Cardinal Priefert 190P Fiche technique

Page 1

Priefert 190P

Digital Weight Indicator

Quick Set Up

Page 2

Page 1

Unpack

Unpack the box and check that you have each of the following:

190P Digital Weight Indicator

Data Cable (PN: 3502-B476-0A)

Cable Gland (PN: 6610-2248)

Mounting Gimbal (PN: 8400-C004-08)

Rubber Feet (x4) (PN: 6540-1004)

Manual on CD (PN: 8400-M022-01)

Charge Battery

To charge the battery pack, plug-in the power cord to an AC power outlet. It will take

approximately six (6) hours to fully recharge the battery pack in the indicator. The

indicator may be operated while the battery is charging.

The battery status indicator indicates the level of charge. When

charging the battery, the charge level status bars will scroll.

Page 2

OPERATION

The following sections give a quick overview of the 190P indicator and its operation.

For detailed information please refer to the 190 Installation, Technical and Operation

Manual (PN: 8400-M022-01) on the CD received with the indicator.

Keypad and Display

The Model 190 uses a capacitive touch keypad that requires a “finger

touch” to function. The keypad will not operate with other items such as

pen, pencil or tools.

Page 3

Key

Description

ON/OFF: The ON/OFF key is used to turn the

indicator on and off.

Press the ON/OFF key when the indicator is

off to turn the indicator ON. The 190 will

perform a display test (turn on all segments)

and then show the model number and

software version.

If the indicator is already on, press the

ON/OFF key and hold for 2 to 3 seconds.

When the display shows OFF, release the

key to turn the indicator OFF.

ZERO: The ZERO key is used to zero the weight

display. Up to the selected limit of 4% or 100%

of the scale’s capacity can be zeroed. This limit

is selected during the setup and calibration of the

indicator.

Note that the indicator will not respond to

pressing the ZERO key unless the weight display

is stable.

When displaying a Tare weight, pressing

the ZERO key will clear the Tare value and

set the display to Gross mode.

When displaying the Peak weight, pressing

the ZERO key will clear the Peak weight.

When displaying the Gross accumulator,

pressing the ZERO key will clear the Gross

accumulator.

When displaying the Net accumulator,

pressing the ZERO key will clear the Net

accumulator.

Page 4

Key

Description

TARE(Enter): The TAREkey is used during

normal operation to store the current Gross weight as

the new Tare weight. The display will change to the Net

weight and the Net annunciator will turn on.

Pressing the TAREkey when in the Net weight

mode will cause the display to show the Tare

weight.

During Setup, pressing the TAREkey will

display the current setting of the parameter.

Pressing the TAREkey a second time (after

changing parameter values or settings), signals

completion of the entry of data and causes the

indicator to process the data entered.

NET/GROSS: The NET/GROSS key is used to toggle

between the Gross and Net weight modes. The

selected mode is indicated by turning on the appropriate

annunciator on the display.

Note that if no valid tare weight has been entered,

pressing the NET/GROSS key will cause a momentary

display error (notArE) and the indicator will remain in

the Gross weight mode.

When in Hold, Count, Peak weight, Live weight, or

Accumulator display mode, press the NET/GROSS key

to return the display to normal weight display mode.

UNITS/(Left Arrow): The UNITS/key is used for

several functions.

In normal operation, the UNITS/key is used to

select the units in which the weight is to be

displayed. The available units of measure ("unit1",

“unit2” and "unit3") are selected in setup. The

available units include pounds, ounces, kilograms,

and grams.

During setup, the UNITS/key is used to advance the

cursor left to the next position when inputting setup

parameters.

Page 5

Key

Description

Fn/(Up Arrow): The Fn/key is used for

several functions.

During indicator setup, when a setup

parameter (not a parameter value or setting)

is displayed, pressing the Fn/key will

"backup" to the previous parameter prompt.

Also during setup, when a parameter value

or setting is displayed, pressing the Fn/

key will "toggle" between the different

available values or settings for that

parameter.

In normal operation, the Fn/key is used in

conjunction with the other keys on the keypad to

access additional indicator features.

PRINT: Pressing the PRINT key during a

weighing operation, will add the displayed Gross

weight, or Net weight to the associated

accumulator and send print ticket data to the

serial interface selected during setup (see

Port=).

NOTE: The indicator will not respond to

pressing the PRINT key unless the weight

display is stable.

If displaying Gross weight, the only weight

printed is Gross weight.

If displaying Net weight, the Gross, Tare,

and Net weights are printed.

When in Gross weight accumulator display

mode, pressing the PRINT key will print the

Gross weight accumulator.

When in Net weight accumulator display

mode, pressing the PRINT key will print the

Net weight accumulator.

When in Peak weight display mode,

pressing the PRINT key will print the Peak

weight.

Page 6

Fn/Key Functions

The Fn/key is used to select several additional functions that may have

been enabled during the setup and calibration of the indicator. Those

functions include: Hold, Count, Time and Date, Peak Hold, Checkweigher,

Live Weight, Weight Accumulation and Backlight Color.

IMPORTANT! The Hold, Count and Live Weight functions cannot

be enabled if the Legal-For-Trade option (LFt=yes) was selected

during setup.

In addition, only one of the functions Hold, Count, Peak Hold,

Checkweigher or Live Weight can be enabled at a time.

Description of Fn/Key Functions

Function

Display

Description or Setting

Hold

HoLd X

X will be 1 if enabled, 0 if disabled

Count

CoUnt X

X will be 1 if enabled, 0 if disabled

Time and Date

HH:MM A

HH=hours, MM=minutes,

A for AM, P for PM

MM.DD.YY

(usa=yes)

DD.MM.YY

(usa=no)

MM=month, DD=day, YY=last two

digits of year

Peak Hold

PhoLd X

X will be 1 if enabled, 0 if disabled

Checkweigher

Lo=

Minimum acceptable weight prompt

= minimum acceptable weight value.

* When the value for Lo= is greater

than 0, the Checkweigher function

is enabled.

Hi=

Maximum acceptable weight prompt.

This prompt is displayed, when the

value for Lo= is greater than 0.

= maximum acceptable weight value

Live Weight

Act X

X will be 1 if enabled, 0 if disabled

Weight

Accumulation

ACCU X

X will be 1 if enabled, 0 if disabled

Backlight Color

Colors

Backlight Colors for normal operation

and Checkweigher results

Page 7

Annunciators

The Model 190 is equipped with annunciators that are turned on to

indicate that the display is in the mode corresponding to the annunciator

label or that the status indicated by the label is active. This section

describes each annunciator. Refer to Figure No. 13 for the location of the

annunciators.

Symbol

Name

Description

0

ZERO

This annunciator is turned on to

indicate that the weight displayed is

within ± 1/4 division of true zero.



STABLE

This annunciator is turned on when

the weight display is stable. When

off, it means that the change in

successive weight samples is

greater than the motion limits

selected during setup.

NET

This annunciator is turned on when

the displayed weight is Net weight

(Gross weight less Tare weight).

GROSS

This annunciator is turned on to

show that gross weight is displayed.

Gross weight will be displayed when

no tare weight is stored.

TARE

This annunciator is turned on to

show that the displayed weight is the

tare weight.

pounds

This annunciator is located to the

right of the weight display and is

turned on to show that the displayed

weight unit is pounds.

ounces

This annunciator is located to the

right of the weight display and is

turned on to show that the displayed

weight unit is ounces.

Page 8

kilograms

This annunciator is located to

the right of the weight display

and is used to indicate that

the displayed unit of weight

measurement is kilograms.

grams

This annunciator is located to

the right of the weight display

and is used to indicate that

the displayed unit of weight

measurement is grams.

COUNT

This annunciator shows that

the display is in the Count

mode and the value displayed

is in pieces (the count

quantity) and not weight.

G and A

N and A

ACCUMULATOR

This annunciator shows that

the displayed value is the

content of the accumulator.



IN1

DIGITAL INPUT

This annunciator is used to

signal that a remote key

function has been activated.

Note that this annunciator is

active only when the Digital

Input feature has been

enabled. Refer to the d in

parameter in Setup.



OUT1 

UNDER

This annunciator is used to

signal that the displayed

weight is less than the

minimum value of acceptable

weight used in the

Checkweigher feature or that

preset 1 is active.

Note that this annunciator is

active only when the

Checkweigher feature or the

preset feature has been

enabled. Refer to the d oUt

parameter in Setup.
