Carmelli NG4009H Manuel utilisateur
NG4009 H
PATRIOT 5' AIR HOCKEY TABLE
ASSEMBLY INSTRUCTIONS
Please Do Not Hesitate to
Contact Our Consumer Hotline
at 800-759-0977
with Any Questions That May
Arise During Assembly or
Use of This Product!
THANK YOU!
Thank you for purchasing this product.
We work around the clock and around the globe to ensure that our products
maintain the highest possible quality. However, in the rare case of issues
during assembly or use of this product, please contact our Consumer Hotline
at 800-759-0977 for immediate assistance before contacting your retailer.
Please read the warranty information at the back of these assembly
instructions for further details.
IMPORTANT! PLEASE READ THESE ASSEMBLY INSTRUCTIONS
IN ENTIRETY BEFORE ASSEMBLING YOUR PRODUCT.
2
PARTS IDENTIFIER (NOT TO SCALE)
ADDITIONAL EQUIPMENT REQUIRED:
3
AAA BATTERY
2PCS
Please see Parts List at end of manual for Part Numbers when ordering parts. For replacement parts please call 800-759-0977.
ASSEMBLY TIPS
1. Find a clean, level surface to begin the assembly of your game table. The table will be par-
tially assembled upside down and then turned over onto its legs. This is a heavy game and
turning it over will require at least two strong adults.
2. Remove all of the contents from box and verify that you have all of the parts shown on the
Note: Some parts may be pre-installed or pre-
assembled.
-
stand the text before beginning each assembly step.
4. When installing parts that have more than one screw or bolt, hand tighten all screws or
bolts in place before nishing tightening with screwdriver or hex wrench.
5. Electric screwdrivers may be helpful during assembly; however, please set a low torque
and use extreme caution because screws may be stripped or overtightened if the electric
screwdriver's torque is set too high.
WARNINGS!
READ AND FOLLOW ALL ASSEMBLY, OPERATION AND SAFETY INSTRUCTIONS CAREFULLY.
CHOKE HAZARD - THIS TABLE CONTAINS SMALL BALLS AND PARTS - NOT
SUITABLE FOR CHILDREN UNDER 3 YEARS OF AGE.
4
ASSEMBLY INSTRUCTIONS
1. Attach RIGHT LEGS #2 and LEFT LEGS #3 to the corners of TABLE BODY #1 as shown with
LARGE BOLT #6 and LARGE FLAT WASHER #7. Note: The table is assembled upside down.
2. Thread one LEG LEVELER #13 to each LEG.
3. Attach each LEG PANEL #4 to LEGS as shown with SCREW #10. Note: Graphics should face
outward.
5
ASSEMBLY INSTRUCTIONS (CONT.)
4. Attach each LEG BRACE #5 to LEGS as shown with SMALL BOLT #8 and SMALL FLAT
WASHER #9. Feed wire leads through gasket, and carefully turn table over.
5. Attach ELECTRONIC SCORER #11 with SCREW #16.
6
* Before turning the
table over, carefully
feed two wire leads
through gasket hole
in center of side panel.
Carefully attach 2 wire leads to
ELECTRONIC SCORER #11.
Insert the lead “ A ”
into the “ A ” receptacle.
Insert the lead “ B ”
into the “ B ” receptacle.
A B
A B
CONGRATULATIONS!
You have now assembled your Game Table.
Please note the Care and Use instructions below to
ensure years of trouble free use of your game table.
CARE AND USE
1. This product is intended for INDOOR use only.
2. Do NOT sit, climb or lean on the table.
3. Do NOT drag the table when moving it as this will damage the legs.
7
180-DAY LIMITED WARRANTY
This product is warranted to the original purchaser to be free from defects in material or workmanship
for a period of 180 days from the date of the original retail purchase.
This warranty does not cover defects or damage due to improper installation, alteration, accident or
any other event beyond the control of the manufacturer. Defects or damage resulting from misuse,
abuse or negligence will void this warranty. This warranty does not cover scratching or damage that
may result from normal usage.
This product is not intended for institutional or commercial use; the manufacturer does not assume
any liability for such use. Institutional or commercial use will void this warranty.
This warranty is nontransferable and is expressly limited to the repair or replacement of the defective
product. During the warranty period, the manufacturer shall repair or replace defective parts at no
cost to the purchaser. Shipping charges and insurance are not covered and are the responsibility of
the purchaser. Labor charges and related expenses for removal, installation or replacement of the
product or components are not covered under this warranty.
The manufacturer reserves the right to make substitutions to warranty claims if parts are unavailable
or obsolete.
The manufacturer shall not be liable for loss of use of the product or other consequential or incidental
costs, expenses or damages incurred by the consumer of any other use. The user assumes all risk of
injury resulting from the use of this product.
This warranty is expressly in lieu of all other warranties, expressed or implied, including warranties of
. Neither the manufac-
turer nor any of its representatives assumes any other liability in connection with this product.
All warranty claims must be made through the retailer where the product was originally
purchased. A purchase receipt or other proof of date of purchase will be required to process
all warranty claims. The model number and part numbers found within the assembly
instructions will be required when submitting any parts requests or warranty claims.
For further warranty information or inquiries, please call 800-759-0977
PATRIOT 5' AIR HOCKEY TABLE - NG4009H
Parts List
PARTS
HARDWARE PACK - NGP54975
#6 #7 #8 #9#10 #12
TLOBEGRAL LARGE FLAT
WASHER SMALL BOLT
TALFLLAMS
WASHER 1/2 INCH SCREW
#16
#1NGP6259 #2NGP54971 #3NGP54972 #4NGP6260 #5NGP54974
TABLE BODY RIGHT LEG LEFT LEG LEG PANEL LEG BRACE
#11 NGP54976
ELECTRONIC
SCORER
1
3/4 INCH SCREW
HEX WRENCH
ADDITIONAL EQUIPMENT
REQUIRED:
PHILLIPS HEAD
SCREWDRIVER
5/15
ADDITIONAL EQUIPMENT
REQUIRED:
AAA BATTERY
2
4
3
5
13
11,17
14
15
#13 NGP54977
LEG LEVELER
#14 NGP5070 #15 NGP5071
STRIKER PUCK
#17 NGP54978
SCORER
SENSOR WIRE
(A & B wires:
1 wire set
per goal)
NG4009 H
JEU DE HOCKEY SUR COUSSIN
D’AIR DE 1,52 m INSTRUCTIONS
D’ASSEMBLAGE
Contactez notre
service à la clientèle au
800-759-0977
avec des questions sur le montage
ou l'utilisation de ce produit.
