CAS CI-2001A Manuel utilisateur
2
CI-2001AB 국문
3
CONTENTS
PRECAUTIONS........................................6
FEATURES ................................................6
TECHNICAL SPECIFICATION...........7
DIMENSIONS ...........................................9
FRONT PANEL (CI-2001A)..................10
FRONT PANEL (CI-2001B) ..................13
REAR PANEL..........................................16
INSTALLATION.....................................17
TEST MODE............................................18
CALIBRATION MODE ........................21
SET MODE...............................................25
SERIAL INTERFACE............................30
ERROR MESSAGE................................34
Warning
Never disassemble, repair or retrofit the
product.
It might exclude the product from the
quality assurance and cause the damage
to devices, electric shock or fire.
Ensure the power plug to be fully
inserted to prevent shaking.
Any instable connection might cause
electric sparks to set fire.
Ensure the grounding of the product.
Poor grounding might cause failure or
electric shock upon electric leak.
Do not damage, process, excessively
jerk, bend or twist the power cord.
It might damage the power cord to
cause fire or electric shock.
Keep any combustible spray or fire
source away.
It might cause fire.
Do not spray water to the outside of the
product or use it in any humid place.
It might deteriorate the insulation of
electric parts that can cause the electric
shock, fire risk or weighing errors.
Do not place the product to the direct
sunlight or near any hot object like a
heater.
It might cause fire.
4
5
Attention
Check the weighing error anytime for
the accurate weighing.
Any use out of the allowed tolerance
for the careless use or other causes
might not ensure the accurate
weighing.
Customer Service：080-022-0022
Avoid any sudden shock to the product.
It might damage the product to fail the
accurate weighing.
Find a proper place to attach the rubber
pad at the bottom of the indicator,
which was shipped together.
Do not use the product at a place with
sudden temperature changes or severe
vibrations.
It might cause the weighing error or
failure.
Do not install the produce at a place with the excessive electromagnetic wave.
It might cause the wrong weighing.
6
PRECAUTIONS
Thank you very much for purchasing CAS International Indicator.
This produce is characterized by the excellent performance and luxurious features
through strict examinations, as well as elaboration for each part under our strict
quality control.
CAS Indicator (CI series) is a product with rich functions and various external
interfaces, which is designed to comply well with special requirements in a variety
of industrial fields under strong and beautiful designs in appearance.
In addition, it is designed for the user-friendly programs for the easier use of
indicator by any user with the built-in message display functions to help users
understand the product.
Please use the product right and sufficiently utilize functions of CI-2000 series as
you read this manual thoroughly before using CI-2000 series.
FEATURES
(1) Features
■Appropriate for weight and measurement system.
■Easy operation and various options.
■Simple Full Digital Calibration.
(SPACTM : Single pass automatic span calibration)
■WATCHDOG circuitry (System restoration).
■Weight Back-up (Power on Zero).
■Wall mount type (CI-2001A/B) - Standard
■Panel mount type (CI-2001A/B(P)) - Optional
(2) Main Function
■Various specification of weight conversion speed.
(Digital filter function)
■Various printer connection.(RS232 Serial printer - optional)
■Users can set the desirous max. weight and a division freely.
■Self hardware test.
Prompt A/S is available for test of each part of circuit by
module is possible.
7
TECHNICAL SPECIFICATION
■ Analog Part
LoadCell Excitation
Voltage DC 5V, Up to 4 x 350Ωload cells
Zero adjust range 0.05 mV ～5mV
2 μV/D (NTEP, OIML, KS)
Input Sensitivity
0.5 μV/D (Non NTEP, OIML, KS)
System Linearity 0.01％F.S.
A/D internal resolution 1 / 200,000
A/D external resolution 1 / 5,000 (NTEP, OIML, KS)
1 / 30,000 (Non NTEP, OIML)
A/D conversion speed 10times/sec
8
■Digital Part
Span calibration Full Digital Calibration : SPACTM
(Single pass automatic span calibration)
CI-2001A LED (6 digit)
Display
Size of letter CI-2001B LCD (5 digit)
CI-2001A 14 mm (Height)Display below zero
Additional Symbols CI-2001B 25 mm (Height)
AC Adapter “-”minus sign
CI-2001A Zero, Tare, Gross,
Net, Stable, lb, kg
Power Consumption
Operating Temperature CI-2001B Zero, Net, Stable, lb, kg
Overall Dimensions AC 110V/220V (DC 6V ～12V, 850mA)
CI-2001A 10 W
Weight
Span calibration CI-2001B 1 W
Display -10℃to +40℃
Size of letter 85mm x 186mm x 58mm
Display below zero 0.5 kg
■ Option
Standard Serial Interface : RS-232
Option-1 Serial Interface : RS-422/485
Option-2 Panel Mount Bracket
Option-3 Inner Clock (only CI-2001B)
9
DIMENSIONS
■ WALL-MOUNT TYPE(CI-2001A/B)-STANDARD
■ PANNEL-MOUNT TYPE (CI-2001A/B(P))
(Cutting Size : 166mm x 76mm)
10
FRONT PANEL (CI-2001A)
CAPACITY
TARE
CI- 2001A
ZERO
ZERO
GROSS
TARE
NET
kgGROSS
NET lb PRINT ENTER
STABLE
lb
kg
1. Display LAMP (■)
lb Lamp ON when the weight unit is pound [lb]
kg Lamp ON when the weight unit is kilogram [kg]
STABLE
Lamp ON when the weight is stable.
TARE Lamp ON when the tare weight is stored.
GROSS Lamp ON when the current weight is GROSS weight.
NET Lamp ON when the current weight is NET weight.
ZERO Lamp ON when the current weight is 0 kg(0 lb).
11
2. KEY PART
▲, ◀Available keys instead of numeric keys.
▲Change the set value
Increase the first place value to 1
◀
Change the digit of the set value
Move to the left by 1 place
USAGE : Input the numeral value in TEST, CAL, SET
mode.
ZERO Key Return the display to 0
TARE Key
Use container in weighing.
Current weight is memorized as tare weight.
If you press TARE key in unload condition, Tare setting is
released.
GROSS/NET
KEY
Display gross and net weight by turn.
GROSS lamp on - gross weight
NET lamp on - net weight
In case tare weight is REGISTERED, tare and item's total
weight is G. weight and only item's weight is N. weight.
Kg / lb
KEY Toggles between lb and kg units.
PRINT KEY PRINT Key
ENTER KEY
▣Total Print KEY.
→In case of F09 : 1
▣Hold KEY.
→In case of F09 : 2
▣In CALIBRATION, TEST, SET mode.
: Store current condition and exit.
