Car-Interface.com CI-RL4-UCON10 Manuel utilisateur

Version 24.01.2023 HW: CAM(V100) / (V30 + V30.3) CI-RL4-UCON10

Video inserter

CI-RL4-UCON10

Compatible with

Fiat vehicles with Uconnect 5 infotainment

with 10inch or 10.25inch ultrawide monitor

Jeep vehicles with Uconnect 5 infotainment with 10.1inch monitor

Video-inserter for front- and rear-view camera

and two more video inputs

Product features

Video-inserter for factory-infotainment systems

1 CVBS Input for rear-view camera

1 CVBS Input for front camera

2 CVBS Video-inputs for after-market Video sources (e.g. USB-Player, DVB-T Tuner)

Automatic switching to rear-view camera input on engagement of the reverse gear

Automatic front camera switching after reverse gear for 10 seconds

Video-in-motion (ONLY for connected video-sources)

Video-inputs NTSC and PAL compatible

Version 24.01.2023 HW: CAM(V100) / (V30) CI-RL4-UCON10

Page2

Contents

1. Prior to installation

1.1. Delivery contents

1.2. Checking the compatibility of vehicle and accessories

1.3. Boxes and connectors –video interface

1.4. Settings - 8 Dip switches (black)

1.4.1. Activating the front camera (dip 1)

1.4.2. Enabling the interface’s video inputs (dip 2-3)

1.4.3. Rear-view camera setting (dip 5)

1.4.4. Monitor selection (Dip 6,78)

1.5. Settings - 4 Dip switches (CAN function –red)

1.6. Settings - 2 Dip switches (Selection head-unit –black)

2. Installation

2.1. Place of installation

2.2. Connection schema

2.3. Connection - factory head unit

2.3.1. Connection - picture signal cable

2.3.2. Connection –10pin Power/CAN cable

2.3.3. Analogue power supply

2.4. Power supply output for front cam

2.5. Connection - video-sources

2.5.1. Audio insertion

2.5.2. After-market front camera

2.5.3. After-market rear-view camera

2.5.3.1. Case 1: Interface receives the reverse gear signal

2.5.3.2. Case 2Interface does not receive the reverse gear signal

2.6. Connection - video-interface and external keypad

2.7. Picture settings

3. Interface operation

4. Specifications

5. FAQ –Trouble Shooting-Interface functions

Version 24.01.2023 HW: CAM(V100) / (V30) CI-RL4-UCON10

Page3

Legal Information

By law, watching moving pictures while driving is prohibited, the driver must not be

distracted. We do not accept any liability for material damage or personal injury resulting,

directly or indirectly, from installation or operation of this product. Apart from using this

product in an unmoved vehicle, it should only be used to display fixed menus or rear-view-

camera video when the vehicle is moving (for example the MP3 menu for DVD upgrades).

Changes/updates of the vehicle’s software can cause malfunctions of the interface. Up to

one year after purchase we offer free software-updates for our interfaces. To receive a free

update, the interface has to be sent in at own cost. Wages for de-and reinstallation and

other expenditures involved with the software-updates will not be refunded.

1. Prior to installation

Read the manual prior to installation. Technical knowledge is necessary for installation. The

video interface’s place of installation must be free of moisture and away from heat sources.

Before the final installation in the vehicle of the video sources, we recommend a test-run

to ensure the compatibility of vehicle and interface. Due to changes in the production of

the vehicle manufacturer there’s always a possibility of incompatibility.

1.1. Delivery contents

Take down the serial number of the interface and store this manual for support

purposes: ____________________

Version 24.01.2023 HW: CAM(V100) / (V30) CI-RL4-UCON10

Page4

Requirements

Brand

Compatible vehicles

Compatible systems

Fiat

Ducato3 (series 8) since model year 2021

Uconnect5 R1 EXT ER with 10inch tablet

monitor with separate head-unit

500e since 11/2020

Uconnect5 R1 INT ER with 10.25inch

ultra-wide tablet monitor with separate

head-unit

Jeep

Compass since model year 2021

Uconnect5 R1 EXT ER with 10.1inch

tablet monitor with separate head-unit

Limitations:

Video only The interface inserts ONLY video signals into the infotainment. For

inserting Audio signals either the possibly existing factory audio-

AUX-input or a FM-modulator can be used. If 2 audio sources shall

be connected to the infotainment, an additional electronic is

necessary to switch them.

Factory rear-view camera Automatically switching-back from inserted video to factory rear-

view camera is only possible while the reverse gear is engaged. To

delay the switch-back an additional electronic part is required.

After market front camera The front camera will automatically be switched 10 seconds after

disengaging the reverse gear. A manually front camera switching is

possible by external keypad.

1.2. Checking the compatibility of vehicle and accessories

Version 24.01.2023 HW: CAM(V100) / (V30) CI-RL4-UCON10

Page5

1.3. Boxes and connectors –video interface

The video-interface converts the video signals of connected after-market sources in a factory

monitor compatible picture signal which is inserted in the factory monitor, by using separate

trigger options. Further it reads the vehicle’s digital signals out of the vehicle’s CAN-bus and

converts them for the video interface.

Version 24.01.2023 HW: CAM(V100) / (V30) CI-RL4-UCON10

Page6

1.4. Settings - 8 Dip switches (black)

Some settings have to be selected by the dip-switches on the

video interface. Dip position down is ON and position up is OFF.

*In case of a non-optimal displayed picture with the mentioned dip settings of dips 6, 7

and 8, we recommend to try each other possible dip switch combination.

*The front camera will automatically be switched for 10, 15 or 20 seconds after disengaging

the reverse gear (according to the menu adjustments).

See the following chapters for detailed information.

After each Dip-switch-change a power-reset of the Video interface has to be performed!

Dip

Function

ON (down)

OFF (up)

Front camera

enabled*

disabled

Power supply

output

(red wire)

+12V (max. 3A) when reverse gear is

engaged incl. delay (10,15 or 20

seconds and +12V by manual

switching to front camera by keypad

+12V ACC out

CVBS Video 1-input

enabled

disabled

CVBS Video 2-input

enabled

disabled

No function

set to OFF

Rear-view cam

type

after-market

factory or none

Monitor

adjustment

set to OFF*

Version 24.01.2023 HW: CAM(V100) / (V30) CI-RL4-UCON10

Page7

1.4.1. Activating the front camera (dip 1)

If set to ON, the interface switches for 10, 15 or 20 seconds from the rear-view camera to

the front camera input after having disengaged the reverse gear, depending on the menu

adjustments. In addition, a manual switch-over to the front camera input is possible via

keypad (short press) from any image mode.

Description of the power supply output: see chapter “Power supply output for front cam”.

1.4.2. Enabling the interface’s video inputs (dip 2-3)

Only the enabled video inputs can be accessed by switching through the interface’s video

sources. It is recommended to enable only the required inputs. So the disabled inputs will be

skipped while switching through the video interfaces inputs.

Note: Dip 4 is out of function and has to be set to OFF!

1.4.3. Rear-view camera setting (dip 5)

If set to OFF, the interface switches to factory picture while the reverse gear is engaged to

display factory rear-view camera or factory optical park system picture.

If set to ON, the interface switches to its rear-view camera input while the reverse gear is

engaged.

1.4.4. Monitor selection (dip 6, 7, 8)

Dips 6, 7 and 8 must be set to OFF. In case of a non-optimal displayed picture with the

mentioned dip settings of dips 6, 7 and 8, we recommend to try each other possible dip

switch combination.

Note: Dips 6-8 customize the monitor-specific video settings which sometimes even vary

within head units of the same version, caused by different monitor specifications. If the

mentioned dip positions don’t give a satisfying picture, try all possible combinations of dip6,

7 and 8 while a working video source is connected to the chosen input of the interface. One

of the combinations will show the best picture size and quality (some may give no picture). It

is possible to first hot plug through the dip combinations. If there is no change of picture

visible after trying all options, retry and disconnect the 6pin connector at the interface box

between every change of the dip setting.

Version 24.01.2023 HW: CAM(V100) / (V30) CI-RL4-UCON10

Page8

1.5. Settings of the 4 Dip switches (CAN functions –red)

Dip position down is ON and position up is OFF.

vehicle/Head-Unit

Dip 1

Dip 2

Dip 3

Dip 4

All vehicles

OFF↑

After each Dip-switch-change a power-reset of the video interface has to be performed!

1.6. Settings of the 2 Dip switches (selection head-unit - black)

The 2 dip switches on the upper side of the interface box are used to select the head

unit.

Warning! Dip position up is ON and position down is OFF (vice versa to the black 8 dips and

the red 4 dips).

vehicles

Dip 1

Dip 2

Jeep Compass

ON↑

OFF↓

Fiat Ducato

ON↑

OFF↓

Fiat 500

OFF↓

Note: In case the CAN functions according to this table do not work, also try the other dip

switch combinations.

After each Dip-switch-change a power-reset of the video interface has to be performed!

2. Installation

To install the interface, first switch off the ignition and disconnect the vehicle’s battery.

Please read the owner`s manual of the car, regarding the battery`s disconnection! If

required, enable the car`s Sleep-mode (hibernation mode)

In case the sleep-mode does not succeed, the disconnection of the battery can be done

with a resistor lead.

As with any installation of retrofit equipment, a stand-by test is neccessary after the

installation of the video interface, to ensure that the unit also switches off after reaching

the vehicle‘s sleep mode.

Before the final installation, we recommend a test-run of the interface. Due to changes in

the production of the vehicle manufacturer, there’s always the possibility of

incompatibility.

2.1. Place of installation

The interface is supposed to be installed at a suitable location behind the vehicle`s head-

unit.

Version 24.01.2023 HW: CAM(V100) / (V30) CI-RL4-UCON10

Page9

2.2. Connection schema

Version 24.01.2023 HW: CAM(V100) / (V30) CI-RL4-UCON10

Page10

2.3. Connection - factory head-unit

Remove the head unit

2.3.1. Connection –picture signal cable

Disconnect the female HSD connector (colours may vary) at the rear-side of the head unit and

connect it to the waterblue coloured male HSD connector „TO LCD“ of the video interface.

Connect the female angled waterblue coloured HSD connector of the enclosed picture signal

cable to the waterblue coloured HSD+2 connector „HU IN“ of the video interface.

Connect the opposite female not-angled waterblue HSD connector of the enclosed picture

signal cable to the previously become free HSD connector of the head unit

Note: Depending on the installation conditions, the enclosed picture signal cable may also

be mounted upside down, concerning it’s HSD connectors . However, it‘s connection must

only be made at the head unit!

Table des matières

Autres manuels Car-Interface.com Système vidéo embarqué

Car-Interface.com

Car-Interface.com RL4-IOR Manuel utilisateur

Car-Interface.com

Car-Interface.com r.Link CI-UCON5N Manuel utilisateur

Car-Interface.com

Car-Interface.com CI-RL4-IOR Manuel utilisateur

Car-Interface.com

Car-Interface.com CI-CARPLAY-NAC Manuel utilisateur

Car-Interface.com

Car-Interface.com RL4-UCON10 Manuel utilisateur

Car-Interface.com

Car-Interface.com r.LiNK RL4-PCM50 Manuel utilisateur

Car-Interface.com

Car-Interface.com CI-VL2-RLINK Manuel utilisateur

Car-Interface.com

Car-Interface.com v.link CI-VL7-NBT2 Manuel utilisateur

Car-Interface.com

Car-Interface.com CI-RL4-SC15 Manuel utilisateur

Car-Interface.com

Car-Interface.com CI-TF-MFD3 Manuel utilisateur

Car-Interface.com

Car-Interface.com CI-RL4-PCM50 Manuel utilisateur

Car-Interface.com

Car-Interface.com CI-CARPLAY-SMEG Manuel utilisateur

Car-Interface.com

Car-Interface.com CI-RL4-PCM60 Manuel utilisateur

Car-Interface.com

Car-Interface.com C1-MFD1 Manuel utilisateur

Car-Interface.com

Car-Interface.com CI-VL6-ZAB Manuel utilisateur

Car-Interface.com

Car-Interface.com CI-RL3-MM-NP Manuel utilisateur

Manuels Système vidéo embarqué populaires d'autres marques

Stinger

Stinger HEIGH10 RB10RAM13B Manuel utilisateur

Eonon

Eonon E1057 Manuel utilisateur

Milion

Milion D2223 Manuel utilisateur

Metra Electronics

Metra Electronics 99-8153 Manuel utilisateur

Voxx Electronics

Voxx Electronics HR8MA1 Manuel utilisateur

Axxera

Axxera AV604Bi Manuel utilisateur

Clarion

Clarion NX706E Manuel utilisateur

Pyle view

Pyle view PLDN74BTi Manuel utilisateur

Clarion

Clarion NX602 Manuel utilisateur

PowerAcoustik

PowerAcoustik PTID-5850N Manuel utilisateur

RCA

RCA DRC6296 - Twin 9" Mobile DVD System Guide de l'utilisateur

Lanzar

Lanzar SVDVD5 Manuel utilisateur

Kia

Kia MTXM100YPPE Manuel utilisateur

Eonon

Eonon E1060 Manuel utilisateur

Macrom

Macrom M-AN900 Manuel utilisateur

Hyundai

Hyundai BAPE-L3000N Manuel utilisateur

r.LiNK

r.LiNK RL2-UCON8-SM Manuel utilisateur

Blaupunkt

Blaupunkt DVP 01C Manuel utilisateur
