHM button

General Guide

DLEFT/TRACK 1 RIGHT/TRACK 2 button

ESONG MEMORY button

FMETRONOME button

GTONE buttons

HTEMPO buttons

ISONG/RHYTHM SELECT buttons

JBEAT buttons

KSPLIT button

NOTE

•Key, button, and other names are indicated in the text of this manual using bold type.

Playing Back All the Music Library Tunes

The following procedure plays back the Music Library tunes in sequence.

While holding down the MUSIC LIBRARY button, press the START/STOP button at the same time.

•This causes the MUSIC LIBRARY indicator lamp to flash, and starts sequential playback of the Music Library

tunes.

•You can play along with the Music Library tunes on the keyboard, if you want. Tone assigned to the keyboard is

the one that is preset for the Music Library tune that is playing.

Press the START/STOP button again to stop Music Library tune play.

412A-E-005A

E-4

Power Supply

You can power this digital piano by plugging it into a

standard household power outlet.

Be sure you turn off power and unplug the power cord

from the electrical outlet whenever the digital piano

is not in use.

Using the AC Adaptor

Make sure that you use only the AC adaptor specified

for this digital piano.

Specified AC Adaptor: AD-12

[Left Side Panel]

IMPORTANT!

•Make sure that the product is turned off before connecting

or disconnecting the AC adaptor.

•Using the AC adaptor for a long time can cause it to

become warm to touch. This is normal and does not

indicate malfunction.

DC 12V jack

AC adaptor AD-12

AC outlet

412A-E-006A

E-5

Connections

412A-E-007A

IMPORTANT!

•Whenever connecting external equipment, first set the

VOLUME knob of the digital piano and the volume

controller of the external equipment to relatively low

volume settings. You can later adjust volume to the level

you want after connections are complete.

•Be sure also to refer to the documentation that comes with

the external equipment for its proper connection

procedures.

Connecting Headphones

Connect commercially available headphones to the

digital piano’s PHONES jacks. This cuts off the built-

in speakers, which means you can practice even late

at night without disturbing others. To protect your

hearing, make sure that you do not set the volume

level too high when using headphones.

[Left Side Panel]

Connecting to a PEDAL Jack

Depending on the type of operation you want the

pedal (SP-3) to perform, connect the pedal’s cable to

the digital piano’s PEDAL DAMPER jack or PEDAL

SOFT/SOSTENUTO jack. If you want to use both

jacks at the same time, you need to purchase another

optionally available pedal.

See “Using the Piano’s Pedals”on page E-8 for

information about using a pedal.

[Back Panel]

Accessories and Options

Use only the accessories and options specified for this

digital piano. Use of non-authorized items creates the

danger of fire, electric shock, and personal injury.

Headphones

PHONES jacks

SP-3

PEDAL jacks

E-6

Playing with Different Tones

Selecting and Playing a Tone

The piano comes with eight built-in tones.

Press the POWER button.

Use the VOLUME knob to adjust the

volume level.

•Before playing, it is a good idea to set the

volume to a relatively low level.

Press the TONE button of the tone you want to select

Now try playing something on the keyboard

Using Tone Effects

Reverb: Makes your notes resonate

Chorus: Adds more breadth to your notes

Press the REVERB CHORUS button to cycle

through the effect settings as shown below.

•You can find out the current reverb/chorus

configuration by looking at the REVERB and

CHORUS indicator lamps.

412A-E-008A

Off

Both on

Both off

Reverb on

Chorus on

CONTROL

REVERB CHORUS METRONOME

TONE

SPLIT

TEMPO BEAT

Other Effect Settings

You can select from among four reverb effects and four

chorus effects by pressing the keyboard keys shown

below.

While holding down the CONTROL

button, press one of the keyboard keys

shown above.

POWER button

▲

1Reverb Effect Keys

2Chorus Effect Keys

Room 2 Hall 2

Hall 1

Room 1

Chorus 2 Chorus 4

Chorus 3

Chorus 1

E-7

Layering Two Tones

Use the following procedure to layer to two tones, so

they sound at the same time.

Simultaneously press the TONE buttons of

the two tones that you want to layer.

Example: Press GRAND PIANO 2 button and

STRINGS button at the same time.

•The tones are now layered.

After you are finished using the layered

tones, press the one of the TONE buttons

again to unlayer them.

Adjusting the Volume of Layered Tones

While holding down the CONTROL

button, use the keyboard keys shown below

to adjust the volume of the layered tones.

+ : Raises the volume

–: Lowers the volume

Playing with Different Tones

412A-E-009A

GRAND PIANO 2

STRINGS

▲

–

Assigning Different Tones to the Left

and Right Sides of the Keyboard

You can assign different tones to keys on the left side

and the right side of the keyboard.

Press the TONE button of the tone you want

to select for the high (right) range.

Example: GRAND PIANO 2

Press the SPLIT button.

•This causes the SPLIT indicator lamp to light.

Press the TONE button of the tone you want

to select for the low (left) range.

•The keyboard is now split between the two

tones.

Example: STRINGS

After you are finished using the split

keyboard, press the SPLIT button again to

unsplit it.

•This causes the SPLIT indicator lamp to go out.

NOTE

You can also perform a kind of “quick split”operation

using the following key operations.

•Press the SPLIT button.

➠Acoustic Bass (built-in tone)

•Hold down the CONTROL button and press the

SPLIT button.

➠Ride Aco Bass (built-in tone)

Split Point

STRINGS GRAND PIANO 2

E-8

Playing with Different Tones

Specifying the Keyboard Tone Split Point

While holding down the SPLIT button,

press the keyboard key where you want the

left limit of the high range (right) tone to

be.

•A note does not sound when you press a

keyboard key at this time.

NOTE

•The split point setting also controls the point where

the keyboard splits between the accompaniment

keyboard (pages E-12, 13) and the melody

keyboard. Moving the split point also affects the

sizes of the accompaniment keyboard and the

melody keyboard.

Using the Piano’s Pedals

The digital piano is equipped with two pedal jacks,

one for a damper pedal and one for a soft/sostenuto

pedal.

412A-E-010A

SP-3

Low range

Left limit of the high range

High range

▲

Soft

Sostenuto

Pedal functions

•Damper pedal

Pressing this pedal causes notes to reverberate and

to sustain longer.

•Soft pedal

Pressing this pedal dampens notes and slightly

reduces their volume. Only notes played after the

pedal is depressed are affected, and any notes

played before the pedal is pressed sound at their

normal volume.

•Sostenuto pedal

Like the damper pedal, this pedal causes notes to

reverberate and to sustain longer. The difference

between the two pedals is the timing when they

are pressed.

With the sostenuto pedal, you press the pedal after

depressing the notes you want to sustain. Only the

notes whose keyboard keys are depressed when the

sostenuto pedal is pressed are affected.

Selecting the Pedal Function

A pedal connected to the piano’s PEDAL jack can

operate as either a soft pedal or a sostenuto pedal.

When you turn on the keyboard, the pedal is initially

configured for soft pedal operation. You can perform

the following operation to select either soft or

sostenuto for the pedal operation.

While holding down the CONTROL

button, use the keyboard keys shown below

to select either soft or sostenuto.

Autres manuels pour Privia PX-100

Table des matières

Autres manuels Casio Clavier électronique

Casio

Casio CELVIANO AP220ES1C Manuel utilisateur

Casio

Casio AZ-1 Guide de dépannage

Casio

Casio PRIVIA PX-330 Manuel utilisateur

Casio

Casio CTK-7000 Manuel utilisateur

Casio

Casio RZ-1 Guide de dépannage

Casio

Casio Celviano AP-24 Manuel utilisateur

Casio

Casio Oriental Maestro AT1 Manuel utilisateur

Casio

Casio CTK-485 Manuel utilisateur

Casio

Casio LK-120 Manuel utilisateur

Casio

Casio MZ-2000 Manuel utilisateur

Casio

Casio KL-130 Manuel utilisateur

Casio

Casio CTK-6300in Manuel utilisateur

Casio

Casio PS-3000 Manuel utilisateur

Casio

Casio Privia PX-330BK Guide de dépannage

Casio

Casio SK-1 Manuel utilisateur

Casio

Casio MA-170 Manuel utilisateur

Casio

Casio Privia PX-320 Manuel utilisateur

Casio

Casio CDP-100 Manuel utilisateur

Casio

Casio LK-50 Manuel de service

Casio

Casio CTK-720 Manuel utilisateur

Casio

Casio WK-1600 Manuel utilisateur

Casio

Casio CTK-230 Manuel utilisateur

Casio

Casio CTK-631 Manuel utilisateur

Casio

Casio Casiotone CT-S190 Manuel utilisateur

Manuels Clavier électronique populaires d'autres marques

Yamaha

Yamaha PortaTone PSR-225GM Manuel utilisateur

Behringer

Behringer U-CONTROL UMX49 Manuel utilisateur

Yamaha

Yamaha Portatone X2500 Manuel utilisateur

Yamaha

Yamaha Portatone PSR-100 Manuel utilisateur

Keith McMillen Instruments

Keith McMillen Instruments K-Board Pro 4 Fiche technique

Yamaha

Yamaha PortaSound PCS-30 Manuel utilisateur

Roland

Roland Juno-6 Manuel utilisateur

McGrey

McGrey 6170 Manuel utilisateur

Yamaha

Yamaha PortaTone PSR-41 Manuel utilisateur

HDC

HDC Kurzweil KP300X Manuel utilisateur

Akai

Akai MPK88 Manuel utilisateur

Waldorf

Waldorf IRIDIUM Manuel utilisateur

Yamaha

Yamaha NP-30 Instructions de montage

Yamaha

Yamaha Portatone PSR-38 Manuel utilisateur

Yamaha

Yamaha PortaTone PSR-40 Manuel utilisateur

Behringer

Behringer MOTÖR 61 Manuel utilisateur

Yamaha

Yamaha PortaTone PSR-62 Manuel utilisateur

Yamaha

Yamaha PS-20 Manuel utilisateur
