Carrier Standing Type Inverter
Air Conditioner
Product features
Using the Premier Green Inverter, Carrier's advanced power saving technology
enables the users to maintain a comfortable indoor environment.
| Inverter control operation |
| Sterilization cleaning |
You can set the button locking function to prevent children from controlling it.
| Safety lock function
|
You can adjust the brightness of the LED display to prevent annoyance to
your eyes when you try to sleep at night.
| Display brightness control l
It uses an environmentally friendly refrigerant called R-410A.
| R-410A refrigerant |
If you stop the operation, the fan will operate at a low speed instead of
immediately stopping so the moisture on the heat exchanger will be removed.
| Auto drying |
It performs maximum cooling/heating operation to quickly reach the set
temperature that a user wants.
| High power operation |
Depending on the room temperature, the unit selects its own operation
mode(cooling/heating) and air flow volume to maintain the best environment.
| A.I. automatic operation |
The air conditioner that rotates horizontally to cool or heat the entire area
completely.
| Swivel head (air discharge) |
It removes indoor moisture during monsoon season or on rainy days.
| Dry operation
|
It removes harmful dusts, smoke and odors to maintain the clean and
refreshing air throughout all four seasons.
| Independent air cleaning
operation |
Check whether the air conditioner is properly installed to find any
defects in installation.
| Smart installation |
It operates properly for the external temperature and body temperature changes
in the hot summer nights in order to help you get nice sleep.
| Sleeping operation |
It reduces power consumption for heating/cooling and maintains the optimal
room temperature.
| Power saving operation |
The soft light of LED lamps can make the indoor atmosphere cozy and
beautiful.
| Indirect lighting |
The air conditioner with an ifD(Intense Field Dielectric) filter that can collect
99.99% of small specks of dust with the size of 0.3㎛.
| ifD filter |
When the unit turns off, the fan will operate at a low speed instead of
immediately stopping and it will turn on the UV lamp to remove germs and
fungus.
Contents
Operation Method
Installation
Precautions‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥
Unit Description ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥
Remote Control Description ‥‥‥‥‥‥‥‥‥‥‥‥‥‥
Unit Operation ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥
Automatic Operation ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥
High Power and Dry Operation ‥‥‥‥‥‥‥‥‥
Independent Air Cleaning Operation ‥‥‥‥‥‥‥‥‥‥
Power Saving Operation ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥
Sleeping Operation ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥
Timer Operation ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥
LED Light ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥
Maintenance ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥
Check before Installation ‥‥‥‥‥‥‥‥‥‥‥‥
Installation Location Selection ‥‥‥‥‥‥‥‥‥‥‥
Installation ‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥
Connecting the Pipes‥‥‥‥‥‥‥‥‥‥‥‥‥
Product Spec/Connection Pipe/Refrigerant Charging‥‥‥‥
Wiring‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥
Operation Range‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥
Troubleshooting‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥‥
2
11
13
15
18
19
20
21
22
24
26
27
30
31
32
33
39
40
42
43
Before Use
Must Know
Wait! This product is only for 220V. If you don't have
a 220V, make sure you use a converter.
Carrier Standing Type Inverter Air Conditioner
2
Installing and servicing air conditioning equipment can be hazardous due to system pressure
and electrical components. Only trained and qualified service personnel should install or
service this equipment.
Untrained personnel can perform basic maintenance functions such as cleaning filters and
replacing filters.
All other operations should be performed by trained service personnel.
When working on air conditioning equipment, observe precautions stated in the manual and
on tags and labels attached to the unit.
Before performing service or maintenance on system, turn off the main power to the unit.
Electric shock may cause personal injury.
Label
Safety Consideration
Warning
Symbol
Forced action. You must follow the action indicated by this symbol.
Specific details are displayed using text and figures inside this symbol.
Forced
Prohibited action. Do not perform this action. Specific prohibitions are
displayed using text and figures inside this symbol.
Prohibited
Cautionary item. Specific details are displayed using text and figures
inside this symbol.
Caution
If you violate this, it can cause personal injury or property damage.
Caution
If you violate this, it can cause death or serious injury.
Warning
PRECAUTIONS
User / Install Manual 3
Forced
Prohibited
Warning
Do not install near flammable gas
or fire. (Gas leakage can cause
explosions or fires)
Ask an expert to install the unit.
(Poor installation can cause
malfunctions, electric shocks, fire or
water leakage)
Installation
Gas
leakages,
fires.
A/S
SERVICE
Forced
Do not cut and attach to another
power cable.
(It can cause malfunctions or
electric shocks)
Do not install the outdoor unit
outside a balcony or on an outer
wall. (A drop can cause serious
physical or property damage)
Prohibited
Make sure the switch and circuit
breaker are properly installed.
(If not, electric shocks may result)
Install the ground connection
properly. Do not connect to gas/
water pipes or telephone lines. (If
not, malfunctions or electric shocks
may result)
Forced Forced
Circuit
breaker
must be
installed
Carrier Standing Type Inverter Air Conditioner
4
Installation
Use
Caution
Prohibited
Forced Forced
Prohibited
Poor drainage is caused by poor
hose installation. (Condensation
dropping on indoor unit can cause
damage)
Make sure the outdoor and indoor
unit sit on a level surface. (If you do
not, noise can be generated)
Do not fix the power cable with
staplers, or place it below heavy
objects. (Damaged wires can cause
fires)
Do not pull the power cable.
(If damaged, it can cause fire or
electric shock)
Maintain
the level
Prohibited
PRECAUTIONS
Prohibited
Do not install in an area with
direct sunlight or near a heating
device. (This will cause low cooling
performance or may cause electric
shock; draw curtains or blinds)
Install in a place to avoid noise and
always keep it in a place away from
obstructions.
Forced
User / Install Manual 5
Warning
Use
Do not touch the switch with wet
hands. (It can cause electric shock
or malfunctions)
Do not attach a heating device or
electrical heater to the unit and do not
modify it. Do not disassemble the unit
without consent of service men.
(It can cause malfunctions, electric
shocks or fire)
When you want to move or reinstall the
unit, consult your local dealer. (Moving
or reinstalling the unit by yourself can
lead to malfunctions, water leaks,
electric shocks and fire)
Forced
Prohibited
Wet
hands
Disassembly
A/S
SERVICE
OK!
ON
OFF
Do not put hands or objects into the
discharge grille of outdoor unit. (The
outdoor unit has a fan running at high
speed. It is very dangerous to touch
the fan)
Forced Forced
Supply the correct voltage.
(Using other voltage than that
specified will damage the unit
or result in fire)
Use only fuses of the proper
amperage.(Do not use steel wire or
copper wire instead of a proper fuse.
It may not only damage the unit, but
could cause a major fire)
Rated
capacity
220V
Caution : 220V power must be
used for the Air Conditioner.
Carrier Standing Type Inverter Air Conditioner
6
Warning
Use
Forced
Power off
Do not turn off the sub switch or
remove the power plug during
operation.
(It can cause electric shocks or fire)
Make sure that the power plug is
correctly inserted into the socket.
(If not, it can cause electric shocks
or fire)
Prohibited
Prohibited
In case of lightning, disconnect
the power supply and remove the
power plug. (Leaving unit plugged
in during thunder/lightning can
cause malfunctions)
If the power cable is damaged, do
not repair or replace it on your own.
Consult your local dealer.
PRECAUTIONS
Keep the unit and power plug
away from water. (It can cause
malfunctions or electric shocks)
If you detect strange noises or
smells from the unit, stop and power
off the unit and notify your local
dealer. (It can cause malfunctions,
electric shocks and fire)
Prohibited Power off
User / Install Manual
Do not step on the unit or place
objects on it. (It can cause
malfunctions or electric shocks)
7
Warning
Use
Do not use flammable sprays
near the unit. (The unit can be
damaged by gasoline, benzene,
thinner, insecticide and other
chemical agents)
Do not put hands into the air outlet
of indoor unit. (The indoor unit has a
fan running at high speed.
It is very dagerous to touch the fan)
Prohibited Prohibited
ON
Prohibited Forced
Do not allow animals or plants to be
directly exposed to the air flow of
the air conditioner. (It can have bad
effects on animals or plants)
Do not use the residential air
conditioner for other purposes. (Do not
use it for special purposes such as
preservation of precision instruments,
food, animals, plants and cosmetics. It
can cause deterioration in quality)
Excessive cooling may be bad for
your health so air should be vented
periodically. (Excessive cold air may
have adverse effects on your health)
Prohibited Prohibited
Carrier Standing Type Inverter Air Conditioner
8
Caution
Use
Prohibited
Power off
Forced
Forced
Clean the air filter once every other
week. (Excessive dust should
be cleaned with lukewarm water
and neutral agents. A excess of
dust could cause performance
degradation, malfunction or excessive
power consumption)
Insert the air filter firmly. (Absence of
air filter can cause reduce the life-
expectancy of the air conditioner or
excessive power consumption)
Turn off the unit when you clean
it. (The high speed rotating fan
can cause physical injury when in
operation)
Do not obstruct the air outlet. (It can
cause malfunctions or accidents)
ON
OFF
Once every
other week
PRECAUTIONS
Do not obstruct the indoor air inlet
and outlet while the unit is on.
(This will block air flow, reduce the
cooling/heating effect and may result
in unit malfunction)
Do not use wax, thinner, or oil to clean
the exterior of the unit. (It can cause
surface damage, malfunctions or electric
shocks. Wipe it with a dry cloth)
ON
Prohibited Prohibited
Table des matières
Autres manuels Carrier Climatiseur
Carrier
Carrier 40MAQ Manuel utilisateur
Carrier
Carrier AIR-COOLED CONDENSIGN UNIT 38AK007 Dimensions et guide d'installation
Carrier
Carrier Creation Green 53KHET30N2-708F Manuel utilisateur
Carrier
Carrier CRTWOPOS012A00 Manuel utilisateur
Carrier
Carrier 40QA024-060 Dimensions et guide d'installation
Carrier
Carrier PGR5 Mode d’emploi
Carrier
Carrier Gemini 38AU 16-28 Series Dimensions et guide d'installation
Carrier
Carrier 38CKC Manuel d'utilisation
Carrier
Carrier 48FC Series Manuel utilisateur
Carrier
Carrier Atmosphera 42EM series Manuel utilisateur
Carrier
Carrier 024-048 Manuel utilisateur
Carrier
Carrier KC Series Manuel utilisateur
Carrier
Carrier 48VL C Series Mode d’emploi
Carrier
Carrier 50TCA04 Manuel utilisateur
Carrier
Carrier 40KMC Manuel utilisateur
Carrier
Carrier 48PG03---16 Mode d’emploi
Carrier
Carrier 48SD Mode d’emploi
Carrier
Carrier AIR-COOLED CONDENSIGN UNIT 38AK007 Dimensions et guide d'installation
Carrier
Carrier COMFORTLINK 48HG014 Mode d'emploi
Carrier
Carrier 51ER Manuel utilisateur
