Caple CAFF207SS Manuel utilisateur
Model code: CAFF207SS / CAFF207BK
Contact Caple on 0117 938 7420 or for spare parts www.caple.co.uk
2
2
2
6
7
8
9
9
9
9
10
17
17
18
23
Basic safety symbols
Connecting the appliance
Safety and warning information
Features
Product components
Appliances and installation dimensions
Transporting
Position
Adjusting the feet
Water supply connection
Operation and control panel
Storing food
Energy saving tips
Care and maintenance
Troubleshooting
Guarantee information 24
Safety and warning information
Basic safety symbols
Connecting the appliance
Safety and warning information
Safety and warning information
Safety and warning information
WARNING
This appliance is intended to be used in a household,
residential environment.
It must not be used in a commerical environment, this
will void the guarantee.
When the refrigerator is plugged in, a 1 minute self-diagnostic
test will be carried out. During this time do not put hands
into the ice box compartment to prevent injury.
Safety and warning information
Safety and warning information
The appliance should be placed close to the socket it will be
connected too, this allows easy access to cut off the power
supply in the case of an accident.
Install the appliance in a dry, well ventilated room.
cause fire.
Do
s
ed.
Do not touch food or containers in the freezer with wet hands,
your hands could stick to the walls of the freezer or food. There
is a danger of frost burn.
Do not clean this appliance by spraying it with water or
using benzene or thiners
Do not use a extension cable.
Safety and warning information
Safety and warning information
a
The manufacturer cannot be held liable for damage caused by non-compliance with these
safety and warning instructions.
Automatic ice maker
The CAFF207 has a automatic ice maker, and you can select
either ice cubes, crushed ice or cold water at the touch of a
button.
Introduction
Features
Energy saving and noise reduction
This product features contains super freeze, a energy saving
system, reduced noise and an optimal refrigeration system.
Precise temperature control
A microcomputer system allows separate control of each
compartment allowing for more precise temperature control.
Automatic defrosting
There is a special program to reduce the temperature
fluctuation of the fridge, it helps keep food fresh for longer.
LED display and touch button controls
The control board respectively displays refrigerator and freezer
compartment temperature settings and the special function
status. The touch button operation is simple and convenient.
Door-opening alarm system
If the door is left open for more than 1 minute the alarm
system will remind you to close the door.
Tempered glass shelves
The shelves are made from tempered safety glass, which are easy clean
and durable.
Compressor condensing unit
This product is supplied with a compressor condensing unit and fan
cooling system, to protect the compressor and provide a long life.
Easy glide drawers
The easy glide drawer is smooth and easy to push/pull.
Easy clean, removable door seal
The door seal removable and easy to clean.
Invisible hinge
The hidden hinge is strong and attractive.
6
Frost-free green refrigerators
R600a refrigerant and foaming agent are hydrocarbons,
which does not destroy the ozone layer and won't produce
the greenhouse effect.
Please note some features and devices may not be consistent with your refrigerator and the
specific structure and configuration may differ slightly to the below drawing.
Product components
Introduction
A Freezing compartment
1 Freezer upper bottle rack
2 Thermal insulation cover
3 Dispenser
4 Freezer Lower bottle rack
5 Ice maker
6 Ice storage box
7 Freezer Glass shelve
8 Freezer Drawer
9 Control panel
10 Ice.water outlet
11 Ice/water discharge button
12 Drip tray
B Refrigerator compartment
13 Refrigerator lamp
14 Refrigerator glass shelves
15 Refrigerator flip glass shelf
16 Refrigerator drawer
17 Refrigerator flip top door storage
18 Water filter
The appearance and specifications of the actual product may differ depending on the model. 7
8
13
14
15
16
17
5
6
7
9
11
10
18
3
12
2
4
The figure above is for installation only, it may not represent the actual
product. The specific dimensions shall be subject to the product that you
have bought.
Select a good location to place your appliance where it is flat and easy to use.Avoid placing the
unit near heat sources (including ovens),direct sunlight or moisture.
To ensure correct air circulation around the fridge, please maintain
sufficient space.If installing a top panel or cabinets, please maintain
sufficient space to open the doors and ventilate the product (see the
following page for ventilation dimensions).
8
Appliances and installation dimensions
Introduction
923 770
700
