Caple CE920WH Manuel utilisateur
Contact Caple on 0117 938 7420 or for spare parts www.caple.co.uk
ceiling extractor
instruction manual
CE920WH
Instruction manual CE920WH
Please keep this instruction manual for future reference
2
CONTENTS
WARNINGS 3
USES 8
INSTALLATION 9
REMOTE CONTROL 11
DIMMABLE LIGHTS FUNCTION 12
OPERATION MODE 12
TIMING 14
MAINTENANCE 15
Instruction manual CE920WH
Please keep this instruction manual for future reference
3
WARNINGS
The appliance is not intended for use by young
children or infirm persons without supervision.
Young children should be supervised to ensure they
do not play with the appliance.
The extracted air can’t be conveyed through or into
a duct used to let out fumes from appliances fed
by energy other than electric power (eg. centralized
heating, radiators, water heaters, etc.).
To evacuate the air outlet, please comply with the
pertaining rules given by competent authorities.
-Provide the room with an adequate aeration when a
cooker hood and appliances fed by energy other than
electric power (gas, oil, or coal stoves, etc.) are used
simultaneously. The cooker hood, when evacuating the
extracted air, could generate a negative pressure in the
room which can’t exceed the limit of 0.04 mbar, in order
to avoid the suck of exhausts deriving from the heat
source. Therefore the room should be provided with air-
intakes to allow a constant flow of fresh air.
-If the rating label in the cooker-hood does show the
symbol the appliance is built in class 11° and it
does not need the earth connection.
Instruction manual CE920WH
Please keep this instruction manual for future reference
4
-If the rating label in the cooker hood does not show the
symbol , the appliance is built in class I° and it needs
the earth connection.
-When performing the electrical connections on the
appliance, please make sure that the current tap is
provided with earth connection and that voltage values
correspond to those indicated on the label placed inside
the appliance itself.
-Before carrying out any cleaning or maintaining
operations, the appliance needs to be removed from the
electric grid.
-If the appliance is not provided with a non-separable
flexible cable and plug, or with another device ensuring
omnipolar disconnections from the grid, with an opening
distance between the contacts of at least 3 mm, then
such disconnecting devices must be supplied within the
fixed installation. If the appliance is endowed with a
supply cord and a plug, the appliance has to be put in a
place where the plug can be reached easily.
The use of materials which can burst into flames should be
avoided in close proximity of the appliance. When frying,
please pay particular attention to fire risk due to oil grease.
Being highly inflammable, fried oil is especially dangerous.
Do not use uncovered electric grills. In order to avoid possible
fire risk, all instructions for grease filter cleaning and for
removing eventual grease deposits should be strictly followed.
Instruction manual CE920WH
Please keep this instruction manual for future reference
5
-This appliance complies with all relevant local and
national safety requirements. Inappropriate use can,
however, lead to personal injury and damage to property.
-The cooker hood is not intended for outdoor use.
-It must only be used as a domestic appliance to extract
vapours and remove odours from cooking. Any other
usage is not supported by the manufacturer and could
be dangerous.
-Where a recirculation cooker hood is fitted above a gas
hob, please ensure that there is an adequate supply of
fresh air into the room in which it is installed. Please
seek the advice of a qualified gas fitter (e.g. GasSafe in
the UK) if necessary.
-Children under 8 years of age must be kept away from
the cooker hood unless they are constantly supervised.
-Children 8 years and older may only use the cooker hood
-unsupervised if they have been shown how to use it
safely and recognise and understand the consequences
of incorrect operation.
-The electrical safety of this appliance can only be
guaranteed when correctly earthed. It is essential
that this standard safety requirement is met. If in any
doubt please have the electrical installation tested by a
qualified electrician.
-Do not connect the appliance to the mains electricity
supply by a multi-socket unit or an extension lead. These
Instruction manual CE920WH
Please keep this instruction manual for future reference
6
are a fire hazard and do not guarantee the required
safety of the appliance.
-The cooker hood can get very hot during cooking due to
heat rising from the hob.
-Do not touch the housing or the grease filters until the
cooker hood has cooled down.
Instruction manual CE920WH
Please keep this instruction manual for future reference
7
ENVIRONMENTAL PROTECTION
Waste electrical products should not be disposed of with household waste. Please
recycle where facilities exist. Check with your Local Authority or retailer for recycling
advice. This appliance is marked according to the European directive 2012/19/EU on
Waste Electrical and Electronic Equipment (WEEE).
By ensuring this product is disposed of correctly, you will help prevent potential
negative consequences for the environment and human health, which could
otherwise be caused by inappropriate waste handling of this product. The symbol
on the product indicates that this product may not be treated as household waste.
Instead it shall be handed over to the applicable collection point for the recycling of
electrical and electronic equipment. Disposal must be carried out in accordance with
local environmental regulations for waste disposal.
For more detailed information about treatment, recovery and recycling of this
product, please contact your local council, your household waste disposal service or
the retailer where you purchased the product
CE DECLARATIONS OF CONFORMITY
Radio Equipment Directive (RED) 2014/53/EU
This Declaration is issued under the sole responsibility of the manufacturer.
Hereby, Caple declares that the radio equipment included in the product is in
compliance with the RED directive 2014/53/EU.
The full text of the EU Declaration of Conformity is available on our website
www.caple.co.uk.
Instruction manual CE920WH
Please keep this instruction manual for future reference
8
USES
CE920WH must be installed with external motors manufactured by the same
producer. The motor does not come included and must be ordered separately.
PANELS OPENING
It is possible to open the panel, which covers the grease filters, by slightly pulling on
a side of the panel itself, as shown in Fig. 1.
For proper working, it is recommended to install the appliance at a distance of
2000 - 2100 mm from the floor.
Before starting the appliance installation, please check that all components are not
damaged, in such a case contact your retailer and do not carry out installation.
Furthermore, please read carefully all of the following installation instructions.
- Use an exhausting pipe whose maximum length does not exceed 5 meters.
- Limit the no. of elbows in the piping, since each elbow reduces the air capacity of
1 linear meter. (Eg.: if you use no. 2 x 90 ° elbows, the length of piping must not
exceed 3 meters).
- Avoid abrupt direction changes.
- Use a 150 mm constant diameter pipe for the whole length.
- Use piping approved by standards in force.
Instruction manual CE920WH
Please keep this instruction manual for future reference
9
INSTALLATION
Take the product out of the packaging and place it on a suitable surface: We
suggest to use a soft material, such as a sponge or a cloth.
Open the glass panel, rotating it as shown in Fig.1, and remove the grease filters.
NOTE: In order to avoid any possible damage to the glass panel, we recommend to
remove this before installation by unscrewing the eight screws as shown in Fig.2.
Where you intend to install the appliance, you must create a recess which will have
a rectangular opening of:
CE920WH - 865x515mm
The depth must range from 200 to 280mm.
Install the hood onto the ceiling, and install the ducting system for the air outlet to
connect to the motor. Set the electrical connection and then complete the plaster
board structure.
The recess shall be provided with a socket and a round pipe of 150mm diameter, or
a similar section, for the air outlet. Drill the holes on the ceiling , as shown in Fig.6.
insert the plastic plugs into the holes made, and then fix the ceiling brackets as
shown in Fig. 3. The ceiling brackets are telescopic, so their height can be adjusted
at 80 mm between the ceiling and the hood.
You can choose one of the three air outlets shown in Fig. 4: fit the air outlet plastic
flange in the desired outlet; the remaining outlets shall be closed with the specific
metal caps as shown in fig. 18. Bring the hood close to the brackets previously fixed
and then connect the appliance to the supply mains. Secure the hood to the ceiling,
by using the screws supplied, as shown in Fig. 5.
After the installation of the hood, follow the instruction described in the remote
motor to complete the installation.
The cable of the remote motor must be connected to the specific terminal block
(SIX way connection) positioned in the ceiling hood.
NOTE: For more information on venting, please see our ‘Extraction & Ventilation
guide’ available on our website www.caple.co.uk.
Instruction manual CE920WH
Please keep this instruction manual for future reference
10
54
2
4
5
3
6
1
1
5
2
4
3
6
