Canon Pixma G3060 Series Manuel utilisateur

Conﬁgurar un teléfono inteligente

Conﬁgurar un ordenador

Hay vídeos e instrucciones detalladas en

el sitio web de Canon.

Conﬁguración en línea

Lea primero Información de seguridad

e información importante (apéndice).

Guía de inicio

Getting Started

Read Safety and Important Information

(addendum) ﬁrst.

Online Setup

Detailed instructions and videos are

available on the Canon website.

Setup a Computer

Setup a Smartphone

Cómo sujetar la impresora

Vídeos instructivos

Conexión con un ordenador, teléfono inteligente o tableta.......................página 4

Instalación de la impresora ...............................................................................................página 1

Installing the Printer...................................................................................................................page 1

Connecting to a Computer, Smartphone or Tablet...............................................page 4

Instructional Videos

Holding the Printer

ENGLISH

Setting Up the Printer

1. Box Contents

•

Print Heads •

Ink Bottles

•

Power Cord

•

Safety and Important Information

•

Getting Started (this manual)

2. Removing Packing Materials

1 Remove and dispose of any packing materials

and orange tape.

2 Open the scanning unit / cover, remove and

dispose of the orange tape and protective

material inside.

3. Installing the Print Heads

1 Open the print head locking cover.

2 Take out each print head from the package and

remove the label.

3 Remove the protective tape.

4 Insert the C (color) print head on the left and the

B (black) print head on the right.

5 Close the print head locking cover and press

down until it clicks.

6 Press down both joint buttons completely until

they click.

Check!

7 Close the scanning unit / cover.

• Open the scanning unit / cover fully and then close it.

Caution

Watch your ngers.

Setting Up the Printer

4. Turning on the Printer

1 Connect the power cord.

Back

2 Press the ON button.

3 When the following screen appears, use the [

and ]buttons to select a language, and then

press the OK button.

Important

If an error appears on the screen, see "If an error message

(support code) appears on the screen" on page 3 and

follow the instructions.

5. Pouring Ink

Important

This product requires careful handling of ink. Ink may splatter

when the ink tanks are lled with ink. If ink gets on your clothes or

belongings, it may not come o.

1 Open the scanning unit / cover.

2 Open the tank cap on the left of the printer.

3 Hold the ink bottle upright and gently twist the

bottle cap to remove.

Check!

PGBK

4 Align the nozzle of the ink bottle with the inlet.

5 Slowly stand the ink bottle upside down and

push down to pour the ink.

• If the ink does not pour, gently remove the ink bottle

and try again.

6 Gently remove the ink bottle from the inlet.

• Be careful not to spill the ink.

ENGLISH

7 Replace the tank cap securely.

8 Repeat steps 2 through 7 to pour all ink into the

corresponding ink tanks on the right.

CMY

Check!

9 Close the scanning unit / cover.

• Open the scanning unit / cover fully and then close it.

Caution

Watch your ngers.

10 When the following screen appears, use the [

and ]buttons to select Yes, and then press the

OK button.

• Please wait momentarily until the following screen

appears. Follow the on-screen instructions, and then

press the OK button.

If you will use the printer without connecting any other

devices, setup is now complete.

Select the connection method that best matches how you

will use the printer.

• To use the printer without connecting to any other

devices

Setup is now complete.

• To use the printer connecting to a computer or

smartphone

Proceed to the next page.

Check the support code, and then follow the

instructions if the displayed code is written below.

• 1890

Protective material remaining.

"2. Removing Packing Materials" on page 1

• 1470

Print heads are not installed correctly.

"3. Installing the Print Heads" on page 1

• 1471

Print heads cannot be recognized.

"3. Installing the Print Heads" on page 1

• 5200

Ink system preparation was not completed successfully.

Press the ON button to restart the printer, and then see "5.

Pouring Ink" on page 2.

For all other cases, refer to the Online Manual.

If an error message (support code) appears on

the screen

Support code

6-a

Setting Up the Printer

Computer Smartphone

Computer and

smartphone

Connecting to a Computer

If you are using multiple computers, perform these steps on each computer.

1 Access the Canon website from your computer.

2 Select Set Up.

3 Enter your printer's model name and click Go.

4 Click Start.

5 Click (B) Connecting to a Computer/Smartphone.

• The following steps are for Windows users.

6 Click Download.

7 Run the downloaded ﬁle.

• Follow the on-screen instructions.

• This may take some time.

• To connect to a smartphone as well, see "6-b. Connecting to a Smartphone" on page 5.

What device are you connecting?

6-a. Connecting to a Computer

6-b

ENGLISH

1 Install the "Canon PRINT Inkjet/SELPHY" app on your smartphone.

• Search for "Canon PRINT" in App Store, or Google Play.

• Access the Canon website to download the app.

2 Open your smartphone's Wi-Fi settings. Check that the network name (SSID) that starts

with "Canon_ij_" appears.

(Example of iOS screen)

The network name (SSID) that starts with "Canon_ij_"

• If "Canon_ij_" appears Proceed to step

• If "Canon_ij_" does not appear Proceed to step

3 Tap the network name (SSID) that starts with "Canon_ij_".

4 Open the installed app, and follow the on-screen instructions in the app to add your

printer.

Connecting to a Smartphone

If you are using multiple smartphones, perform these steps on each smartphone.

6-b. Connecting to a Smartphone

Once you have added your printer, you can print from your smartphone.

To print photos, see "Loading Paper" on page 6.

1 Extend the paper support.

2 Open the feed slot cover and slide the right-

hand side paper guide to the far right.

3 Load several sheets of paper with the print side

facing up and slide the side paper guide against

the edge of the paper stack.

4 Close the feed slot cover.

5 When Save the rear tray paper information

appears on the printer's screen, press the OK

button.

6 Select the paper size and type, and press the OK

button.

7 Extend the paper output tray.

Transporting Your Printer

When relocating the printer, check the following. Refer to the Online Manual for details.

Check that both joint buttons are pressed down

completely to avoid ink leaks.

Check that the position of the ink valve lever is closed.

Pack the printer in a plastic bag in case ink leaks.

• Pack the printer in a sturdy box so that it is placed with its

bottom facing down, using sucient protective material

to ensure safe transport.

• Do not tilt the printer. Ink may leak.

• Please handle with care and ensure the box remains at

and NOT turned upside down or on its side, as the printer

may be damaged and ink in the printer may leak.

• When a shipping agent is handling transport of the

printer, have its box marked "THIS SIDE UP" to keep the

printer with its bottom facing down. Mark also with

"FRAGILE" or "HANDLE WITH CARE".

Loading Paper

ESPAÑOL

Instalación de la impresora

1. Contenido de la caja

•

Cabezales de impresión •

Frascos de tinta

•

Cable de alimentación

•

Información de seguridad e

información importante

•

Guía de inicio (este manual)

2. Retirar los materiales de

protección

1 Retire y tire los materiales de protección y la

cinta naranja.

2 Abra la cubierta/unidad de escaneado, retire y

tire la cinta naranja y el material de protección

que hay dentro.

a b

3. Instalar los cabezales de

impresión

1 Abra la cubierta de bloqueo del cabezal de

impresión.

2 Saque cada cabezal de impresión del paquete y

retire la etiqueta.

3 Retire la cinta protectora.

4 Inserte el cabezal de impresión C (color) a la izquierda

y el cabezal de impresión B (negro) a la derecha.

5 Cierre la cubierta de bloqueo del cabezal de

impresión y presione hacia abajo hasta que haga clic.

6 Presione hacia abajo los dos botones de unión

completamente hasta que hagan clic.

¡Comprobar!

7 Cierre la cubierta/unidad de escaneado.

• Abra la cubierta/unidad de escaneado

completamente y luego ciérrela.

Precaución

Tenga cuidado con

los dedos.

Instalación de la impresora

4. Encender la impresora

1 Conecte el cable de alimentación.

Atrás

2 Pulse el botón ACTIVADO (ON).

3 Si aparece la siguiente pantalla, use los botones

[y ]para seleccionar el idioma y pulse el

botón OK.

Importante

Si aparece un error en la pantalla, consulte "Si se muestra un

mensaje de error (código de asistencia) en la pantalla" en la

página 3 y siga las instrucciones.

5. Verter la tinta

Importante

Este producto requiere un tratamiento cuidadoso de la tinta, ya que

puede salpicar cuando se rellenan de tinta los depósitos de tinta.

Es posible que las manchas de tinta no salgan de la ropa u otras

pertenencias.

1 Abra la cubierta/unidad de escaneado.

2 Abra la tapa del depósito de la izquierda de la

impresora.

3 Sujete el frasco de tinta hacia arriba y gire

suavemente la tapa del frasco para retirarla.

¡Comprobar!

PGBK

4 Alinee la boquilla del frasco de tinta con la entrada.

5 Coloque el frasco de tinta boca abajo despacio y

empuje hacia abajo para verter la tinta.

• Si la tinta no se vierte, retire suavemente el frasco de

tinta e inténtelo de nuevo.

6 Retire suavemente el frasco de tinta de la entrada.

• Tenga cuidado de no derramar la tinta.

Autres manuels pour Pixma G3060 Series

Table des matières

Langues :

Autres manuels Canon Imprimante

Canon

Canon PIXMA MG7500 Series Manuel utilisateur

Canon

Canon MG2100 Series Manuel utilisateur

Canon

Canon PIXMA E560 Manuel utilisateur

Canon

Canon iP100 - PIXMA Color Inkjet Printer Manuel utilisateur

Canon

Canon MG2900 Series Manuel utilisateur

Canon

Canon NP6330 Manuel utilisateur

Canon

Canon BJC-S9000 Manuel utilisateur

Canon

Canon CX-G6400 Manuel utilisateur

Canon

Canon Ivy Manuel utilisateur

Canon

Canon BJC-5100 Series Manuel utilisateur

Canon

Canon PowerShot A550 Manuel utilisateur

Canon

Canon PIXMA MX882 Series Manuel

Canon

Canon imageCLASS MF4890dw Instructions de montage

Canon

Canon iR3570 Series Manuel utilisateur

Canon

Canon BJC-55 Series Manuel utilisateur

Canon

Canon TS3300 Series Manuel utilisateur

Canon

Canon MAXIFY MB5020 Manuel utilisateur

Canon

Canon MP270 series Manuel utilisateur

Canon

Canon MG6110 Manuel utilisateur

Canon

Canon 7611A001 - S 330 Color Inkjet Printer Guide de l'utilisateur

Canon

Canon PIXMA MP970 Manuel utilisateur

Canon

Canon GX7000 Series Guide de configuration

Canon

Canon imageRUNNER ADVANCE DX 6870i Guide d'installation

Canon

Canon iP3300 - PIXMA Color Inkjet Printer Manuel utilisateur

Manuels Imprimante populaires d'autres marques

Lexmark

Lexmark 1400 Series Manuel

Evolis

Evolis Elypso Manuel utilisateur

Kyocera

Kyocera FS-9530DN Manuel utilisateur

Samsung

Samsung BIXOLON SRP-350plusF Manuel utilisateur

Dell

Dell Color Laser Printer 2130cn Manuel utilisateur

Tektronix

Tektronix Phaser 840 Manuel utilisateur

Epson

Epson ET-7750 Mode d'emploi

Eltron

Eltron P210 Guide Manuel utilisateur

Ricoh

Ricoh MD-P1 Manuel utilisateur

Epson

Epson SC-F7100 series Manuel utilisateur

Epson

Epson Stylus C40UX Manuel utilisateur

IRA3D

IRA3D POETRY4 Manuel utilisateur

Ricoh

Ricoh Aficio AP400 Manuel utilisateur

BIXOLON

BIXOLON SRP-352plusV Manuel utilisateur

Epson

Epson Stylus Photo PX700W Instructions de montage

Ricoh

Ricoh SP204SF Manuel utilisateur

Star Micronics

Star Micronics futurePRNT TSP100 Manuel utilisateur

Epson

Epson TM-TM88V-i Manuel d'utilisation et d'entretien
