Read this manual completely before operating or maintaining this machine.
Failure to follow safety precautions could result in serious injury or death.
Keep this manual for future reference by you and by all those who operate
and maintain this machine.
Off-road Rubber Track Carrier
SC45
Operator's Manual
3577 6107 000
http://www.canycom.jp/
All rights reserved. Unauthorized use or reproduction of this material is prohibited.
Authorized Dealer
CHIKUSUI CANYCOM, INC.
90-1 Fukumasu, Yoshii-machi,
Ukiha-shi, Fukuoka, Japan 839-1396
Sales Headquarters (International) TEL +81-(0)943-75-2195
FAX +81-(0)943-75-4396
Notice to Users and Maintenance Personnel
• This machine can be very dangerous if the safety precautions in this manual
and on labels attached to this machine are not followed. Read and understand
this manual and safety labels on machine thoroughly before using this machine.
Always follow the instructions and safety precautions, or serious injury or
death could result.
• This machine should only be used for its intended purpose: hauling and
dumping. Any other use could be dangerous.
• This machine may not be operated on public road or what is considered to
be public road. It is the sole responsibility of the operator to consult the local
regulations.
• Do not modify this machine, or do not operate this machine with safety covers
removed or open. A serious accident could result.
Thank you for purchasing this machine.
This manual provides information needed for safe and effective use of this machine to
those who operate or maintain this machine. Make sure to read and understand this manual
thoroughly before operating this product. Also make sure to read the separate operator's
manual for the engine.
• Store this manual in a safe, accessible place for easy reference.
Warning Term Denition
Indicates an imminently hazardous situation which will result
in death or serious injury if the user does not follow the
procedures or the instructions.
Indicates a potentially hazardous situation which could result
in death or serious injury if the user does not follow the
procedures or the instructions.
Indicates a potentially hazardous situation which could result
in minor to moderate injury or damage to the machine if the
user does not follow the procedures or the instructions.
Indicates important information which needs particular
attention.
In this manual, the following four warning terms are used to signal the four levels of hazard (or
seriousness of possible accidents). Read and understand what they mean and always follow
the instructions in this manual.
Warning Terms Used in this Manual
NOTE
Notice to Owner
• Be sure that everyone who uses this machine, including those who rent or
lease this machine, receives a copy of this Operator's Manual and understands
the importance of reading and following the information in this manual.
Warranty and After-Sales Service
CHIKUSUI CANYCOM, INC. provides a warranty through your local CANYCOM dealer. A
copy of this warranty is attached to the back of this manual.
Warranty
Consult your local CANYCOM dealer or our company’s sales department regarding service
orders or any questions or problems that may arise when using this machine. Please make
sure to have the product name, serial number, and the make and type of engine handy at
the time of contact. The model and serial number can be found on the model label as shown
below, and the make and type of engine can be found in Chapter 3 "Specications" of this
manual (Page11).
After-Sales Service
Location of Model Label Model Label
The replacement or repair parts for this product shall remain available for nine years after the
production of this type of machine is discontinued.
Availability of Spare Parts
3577M-0005-010US
Location of Model Label
3577M‑0005‑020US
○○○○○○○
This product meets the applicable emissions and evaporative regulations as required by the
United States Environmental Protection Agency or the California Air Resources Board. The
relevant information is provided in the label shown below.
Emission Control Information
Location of Emissions Label Emissions Label
3577M-0005-031US
Emissions Label
5355M-0005-050US
Month and Year of Manufacture
THIS EQUIPMENT
MEETS U.S. EPA EVAP
STANDARDS.
Equipment Model
Equipment Family No.
Engine
Engine Model
EPA Emissions Family No.
○○○○○○○○○○○○○○
○○○○○○○○○○○○○○
○○○○○○○○○○○
○○○○○○○○○○○
Japan
○○.○○○○
Sample label shown. Emission control
information is subject to change each model-
year. Please refer to the actual emissions
label on the machine for details.
Contents
1. Safety 1
Safety Labels ...................................1
Safety Precautions...............................2
Training .......................................................2
Preparation ....................................................3
Operation .....................................................3
Servicing ......................................................8
2. Controls and Components 9
Name and Function of Controls ....................9
3. Specications 11
Product Specications ..........................11
Contents of the Tool Bag ........................13
4. Operation 14
Preparation ....................................14
Pre-start up Inspection .........................................14
Checking and Filling Fuel .......................................14
Adjusting Handle Lever Angle ...................................15
Driving........................................16
Starting ......................................................16
Driving .......................................................19
Stopping .....................................................22
Shifting ......................................................23
Parking ......................................................24
Working .......................................25
Dumping .....................................................25
Using Safety Lock Plate ........................................28
5. Maintenance 29
Maintenance Schedule ..........................29
Engine .......................................................29
Chassis ......................................................30
List of Fluids and Lubricants .....................32
List of lubricants ...............................33
List of Consumables and Spares ..................34
Removing and Installing Body Panels ..............35
Fender .......................................................35
Belt Cover ....................................................35
Engine ........................................36
Engine Oil ....................................................36
Air Cleaner ...................................................37
Spark Plug ...................................................38
Fuel Filter ....................................................38
Drive Train.....................................39
Track. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
Transmission Oil...............................................40
Drive Belt .....................................................41
Parking Brake .................................................42
Side Clutch ...................................................43
Lubrication ...................................................43
Hydraulic System ...............................44
Hydraulic Package .............................................44
Hydraulics Belt ................................................45
Loading Deck ..................................46
Lubrication ...................................................46
After Use Care .................................47
After Normal Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
After Cold Weather Use .........................................47
Storage .......................................48
6. Troubleshooting 49
Troubleshooting ................................49
7. Transporting 53
Hauling .......................................53
Loading and Unloading .........................................53
Warranty
Warranty Certicate is attached at the end of this manual.
* Have the warranty certicate signed and sealed after you have received and fully
understood the instructions for handling this machine and received the receipt.
Appendix
• Operator's Manual for the Engine
* Be sure to read and understand it together with this manual .
