CAS BP-1100PLUS Manuel utilisateur

BP-1100P User's Manual 영문

CONTENTS

1. Safety Instructions ..................................................................4

2. BARCODE PRINTER

.........................................................5

1. Printer Accessories ..............................................................5

2. General Specifications ........................................................5

3. Communication Interface .....................................................7

4. Printer Parts .........................................................................8

3. PRINTER INSTALLATION .............................................11

1. Ribbon Installation ............................................................ 11

2. Label Installation ..............................................................14

3. Label Roll Core Installation Instruction ...........................16

4. Card/Hang Tags Installation .............................................17

5. PC Connection ..................................................................17

6. Driver Installation .............................................................18

4.ACCESSORY

.......................................................................20

1. Stripper Module Installation .............................................20

2. Cutter Module Installation ................................................ 23

3. CF Card Adapter Installation ............................................ 26

4. CF Card Installation ..........................................................27

5. PRINTER SETTING ..........................................................28

1. FEED Key .........................................................................28

2. LED Status ........................................................................28

3. Auto Sensing .....................................................................29

4. Self-Test Page ................................................................... 29

5. Dump Mode ...................................................................... 30

6. Direct Thermal/Thermal Transfer Mode Switch................30

7. Sensor Switch...................................................................... 31

8. Error Messages

..................................................................32

6. MAIN TENANCE ANDADJUSTMENT ........................33

1. Thermal Print Head Cleaning ...........................................33

2. Thermal Print Head BalanceAdjustment........................... 34

3. Print Line Adjustment .......................................................34

4. Adjust the Cutter ...............................................................35

5. Troubleshooting

................................................................36

1. Safety Instructions

Please read the following instructions seriously.

1) Keep the equipment away from humidity.

2) Before you connect the equipment to the power outlet, please check

the voltage of the power source.

3) Disconnect the equipment from the voltage of the power source to

prevent possible transient over voltage damage.

4) Don’t pour any liquid to the equipment to avoid electrical shock.

5) ONLY qualified service personnel for safety reason should open

equipment.

6) Don’t repair or adjust energized equipment alone under any

circumstances. Someone capable of providing first aid must always

be present for your safety

7) Always obtain first aid or medical attention immediately after an injury.

Never neglect an injury, no matter how slight it seems.

2.Barcode Printer

1) Printer Accessories

After unpacking, please check the accessories that come with the package,

and store appropriately.

Barcode printer

Power cord

Switching Power

USB Cable / Parallel Cable

Label (Sample)

Ribbon (Sample)

Empty Ribbon Roll

Quick Start Guide

CD (includes label editing software Qlabel/Manual)

2) General Specifications

Model BP-1100plus

Print Method Thermal Transfer / Direct Thermal

Resolution 203 dpi (8 dot/mm)

Print Speed Max . 4 IPS (100 mm/s)

Print Width Max. 108 mm(4.25 Inch)

Print Length Min. 0.39” (10 mm)

Max. 68” (1727 mm)

Memory 4MB Flash (User Memory 2MB) , 8MB SDRAM

Sensor Type Adjustable reflective sensor. Fixed transmissive sensor,

central aligned

Types: Continuous form, gap labels, black mark sensing, and

punched hole; label length set by auto sensing or programming

Media Width: 1” (25.4 mm) Min. - 4.64” (118 mm) Max.

Thickness: 0.003” (0.06 mm) Min. - 0.01” (0.25 mm) Max.

Label roll diameter: Max. 5” (127 mm)

Core diameter: 1”, 1.5”, 3” (25.4 mm, 38.1 mm, 76.2 mm)

Ribbon

Types: Wax, wax/resin, resin

Length: 981’ (300 m)

Width: 1.18” Min - 4.33” (30 mm - 110 mm) Max

Ribbon roll diameter.: 2.67“ (68 mm)

Core diameter: 1” (25.4 mm)

Printer Language EZPL (GEPL firmware downloadable)

Software Label design software: QLabel-IV (for EZPL only)

Driver & DLL: Windows 2000, XP and Vista

Resident Fonts Bitmap fonts: 6, 8, 10, 12, 14, 18, 24, 30, 16X26 and OCR A & B

Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°,

180°, 270° rotatable

Bitmap fonts 8 times expandable in horizontal and vertical

directions

Scalable fonts 90°, 180°, 270° rotatable

Download Fonts

Bitmap fonts 90°, 180°, 270° rotatable, single characters 90°,

180°, 270° rotatable

Asian fonts 90°, 180°, 270° rotatable and 8 times expandable in

horizontal and vertical directions

Scalable fonts 90°, 180°, 270° rotatable

1D Barcode:

Code 39, Code 93, Code 128 (subset A, B, C), UCC/EAN-128 K-

Mart, UCC/EAN-128, UPC A / E (add on 2 & 5), I2 of 5, I2 of 5

with Shipping Bearer Bars, EAN 8 / 13 (add on 2 & 5), Codabar,

Post NET, EAN 128, DUN 14,

MaxiCode, HIBC, Plessey, Random Weight, Telepen, FIM,

China Postal Code, RPS 128, GS1 Data Bar

Barcodes

2D Barcode:

PDF 417, Datamatrix code, matrix code, QR code, Micro QR code

Code Pages

CODEPAGE 437, 850, 851, 852, 855, 857, 860, 861, 862, 863,

865, 866, 869, 737

WINDOWS 1250, 1251, 1252, 1253, 1254, 1255

Unicode (UTF8, UTF16)

Graphics Resident graphic file types are BMP and PCX, other graphic

formats are downloadable from the software

Interfaces Serial Port : RS-232 (DB-9)

USB Port : V2.0

Parallel Port : Centronics 36-pin

Control Panel Two bi-color status-LEDs: Ready, Status

Control key: FEED

Power 100-240VAC, 50/60 Hz

Environment Operation temperature: 41°F to 104°F (5°C to 40°C)

Storage temperature: -4°F to 122°F (-20°C to 50°C)

Humidity Operation: 30-85%, non-condensing.

Storage: 10-90%, non-condensing.

Agency

Approvals CE(EMC), FCC Class A, CB, cUL, CCC

Dimension Length: 11.2” (285 mm)

Height: 6.8” (171 mm)

Width: 8.9” (226 mm)

Weight 2.72kg

Options

Cutter

Label Stripper

External label roll holder for 10” (250 mm) O.D. label rolls

CF card adapter with real time clock (max. 1GB CF card)

* Specifications are subject to change without notice.

3) Communication Interface

Parallel Interface

Handshake : DSTB connects to the printer, BUSY connects to the host

Interface cable : Parallel cable compatible to IBM PC

Pin out : See below

Pin No Function Transmitter

2-9

19-30

34-35

/Strobe

Data 0-7

/Acknowledge

Busy

/Paper empty

/Select

/Auto-Linefeed

N/C

Signal Gnd

Chasis Gnd

+5V, max 500mA

Signal Gnd

/Initialize

/Error

Signal Ground

N/C

/Select-in

host / printer

host

printer

host / printer

host

host / printer

printer

host / printer

Serial Interface

Serial Default Setting : 9600 baud rate, no parity, 8 data bits, 1 stop bits,

XON/XOFF protocol and RTS/CTS

RS232 HOUSING (9-pin – 9-pin)

DB9 SOCKET DB9 PLUG

--- 1 1 +5V,max 500mA

RXD 2 2 TXD

TXD 3 3 RXD

DTR 4 4 N/C

GND 5 5 GND

DSR 6 6 RTS

RTS 7 7 CTS

CTS 8 8 RTS

RI 9 9 N/C

PC PRINTER

[Note] The total current output from parallel port and serial port altogether can

not exceed 500mA.

USB Interface

Connector Type : Type B

Pin No 1 2 3 4

Function VBUS D- D+ GND

4) Printer parts

1 Cover Open Button 2 Top Cover

3 Label Roll Core 4 Ribbon Rewind Wheel

5 Print Mechanism 6

Ribbon Rewind Shaft +

Empty Ribbon Roll

7 Locking Tenon(left/right) 8 Front Cover Piece

1 LED Light (READY)

2 LED Light (STATUS)

3 FEED Key

4 CF Card Slot Cover

5 Print Head Pressure Adjustment Screw(left/right)

1 Ribbon Supply Shaft

2 Label Guide

3 Platen Roller

4 Print Line Adjustment Gear

5 Label Sensor

1 Fan-Fold Label Insert

2 Power Switch

3 USB Port

4 Parallel Port

5 Serial Port (RS-232)

6 Power Socket

3.Printer Installation

This printer model has the following print modes.

Thermal Transfer (TT) When printing, ribbon must be installed to transfer the print

contents onto the media.

Direct Thermal (DT) When printing, no ribbon is necessary; it only requires

direct thermal media.

Please check the specific print mode, and then go into the Setting Mode after

power on the printer.

1) Ribbon Installation

1. Place the printer

on a horizontal

surface, and open

the top cover by

pressing the Cover

Open Buttons on

both sides.

2. the printer on a

horizontal surface,

and open the top

cover by pressing

the Cover Open

Buttons on both

sides.
