Caple C995T Manuel utilisateur

Instruction manual for

TEPPANYAKI

Model code: C995T

Contact Caple on 0117 938 7420 or for spare parts www.caple.co.uk

www.caple.co.uk

WARNING:

•The appliance and its accessible parts become

hot during use. Care should be taken to avoid

touching heating elements. Children less

than 8 years of age shall be kept away unless

continuously supervised.

•This appliance can be used by children aged

from 8 years and above and persons with

reduced physical, sensory or mental capabilities

or lack of experience and knowledge if they

have been given supervision or instruction

concerning use of the appliance in a safe way

and understand the hazards involved. Children

shall not play with the appliance. Cleaning

and user maintenance shall not be made by

children without supervision.

•Unattended cooking on a hob with fat or oil

can be dangerous and may result in fire. NEVER

try to extinguish a fire with water, but switch

off the appliance and then cover flame e.g.

with a lid or a fire blanket.

•Danger of fire: do not store items on the

cooking surfaces.

•Don’t use a steam cleaner for the cleaning the

hob.

•The appliance is not intended to be operated

by means of an external timer or separate

remote-control system.

•Do not use the hob during cleaning

•These instructions apply only if the symbol of

the country appears on the appliance. If the

symbol not appear on the device you need

to refer to the technical instructions required

that the manufacturer will provide for the

amendment of the appliance in terms of use of

the destination country.

•Carefully read the instructions before installing

and using the appliance. The manufacturer is

not responsible if the installation and improper

use of the device causing injury or damage.

Keep the instructions handy as a reference for

the future.

•Never leave the appliance unattended during

food preparation because oil and grease could

cause a fire.

•When the unit is connected directly to the

power supply, you need a switch insulating

omnipolar. It is necessary that the appliance

can be completely disconnected from the

network in accordance with the conditions of

the category III on the overvoltage. The earth

cable is not included.

•If the power cable is damaged, it must

be replaced by the manufacturer, by an

authorized technician or by a qualified person

to avoid danger.

•When connecting the power cable, make sure

it is not in direct contact (eg. through the use

of insulation sleeves) with parts that can reach

temperatures of over 50 ° C.

1 / INSTALLATION INSTRUCTIONS

2 / FITTING

3 / USING THE APPLIANCE

4 / SOME HINTS

5 / MAINTENANCE

6 / AFTER SALES SERVICE

INDEX

Disposal of old electrical appliances

Consumers should contact their local authority or retailer for information

concerning the correct disposal of their old appliance

The European Directive on Waste Electrical and Electronic

Equipment (WEEE), requires that old household electrical appliances

must not be disposed of in the normal unsorted municipal waste stream.

Old appliances must be collected separately in order to optimise the

recovery and recycling of the materials they contain and reduce the

impact on human health and the environment.

The crossed out “wheeled bin” symbol on the product reminds you

of your obligation, that when you dispose of the appliance it must be

separately collected.

IT IS ABSOLUTELY IMPERATIVE TO LEAVE A SPACE OF AT LEAST 5 CM

BETWEEN THE BOTTOM OF THE TEPPAN YAKI AND THE FIRST SHELF OF THE

KITCHEN UNIT.

DO NOT STORE INFLAMMABLE GOODS IN THE SPACE BELOW THIS

APPLIANCE.

WARNING : If the teppan yaki malfunctions in any way, unplug the

appliance or remove the fuse corresponding to the sector where the teppan

yaki is hooked up.

1 / INSTALLATION INSTRUCTIONS

•The appliance must be connected by an approved engineer in accordance with

the regulations in force.

•The installer is responsible for the good operation of the appliance. He must

explain its operation to the user, with the aid of this manual.

•The plug must be accessible after installation.

•If the supply lead is damaged, it must be replaced by an equivalent lead

(H05GG-F or H05SS-F 3x1,5mm²) available from the after-sales department.

•It is also necessary to provide a bipolar cut-off device in your power supply

circuit, where the opening of the contacts is more than 3 mm.

•A 16-ampere fuse is necessary.

•Your teppan yaki uses 2.500 watts. It is therefore absolutely necessary for your

electric wiring system to be able to supply that power without danger.

•Your teppan yaki MUST be connected to earth.

•Cooking with the teppan yakki necessarily involves the emission of fumes. This

factor will have to be taken into account when choosing the place where your

teppan yaki is to be fitted.

2 / FITTING

This teppan yaki is built into a work surface or kitchen unit by simply cutting a

hole the corresponding shape.

Any support may be suitable: brickwork, timber, metal, granite, laminate, etc.

Dimensions of appliance: 520 x 380 mm

Dimensions of hole cut in work surface: 495 x 350 mm.

•Electrical connection:

The appliance is fixed to the work surface with four fixing pins delivered in the

package..

520

495

350

380

3 / USING THE APPLIANCE

•Special precautions:

This appliance is exclusively intended for domestic use. Any other use will nullify

the guarantee.

Do not forget that the teppan yaki reaches very high temperatures when

operational.

Never leave the appliance in operation without supervision.

Do not allow children to operate the appliance.

No guarantee will be given for damage caused by non-observance of this

document.

This appliance complies with the EN 60335-2-6 standard with regard to the

heating of cabinets.

•The controls:

The control knob enables you to regulate the cooking temperature.

The warning lights give you information on the operation of the appliance:

This warning light shows when the appliance is ON.

This warming light turns off when the selected temperature

is reached.

This warming light enables you to check the residual heat of

the cooking panel.

•The appliance:

Stainless steel plate

Glass frame

Residual heat warning light

ON/OFF warning light

Heating warning light

Thermostat knob
