WHEELED EXCAVATOR
WX145 - Series 2
Engine Horsepower 90 kW - 121 hp
Max Operating weight 16 500 kg
Bucket 0.2 m3 to0.8 m3
2
SERVICE ACCESS
The WX series of wheeled excavators use the latest Family III Case diesel engines. All engines feature extended
500 hour service intervals, for minimal downtime, and the machines have easy access to all service and diagnostic
points. An ecological oil drain reduces the risk of ground contamination during regular maintenance work.
Ease of service. Minimum downtime.
OPERATOR SECURITY
Large volume fully glazed cab features outstanding visibility all around the machine. An air suspension seat and tilting steering
column ensure that all operators can achieve a comfortable driving position, reducing fatigue and increasing productivity.
Automatically operating brakes and front axle lock, along with direction control switch on the joystick reduce operator effort,
while Digipower management and fine grading mode allow the operator total control of the engine and hydraulic power.
Reduced fatigue. Maximum productivity.
3
CASE PERFORMANCE
The WX machines have a compact upperstructure that promotes high lifting and digging performance. With full blade and
stabiliser independence, and mechanically lockable stabiliser pads, the WX excavators offer a solid working platform. High engine
output with Power Boost function ensures total productivity, while a PowerShift transmission allows optional travel speeds of
30 km/h with on-the-move gear shifting. Quick coupler compatible with previous generation machines and quick connectors on
auxiliary hydraulics provides rapid changeover between attachments, increasing machine versatility.
Designed to work. Built to perform.
SECURE OPERATION
Case inching and extra slow speed setting, along with road travel mode swing and attachment cut-out, provide safe operation
in all conditions. Engine safe warm-up control and automatic battery cut-off reduce the possibility of damage to the engine and
hydraulic system at start-up. Stabiliser cylinder protection cuts the risk of damage in rough ground and abrasive material.
Integrated anti-theft device provides peace of mind for Case WX customers.
Safety First. Investment Protection.
4
Large glass area with two-piece full height front windscreen
offers unparalleled visibility all around the machine. The operator
has a clear view to the work area when digging and loading, and
to the road ahead when travelling the machine between job sites.
A low engine canopy to the rear of the machine provides a clear
view behind the excavator when manoeuvring on confined sites.
The WX145 uses a four cylinder Case engine for maximum fuel
economy. This EU Tier III compliant engine is turbocharged and
intercooled for optimised clean combustion and high power
output. The engine has been designed for maximum reliability
and durability, with an auto warm-up feature ensuring long service
life and minimal downtime.
ENGINE
A two speed range transmission offers an optional maximum
travel speed between job sites of 30 km/h. Excellent ground
clearance, with the option of a two-piece drive shaft, offers true
off-road capability for maximum versatility on site. As with all
Case WX machines the WX145 has the Case inching control,
which allows the operator to gradually move the machine for
safe and accurate positioning. The machine is available with
single wheels or double wheels with a twinning ring, allowing the
customer to tailor the layout to meet their application.
UNDERCARRIAGE
VISIBILITY
5
OPERATOR’S CAB
Ergonomic design with large tinted glass area provides
feeling of space and excellent all round visibility,
ensuring safe operation on site. Large roof window
with shade, fully adjustable suspension seat, adjustable
tilt steering column and exceptionally low internal
noise levels allow fatigue-free operation and full day
productivity. Large LCD display provides all operating
information and diagnostic functions, along with
integrated working mode display. All major operating
controls, including travel direction, attachment and
blade/stabiliser selection, levelling mode and power
boost function are integrated into the joystick levers,
reducing operator effort and ensuring total control
of the machine.
6
Even with the reduced tail radius of the Case WX, the machine
retains the Case access catwalk behind the cab, offering the
service engineer excellent access to the regular service and
maintenance points and providing a safe working area. A lift up
engine canopy provides a clear view to the top of the engine, the
hydraulic valves and the cooling pack.
Clean, easy to maintain hydraulic valve layout. The Case Digipower
hydraulic control system monitors the main pumps and regulates
engine power to meet the needs of the operator. The WX
machines offer a range of selectable power levels, for specific
digging and lifting tasks, including a levelling mode for fine grading
work. PowerBoost is standard in the lifting modes and works for
8 seconds in all other modes on request.
HYDRAULICS
Customers can choose between a stabilisers, blade or a
combination of the two, thanks to the modular design of the Case
WX chassis. The stabilisers and dozer blade are independently
controlled, to allow for levelling on rough ground. Optional City
stabilisers have numerous pad positions, providing full stability
with the ability to work the machine in confined areas, such as
alongside kerbs and raised ironwork.
STABILIZERS
ACCESSIBILITY
7
8
7700 3050 14450 8000 3040 14900 8100 3050 14800 8100 3050 15350 8250 3050 14700 8250 3050 15250
15300*15850*15200*15750*
7700 3050 14500 8000 3050 14950 8100 3050 14800 8100 3050 15400 8250 3050 14750 8250 3050 15300
15350*15900*15250*15800*
7700 3235 14550 8000 3235 15000 8100 3235 14800 8100 3235 15450 8250 3235 14800 8250 3235 15350
15400*15950*153500*15850*
7900 3050 14850 8200 3050 15300 8300 3050 15300 8300 3050 15850 8450 3050 15200 8300 3050 15750
7900 3050 14850 8200 3050 15350 8300 3050 15350 8300 3050 15900 8450 3050 15250 8300 3050 15800
7900 3050 14900 8200 3050 15400 8300 3050 15400 8300 3050 15950 8450 3050 15300 8300 3050 15850
7750 3050 14950 8050 3050 15400 8150 3050 15900 8150 3050 16400 8300 3050 15800 8150 3050 16300
7750 3050 15000 8050 3050 15450 8150 3050 15950 8150 3050 16450 8300 3050 1850 8150 3050 16350
77750 3350 15050 8050 3350 15500 8150 3350 16000 8150 3350 16500 8300 3350 15900 8150 3350 16400
SPECIFICATIONS
ENGINE
Make ___________________________________CASE - Family III
Model _____________________________________445TA/MLH
Type __________4 cyl. turbo charged, direct injection, intercooler
Displacement ______________________________________4.5 l
Bore x stroke _____________________________104 x 132 mm
Output power (ISO 14396) __________________90 kW/121 hp
Rated speed __________________________________2000 rpm
HYDRAULIC SYSTEM
Main pumps __________3 variable displacement, axial piston
Total maximum flow ________________2 x 143 lpm + 73 lpm
Attachment maximum pressure/PowerBoost 345/370 bar
Travel maximum pressure ______________________370 bar
Swing maximum pressure ______________________360 bar
SWING
Swing speed ___________________________________9 rpm
Swing torque_________________________________36 kNm
Tail swing radius _______________________________1.85 m
TRAVEL
Maximum travel speed (field range)_______________8 km/h
Maximum travel speed (road range) _______20 or 30 km/h
Maximum drawbar pull (field range) ________________87 kN
ELECTRICAL SYSTEM
Voltage ________________________________________24 V
Batteries ____________________________2 x 12 V - 100 Ah
Alternator ______________________________________70 A
Automatic isolator switch and 12 V power supply in cab as standard.
CIRCUIT AND COMPONENT CAPACITIES
Engine oil________________________________________16 l
Cooling circuit ___________________________________26 l
Fuel tank _______________________________________210 l
Hydraulic tank___________________________________110 l
Swing gear______________________________________5.5 l
TYRES
4 wheels _________________________________18 -19.5 XF
8 wheels with twinning rings __________________10.00 - 20
11.00 - 20
600/400 - 22.5
315/8012 - 22.5
Dipper 2.00 m
Dipper 2.30 m
Dipper 2.60 m
SHIPPING DIMENSIONS AND WEIGHT
without uc attach
.
PL P2A P2AL P2A CITY STABS P2AL CITY STABS
Rear Blade Rear Stabilisers Front Blade + 2 Stab. Rear City Stabs Front Blade + City Stabs
max max max max max max max max max max max max
length height length height length height length height length height length height
mm mm kg mm mm kg mm mm kg mm mm kg mm mm kg mm mm kg
MONOBOOM
Weights are indicated fitted with a 440 kg bucket, twin tyres 10.00 - 20 16 PR - * Option counterweight 3.7 t
Dipper 2.00 m
Dipper 2.30 m
Dipper 2.60 m
without uc attach
.
PL P2A P2AL P2A CITY STABS P2AL CITY STABS
Rear Blade Rear Stabilisers Front Blade + 2 Stab. Rear City Stabs Front Blade + City Stabs
max max max max max max max max max max max max
length height length height length height length height length height length height
mm mm kg mm mm kg mm mm kg mm mm kg mm mm kg mm mm kg
ARTICULATED
BOOM
Dipper 2.00 m
Dipper 2.30 m
Dipper 2.60 m
without uc attach
.
PL P2A P2AL P2A CITY STABS P2AL CITY STABS
Rear Blade Rear Stabilisers Front Blade + 2 Stab. Rear City Stabs Front Blade + City Stabs
max max max max max max max max max max max max
length height length height length height length height length height length height
mm mm kg mm mm kg mm mm kg mm mm kg mm mm kg mm mm kg
OFFSET BOOM
WX145
WX145
WX145
9
l
mm
kg
210 310 420 520 580 630 740
450 600 750 900 1000 1100 1200
245 278 312 355 388 421 445
D
B
F
I
L
KJ
C
D1
G
EE
D2
H
M
A
D
B
F
KJ
I
L
B
D
K
F
J
I
L
C C
l
mm
kg
540
1830
475
l
mm
kg
l
mm
kg
m
m
m
m
m
m
m
m
m
m
m
m
m
m
A
B
C
D
D1
D2
E
F
G
H
I
J
K
L
M
Overall height (with attachment)
Height of machine
Overall length
Swing tail radius
Gauge with 4 wheels
Gauge with 8 wheels
Ground clearance of undercarriage
Ground clearance of uppercarriage
Width unit blade/stabilizers
Width over stabs (max height)
Wheel base
Dimension rear axle to center
Undercarriage rear
Rear Stabilisers
Undercarriage front end
Width of uppercarriage
GENERAL DIMENSIONS
BUCKETS
GENERAL PURPOSE
SAE capacity
Width
Weight
3.05 3.05 3.05
2.35 2.35 2.35
8.25* 8.30* 8.15*
1.85 1. 8 5 1. 85
1.89 1. 8 9 1. 89
1.91 1.91 1.91
0.37 0.37 0.37
1.25 1. 2 5 1. 25
2.53 2.53 2.53
3.73 3.73 3.73
2.55 2.55 2.55
1.17 1.17 1.17
1.08 1. 0 8 1. 08
0.56 0.56 0.56
2.50 2.50 2.50
MONOBOOM ARTICULATED BOOM OFFSET BOOM
Tires type 600/40 - 22,5 I-331 Alliance
* Front blade and City stabs
DITCH CLEANING
SAE capacity
Width
Weight
246810
7
8 m
6
5
4
3
2
1
0
1
2
3
4
5
6
7
8
9
10
11
H
F
G
D
E
CB
A
Series 2
0 m
10
m
m
m
m
m
m
m
m
m
kN
kN
A
B
C
C’
D
E
F
G
H
PERFORMANCE DATA
Max. digging height
Max. loading height
Max. digging depth
Max. digging depth with offset
Max. vert. wall digging depth
Max. depth of cut for 8' level bottom
Max. digging reach
Max. digging reach at ground level
Min. front swing radius
Bucket breakout force (370 bar) ISO
Stick crowd force (370 bar) ISO
DIPPERSTICK
8.4 8.4 8.6 9.2 9.3 9.5 8.3 8.3 8.4
6.0 6.0 6.2 6.8 6.9 7.2 6.0 6.0 6.2
4.8 5.1 5.5 4.7 5.0 5.3 4.7 5.0 5.3
--- ---1.41.72.0
3.0 3.0 3.2 2.5 2.8 2.8 2.2 2.0 2.3
4.5 4.8 5.1 4.6 4.9 5.2 4.4 4.7 5.0
8.2 8.4 8.7 8.3 8.5 8.8 8.1 8.3 8.6
8.0 8.2 8.4 8.1 8.3 8.6 7.9 8.1 8.4
3.0 3.0 3.0 2.7 2.6 2.7 2.9 2.9 2.9
104 .3 104 . 3 104.3 104 .3 10 4. 3 10 4. 3 104 .3 10 4. 3 104.3
69.8 63.6 58.4 69.8 63.6 58.4 69.8 63.6 58.4
MONO BOOM 4.65 m ARTICUL. BOOM 4.70 m OFFSET BOOM 4.80 m
2.00 m 2.30 m 2.65 m 2.00 m 2.30 m 2.65 m 2.00 m 2.30 m 2.65 m
Autres manuels pour WX145
3
Table des matières
Autres manuels Case Excavatrice
Case
Case CX17B Manuel utilisateur
Case
Case CX350C Manuel utilisateur
Case
Case Cruz-Air 45 Manuel utilisateur
Case
Case CX240C Manuel utilisateur
Case
Case CX26B Manuel utilisateur
Case
Case WX185 Manuel utilisateur
Case
Case CX300C Manuel utilisateur
Case
Case CX31B Manuel utilisateur
Case
Case CX490D Manuel utilisateur
Case
Case CX800B Manuel utilisateur
Case
Case 788 Manuel utilisateur
Case
Case 845B Manuel utilisateur
Case
Case WX210 Manuel utilisateur
Case
Case 9040B Mode d'emploi
Case
Case CX145C SR Manuel utilisateur
Case
Case CX130 Manuel utilisateur
Case
Case CX290B Manuel utilisateur
Case
Case CX500C Manuel utilisateur
Case
Case CX350B Manuel utilisateur
Case
Case WX145 Manuel utilisateur
