Introduction

Congratulations and thank you for purchasing

the scala-rider™ Bluetooth headset for

motorcycle helmets. No you can ear your

helmet hile talking hands-free on your

Bluetooth enabled mobile phone, made possible by the short-range ireless

connection bet een your cell phone and the scala-rider headset.

If you are using a standard non-Bluetooth mobile phone, you can still enjoy the

headset’s advantages by connecting our optional BT Adapter to your mobile phone

(purchased separately).

The scala-rider headset is compatible ith the latest Bluetooth ver. 1.2

specifications, and orks equally ell ith Bluetooth ver. 1.1.

Please read and familiarize yourself ith all the instructions, components and

controls of your headset prior to first use.

We ish you a great scala-rider experience.

CARDO SYSTEMS, Inc.

DRAFT

Page 3 of 19

Retail Package Contents.

Your retail package contains the follo ing items:

• Headset

• Clamp

• Large sponge for microphone (for 3/4 helmets)

• Small sponge for microphone (for full-faced helmets)

• extension pad for the helmet unit

• Allen rench

• Wall Charger (universal travel version)

• CD-Manual & Quick Start Guide

• Warranty + Registration Card

• Velcro for speaker (needed only for certain helmet types).

Headset

Allen wrench

Large microphone

sponge

Wall Charger (dual voltage)

Printed Quick Guide and

multilingual manual on mini-CD

Clamp

elcro to place the

speaker

Travel Pouch

Optional extension pad for

Clamp Base.

Small microphone

sponge

DRAFT

Page 4 of 19

CTRL (control button) –

Press

CTRL button to

• Accept or initiate calls

• Turn po er ON/OFF

• Pair

Redial/Reject/End button –

• End/Reject calls (*)

• Redial function

Before using the headset

Read and familiarize yourself ith all instructions, components and controls of your scala-

rider headset prior to first use.

Regarding call terminations, see NOTE in

section 6.4

Sliding-Plate of the clamp

Charging socket

Volume do n button –

Press to decrease the

volume

Volume Up button –

Press to increase the volume

Microphone

Speaker

Press on arc to

release

headset

Charge the headset by inserting the

all-charger into the charging socket

(lift the rubber cover to insert the plug)

DRAFT

Page 5 of 19

.1 Charging Battery

Make sure the headset is fully charged prior to initial use. Allo at

least Four hours for a full charge before using for the first time. Normally 2-3 hours

ill suffice for complete charge. The headset should be off the helmet hen being

charged (solely for purposes of convenience)

• Plug the Wall Charger into the charging socket of the headset and connect it to an

electrical outlet.

• The Red Light Indicator (LED) on the scala-rider ill turn on hen charging begins.

Allo the headset to charge until the Red LED turns off.

• When charging is complete, release the headset from the charger.

NOTE: You may leave the unit connected even if charging is completed. There is no

danger of over-charging.

.2 Attaching and removing the scala-rider from your helmet

4.2.1 First installation

Once the headset is fully charged you should pair it to your mobile

phone. You cannot operate the headset prior to successful pairing

(see section 5 belo ). When done, proceed ith attaching the unit to your helmet

as follo s: back plate

• The clamp serves as the base for the headset and must be attached to your

helmet before using the headset

• Use the enclosed Allen Wrench to loosen the t o

scre s of the clamp (FIG. 1). Then slide the back-

plate of the clamp bet een the internal padding and

the external shell of the helmet (FIG. 2).

(In case the external shell of the helmet is too ide,

use the optional extension pad)

• Before fastening the scre s, make sure to adjust the

clamp’s location to an ideal position, i.e. to the spot

here the attached speaker sits opposite your ear

and the microphone is located slightly off the corner

of your mouth (FIG. 3). You may need to re-position

the clamp repeatedly until you identify the ideal spot.

The speaker can be easily placed into position and

removed by means of the Velcro layer that

attaches to the inner padding of your helmet.

(Velcro pad included in your retail box).

• Once you have identified the ideal position for

The microphone and speaker, use the Allen

Wrench to fasten the clamp.

• No slide the scala-rider headset do n ards along the Sliding-Panel of the

clamp (FIG. 4) until a light clicking sound indicates that the

headset has reached its proper operational position.

• Turn on the headset by pressing and holding CTRL for at least 6 seconds

until the Blue LED flashes three times and an ascending alert tone is heard.

FIG 2

FIG 1

Microphone should be placed just slightly off

the corner of your mouth and not at the center

FIG 3

DRAFT

Page 6 of 19

Quickly release the button.

4.2.2 Removing the headset from the helmet.

The clamp usually stays attached to the helmet, but you can also easily remove it

by proceeding in the reverse order of the attachment procedure (see 4.2.1 above).

• To remove the headset from the clamp, press your finger firmly against the

arched tip of the sliding-panel (FIG. 5) and use the other hand to slide the

headset up ards along the Sliding-Panel (FIG. 5).

4.2.3 Re-attaching the headset to the helmet.

• To re-attach the headset, simply slide it do n ards along the Sliding-Panel

of the clamp (FIG. 4) until a light clicking sound indicates that the headset

has reached its proper operational position.

4 Getting Started with the scala-rider headset

Before you can use your headset for the first time, the pairing process

bet een your headset and mobile phone must be completed. Pairing is the required

process of mutual recognition bet een your headset and mobile phone.

Please note: Your headset ill not ork prior to successful completion of the pairing

process!

4.1 Pairing process

4.1.1 Turn on the phone and activate its Bluetooth function.

4.1.2 Press and hold the CTRL button until the red and blue LEDs begin flashing rapidly

FIG 4

Press against the

arc,

then slide the headset

unit upwards.

FIG 5

DRAFT

Page 7 of 19

alternating.

4.1.3 On your Bluetooth phone, search for Bluetooth devices by follo ing your phone’s

instructions. Usually this is done by selecting the earch or Discover option in the

Bluetooth or Connection menu. Refer to your phone’s manual for detailed

instructions on ho to pair using your specific phone.

4.1.4 After a fe seconds of searching, your phone ill list the “scala-rider” as a

discovered device. Select it, and hen asked, follo your phone’s instructions to

accept pairing.

4.1.5 When prompted by your phone, enter 0000 (4 zeros) as your PIN or passkey.

4.1.6 Your phone ill confirm hen pairing has been successfully completed.

NOTE: If pairing is not completed within two minutes, the headset will return to

tandby mode (flashing Blue every 3 seconds). To pair again, turn off the headset

by pressing and holding the CTRL button until the red led flashes three times and

repeat the process as shown above (5.1).

Congratulations! You have no successfully completed your Bluetooth

pairing process and are able to use your scala-rider headset ith your mobile phone.

From no on, hen using your headset, you ill no longer need to pair the headset to the

phone. The t o devices ill remain paired until you delete that pairing from the phone.

4.2 Power On/Off

To turn ON, press and hold the CTRL button for at least 6 seconds until the Blue LED

flashes three times and an ascending alert tone is heard. Quickly release the button.

To turn OFF the headset, press and hold the CTRL button for at least 3 seconds until the

Red LED flashes three times and a descending alert tone is heard.

4. Renewed Pairing

If you ish to use a different phone or in case you need to repeat the pairing process for

any other reason, please proceed as follo s:

5.3.1 Turn the headset off.

5.3.2 Press the CTRL button for 10 seconds until the red and blue LEDs begin flashing

rapidly alternating.

5.33 Follo sections 5.1.3 to 5.1.6 above.

4.4 Reconnecting the scala-rider headset to a paired phone

Although you may have previously paired your headset to your phone,

each time you turn one of them off, some phones require that you re-establish the

connection.(not to be confused ith pairing)

Reconnecting may also be necessary hen your headset and phone have lost the radio

signal because the distance bet een them has exceeded 30 feet or 10 meters.

After you have turned on your mobile phone, there are several methods to reestablish the

connection:

DRAFT

Page 8 of 19

• Turning the headset on should reconnect it automatically to the phone.

• With some mobile phones you need to reestablish the link to your headset

by using your phone’s menu. Please refer to your mobile phone’s manual

for operating instructions.

• Assuming your phone features voice activation, tap the CTRL button on your scala-rider

headset. This ill activate your phones voice dial function, indicating that the connection

is established.

• Do nothing. Once a call is received, ans er by pressing the CTRL button.

5 Handling Calls

NOTE: Certain advanced features of the scala-rider are only accessible to phones

equipped with the hands-free profile.

5.1 Initiating calls by using your phone’s keypad

a. Dial the phone number on your phone’s keypad.

b. Press “Talk” or “Send” on your phone to dial the number.

5.2 Voice Dialing

a. Make sure your phone is ON but no call is in progress.

b. Tap the CTRL button and listen for a tone.

c. No pronounce the name of the party you ish to call and ait for feedback from

the phone. The type of feedback depends on your phone.

5. Answering Calls (including Special Voice Recognition Feature)

The ringtone for incoming calls increases gradually. When you hear the ring tone

(on the headset), there are t o ays you can ans er the call:

- Tap the CTRL button on your headset once (FIG. 6)

- Assuming the Voice Recognition feature is active (see section 7 belo ), ans er

the call by pronouncing loudly any ord of your choice ithin 7 seconds. If you

remain silent for 7 seconds the call ill be automatically rejected and the ringing

ill stop.

5.4 Terminating Calls

To terminate a call, tap the Reject/Redial/End button, follo ed by a tone confirming

the termination (FIG. 7)

Tap

here to

answer

the

call

FIG.

DRAFT

Page 9 of 19

If the other party terminates the call first, you don't have to do anything.

Wait at least three seconds before pressing the CTRL button to start voice dialing.

NOTE: If your mobile phone does not support the handsfree protocol you will not

be able to end calls by pressing the Reject/redial/End Button. Instead, please tap

the CTRL button to terminate calls.

5.5 Volume Control

The scala-rider headset comes equipped ith AGC technology to automatically

adjust itself to the optimal speaker volume. Its embedded sensors continuously

measure the ambient noise and driving speed to make manual adjustment of the

volume buttons virtually unnecessary.

Irrespective of this feature, you can adjust the volume anytime by pressing the

volume buttons one step at a time (FIG. 8). For each step of adjustment, you ill

hear a short beep.

5.6 Call Reject

While you hear the ring tone on the headset, there are t o ays you can reject the

call:

- Tap the Redial/Reject/End button on your headset to reject the call (FIG. 9).

- Assuming the VR feature is enabled (see section 7 belo ), remain silent for 7

seconds to reject the incoming call.

Tap here to reject the

call or initiate redial

FIG. 9

Press here to decrease the

volume

Press here to increase

the volume

FIG.8

Tap here to terminate

the call

FIG. 7

DRAFT

Page 10 of 19

5.7 Redial

While no call is in progress, tap the Redial/Reject/End button on your headset to

redial to the last number (FIG. 9).

7 Voice Recognition (VR) feature

The VR feature allo s you to ans er or reject incoming calls by voice control

ithout having to remove your hands from the handlebars.

The default mode of this feature is ON.

To disable the VR feature, please refer to section 7.1 belo .

NOTE: The VR feature works well while driving up to 70km/h or 44m/h with 3/4

helmet and up to 120km/h or 75m/h with closed full faced helmet.

For best performance use the enclosed large microphone sponge.

7.1 Enable/Disable the Voice Recognition feature

Press and hold the Volume Up and Volume Do n buttons simultaneously for 3

seconds to enable/disable the VR feature. You ill hear an ascending/descending

tone confirming the change each time you s itch this feature ON or OFF

respectively.

7.2 Answering calls using Voice Recognition

When you hear an incoming call via the headset, pronounce loudly any ord of

your choice ith in 7 seconds in order to ans er the call.

7. Rejecting calls using Voice Recognition

When you hear an incoming call via the headset, remain silent for the next 7

seconds in order to reject the call and stop the ringing.

8. Light and Sound Signals

LED indication

Status

Triple blue flash Headset being turned on

Triple red flash Headset being turned off

Single blue flash every 3

seconds

STANDBY:

Not on a call

Double blue flash every 3

seconds

ACTIVE:

On a call or initiating a connection.

Rapid red-blue alternating

flash

PAIRING MODE

Single red flash every 3

seconds

Lo battery hile in STANDBY

Autres manuels pour ScalaRider

Table des matières

Autres manuels Cardo Systems casque

Cardo Systems

Cardo Systems Scala 700 Manuel utilisateur

Cardo Systems

Cardo Systems PACKTALK EDGE Manuel utilisateur

Cardo Systems

Cardo Systems FREECOM 2x Manuel utilisateur

Cardo Systems

Cardo Systems Packtalk Bold Manuel utilisateur

Cardo Systems

Cardo Systems FREECOM 1 Manuel utilisateur

Cardo Systems

Cardo Systems Scala-500 Combo Manuel utilisateur

Cardo Systems

Cardo Systems SCALA RIDER SOLO Manuel utilisateur

Cardo Systems

Cardo Systems SCALARIDER Q2 MULTISET PRO Manuel utilisateur

Cardo Systems

Cardo Systems SCALA RIDER G4 POWERSET Manuel utilisateur

Cardo Systems

Cardo Systems scalarider q1 Manuel utilisateur

Cardo Systems

Cardo Systems Packtalk NEO Manuel utilisateur

Cardo Systems

Cardo Systems G9 Powerset Manuel utilisateur

Cardo Systems

Cardo Systems SCALA RIDER G4 Manuel utilisateur

Cardo Systems

Cardo Systems Scala Rider MultiSet Q2 Manuel utilisateur

Cardo Systems

Cardo Systems Scala rider Q2 Manuel utilisateur

Cardo Systems

Cardo Systems SCALA RIDER FM - Manuel utilisateur

Cardo Systems

Cardo Systems scala rider Q-solo Manuel utilisateur

Cardo Systems

Cardo Systems scala rider Q-solo Manuel utilisateur

Cardo Systems

Cardo Systems allways Manuel utilisateur

Cardo Systems

Cardo Systems Scala 700 Manuel utilisateur

Cardo Systems

Cardo Systems Packtalk black Manuel utilisateur

Cardo Systems

Cardo Systems Headset Scala 600 Manuel utilisateur

Cardo Systems

Cardo Systems Scala-rider TeamSet Manuel utilisateur

Cardo Systems

Cardo Systems SPIRIT Manuel utilisateur

Manuels casque populaires d'autres marques

Sena

Sena SMH10 Manuel utilisateur

IASUS

IASUS Stealth IA-NT4-BASIC-BT Manuel utilisateur

Sennheiser

Sennheiser EPOS ADAPT 230 Manuel utilisateur

Doro

Doro Flexus HS2005 Manuel utilisateur

GE 98971 Manuel utilisateur

Hama

Hama 00184070 Manuel utilisateur

Plantronics

Plantronics Blackwire 3200 Series Manuel utilisateur

Blue Tiger

Blue Tiger Advantage PLUS Manuel utilisateur

Jawbone

Jawbone Icon Manuel utilisateur

Jabra

Jabra FR 20 Manuel utilisateur

Roxcore

Roxcore Flow A+ Manuel utilisateur

Turtle Beach

Turtle Beach XP 510 Manuel utilisateur

Philips

Philips SHB6101 Manuel utilisateur

Jabra

Jabra PRO 9460 Duo Manuel utilisateur

HyperX

HyperX HyperX Cloud Flight Manuel utilisateur

Bose

Bose MIE2 Mobile Manuel utilisateur

Jabra

Jabra Steel Manuel utilisateur

HyperX

HyperX cloud ii Manuel utilisateur
